Bumper System Ford Explorer Sport Trac II

Exterior Body Panels 5 illustrations ~444 words

TORQUE SPECIFICATIONS

DescriptionNm
Front bumper mounting bolts48
Rear bumper cover bracket bolts - Explorer11
Rear bumper cover bracket bolts - Explorer Sport Trac6
Rear bumper cover screws6

TORQUE SPECIFICATIONS

Scheme 50

Scheme 50: Bumper - Exploded View, Front
ItemPart NumberDescription
1W711666Radiator grille scrivet (6 required)
2W712584Bumper cover lower bolt (2 required)
317D957Bumper cover
4W505444Front bumper mounting bolt (4 required)
517K820Front bumper
617E814Front bumper cover retaining clip (LH/RH)

Scheme 51

Scheme 51
ItemPart NumberDescription
1W712584Bumper cover lower bolt (2 required)
217D957Bumper cover
3W505427Bumper cover upper bolt (2 required)
4W701014Bumper cover upper nut (4 required)
5W505444Front bumper cover mounting bolt (4 required)
617K820Front bumper
  1. For additional information, refer to the procedures in this article.

REMOVAL AND INSTALLATION

Explorer/Explorer Sport Trac

  1. Remove the headlamp assemblies. For additional information, refer to «EXTERIOR LIGHTING»(/ford/explorer-sport-trac/ii-2006-2010/remont/exterior-lights/#exterior-lighting-system) article.
  2. Disconnect the fog lamp electrical connectors, if equipped. For additional information, refer to «EXTERIOR LIGHTING»(/ford/explorer-sport-trac/ii-2006-2010/remont/exterior-lights/#exterior-lighting-system) article.
  3. Disconnect the side turn signal lamp electrical connectors, if equipped. For additional information, refer to «EXTERIOR LIGHTING»(/ford/explorer-sport-trac/ii-2006-2010/remont/exterior-lights/#exterior-lighting-system) article.
  4. Remove the front fender inner splash shield screws.
  5. Remove the front fender inner splash shield pin-type retainers.
  6. Remove the front fender inner splash shields.
  7. Remove the 2 bolts from the bottom of the bumper cover.
  8. Remove the 6 grille-to-grille opening panel scrivets.
  9. Release the bumper cover-to-fender clips.
  10. Remove the bumper cover upper screws.
  11. Rotate the bottom of the front bumper cover upward.
  12. Apply downward pressure to the top of the front bumper cover to release the 3 locking tabs.
  13. Remove the front bumper cover.
  14. To install, reverse the removal procedure.
  1. Remove the front bumper cover. For additional information, refer to «Bumper Cover - Front»(/ford/explorer-sport-trac/ii-2006-2010/remont/exterior-body-panels/#bumper-system) .
  2. Remove the 4 front bumper bolts. To install, tighten to 48 Nm (35 lb-ft).
  3. Remove the front bumper.
  4. To install, reverse the removal procedure.

Scheme 52

Scheme 52: Bumper - Exploded View, Rear
ItemPart NumberDescription
1W708530Bumper cover pin-type retainer (9 required)
217D781Rear bumper cover
3W505153Rear bumper cover bracket bolt (4 required)
414A464Parking aid sensor wiring assembly
5N811487Rear bumper cover bracket rivet (6 required)
6605872STrailer hitch light plug bolt
714A464Trailer hitch light plug

Scheme 53

Scheme 53
ItemPart NumberDescription
1W708530Bumper cover-to-splash shield pin-type retainers (8 required)
2W708530Bumper cover pin-type retainer (7 required)
317K835Rear bumper cover
414A464Rear parking aid sensor wiring assembly
5605872STrailer hitch light plug bolt
614A464Trailer hitch light plug
7W705549Bumper cover bracket bolts

Scheme 54

Scheme 54
ItemPart NumberDescription
1W712247Rear bumper cover screw (6 required)
2W711414Rear bumper cover splash shield screw (6 required)
313412Rear bumper cover wiring harness
4180103-13A409Rear license plate wiring harness connector
517K835Rear bumper cover
6W505424Rear bumper cover bracket bolt and washer (4 required)
717E850Rear bumper cover mounting bracket
  1. For additional information, refer to the procedures in this article.
  1. Remove the tail lamp assemblies.
  2. Remove the 2 rear bumper cover bracket bolts. To install, tighten to 11 Nm (8 lb-ft).
  3. Remove the 9 bumper cover pin-type retainers.
  4. Disconnect the rear parking aid sensor electrical connector, if equipped.
  5. Remove the bumper cover. Lift the outer corners upward and pull the bumper cover straight up and out.
  6. Transfer components as necessary.
  7. To install, reverse the removal procedure.
  1. Remove the taillamp assemblies.
  2. Remove the 2 rear bumper bracket bolts.
  3. Remove the bumper cover pin-type retainers.
  4. Disconnect the rear parking aid sensor electrical connector, if equipped.
  5. Remove the side marker lamp electrical connector, if equipped.
  6. Remove the 8 bumper cover-to-splash shield pin-type retainers.
  7. Remove the rear bumper cover. Lift the front corner of the rear bumper cover straight up and pull away. Repeat on the opposite side.
  8. Transfer components as necessary.
  9. To install, reverse the removal procedure.

Bumper Cover - Rear, Sport Trac

  1. Remove the 6 rear bumper cover screws. To install, tighten to 6 N.m (53 lb-in).
  2. Remove the 6 rear bumper cover splash shield screws (3 each side).
  3. Disconnect the license plate electrical connector.
  4. Remove the bumper cover. Pull the outer corners outward and pull the bumper cover rearward to disengage the cover from the retaining clips.
  5. Transfer the components as necessary.
  6. To install, reverse the removal procedure.
