Material
| Item | Specification | Fill Capacity |
|---|---|---|
| Silicone Brake Caliper Grease and Dielectric Compound XG-3-A | ESE-M1C171-A |
Material
GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Base ignition timing | 10 degrees before top dead center (BTDC) Non-adjustable |
| Firing order | 1-4-2-5-3-6 |
| Spark plug gap | 1.32-1.42 mm (0.052-0.056 in) |
| Spark plug type | AGSF24N |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Ignition coil bolts | 6 |
| Spark plugs | 17 |
TORQUE SPECIFICATIONS
The ignition system consists of the
- crankshaft position (CKP) sensor.
- ignition coil.
- spark plug wires.
- spark plugs.
The CKP sensor
- is a variable reluctance sensor.
- is mounted on the engine front cover.
- is triggered by a 36-minus-1 tooth trigger wheel located on the crankshaft damper pulse ring.
- provides ignition timing and crankshaft speed (RPM) to the PCM.
The ignition coil
- changes low-voltage pulses from the PCM to high-voltage pulses.
- fires 2 spark plugs simultaneously.
- has 3 transformers. One transformer fires the spark plugs for cylinders 1 and 5 One transformer fires the spark plugs for cylinders 2 and 6 One transformer fires the spark plugs for cylinders 3 and 4
Spark plug wires
- carry high-voltage pulses from the ignition coil to the spark plugs.
The spark plugs
- change high-voltage pulses to spark at the gap, which ignites the fuel and air mixture.
The firing order is 1-4-2-5-3-6.
Scheme 3
Refer to the Introduction - Gasoline Engines article.
Scheme 4
| Item | Part Number | Description |
|---|---|---|
| 1 | 14A464 | Ignition coil electrical connector |
| 2 | 14489 | Radio noise suppressor electrical connector |
| 3 | 12297 | Spark plug wire retainers |
| 4 | 12286 | Spark plug wire (6 required) |
| 5 | 12405 | Spark plug (6 required) |
| 6 | W706216-S | Ignition coil bolt (4 required) |
| 7 | 12029 | Ignition coil |
- For additional information, refer to the procedures in this article.
Ignition Coil
| Item | Specification |
|---|---|
| Silicone Brake Caliper Grease and Dielectric Compound XG-3-A | ESE-M1C171-A |
Material
REMOVAL AND INSTALLATION
- Disconnect the ignition coil electrical connector.
- Disconnect the radio noise suppressor electrical connector.
- Squeeze the tabs and twist, while pulling upward to disconnect the 6 spark plug wires from the ignition coil.
- Remove the 4 bolts and the ignition coil. To install, tighten to 6 Nm (53 lb-in).
- To install, reverse the removal procedure.
Spark Plug Wires
Special Tools Illustration Tool Name Tool Number Remover, Spark Plug Wire 303-106 (T74P-6666-A)
| Item | Specification |
|---|---|
| Silicone Brake Caliper Grease and Dielectric Compound XG-3-A | ESE-M1C171-A |
Material
- Squeeze the locking tabs and twist while pulling upward to disconnect the 6 spark plug wires from the ignition coil.
- Detach the spark plug wires from the spark plug wire retainers.
- With a twisting motion, use the special tool to pull the spark plug wires from the spark plugs.
- To install, reverse the removal procedure.
Spark Plugs
Special Tools Illustration Tool Name Tool Number Remover, Spark Plug Wire 303-106 (T74P-6666-A)
| Item | Specification |
|---|---|
| Silicone Brake Caliper Grease and Dielectric Compound XG-3-A | ESE-M1C171-A |
Material
- With a twisting motion, use the special tool to pull the spark plug wire from the spark plug.
- Remove the spark plugs. To install, tighten to 17 Nm (13 lb-ft).
- Use a suitable spark plug gap tool to check and adjust the spark plug gap.
- To install, reverse the removal procedure.
