GENERAL SPECIFICATIONS
| Item | Specification |
| Measurements For the Box to Cab |
| Pickup box leading edge to cab distance | 29 mm (1.14 in) |
TORQUE SPECIFICATIONS
| Description | Nm |
| Body side outer front bolts | 12 |
| Body side outer mounting bolts | 12 |
| Body side outer panel bolts | 12 |
| Body side outer rear bolts | 12 |
| Fuel filler pipe screws | 3 |
| Lower rear body side outer bolt | 12 |
| Pickup bed exterior tie-down bolt | 5 |
| Pickup bed front nuts and rear bolts | 62 |
| Pickup bed reinforcement mounting bolts | 25 |
| Pickup bed reinforcement outer bolts | 25 |
| Pickup bed storage compartment front hinge nuts | 12 |
| Pickup bed storage compartment lid nuts | 12 |
| Pickup bed tailgate hinge bolts | 47 |
| Tailgate striker | 40 |
Pickup Bed
The pickup bed consists of the following components
- Bed extender (optional)
- Box inner panel
- Body side outer molding
- Body side outer panels
- Cargo divider (optional)
- Front/side storage compartments
- Fuel filler door
- Fuel filler housing
- Pickup bed inner tie-downs
- Pickup bed exterior tie-downs
- Pickup bed reinforcement assembly
- Power point receptacle
- Rear wheel house panels
- Tonneau cover (optional)
- Tailgate assembly
- Wiring harnesses
Pickup Bed Alignment
- Remove the 6 bumper cover screws (3 each side).
- Loosen the pickup bed rear bolts.
- Loosen the front pickup bed bolts.
- Center the pickup bed to the rear of the cab.
- Align the leading edge of the pickup bed and the rear of the cab to specifications.
- Tighten the pickup bed bolts and nuts. To install, tighten to 62 N.m (46 lb-ft).
- Install the 6 bumper cover screws (3 each side).
Pickup Bed Body Side
Note. RH shown, LH similar.
Scheme 1
Scheme 1: Pickup Bed Body Side
| Item | Part Number | Description |
| 1 | 7829141 LH/ 7829140 RH | Body side outer moulding |
| 2 | W710478-S | Rear body side outer bolt (2 required) |
| 3 | | Pickup bed wheel house opening screw (4 required) |
| 4 | W710478-S | Front body side outer bolt (4 required) |
| 5 | W710478-S | Lower rear body side outer bolt |
| 6 | W711589-S | Fuel filler neck pipe screw (3 required) |
| 7 | W710478-S | Upper body side outer bolt (3 required) |
| 8 | 9927841 LH/ 9927840 RH | Pickup bed body side outer panel |
- Remove the 3 exterior pickup bed tie-downs. Remove the 6 bolts. To install, tighten to 5 N.m (44 lb-in). Remove the 3 tie-downs.
- Remove the body side outer molding. To release the molding, start at the inside and roll the molding to the outside.
- Remove the pickup bed. For additional information, refer to «Pickup Bed»(/ford/explorer-sport-trac/ii-2006-2010/remont/frames-subframes-crossmembers/#body-panel-system) .
- Remove the rear lamp assembly. Remove the bolts. Remove the rear lamp. Disconnect the electrical connectors.
- Remove the 2 rear body side outer bolts. To install, tighten to 12 N.m (9 lb-ft).
- Remove the 4 pickup bed wheel house screws.
- Remove the 4 front body side outer bolts. To install, tighten to 12 N.m (9 lb-ft).
- Remove the lower rear body side outer bolt and disconnect the wiring harness from the body side outer panel. To install, tighten to 12 N.m (9 lb-ft).
- Remove the 3 upper body side outer mounting bolts and remove the body side outer panel. To install, tighten to 12 N.m (9 lb-ft).
- To install, reverse the removal procedure.
Pickup Bed Wheel House
Note. RH shown, LH similar.
Scheme 2
Scheme 2: Pickup Bed Wheel House
| Item | Part Number | Description |
| 1 | W711687-S | Wheel house pin-type retainer |
| 2 | N808650-S | Rear wheel house screw (4 required) |
| 3 | W706805-S | Rear wheel house-to-wheel house opening screw (4 required) |
| 4 | 7827886 LH/ 7827887 RH | Rear wheel house |
- Remove the rear fender molding. For additional information, refer to «EXTERIOR TRIM AND ORNAMENTATION»(/ford/explorer-sport-trac/ii-2006-2010/remont/exteriorinterior-trim/#exterior-trim-and-ornamentation) article.
- Remove the 3 bumper cover screws.
- Remove the 4 rear wheel house-to-wheel house opening screws.
- Remove the pin-type retainer.
- Remove the rear wheel house. Remove the screws. Remove the rear wheel house.
- To install, reverse the removal procedure.
Scheme 3
Scheme 3: REMOVAL AND INSTALLATION
| Item | Part Number | Description |
| 1 | W504696-S | Power point screw (4 required) |
| 2 | 19G257 | Power point receptacle |
| 3 | 14A464 | Power point wiring connector |
- Remove the 4 screws and the power point receptacle from the pickup bed side.
- Disconnect the power point receptacle electrical connector and remove the power point receptacle.
- To install, reverse the removal procedure.
Scheme 4
Scheme 4: REMOVAL AND INSTALLATION
| Item | Part Number | Description |
| 1 | W711319-S | Pickup bed rear bolt (2 required) |
| 2 | W709404-S | Pickup bed rear nut retainer (2 required) |
| 3 | W708731-S | Pickup bed front nut (2 required) |
| 4 | 99286E44 | Stud plate |
| 5 | W702065 | Rivet (4 required) |
- With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(/ford/explorer-sport-trac/ii-2006-2010/remont/hoistjack/#jacking-and-lifting) article.
- If equipped, remove the Tonneau cover.
- If equipped, remove the cargo divider.
- Remove the tailgate assembly.
- Remove the fuel filler cap.
- Remove the fuel filler pipe screws and position the filler pipe aside. To install, tighten to 3 Nm (27 lb-in).
- Remove the rear fender moldings. For additional information, refer to «EXTERIOR TRIM AND ORNAMENTATION»(/ford/explorer-sport-trac/ii-2006-2010/remont/exteriorinterior-trim/#exterior-trim-and-ornamentation) article.
- Raise the vehicle.
- Disconnect the electrical connector.
- Disconnect the license plate lamp electrical connectors.
- Remove the 2 pickup bed front nuts from under the vehicle (1 each side). To install, tighten to 62 N.m (46 lb-ft).
- Remove the 6 rear bumper cover screws (3 each side).
- Remove the 6 rear bumper cover screws and the bumper cover.
- Lower the vehicle.
- Remove the 2 pickup bed rear bolts (1 each side). To install, tighten to 62 N.m (46 lb-ft).
- With the help of an assistant, remove the pickup bed and place it on a suitable support.
- To install, reverse the removal procedure.
Scheme 5
Scheme 5: REMOVAL AND INSTALLATION
| Item | Part Number | Description |
| 1 | 99432A06 | Tailgate striker (2 required) |
| 2 | N805156-S | Tailgate cable anchor (2 required) |
| 3 | W710261-S | Tailgate hinge bolt (4 required) |
| 4 | 78430B39 | LH tailgate hinge |
| 5 | 78430B38 | RH tailgate hinge |
| 6 | W706056-S | Reinforcement mounting bolt (4 required) |
| 7 | W706056-S | Reinforcement outer mounting bolt (2 required) |
| 8 | 99281B44 | Pickup bed reinforcement |
- Remove the LH and RH body side outer panels. For additional information, refer to «Pickup Bed Body Side»(/ford/explorer-sport-trac/ii-2006-2010/remont/frames-subframes-crossmembers/#body-panel-system__pickup-bed-body-side) .
- Remove the 2 tailgate hinges (1 each side).
- Remove the 2 tailgate cable anchors (1 each side).
- Remove the 2 tailgate strikers (1 each side).
- Remove the 4 reinforcement mounting bolts from the pickup bed (2 each side). To install, tighten to 25 N.m (18 lb-ft).
- Turn the pickup bed upside down on a suitable support.
- Remove the 2 outer pickup bed reinforcement bolts and remove the reinforcement. To install, tighten to 25 N.m (18 lb-ft).
- Disconnect the wiring harness from the pickup bed reinforcement.
- To install, reverse the removal procedure.
Scheme 6
Scheme 6: Pickup Bed Storage Compartment - Exploded View
| Item | Part Number | Description |
| 1 | 99286A30 | Side storage compartment seal |
| 2 | 99286E52 | Side storage compartment lid seal |
| 3 | 99461A30 | Side storage compartment hinge |
| 4 | 99461A30 | Side storage compartment lid |
| 5 | 99461A30 | Front storage compartment lid |
| 6 | 99286A30 | Front storage compartment lid-to-hinge nut (6 required) |
| 7 | 99286E46 | Front storage compartment hinge seal |
| 8 | 9928A32 | Front storage compartment hinge |
| 9 | 99286D18 | Front compartment strut |
| 10 | 99286A30 | Front storage compartment seal |
| 11 | 99286A30 | Front storage compartment side seal LH |
| 12 | 99286A30 | Front storage compartment side seal RH |
| 13 | 99286A30 | Front storage compartment-to-box nut (6 required) |
- For additional information, refer to the procedures in this article.
Pickup Bed Storage Compartment Hinge - Side Compartment
- Remove the side compartment lid. For additional information, refer to «Pickup Bed Storage Compartment Lid - Side Compartment»(/ford/explorer-sport-trac/ii-2006-2010/remont/frames-subframes-crossmembers/#body-panel-system__pickup-bed-storage-compartment-lid) .
- Remove the storage compartment hinge. Remove the storage compartment seal. Remove the storage compartment hinge. Clean the lid surface of any residual seal material. Scuff the seal surface area. Apply adhesive promoter. Apply pressure to the hinge surface with a roller and allow seal to cure before installation for one hour.
- To install, reverse the removal procedure.
Pickup Bed Storage Compartment Hinge - Front Compartment
- Remove the front compartment lid. For additional information, refer to «Pickup Bed Storage Compartment Lid - Front Compartment»(/ford/explorer-sport-trac/ii-2006-2010/remont/frames-subframes-crossmembers/#body-panel-system__pickup-bed-storage-compartment-lid) .
- Remove the pickup bed. For additional information, refer to «Pickup Bed»(/ford/explorer-sport-trac/ii-2006-2010/remont/frames-subframes-crossmembers/#body-panel-system) .
- Remove the front compartment lid hinge nuts from the front of the pickup bed. To install, tighten to 12 Nm (9 lb-ft).
- Remove the front compartment lid hinge from the pickup box.
- To install, reverse the removal procedure.
Pickup Bed Storage Compartment Lid - Front Compartment
- Open the storage compartment lid and disconnect the compartment lid struts from the door.
- Remove the 6 storage compartment lid nuts. To install, tighten to 12 Nm (9 lb-ft).
- Remove the storage compartment lid.
- To install, reverse the removal procedure.
Pickup Bed Storage Compartment Lid - Side Compartment
- Open the compartment lid and remove the pickup bed seal.
- Remove the storage compartment door.
- To install, reverse the removal procedure.
Pickup Bed Storage Compartment Seal - Side Compartment
- Remove the side compartment lid. For additional information, refer to «Pickup Bed Storage Compartment Lid - Side Compartment»(/ford/explorer-sport-trac/ii-2006-2010/remont/frames-subframes-crossmembers/#body-panel-system__pickup-bed-storage-compartment-lid) .
- Remove the storage compartment seal from the storage compartment. Remove any adhesive or residual seal material. Clean the lid surface with a 50/50 solution of alcohol and water. Apply adhesive promotor. Apply seal. Apply pressure to the seal with a roller and allow seal to cure before installation for one hour.
- To install, reverse the removal procedure.
Pickup Bed Storage Compartment Seal - Front Compartment
- Remove the front compartment lid. For additional information, refer to «Pickup Bed Storage Compartment Lid - Front Compartment»(/ford/explorer-sport-trac/ii-2006-2010/remont/frames-subframes-crossmembers/#body-panel-system__pickup-bed-storage-compartment-lid) .
- Remove the storage compartment seal from the storage compartment. Remove any adhesive or residual seal material. Clean the lid surface with a 50/50 solution of alcohol and water. Apply adhesive promotor. Apply seal. Apply pressure to the seal with a roller and allow seal to cure before installation for one hour.
- To install, reverse the removal procedure.
