Driveline System: Overview Ford Explorer III

Differentials & Drive Axles 17 illustrations ~493 words

Scheme 1

Scheme 1: DRIVELINE SYSTEM COMPONENT LOCATION INDEX

Scheme 2

Scheme 2: 4X4 REAR DRIVELINE ANGLES @ CURB SPECIFICATIONS

Scheme 3

Scheme 3

Scheme 4

Scheme 4: AXLE LUBRICANTS AND CAPACITIES

Scheme 5

Scheme 5: GENERAL SPECIFICATIONS

Scheme 6

Scheme 6

Scheme 7

Scheme 7: REAR AXLE BACKLASH SHIM ADJUSTMENT TABLE

Scheme 8

Scheme 8

Scheme 9

Scheme 9: TORQUE SPECIFICATIONS

Scheme 10

Scheme 10

Scheme 11

Scheme 11

The source of the drivetrain's power is generated by the engine and delivered to the transmission. The driveline transfers the engine torque through the driveshaft to the axle.

  1. On 2-wheel drive vehicles, power is transmitted through the transmission to the driveshaft and then to the rear axle.
  2. On 4-wheel drive vehicles, power is transmitted through the transmission and the transfer case. The transfer case directs the power to the rear driveshaft and then to the rear axle. When engaged, it also transmits power through the front driveshaft to the front axle.
  3. On all wheel drive vehicles, power is transmitted through the transmission and continuously proportioned to the front and rear axles through the transfer case.

The rear driveshaft is connected to the output shaft of the transmission and to the rear axle. The front driveshaft is connected to the transfer case and to the front axle. Universal joints and CV joints are used at the ends of the driveshaft to allow for angular motions. Slip-yokes are used to allow for any changes to the length of the driveshaft. The engine torque enters the axle through the drive pinion, which rotates the ring gear. The ring gear is mounted to the differential case, which contains the gears that transmit power to the rear axle shafts or front halfshafts. These shafts rotate the drive wheels.

Vehicles have the following types of driveshafts

  1. One-piece rear driveshaft with two U-joints and a front slip-yoke.
  2. One-piece front driveshaft with one front U-joint, a slip-yoke and a rear CV joint.

The engine angle is built into the engine mounts. If the engine angle is out of specification, the engine mounts must be inspected for damage.

Scheme 12

Scheme 12

The vehicle certification (VC) label is located in the driver door jamb. The first two digits of the axle code indicate the rear axle and the third digit refers to the front axle, if so equipped.

Scheme 13

Scheme 13

A manufacturing date code and a complete part number is stamped on the left carrier arm between the fill plug and axle end. A metal axle identification tag is attached to the differential by a housing cover bolt.

Scheme 14

Scheme 14

Scheme 15

Scheme 15
CAUTIONThe axle identification tag is the official service identifier. Do not damage the tag. Always reinstall the tag after removing it for axle inspection/repair.

The axle identification tag identifies a particular axle design, a specific ratio, and if it is a conventional or limited slip (Traction-Lok(R) type. In addition, the plant code will not change as long as that particular axle assembly never undergoes an external design change. If, however, an internal design change takes place during the production life of the axle and that internal change affects parts interchangeability, a dash and numerical suffix is added to the plant code. This means that as an assembly both axles are interchangeable; however, internally they are different. Therefore, each requires different internal parts at the time of repair.

Scheme 16

Scheme 16: Special Tool(s)

Scheme 17

Scheme 17
