Multifunction Electronic Control Modules Ford Explorer Sport Trac I

Communication Devices 12 illustrations ~929 words

MODULE CONTROLLED FUNCTIONS

Note. Prior to removal of the generic electronic module (GEM), it is necessary to upload module configuration information to a diagnostic tool. This information needs to be downloaded into the new module once installed. For additional information, refer to MODULE COMMUNICATIONS NETWORK article.

The multifunction module consists of the following

  1. Generic Electronic Module (GEM)
  2. Central Security Module

The GEM controls the following features

  1. Front Wiper And Washer
  2. Rear Wiper And Washer
  3. Warning Chime
  4. Illuminated Entry And Interior Lighting
  5. Driver One-Touch Down Power Window (Optional)
  6. Battery Saver Relay
  7. Door Ajar Warning Indicator Lamp
  8. Safety Belt Warning Indicator Lamp

The remote anti-theft personality (RAP)/central security module controls the following features

  1. Remote Keyless Entry
  2. Computer-Operated Locks

DIAGNOSTIC TROUBLE CODE CHART

DTCDescriptionSourceAction
B1213Anti-Theft Number of Programmed Keys is Below MinimumPCMREFER to ANTI-THEFT - PATS article
B1231Longitudinal Acceleration Threshold ExceededRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1309Power Door Lock Circuit Short to GroundCentral Security ModuleREFER to HANDLES, LOCKS, LATCHES & ENTRY SYSTEMS article
B1313Battery Saver Relay Coil Circuit Open, Short to GroundGEMREFER to INTERIOR LIGHTING article
B1315Battery Saver Relay Coil Circuit Short to BatteryGEMREFER to INTERIOR LIGHTING article
B1317Battery Voltage High4WD Control ModuleREFER to GENERATORS & REGULATORS article
B1317Battery Voltage HighGEMREFER to GENERATORS & REGULATORS article
B1318Battery Voltage Low4WD Control ModuleREFER to GENERATORS & REGULATORS article
B1318Battery Voltage LowGEMREFER to GENERATORS & REGULATORS article
B1318Battery Voltage LowRCMREFER to GENERATORS & REGULATORS article
B1322Driver Door Ajar Circuit Short to Ground4WD Control ModuleREFER to INTERIOR LIGHTING article
B1322Door Ajar Driver Circuit Short to GroundGEMREFER to INTERIOR LIGHTING article
B1323Door Ajar Lamp Circuit FailureGEMREFER to GAUGES & INSTRUMENT PANELS article
B1325Door Ajar Lamp Circuit Short to BatteryGEMREFER to GAUGES & INSTRUMENT PANELS article
B1330Passenger Door Ajar Circuit Short to GroundGEMREFER to INTERIOR LIGHTING article
B1334Decklid Ajar Rear Door Circuit Short to GroundGEMREFER to INTERIOR LIGHTING article
B1334Decklid Ajar Rear Door Circuit Short to GroundCentral Security ModuleRefer to INTERIOR LIGHTING article
B1338RR Door Ajar Circuit Short to GroundCentral Security ModuleRefer to INTERIOR LIGHTING article
B1338RR Door Ajar Circuit Short to GroundGEMREFER to INTERIOR LIGHTING article
B1340Chime Input Request Circuit Short to GroundGEMREFER to WARNING DEVICES article
B1341Power Door Unlock Circuit Short to GroundCentral Security ModuleREFER to HANDLES, LOCKS, LATCHES & ENTRY SYSTEMS article
B1342ECU is DefectiveABS ModuleCLEAR DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new ABS module. REFER to ANTI-LOCK BRAKES article. CLEAR the DTCs. REPEAT the self-test.
B1342ECU is DefectiveCentral Security ModuleClear DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new central security module. REFER to VEHICLE SECURITY MODULE . CLEAR the DTCs. REPEAT the self-test.
B1342ECU is Defective4WD Control ModuleClear DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new 4WD Control Module. REFER to FOUR-WHEEL DRIVE SYSTEMS article. CLEAR the DTCs. REPEAT the self-test.
B1342ECU is DefectiveGEMCLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new GEM. REFER to GENERIC ELECTRONIC MODULE (GEM) .
B1342ECU is DefectiveRCMClear DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new RCM. REFER to AIR BAG RESTRAINT SYSTEMS article. CLEAR the DTCs. REPEAT the self-test.
B1345Heated Backlight Input Circuit Short to GroundGEMREFER to GLASS, FRAMES & MECHANISMS article
B1347Heated Backlight Relay Circuit FailureGEMREFER to GLASS, FRAMES & MECHANISMS article
B1349Heated Backlight Relay Circuit Short to BatteryGEMREFER to GLASS, FRAMES & MECHANISMS article
B1352Ignition Key-In Circuit FailureGEMREFER to WARNING DEVICES article
B1355Ignition Run Circuit Failure4WD Control ModuleREFER to STEERING COLUMN SWITCHES article
B1355Ignition RUN Circuit FailureGEMREFER to STEERING COLUMN SWITCHES article
B1359Ignition RUN/ACC Circuit FailureGEMREFER to STEERING COLUMN SWITCHES article
B1365Ignition Start Circuit Short to BatteryGEMREFER to STEERING COLUMN SWITCHES article
B1371Illuminated Entry Relay Circuit FailureGEMREFER to INTERIOR LIGHTING article
B1373Illuminated Entry Relay Short to BatteryGEMREFER to INTERIOR LIGHTING article
B1398Driver Power Window One-Touch Window Relay Circuit FailureGEMREFER to GLASS, FRAMES & MECHANISMS article
B1400Driver Power Window One-Touch Window Relay Coil Circuit Short to BatteryGEMREFER to GLASS, FRAMES & MECHANISMS article
B1405Driver Power Window Down Circuit Short to BatteryGEMREFER to GLASS, FRAMES & MECHANISMS article
B1408Driver Power Window Up Circuit Short to BatteryGEMREFER to GLASS, FRAMES & MECHANISMS article
B1410Driver Power Window Motor Circuit FailureGEMREFER to GLASS, FRAMES & MECHANISMS article
B1426Safety Belt Lamp Circuit Short to BatteryGEMREFER to GAUGES & INSTRUMENT PANELS article
B1428Safety Belt Lamp Circuit FailureGEMREFER to GAUGES & INSTRUMENT PANELS article
B1431Wiper Brake/Run Relay Circuit FailureGEMREFER to WIPERS & WASHERS article
B1432Wiper Brake/Run Relay Circuit Short to BatteryGEMREFER to WIPERS & WASHERS article
B1434Wiper Hi/Lo Speed Relay Coil Circuit FailureGEMREFER to WIPERS & WASHERS article
B1436Wiper Hi/Lo Speed Relay Coil Circuit Short to BatteryGEMREFER to WIPERS & WASHERS article
B1438Wiper Mode Select Switch Circuit FailureGEMREFER to WIPERS & WASHERS article
B1441Wiper Mode Select Switch Circuit Short to GroundGEMREFER to WIPERS & WASHERS article
B1446Wiper Park Sense Circuit FailureGEMREFER to WIPERS & WASHERS article
B1450Wiper Wash/Delay Switch Circuit FailureGEMREFER to WIPERS & WASHERS article
B1453Wiper Wash/Delay Switch Circuit Short to GroundGEMREFER to WIPERS & WASHERS article
B1458Wiper Washer Pump Motor Relay Circuit FailureGEMREFER to WIPERS & WASHERS article
B1460Wiper Washer Pump Motor Relay Coil Circuit Short to BatteryGEMREFER to WIPERS & WASHERS article
B1462Safety Belt Switch Circuit FailureGEMREFER to WARNING DEVICES article
B1466Wiper Hi/Lo Speed Not SwitchingGEMREFER to WIPERS & WASHERS article
B1473Wiper Low Speed Circuit Motor FailureGEMREFER to WIPERS & WASHERS article
B1476Wiper High Speed Circuit Motor FailureGEMREFER to WIPERS & WASHERS article
B1483Brake Pedal Input Circuit Failure4WD Control ModuleREFER to STEERING COLUMN SWITCHES article
B1485Brake Pedal Switch Input Circuit Short to BatteryABS ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
B1485Brake Pedal Input Circuit Short to BatteryCentral Security ModuleREFER to GENERATORS & REGULATORS article
B1485Brake Pedal Input Circuit Short to Battery4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
B1522Hood Switch Circuit Short to GroundCentral Security ModuleREFER to ANTI-THEFT - PATS article
B1526Keyless Entry Circuit Short to GroundCentral Security ModuleREFER to HANDLES, LOCKS, LATCHES & ENTRY SYSTEMS article
B1555Ignition Run/Start Circuit Failure 4WD Control ModuleREFER to STEERING COLUMN SWITCHES article
B1562Door Lock Cylinder Circuit Short to GroundCentral Security ModuleREFER to HANDLES, LOCKS, LATCHES & ENTRY SYSTEMS article
B1577Park Lamp Input Circuit Short to BatteryGEMREFER to WARNING DEVICES article
B1600PATS Ignition Key Transponder Signal is Not ReceivedPCMREFER to ANTI-THEFT - PATS article
B1601PATS Received Incorrect Key-Code From Ignition Key TransponderPCMREFER to ANTI-THEFT - PATS article
B1602PATS Received Invalid Format Of Key-Code From Ignition Key TransponderPCMREFER to ANTI-THEFT - PATS article
B1610Illuminated Entry Input Circuit Short to GroundGEMREFER to INTERIOR LIGHTING article
B1611Wiper Rear Mode Select Switch Circuit FailureGEMREFER to WIPERS & WASHERS article
B1614Wiper Rear Mode Select Switch Circuit Short to GroundGEMREFER to WIPERS & WASHERS article
B1629PRNDL Reverse Input Short To BatteryCentral Security ModuleREFER to TRANSMISSION EXTERNAL CONTROLS article
B1676Battery Voltage Out of RangeABS ModuleREFER to ANTI-LOCK BRAKES article
B1681PATS Transceiver Module Signal is Not ReceivedPCMREFER to ANTI-THEFT - PATS article
B1814Wiper Rear Motor Down Relay Coil Circuit FailureGEMREFER to WIPERS & WASHERS article
B1816Wiper Rear Motor Down Relay Coil Circuit Short to BatteryGEMREFER to WIPERS & WASHERS article
B1818Wiper Rear Motor Up Relay Coil Circuit FailureGEMREFER to WIPERS & WASHERS article
B1820Rear Wiper Motor Up Relay Circuit Short to BatteryGEMREFER to WIPERS & WASHERS article
B1840Wiper Front Power Circuit FailureGEMREFER to WIPERS & WASHERS article
B1869Lamp Air Bag Warning Indicator Circuit OpenRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1870Lamp Air Bag Warning Indicator Circuit Short To BatteryRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1887Air Bag Driver Circuit Short to GroundRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1888Air Bag Passenger Circuit Short to GroundRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1891Air Bag Tone Warning Indicator Circuit Short to BatteryRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1892Air Bag Tone Warning Indicator Circuit FailureRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1894Wiper Rear Motor Speed Sense Circuit FailureGEMREFER to WIPERS & WASHERS article
B1916Air Bag Driver Circuit Short to BatteryRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1921Air Bag Diagnostic Monitor Ground Circuit OpenRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1925Air Bag Passenger Circuit Short to BatteryRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1932Air Bag Driver Circuit OpenRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1933Air Bag Passenger Circuit OpenRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1934Air Bag Driver Inflator Circuit Resistance Low on SquibRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1935Air Bag Passenger Inflator Circuit Resistance Low on SquibRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1992Driver Side, Side Mount Air Bag Circuit Short to BatteryRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1993Driver Side, Side Mount Air Bag Circuit Short to GroundRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1994Driver Side, Side Mount Air Bag Circuit OpenRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1995Driver Side, Side Mount Air Bag Circuit Resistance Low On SquibRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1996Passenger Side, Side Mount Air Bag Circuit Short to BatteryRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1997Passenger Side, Side Mount Air Bag Circuit Short to GroundRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1998Passenger Side, Side Mount Air Bag Circuit OpenRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B1999Passenger Side, Side Mount Air Bag Circuit Resistance Low on SquibRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B2103Antenna Not ConnectedPCMREFER to ANTI-THEFT - PATS article
B2276Less Than Two Transmitters ProgrammedCentral Security ModuleREFER to HANDLES, LOCKS, LATCHES & ENTRY SYSTEMS article
B2425Remote Keyless Entry Out of SynchronizationCentral Security ModuleREFER to HANDLES, LOCKS, LATCHES & ENTRY SYSTEMS article
B2431Transponder Programming FailurePCMREFER to ANTI-THEFT - PATS article
B2432Driver Seat Belt Buckle Switch Circuit OpenRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B2434Driver Seat Belt Buckle Switch Circuit Short to GroundRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B2435Driver Seat Belt Buckle Switch Circuit Resistance Out of RangeRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B2436Passengers Seat Belt Buckle Switch Circuit OpenRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B2438Passenger Seat Belt Buckle Switch Circuit Short to GroundRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B2439Passenger Seat Belt Buckle Switch Circuit Resistance Out of RangeRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B2440Passenger Side, Side Crash Sensor Mount FaultRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B2441Driver Side, Side Crash Sensor Mount FaultRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B2444Driver Side Crash Sensor Internal FaultRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B2445Passenger Side Crash Sensor Internal FaultRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B2477Module Configuration FailureABS ModuleREFER to MODULE COMMUNICATIONS NETWORK article
B2477Module Configuration Failure (Unconfigured, Incorrect Or Rejected)Central Security ModuleREFER to MODULE CONFIGURATION article
B2477Module Configuration FailureGEMREFER to MODULE CONFIGURATION article
B2477Module Configuration FailureRCMREFER to AIR BAG RESTRAINT SYSTEMS article
B2607Harness/Configuration MismatchABS ModuleREFER to ANTI-LOCK BRAKES article
B9610Illuminated Entry Input Short Circuit to GroundGEMNo Action
C1095ABS Hydraulic Pump Motor Circuit FailureABS ModuleREFER to ANTI-LOCK BRAKES article
C1145Wheel Speed Sensor RF Input Circuit FailureABS ModuleREFER to ANTI-LOCK BRAKES article
C1155Wheel Speed Sensor LF Input Circuit FailureABS ModuleREFER to ANTI-LOCK BRAKES article
C1230Wheel Speed Sensor Rear Center Input Circuit FailureABS ModuleREFER to ANTI-LOCK BRAKES article
C1233Wheel Speed LF Input Signal MissingABS ModuleREFER to ANTI-LOCK BRAKES article
C1234Wheel Speed RF Input Signal MissingABS ModuleREFER to ANTI-LOCK BRAKES article
C1237Rear Wheel Speed Input Signal MissingABS ModuleREFER to ANTI-LOCK BRAKES article
C1414Incorrect Module Design LevelRCMREFER to AIR BAG RESTRAINT SYSTEMS article
C1728Transfer Case Unable To Transition Between 2H and 4H4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
C1729Transfer Case Unable To Transition Between 4H and 4L4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
P0500Vehicle Speed Sensor Malfunction4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
P0500Vehicle Speed Sensor MalfunctionGEMREFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV article
P1804Transmission 4-Wheel Drive High Indicator Circuit Failure4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
P1806Transmission 4-Wheel Drive High Indicator Circuit Short to Battery4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
P1808Transmission 4-Wheel Drive Low Indicator Circuit Failure4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
P1810Transmission 4-Wheel Drive Low Indicator Circuit Short to Battery4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
P1812Transmission 4-Wheel Drive Mode Select Circuit Failure4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
P1815Transmission 4-Wheel Drive Mode Select Circuit Short to Ground4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
P1816Transmission Neutral Safety Switch Circuit Failure4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
P1819Transmission Neutral Safety Switch Circuit Short to Ground4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
P1849Transmission Transfer Case Contact Plate A Circuit Short to Ground4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
P1853Transmission Transfer Case Contact Plate B Circuit Short to Ground4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
P1857Transmission Transfer Case Contact Plate C Circuit Short to Ground4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
P1861Transmission Transfer Case Contact Plate D Circuit Short to Ground4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
P1867Transmission Transfer Case Contact Plate General Circuit Failure4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
P1891Transmission Transfer Case Contact Plate Ground Return Open Circuit4WD Control ModuleREFER to FOUR-WHEEL DRIVE SYSTEMS article
U2017Driver Side Crash Sensor Communications FaultRCMREFER to AIR BAG RESTRAINT SYSTEMS article
U2018Passenger Side Crash Sensor Communications FaultRCMREFER to AIR BAG RESTRAINT SYSTEMS article

DIAGNOSTIC TROUBLE CODE CHART

MULTIFUNCTION ELECTRONIC MODULE

For wiring diagrams for Explorer Sport, see BODY COMPUTER in SYSTEM WIRING DIAGRAMS article. For wiring diagrams for Explorer Sport Trac, see BODY COMPUTER in SYSTEM WIRING DIAGRAMS article.

Scheme 39

Scheme 39: Special Tools

Principles Of Operation

Note. Upon installation of a new generic electronic module (GEM), the module must be reconfigured. Refer to MODULE CONFIGURATION article prior to GEM removal.

The GEM receives inputs and delivers outputs to a majority of the electronically controlled features of the vehicle. The GEM constantly monitors the systems under its control and reports a concern in the form of a diagnostic trouble code (DTC). The DTC can be retrieved with a diagnostic tool through the ISO 9141 communication network. The GEM controls the following features

  1. Front Wiper And Washer
  2. Warning Chime
  3. Battery Saver
  4. Illuminated Entry And Interior Lighting
  5. Driver One-Touch Down Power Window (Optional)
  6. Door Ajar Warning Indicator Lamp
  7. Safety Belt Warning Indicator Lamp

Inspection & Verification

  1. Verify the customer concern by operating the system.
  2. Visually inspect for obvious signs of electrical damage: Electrical Visual Inspection Central Junction Box (CJB) fuse: 10 (7.5A) 20 (7.5A) 25 (7.5A) 28 (7.5A) Wiring Harness Connector(s) Circuitry
  3. If the concern remains after the inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: Check that the program card is correctly installed. Check the connections to the vehicle. Check the ignition switch position.
  4. If diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool manual.
  5. Carry out the DATA LINK DIAGNOSTICS test. If the diagnostic tool responds with: CKT914, CKT915 or CKT70 = ALL ECUS NO RESP/NOT EQUIP, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/explorer-sport-trac/i-2000-2005/remont/communication-devices/#module-communications-network) article. NO RESPONSE/NOT EQUIP for GEM, go to «PINPOINT TEST A: NO COMMUNICATION WITH THE GENERIC ELECTRONIC MODULE (GEM)»(/ford/explorer-sport-trac/i-2000-2005/remont/communication-devices/#multifunction-electronic-control-modules) . SYSTEM PASSED, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs and carry out self-test diagnostics for the GEM.
  6. If the DTCs retrieved are related to the concern, go to the «DIAGNOSTIC TROUBLE CODE CHART»(/ford/explorer-sport-trac/i-2000-2005/remont/communication-devices/#multifunction-electronic-control-modules__diagnostic-trouble-code-chart) to continue diagnostics.
  7. If no DTCs related to the concern are retrieved, refer to the appropriate system article to continue diagnostics.

Scheme 40

Scheme 40: Symptom Chart

Scheme 41

Scheme 41: Pinpoint Test A: No Communication With The Generic Electronic Module (GEM)

Scheme 42

Scheme 42

Scheme 43

Scheme 43: Special Tools

The central security module controls the following features

  1. Remote Keyless Entry System
  2. Computer-Operated Lock System
  1. Verify the customer concern by operating the system.
  2. Visually inspect for obvious signs of electrical damage: Electrical Visual Inspection Central Junction Box (CJB) fuse: 18 (25A) 11 (7.5A) Wiring Harness Connector(s) Circuitry
  3. If the concern remains after the inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: Check that the program card is correctly installed. Check the connections to the vehicle. Check the ignition switch position.
  4. If diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool manual.
  5. Carry out the DATA LINK DIAGNOSTICS test. If the diagnostic tool responds with: CKT914, CKT915 or CKT70 = ALL ECUS NO RESP/NOT EQUIP, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/explorer-sport-trac/i-2000-2005/remont/communication-devices/#module-communications-network) article. NO RESPONSE/NOT EQUIP for central security module, go to «PINPOINT TEST B: NO COMMUNICATION WITH THE CENTRAL SECURITY MODULE»(/ford/explorer-sport-trac/i-2000-2005/remont/communication-devices/#multifunction-electronic-control-modules) . SYSTEM PASSED, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs and carry out self-test diagnostics for the central security module.
  6. If the DTCs retrieved are related to the concern, go to the «DIAGNOSTIC TROUBLE CODE CHART»(/ford/explorer-sport-trac/i-2000-2005/remont/communication-devices/#multifunction-electronic-control-modules__diagnostic-trouble-code-chart) to continue diagnostics.
  7. If no DTCs related to the concern are retrieved, refer to the appropriate system article to continue diagnostics.

Scheme 44

Scheme 44: Symptom Chart

Scheme 45

Scheme 45: Pinpoint Test B: No Communication With The Central Security Module

Scheme 46

Scheme 46

Scheme 47

Scheme 47: Removal & Installation

Scheme 48

Scheme 48
  1. Disconnect the battery ground cable.
  2. Remove the radio chassis.
  3. Remove the center instrument panel finish panel. Remove the screws. Remove the center instrument panel finish panel. Disconnect the electrical connectors.
  4. Remove the GEM. Remove the bolt. Disconnect the electrical connectors from the GEM.
  5. To install, reverse the removal procedure.

Removal & Installation

CAUTIONPrior to removal of the module, it is necessary to upload module configuration information to the appropriate diagnostic equipment. This information needs to be downloaded into the new module once installed. For additional information, refer to MODULE CONFIGURATION article.

Scheme 49

Scheme 49

Scheme 50

Scheme 50
  1. Disconnect the battery ground cable.
  2. Remove the LH rear quarter trim panel.
  3. Disconnect the electrical connectors.
  4. Remove the central security module. Remove the bolts. Remove the central security module.
  5. To install, reverse the removal procedure.
