GENERAL SPECIFICATIONS

ItemSpecification
Roof Opening Panel Alignment
Roof opening panel glass clearance: roof to the front of the roof opening panel3 to 1 mm (-0.12 to 0.04 in) flush front to rear
Roof opening panel glass clearance: rear of the roof opening panel to the roof3 to -1 mm (0.12 to -0.04 in) flush front to rear

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

DescriptionNm
Air deflector screws1
Roof opening panel frame bolts6
Roof opening panel glass screws4
Roof opening panel motor mounting screws3

TORQUE SPECIFICATIONS

Roof Opening Panel

The roof opening panel consists of the following

  1. Roof opening panel glass
  2. Roof opening panel glass seal
  3. Roof opening panel shield (sun shade)
  4. Roof opening panel shield guide feet
  5. Overhead console
  6. Roof opening panel switch
  7. Roof opening panel motor and module assembly
  8. Air deflector
  9. Roof opening panel trough
  10. Roof opening panel trough guides
  11. Roof opening panel frame
  12. Roof opening panel drain hose
  13. Skid plates
  14. Trim lace

Note. To protect the roof opening panel motor from overheating, the motor will only run for approximately 2 minutes at a time. After this amount of time, the motor will shut down and then ignore all commands (except close) for 20 seconds. When the 20 seconds have elapsed, the motor will function normally again.

The roof opening panel is an electronically operated panel that can be opened or closed by depressing a switch located inside the vehicle on the overhead console. It also has one-touch open and close features.

When the roof opening panel switch is momentarily rocked rearward, the roof opening panel moves back into the storage space between the headliner and the roof panel.

When the roof opening panel switch is momentarily rocked forward, the roof opening panel will move to the fully CLOSED position.

The roof opening panel can be moved to the fully CLOSED position by rocking the switch forward and holding it until the roof opening panel is fully closed.

When the roof opening panel is in the fully CLOSED position, the rear portion can be raised to the VENT position to provide ventilation by rocking the switch forward. The roof opening panel can be closed by rocking the switch rearward.

Special Tools Illustration Tool Name Tool Number 73III Automotive Meter 105-R0057 or equivalent

Inspection and Verification

  1. Verify the customer concern by operating the system.
  2. Visually inspect for obvious signs of mechanical or electrical damage. VISUAL INSPECTION CHART Mechanical Electrical Roof opening panel Roof opening panel shield Roof panel frame Opening shield guide feet Smart junction box (SJB) fuses: 1 (20A) 5 (5A) Accessory delay relay Roof opening panel control switch Circuitry Roof opening panel motor
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. If the concern is not visually evident, determine the symptom. Go to «Symptom Chart - Roof Opening Panel»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) or Go to «Symptom Chart - Noise, Vibration and Harshness (NVH)»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) .

Symptom Chart - Roof Opening Panel

ConditionPossible SourcesAction
The roof opening panel leaksGlass panel not fully closed Incorrect adjustment Roof opening panel drain hose missing, kinked or obstructed Roof opening panel seals Roof opening panel frameGo to Pinpoint Test B .
The roof opening panel does not open or closeFuse(s) Circuitry Roof opening panel control switch Roof opening panel motor Roof opening panel motor jumper harness Obstruction in roof opening panel frame guide trackFor Explorer, go to Pinpoint Test E . For Sport Trac, go to Pinpoint Test G .
The roof opening panel does not open or close in vent position.Roof opening panel control switch Roof opening panel motorFor Explorer, go to Pinpoint Test F . For Sport Trac, go to Pinpoint Test H .
The roof opening panel does not stop in flush from any positionIncorrect adjustmentREFER to Roof Opening Panel Alignment .
The roof opening panel does not open, close or operate smoothlyRoof opening panel shield guide feet out of track Roof opening panel shield guide feet broken Interference with headliner trimINSPECT the roof opening panel shield guide feet and CHECK for interference with headliner and trim. REPAIR as necessary.
The roof opening panel reverses direction during attempted opening or closing operationRoof opening panel glass screws loose or missing Air deflector fasteners loose or missing Obstruction in roof opening panel frame guide trackINSPECT roof opening panel glass and air deflector fasteners and VERIFY the roof opening panel frame guide track is free of any obstructions. REPAIR as necessary.

Symptom Chart - Roof Opening Panel

Symptom Chart - Noise, Vibration and Harshness (NVH)

Note. Noise, vibration and harshness (NVH) symptoms should be identified using the diagnostic tools that are available. For a list of these tools, an explanation of their uses and a glossary of common terms, refer to NOISE, VIBRATION AND HARSHNESS article. Since it is possible any one of multiple systems may be the cause of a symptom, it may be necessary to use a process of elimination type of diagnostic approach to pinpoint the responsible system. If this is not the causal system for the symptom, refer back to NOISE, VIBRATION AND HARSHNESS article for the next likely system and continue diagnosis.

ConditionPossible SourcesAction
The roof opening panel has excessive wind noiseGlass panel not fully closed Incorrect adjustment Roof opening panel seals damagedGo to Pinpoint Test A .
The roof opening panel rattlesRoof opening panel Roof opening panel rail or guide Roof opening panel lifter assemblies Loose roof opening panel fasteners Roof opening panel shield DVD entertainment systemGo to Pinpoint Test C .
The roof opening panel is noisy during operationRoof opening panel Roof opening panel rail or guide Roof opening panel lifter assemblies Roof opening panel adjustment Roof opening panel motorGo to Pinpoint Test D .

Symptom Chart- Noise, Vibration and Harshness (NVH)

Normal Operation

When the roof opening panel glass is completely closed, it is flush with the roof panel.

This pinpoint test is intended to diagnose the following

  1. Incorrect roof opening panel alignment
  2. Poorly fitting roof opening panel seal/weatherstrip
  3. Incorrect installation of the roof opening panel and motor/module
  4. Incorrect curvature of the air deflector

PINPOINT TEST A: THE ROOF OPENING PANEL HAS EXCESSIVE WIND NOISE

  1. A1 VERIFY THE ROOF OPENING PANEL NOISE Road test the vehicle with the roof opening panel in the CLOSED and OPEN positions. Is the wind noise present only in the OPEN position? YES : Go to A4 . NO : Go to A2 .
  2. A2 CHECK THE ROOF OPENING PANEL WEATHERSTRIP NOTE: Make sure the weatherstrip is secured to the glass, not cut, cracked, pinched, loose or obstructed in CLOSED, VENT and OPEN positions. Check the roof opening panel weatherstrip. Is the roof opening panel weatherstrip OK? YES : Go to A3 . NO : INSTALL a new roof opening panel weatherstrip. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  3. A3 CHECK THE ROOF OPENING PANEL ALIGNMENT Check the roof opening panel alignment. Is the alignment OK? YES : CHECK for correct installation of the roof opening panel and motor/module. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) , «Roof Opening Panel Frame»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Motor»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : ADJUST the roof opening panel. REFER to «Roof Opening Panel Alignment»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-alignment) . TEST the system for normal operation.
  4. A4 CHECK THE AIR DEFLECTOR Make sure the air deflector is securely attached and check for damaged or unsecured springs. Is the air deflector OK? YES : PARTIALLY close the roof opening panel until the noise is eliminated. If the noise is eliminated, INFORM the customer that changing glass location will eliminate the wind noise. If the wind noise is not eliminated, INSTALL a new air deflector. TEST the system for normal operation. NO : INSTALL new air deflector assembly. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Air Deflector»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.

When the roof opening panel glass is completely closed, it is flush with the roof panel.

This pinpoint test is intended to diagnose the following

  1. Incorrect roof opening panel adjustments
  2. Damaged roof opening panel drain hoses
  3. Damaged roof opening panel seal
  4. Incorrect position of the roof opening panel glass

PINPOINT TEST B: THE ROOF OPENING PANEL LEAKS

  1. B1 VERIFY CUSTOMER OPERATION OF ROOF OPENING PANEL WHEN PARKED Make sure customer is parking with the roof opening panel correctly in the CLOSED position. Is the customer parking with the roof opening panel in the CLOSED position? YES : Go to B2 . NO : INSTRUCT the customer to REFER to the Owner's Literature for correct operation of the roof opening panel.
  2. B2 CHECK THE ALIGNMENT OF THE ROOF OPENING PANEL Make sure the roof opening panel glass is centered and flush with roof line. Is the roof opening panel alignment correctly? YES : Go to B3 . NO : ADJUST the roof opening panel. REFER to «Roof Opening Panel Alignment»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-alignment) . TEST the system for normal operation.
  3. B3 CHECK THE WEATHERSTRIP CONDITION NOTE: The seal has a bonded joint located on the passenger side or rear edge. This is not a defect. Make sure the roof opening panel seal is not cracked, torn or loose. Check the roof opening panel seal. Is the roof opening panel seal in good condition and free from damage? YES : Go to B4 . NO : INSTALL a new roof opening panel seal. TEST the system for normal operation.
  4. B4 CHECK THE WATER TROUGH CONDITION Check the water trough and guides for damage and/or correct attachment and function. Is the water trough OK? YES : Go to B5 . NO : REPAIR the water trough or replace as necessary. TEST the system for normal operation.
  5. B5 CHECK THE DRAIN HOSES NOTE: Drain hoses can be viewed with a flashlight by removing the headliner lace around the inside opening and gently pulling down on the headliner. (On some vehicles, the trim lace has been replaced by Velcro style attachments.) Make sure the drain hoses are all connected and not cracked, slit, pinched or obstructed. Are all the drain hoses present and attached correctly? YES : Go to B6 . NO : REPAIR or INSTALL a new drain hose(s). TEST the system for normal operation.
  6. B6 CHECK THE DRAIN HOSES FOR CORRECT FLOW NOTE: Drain hoses must flow downhill and can not be pinched or restricted by headliner or any other trim components. With the panel open, slowly pour water into the water trough area and make sure that the same amount of water exits the vehicle at the bottom of the A- and C-pillars. Check the drain hoses for obstructions by blowing compressed air through the drain spouts in the water trough area, then retest with water. Are the drain hoses operating correctly? YES : INSPECT other areas of the vehicle that may cause water to enter the roof area such as the windshield or luggage rack, if equipped. If no problem is found, go to B7 . NO : LOWER the headliner and INSPECT drain hoses for correct routing. REPAIR or INSTALL a new drain hose(s). TEST the system for normal operation.
  7. B7 CHECK THE CONDITION OF THE ROOF OPENING PANEL FRAME Check the roof opening panel frame for damage that may cause the roof opening panel seal to seat incorrectly. Is the roof opening panel frame OK? YES : INSTALL a new roof opening panel. REFER to «Roof Opening Panel»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : REPAIR roof opening panel frame as necessary. TEST the system for normal operation.

When the roof opening panel glass is completely closed, it is flush with the roof panel. All components should be secured correctly.

This pinpoint test is intended to diagnose the following

  1. Roof opening panel
  2. Roof opening panel air deflector assembly
  3. Roof opening panel water trough
  4. Roof opening panel lifter assemblies
  5. Headliner
  6. Roof opening panel motor/module pad
  7. Roof opening panel frame
  8. Loose fasteners
  9. DVD entertainment system

PINPOINT TEST C: THE ROOF OPENING PANEL RATTLES

  1. C1 CHECK THE ROOF OPENING PANEL WEATHERSTRIP NOTE: Make sure the weatherstrip is secured to the glass, not cut, cracked, pinched, loose or obstructed in CLOSED, VENT and OPEN positions. Check the roof opening panel weatherstrip. Is the roof opening panel weatherstrip OK? YES : Go to C2 . NO : INSTALL a new roof opening panel weatherstrip. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  2. C2 CHECK THE ROOF OPENING PANEL TIGHTNESS Manually push up and fore/aft. Is the roof opening panel loose? YES : ADJUST the roof opening panel. REFER to «Roof Opening Panel Alignment»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-alignment) . TEST the system for normal operation. NO : Go to C3 .
  3. C3 CHECK THE ROOF OPENING PANEL TRACKS Open the roof opening panel. Check the roof opening panel tracks for obstructions and damage. Are the roof opening panel tracks OK? YES : Go to C4 . NO : REMOVE all the roof opening panel track obstructions and REPAIR the roof opening panel tracks. If the roof opening panel tracks cannot be repaired, INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Frame»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  4. C4 CHECK THE ROOF OPENING PANEL WATER TROUGH AND TROUGH GUIDES Check the water roof opening panel water trough and trough guides for any loose obstructions. Are the roof opening panel water trough and trough guides installed securely and free from obstructions? YES : Go to C5 . NO : REMOVE all obstructions from the roof opening panel water trough guides and install securely. INSTALL a new roof opening panel frame if the water trough guides are damaged. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Frame»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  5. C5 CHECK THE ROOF OPENING PANEL SHIELD (SUNSHADE) Check the roof opening panel shield for correct installation. Is the roof opening panel shield installed correctly? YES : Go to C6 . NO : INSTALL the roof opening panel shield correctly. REFER to «Roof Opening Panel Shield»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  6. C6 CHECK THE ROOF OPENING PANEL AIR DEFLECTOR ASSEMBLY Check the roof opening panel air deflector assembly for obstructions and damage. Is the roof opening panel air deflector assembly OK? YES : Go to C7 . NO : REMOVE all obstructions and REPAIR or INSTALL a new roof opening panel air deflector assembly. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Frame»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  7. C7 CHECK THE ROOF OPENING PANEL GLASS Verify the roof opening panel glass is free from obstructions and damage, and is securely fastened. Is the roof opening panel glass OK? YES : Go to C8 . NO : REPAIR or INSTALL a new roof opening panel glass. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Glass»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  8. C8 CHECK THE ROOF OPENING PANEL LIFTER ASSEMBLIES Verify the roof opening panel lifter assemblies are free from obstructions and damage. Are the roof opening panel lifter assemblies OK? YES : Go to C9 . NO : REMOVE all obstructions from the roof opening panel lifter assemblies and REPAIR any damage. If the roof opening panel lifter assemblies cannot be repaired, INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Frame»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  9. C9 CHECK ROOF OPENING PANEL FRAME INSTALLATION Check all roof opening fasteners for correct torque and verify correct installation of the roof opening panel frame. Refer to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Frame»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . Is the roof opening panel correctly installed and tightened to specification? YES : Go to C10 . NO : TIGHTEN the loose fasteners or REINSTALL the roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Frame»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  10. C10 CHECK THE ROOF OPENING PANEL FRAME FOR RATTLES Check the roof opening panel frame assembly for any loose parts or for any condition that will cause rattles. Is there a condition that will cause rattles? YES : INSTALL a suitable sound damper material to correct the condition. If the rattle still persists, INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Frame»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : If equipped with DVD entertainment system, go to C11 . INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Frame»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  11. C11 CHECK THE DVD ENTERTAINMENT SYSTEM FOR RATTLES Check all DVD entertainment system fasteners for correct torque and verify correct installation. Refer to «INFORMATION AND ENTERTAINMENT SYSTEMS»(/ford/explorer-sport-trac/ii-2006-2010/remont/entertainment-systems/#information-system-and-entertainment-systems) article. Is the DVD entertainment system correctly installed and tightened to specification? YES : INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Frame»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : TIGHTEN the loose fasteners or REINSTALL the DVD entertainment system. REFER to «INFORMATION AND ENTERTAINMENT SYSTEMS»(/ford/explorer-sport-trac/ii-2006-2010/remont/entertainment-systems/#information-system-and-entertainment-systems) article. TEST the system for normal operation.

The roof opening panel operates smoothly while opening and closing.

This pinpoint test is intended to diagnose the following

  1. Obstructed or damaged roof opening panel
  2. Obstructed or damaged roof opening panel lifter assemblies
  3. Incorrect roof opening panel adjustment
  4. Noisy roof opening panel motor/module assembly

PINPOINT TEST D: THE ROOF OPENING PANEL IS NOISY DURING OPERATION

  1. D1 CHECK THE ROOF OPENING PANEL FOR OBSTRUCTIONS OR DAMAGE Check the roof opening panel for any obstructions and damage. Are there any obstructions and/or damage? YES : REMOVE all obstructions. REPAIR any damage. If the damage cannot be repaired, INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Frame»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : Go to D2 .
  2. D2 CHECK THE ROOF OPENING PANEL OPERATION Check the roof opening panel during operation. Is the roof opening panel loose or incorrectly adjusted? YES : ADJUST the roof opening panel. REFER to «Roof Opening Panel Alignment»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-alignment) . TEST the system for normal operation. NO : Go to D3 .
  3. D3 CHECK THE ROOF OPENING PANEL TRACKS Open the roof. Check the roof opening panel tracks for obstructions and damage. Are the roof opening panel tracks OK? YES : Go to D4 . NO : REMOVE all obstructions and REPAIR any damage. If the roof opening panel tracks cannot be repaired, INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Frame»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  4. D4 CHECK THE ROOF OPENING PANEL SHIELD Check the roof opening panel shield for correct movement. Is the roof opening panel shield moving correctly? YES : Go to D5 . NO : REMOVE and REINSTALL the roof opening panel shield. REFER to «Roof Opening Panel Shield»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  5. D5 CHECK THE ROOF OPENING PANEL LIFTER ASSEMBLIES Check the roof opening panel lifter assemblies for obstructions and damage. Are the roof opening panel lifter assemblies OK? YES : Go to D6 . NO : REMOVE all obstructions and REPAIR any damage. If the roof opening panel lifter assemblies cannot be repaired, INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Frame»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation.
  6. D6 CHECK THE ROOF OPENING PANEL MOTOR/MODULE Remove the roof opening panel motor/module and leave the electrical connector connected. Operate the roof opening panel to the full OPEN and CLOSED positions. Does the motor/module make excessive noise? YES : INSTALL a new roof opening panel motor/module. REFER to «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Motor»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : REINSTALL the roof opening panel motor/module. TEST the system for normal operation. If the roof opening panel is still noisy, INSTALL a new roof opening panel frame. «Roof Opening Panel - Exploded View»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) and «Roof Opening Panel Frame»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . If the roof opening panel is no longer noisy, the system is operating correctly. The concern may have been caused by an incorrectly installed roof opening panel motor.

Pinpoint Test E: The Roof Opening Panel Does Not Open or Close - Explorer

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Roof Opening Panel for schematic and connector information.

The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to Roof Opening Panel Motor Initialization .

The roof opening panel uses an integrated motor and module to operate the roof opening panel. A new roof opening panel motor/module is installed as an assembly.

Note. To protect the roof opening panel motor from overheating, the motor will only run for approximately 2 minutes at a time. After this amount of time, the motor will shut down and then ignore all commands (except close) for 20 seconds. When the 20 seconds have elapsed, the motor will function normally again.

The roof opening panel motor/module receives voltage from the accessory delay relay through circuit CBP05 (YE) when the key is in the ACC or RUN position and voltage at all times through circuit SBP01 (RD). Ground is provided to the roof opening panel motor/module through circuit GD133 (BK). For vehicles equipped with a mini overhead console, the roof opening panel motor/module provides ground to the roof opening panel switch through circuit CPR39 (VT/WH). For vehicles equipped with a medium overhead console, the roof opening panel switch is grounded through circuit GD133 (BK). When the roof opening panel switch is pressed to the CLOSE position, a ground signal is sent to the roof opening panel motor/module through circuit CPR40 (YE/OG), which causes the roof opening panel to close. When the roof opening panel switch is pressed to the OPEN position, a ground signal is sent to the roof opening panel motor/module through circuit CPR31 (VT/BN), which causes the roof opening panel to open.

This pinpoint test is intended to diagnose the following

  1. Fuse(s)
  2. Wiring, terminals or connectors
  3. Inoperative roof opening panel switch
  4. Inoperative roof opening panel motor/module assembly
  5. Inoperative accessory delay relay
  6. Roof opening panel motor not initialized
  7. Foreign material in tracks

Note. Before carrying out this pinpoint test, make sure that the tracks are free from foreign material.

Scheme 1

Scheme 1: PINPOINT TEST E: THE ROOF OPENING PANEL DOES NOT OPEN OR CLOSE - EXPLORER
Scheme 1: PINPOINT TEST E: THE ROOF OPENING PANEL DOES NOT OPEN OR CLOSE - EXPLORER

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5
  1. E1 CHECK THE MOTOR/MODULE FOR INITIALIZATION Carry out the roof opening panel motor initialization procedure. Refer to «Roof Opening Panel Motor Initialization»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) . Is the concern still present? YES : Go to E2 . NO : The system is operating normally at this time. The roof opening panel motor was not initialized.
  2. E2 CHECK THE POWER WINDOWS Key in ON position. Verify the power windows operate. Do the power windows operate? YES : Go to E3 . NO : REFER to «GLASS, FRAMES AND MECHANISMS»(/ford/explorer-sport-trac/ii-2006-2010/remont/heated-glassdefoggers/#windows-and-glass) article to diagnose the accessory delay relay circuit.
  3. E3 CHECK THE ROOF OPENING PANEL SWITCH Key in OFF position. Disconnect: Roof Opening Panel Switch C912 (Mini Console) or C9001 (Medium Console) Carry out the Roof Opening Panel Switch Component Test. Refer to appropriate COMPONENT TESTING article. Is the roof opening panel switch OK? YES : Go to E4 . NO : INSTALL a new roof opening panel switch. TEST the system for normal operation.
  4. E4 CHECK THE VOLTAGE TO THE ROOF OPENING PANEL MOTOR/MODULE - CIRCUITS CBP05 (YE) AND SBP01 (RD) Key in OFF position. Disconnect: Roof Opening Panel Motor/Module C921 Key in ON position. Measure the voltage between roof opening panel motor/module C921-3, circuit CBP05 (YE) and C921-6, circuit SBP01 (RD), harness side and ground. Are the voltages greater than 9 volts? YES : Go to E5 . NO : VERIFY SJB fuse 1 (20A) and fuse 5 (5A) are OK. If OK, REPAIR the circuit. TEST the system for normal operation.
  5. E5 CHECK THE ROOF OPENING PANEL GROUND - CIRCUIT GD133 (BK) Key in OFF position. Measure the resistance between roof opening panel motor/module C921-1, circuit GD133 (BK), harness side and ground. Is the resistance less than 5 ohms? YES : Go to E6 . NO : REPAIR the circuit. TEST the system for normal operation.
  6. E6 CHECK CIRCUIT CPR39 (VT/WH) OR GD133 (BK) FOR AN OPEN For vehicles equipped with mini overhead console, measure the resistance between overhead console C912-3, circuit CPR39 (VT/WH), and roof opening panel motor/module C921-2, circuit CPR39 (VT/WH) harness side. For vehicles equipped with medium overhead console, measure the resistance between overhead console C9001-2, circuit GD133 (BK) harness side and ground. Is the resistance less than 5 ohms? YES : Go to E7 . NO : REPAIR the circuit. TEST the system for normal operation.
  7. E7 CHECK CIRCUIT CPR40 (YE/OG) FOR AN OPEN Measure the resistance between overhead console C912-5 (mini console) or C9001-1 (medium console), circuit CPR40 (YE/OG), and roof opening panel motor/module C921-10, circuit CPR40 (YE/OG) harness side. Is the resistance less than 5 ohms? YES : Go to E8 . NO : REPAIR the circuit. TEST the system for normal operation.
  8. E8 CHECK CIRCUIT CPR31 (VT/BN) FOR AN OPEN Measure the resistance between overhead console C912-2 (mini console) or C9001-7 (medium console), circuit CPR31 (VT/BN), and roof opening panel motor/module C921-5, circuit CPR31 (VT/BN) harness side. Is the resistance less than 5 ohms? YES : Go to E9 . NO : REPAIR the circuit. TEST the system for normal operation.
  9. E9 CHECK THE ROOF OPENING PANEL MOTOR/MODULE FOR CORRECT OPERATION Disconnect all roof opening panel motor/module connectors. Check for: corrosion. bent or pushed-out pins. Connect all roof opening panel motor/module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new roof opening panel motor/module. REFER to «Roof Opening Panel Motor»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. TEST the system for normal operation.

Pinpoint Test F: The Roof Opening Panel Does Not Open or Close in VENT Position - Explorer

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Roof Opening Panel for schematic and connector information.

The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to Roof Opening Panel Motor Initialization .

The roof opening panel uses a integrated motor and module to operate the roof opening panel. A new roof opening panel motor/module is installed as an assembly.

The roof opening panel motor/module receives voltage from the accessory delay relay through circuit CBP05 (YE) when the key is in the ACC or RUN position and voltage at all times through circuit SBP01 (RD). Ground is provided to the roof opening panel motor/module through circuit GD133 (BK). For vehicles equipped with a mini overhead console, the roof opening panel motor/module provides ground to the roof opening panel switch through circuit CPR39 (VT/WH). For vehicles equipped with a medium overhead console, the roof opening panel switch is grounded through circuit GD133 (BK). When the roof opening panel is in the fully closed position and the roof opening panel switch is pressed to the CLOSE position, a ground signal is sent to the roof opening panel motor/module through circuit CPR40 (YE/OG), which causes the roof opening panel to open to the TILT position. When the roof opening panel switch is pressed to the OPEN position, a ground signal is sent to the roof opening panel motor/module through circuit CPR31 (VT/BN), which causes the roof opening panel to close.

This pinpoint test is intended to diagnose the following

  1. Wiring, terminals or connectors
  2. Inoperative roof opening panel switch
  3. Inoperative roof opening panel motor/module assembly
  1. F1 CHECK THE MOTOR/MODULE FOR INITIALIZATION Attempt to carry out the roof opening panel motor initialization procedure. Refer to «Roof Opening Panel Motor Initialization»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) . Is the concern still present, or does the roof opening panel motor fail to initialize? YES : Go to F2 . NO : The system is operating normally at this time. The roof opening panel motor was not initialized.
  2. F2 CHECK THE ROOF OPENING PANEL SWITCH Key in OFF position. Disconnect: Roof Opening Panel Switch C912 (mini console) or C9001 (medium console) Carry out the Roof Opening Panel Switch Component Test. Refer to appropriate COMPONENT TESTING article. Is the roof opening panel switch OK? YES : Go to F3 . NO : INSTALL a new roof opening panel switch. TEST the system for normal operation.
  3. F3 CHECK CIRCUIT CPR40 (YE/OG) FOR AN OPEN Measure the resistance between overhead console C912-5 (mini console) or C9001-1 (medium console), circuit CPR40 (YE/OG), and roof opening panel motor/module C921-10, circuit CPR40 (YE/OG) harness side. Is the resistance less than 5 ohms? YES : Go to F4 . NO : REPAIR the circuit. TEST the system for normal operation.
  4. F4 CHECK CIRCUIT CPR31 (VT/BN) FOR AN OPEN Measure the resistance between overhead console C912-2 (mini console) or C9001-7 (medium console), circuit CPR31 (VT/BN), and roof opening panel motor/module C921-5, circuit CPR31 (VT/BN) harness side. Is the resistance less than 5 ohms? YES : Go to F5 . NO : REPAIR the circuit. TEST the system for normal operation.
  5. F5 CHECK THE ROOF OPENING PANEL MOTOR/MODULE FOR CORRECT OPERATION Disconnect all roof opening panel motor/module connectors. Check for: corrosion. bent or pushed-out pins. Connect all roof opening panel motor/module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new roof opening panel motor/module. REFER to «Roof Opening Panel Motor»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. TEST the system for normal operation.

Pinpoint Test G: The Roof Opening Panel Does Not Open or Close - Sport Trac

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Roof Opening Panel for schematic and connector information.

The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to Roof Opening Panel Motor Initialization .

The roof opening panel uses an integrated motor and module to operate the roof opening panel. A new roof opening panel motor/module is installed as an assembly.

Note. To protect the roof opening panel motor from overheating, the motor will only run for approximately 2 minutes at a time. After this amount of time, the motor will shut down and then ignore all commands (except close) for 20 seconds. When the 20 seconds have elapsed, the motor will function normally again.

The roof opening panel motor/module receives voltage from the accessory delay relay through circuit CBP05 (YE) when the key is in the ACC or RUN position and voltage at all times through circuit SBP01 (RD). Ground is provided to the roof opening panel motor/module through circuit GD133 (BK). The roof opening panel motor/module provides ground to the roof opening panel switch through circuit CPR39 (VT/WH). When the roof opening panel is in the fully OPEN or TILT position and the roof opening panel switch is pressed to the CLOSE position, a ground signal is sent to the roof opening panel motor/module through circuit CPR40 (YE/OG), which causes the roof opening panel to close. When the roof opening panel switch is pressed to the OPEN position, a ground signal is sent to the roof opening panel motor/module through circuit CPR31 (VT/BN), which causes the roof opening panel to open.

This pinpoint test is intended to diagnose the following

  1. Fuse(s)
  2. Wiring, terminals or connectors
  3. Inoperative roof opening panel switch
  4. Inoperative roof opening panel motor/module assembly
  5. Inoperative accessory delay relay
  6. Roof opening panel motor not initialized
  7. Foreign material in tracks

Note. Before carrying out this pinpoint test, make sure that the tracks are free from foreign material.

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. G1 CHECK THE MOTOR/MODULE FOR INITIALIZATION Carry out the roof opening panel motor initialization procedure. Refer to «Roof Opening Panel Motor Initialization»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) . Is the concern still present? YES : Go to G2 . NO : The system is operating normally at this time. The roof opening panel motor was not initialized.
  2. G2 CHECK THE POWER WINDOWS Key in ON position. Verify the power windows operate. Do the power windows operate? YES : Go to G3 . NO : REFER to «GLASS, FRAMES AND MECHANISMS»(/ford/explorer-sport-trac/ii-2006-2010/remont/heated-glassdefoggers/#windows-and-glass) article to diagnose the accessory delay relay circuit.
  3. G3 CHECK THE ROOF OPENING PANEL SWITCH Key in OFF position. Disconnect: Roof Opening Panel Switch C912 (Without Power Rear Window) Disconnect: Roof Opening Panel Switch C9038 (With Power Rear Window) Carry out the Roof Opening Panel Switch Component Test. Refer to appropriate COMPONENT TESTING article. Is the roof opening panel switch OK? YES : Go to G4 . NO : INSTALL a new roof opening panel switch. TEST the system for normal operation.
  4. G4 CHECK THE VOLTAGE TO THE ROOF OPENING PANEL MOTOR/MODULE - CIRCUITS CBP05 (YE) AND SBP01 (RD) Key in OFF position. Disconnect: Roof Opening Panel Motor/Module C921 Key in ON position. Measure the voltage between roof opening panel motor/module C921-3, circuit CBP05 (YE) and C921-6, circuit SBP01 (RD), harness side and ground. Are the voltages greater than 9 volts? YES : Go to G5 . NO : VERIFY SJB fuses 1 (20A) and 5 (5A) are OK. If OK, REPAIR the circuit. TEST the system for normal operation.
  5. G5 CHECK THE ROOF OPENING PANEL GROUND - CIRCUIT GD133 (BK) Key in OFF position. Measure the resistance between roof opening panel motor/module C921-1, circuit GD133 (BK), harness side and ground. Is the resistance less than 5 ohms? YES : Go to G6 . NO : REPAIR the circuit. TEST the system for normal operation.
  6. G6 CHECK CIRCUITS CPR39 (VT/WH) OR GD133 (BK) FOR AN OPEN For vehicles without power rear window, measure the resistance between overhead console C912-3, circuit CPR39 (VT/WH), and roof opening panel motor/module C921-2, circuit CPR39 (VT/WH) harness side. For vehicles equipped with power rear window, measure the resistance between overhead console C9038-2, circuit CPR39 (VT/WH) harness side and roof opening panel motor/module C921-2, circuit CPR39 (VT/WH) harness side. Is the resistance less than 5 ohms? YES : Go to G7 . NO : REPAIR the circuit. TEST the system for normal operation.
  7. G7 CHECK CIRCUIT CPR40 (YE/OG) FOR AN OPEN Measure the resistance between overhead console C912-5 (without power rear window) or C9038-1 (with power rear window), circuit CPR40 (YE/OG), and roof opening panel motor/module C921-10, circuit CPR40 (YE/OG) harness side. Is the resistance less than 5 ohms? YES : Go to G8 . NO : REPAIR the circuit. TEST the system for normal operation.
  8. G8 CHECK CIRCUIT CPR31 (VT/BN) FOR AN OPEN Measure the resistance between overhead console C912-2 (without power rear window) or C9038-5 (with power rear window), circuit CPR31 (VT/BN), and roof opening panel motor/module C921-5, circuit CPR31 (VT/BN) harness side. Is the resistance less than 5 ohms? YES : Go to G9 . NO : REPAIR the circuit. TEST the system for normal operation.
  9. G9 CHECK THE ROOF OPENING PANEL MOTOR/MODULE FOR CORRECT OPERATION Disconnect all roof opening panel motor/module connectors. Check for: corrosion. bent or pushed-out pins. Connect all roof opening panel motor/module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new roof opening panel motor/module. REFER to «Roof Opening Panel Motor»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. TEST the system for normal operation.

Pinpoint Test H: The Roof Opening Panel Does Not Open or Close in VENT Position - Sport Trac

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Roof Opening Panel for schematic and connector information.

The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to Roof Opening Panel Motor Initialization .

The roof opening panel uses a integrated motor and module to operate the roof opening panel. A new roof opening panel motor/module is installed as an assembly.

The roof opening panel motor/module receives voltage from the accessory delay relay through circuit CBP05 (YE) when the key is in the ACC or RUN position and voltage at all times through circuit SBP01 (RD). Ground is provided to the roof opening panel motor/module through circuit GD133 (BK). The roof opening panel motor/module provides ground to the roof opening panel switch through circuit CPR39 (VT/WH). When the roof opening panel is in the fully CLOSED position and the roof opening panel switch is pressed to the CLOSE position, a ground signal is sent to the roof opening panel motor/module through circuit CPR40 (YE/OG), which causes the roof opening panel to open to the TILT position. When the roof opening panel switch is pressed to the OPEN position, a ground signal is sent to the roof opening panel motor/module through circuit CPR31 (VT/BN), which causes the roof opening panel to close.

This pinpoint test is intended to diagnose the following

  1. Wiring, terminals or connectors
  2. Inoperative roof opening panel switch
  3. Inoperative roof opening panel motor/module assembly
  1. H1 CHECK THE MOTOR/MODULE FOR INITIALIZATION Attempt to carry out the roof opening panel motor initialization procedure. Refer to «Roof Opening Panel Motor Initialization»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) . Is the concern still present or does the roof opening panel motor fail to initialize? YES : Go to H2 . NO : The system is operating normally at this time. The roof opening panel motor was not initialized.
  2. H2 CHECK THE ROOF OPENING PANEL SWITCH Key in OFF position. Disconnect: Roof Opening Panel Switch C912 (Without Power Rear Window) Disconnect: Roof Opening Panel Switch C9038 (With Power Rear Window) Carry out the Roof Opening Panel Switch Component Test. Refer to appropriate COMPONENT TESTING article. Is the roof opening panel switch OK? YES : Go to H3 . NO : INSTALL a new roof opening panel switch. TEST the system for normal operation.
  3. H3 CHECK CIRCUIT CPR40 (YE/OG) FOR AN OPEN Measure the resistance between overhead console C912-5 (without power rear window) or C9038-1 (with power rear window), circuit CPR40 (YE/OG), and roof opening panel motor/module C921-10, circuit CPR40 (YE/OG) harness side. Is the resistance less than 5 ohms? YES : Go to H4 . NO : REPAIR the circuit. TEST the system for normal operation.
  4. H4 CHECK CIRCUIT CPR31 (VT/BN) FOR AN OPEN Measure the resistance between overhead console C912-2 (without power rear window) or C9038-5 (with power rear window), circuit CPR31 (VT/BN), and roof opening panel motor/module C921-5, circuit CPR31 (VT/BN) harness side. Is the resistance less than 5 ohms? YES : Go to H5 . NO : REPAIR the circuit. TEST the system for normal operation.
  5. H5 CHECK THE ROOF OPENING PANEL MOTOR/MODULE FOR CORRECT OPERATION Disconnect all roof opening panel motor/module connectors. Check for: corrosion. bent or pushed-out pins. Connect all roof opening panel motor/module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new roof opening panel motor/module. REFER to «Roof Opening Panel Motor»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) . TEST the system for normal operation. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. TEST the system for normal operation.

Roof Opening Panel Manual Operation

  1. Remove the overhead console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(/ford/explorer-sport-trac/ii-2006-2010/remont/gauges-instrument-panels/#instrument-panel-and-console) article.
  2. Insert an Allen wrench into the center of the manual drive hole of the roof opening panel motor. Rotate the Allen wrench counterclockwise until the roof opening panel is closed.

Roof Opening Panel Motor Initialization

WARNINGKeep objects and body parts clear of the glass panel when carrying out the initialization procedure. During the initialization procedure, the glass panel closes with high force and cannot detect objects in its path. Failure to follow this instruction may result in serious personal injury.

Note. A new roof opening panel motor will only move to the vent position and must be initialized.

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed.

Pinpoint Test H

H2 For an existing roof opening panel motor,
H3 For a new roof opening panel motor,
  1. For an existing motor, press and hold the close switch (for approximately 10 seconds) until the roof opening panel glass moves past full VENT and suddenly back to full VENT.

Roof Opening Panel Alignment

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to Roof Opening Panel Motor Initialization .

  1. Cycle the roof opening panel to the VENT position.
  2. Loosen the roof opening panel glass screws. Loosen only the front screws to adjust the front. Loosen only the rear screws to adjust the rear.
  3. Cycle the roof opening panel in the following sequence: OPEN, CLOSED, VENT, CLOSED.
  4. Adjust the roof opening panel glass to specification.
  5. Cycle the roof opening panel to the VENT position.
  6. Tighten the roof opening panel glass screws. Tighten to 4 Nm (35 lb-in).

Scheme 9

Scheme 9: Roof Opening Panel - Exploded View
Scheme 9: Roof Opening Panel - Exploded View
ItemPart NumberDescription
178502F90Roof opening panel glass screw (4 required)
278500A18Roof opening panel glass
378502C46Skid plate (2 required)
415C682Roof opening panel motor screw (3 required)
578515B689Roof opening panel motor
67851884Glass seal
77854022Trough assembly
878500A64Trough guide shoe assembly (2 required)
978502F92Air deflector screw (4 required)
1078500A26Air deflector assembly
1178519A02Roof opening panel shield
127850152Roof opening panel shield spring-loaded guide feet (4 required)
137852124Headliner trim piece
14W505179-S424Roof opening panel frame bolt (10 required)
1578502C52Roof opening panel front drain hose (2 required)
1678502C53Roof opening panel rear drain hose (2 required)
177851070Roof opening panel frame
  1. For additional information, refer to the procedures in this article.

REMOVAL AND INSTALLATION

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to Roof Opening Panel Motor Initialization .

  1. Open the roof opening panel to the VENT position.
  2. Remove the 4 roof opening panel glass screws. To install, tighten to 4 Nm (35 lb-in).
  3. From the outside of the vehicle, remove the roof opening panel glass assembly.
  4. To install, reverse the removal procedure. If installing a new roof opening panel glass seal, use care around the corners to make sure of a correct seal to the roof opening panel glass. Check for correct alignment of the roof opening panel. For additional information, refer to «Roof Opening Panel Alignment»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-alignment) . Initialize the roof opening panel motor. For additional information, refer to «Roof Opening Panel Motor Initialization»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to Roof Opening Panel Motor Initialization .

  1. Remove the headliner. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/explorer-sport-trac/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) article.
  2. Remove the 2 retaining screws and the upper console bracket.
  3. Disconnect the roof opening panel motor electrical connector.
  4. Disconnect the 4 roof opening panel drain hoses from the corners of the roof opening panel frame.
  5. Remove the entertainment center support bracket (if equipped). Remove the 7 bolts. Remove the support bracket.
  6. Remove the 10 roof opening panel frame bolts. To install, tighten to 6 Nm (53 lb-in).
  7. Remove the roof opening panel frame.
  8. To install, reverse the removal procedure. Initialize the roof opening panel motor. For additional information, refer to «Roof Opening Panel Motor Initialization»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .
CAUTIONThe roof opening panel motor contains ceramic magnets that may fail at any time if cracked. Any roof opening panel motor that has been dropped onto a hard surface during removal or installation should be replaced with a new motor.

Note. The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to Roof Opening Panel Motor Initialization .

  1. Remove the overhead console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(/ford/explorer-sport-trac/ii-2006-2010/remont/gauges-instrument-panels/#instrument-panel-and-console) article.
  2. Disconnect the roof opening panel electrical connectors.
  3. Remove the 3 roof opening panel motor screws. To install, tighten to 3 Nm (27 lb-in).
  4. Remove the roof opening panel motor.
  5. To install, reverse the removal procedure. Initialize the roof opening panel motor. For additional information, refer to «Roof Opening Panel Motor Initialization»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .
  1. Remove the roof opening panel glass. For additional information, refer to «Roof Opening Panel Glass»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) .
  2. Remove the trough. Pull the trough assembly arms outward to release the trough assembly guide arm pins from the roof opening panel frame to remove.
  3. Remove the air deflector. Remove the 4 screws. To install, tighten to 1 N.m (9 lb-in). Remove the air deflector.
  4. Slide the roof opening panel shield forward halfway.
  5. Disengage the roof opening panel shield guide feet. Push the roof opening panel shield toward one side of the vehicle. Lift the front portion of the roof opening panel shield upward to disengage the guide feet.
  6. Slide the roof opening panel shield forward and release the rear guide feet.
  7. If necessary, new roof opening panel shield guide feet may be installed at this time.
  8. To install, reverse the removal procedure.

Scheme 10

Scheme 10: Roof Opening Panel Control Switch
Scheme 10: Roof Opening Panel Control Switch
ItemPart NumberDescription
1519A58Overhead console
214334Overhead console electrical connectors
3519A58Roof opening panel control switch
  1. Remove the overhead console.
  2. Disconnect the overhead console electrical connectors.
  3. Disengage the clips and remove the switch from the overhead console.
  4. To install, reverse the removal procedure.
  1. Remove the roof opening panel glass. For additional information, refer to «Roof Opening Panel Glass»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof) .
  2. Remove the trough assembly. Pull the trough assembly arms outward to release the trough assembly guide arm pins from the roof opening panel frame to remove.
  3. To install, reverse the removal procedure.
  1. Move roof opening panel to full OPEN position.
  2. Remove the air deflector. Remove the 4 screws. To install, tighten to 1 N.m (9 lb-in). Remove the air deflector from the roof opening panel frame.
  3. To install, reverse the removal procedure. Initialize the roof opening panel motor. For additional information, refer to «Roof Opening Panel Motor Initialization»(/ford/explorer-sport-trac/ii-2006-2010/remont/sun-rooft-topconvertible-top/#sunroof__roof-opening-panel-motor-initialization) .
