Automatic Transmission Cooling: Other Ford Expedition II

Automatic Trans 18 illustrations ~598 words

Material

ItemSpecification
MERCON® V Automatic Transmission FluidXT-5-QMMERCON® V
MERCON® Multi-Purpose (ATF) Transmission Fluid XT-2-QDXMERCON®

MATERIALS

Scheme 464

Scheme 464: Removal
Scheme 464: Removal

Scheme 465

Scheme 465
Scheme 465

Scheme 466

Scheme 466
Scheme 466
  1. Put the vehicle in NEUTRAL and position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-209881) article.
  2. Remove the bolts and the skid plate (4x4 vehicles).
  3. Remove three fasteners and position the air deflector aside.
  4. Remove the auxiliary transmission fluid cooler. Using the special tool, disconnect the fluid cooler tube fittings from the fluid cooler. Remove the three bolts and the fluid cooler.

Scheme 467

Scheme 467: Installation
Scheme 467: Installation

Scheme 468

Scheme 468
Scheme 468

Scheme 469

Scheme 469
Scheme 469
  1. Install the auxiliary transmission fluid cooler. Position the fluid cooler and install the three bolts. Connect the fluid cooler tube fittings to the fluid cooler.
  2. Position the air deflector and install the fasteners.
  3. Position the skid plate and install the bolts (4x4 vehicles).
  4. Fill the transmission with the specified type and quantity of transmission fluid. For additional information, refer to «AUTOMATIC TRANSMISSION - 4R100»(ref-209910) .
  5. Fill the transmission with the specified type and quantity of transmission fluid. For additional information, refer to «AUTOMATIC TRANSMISSION - 4R70W»(ref-209911) .
  6. Check for leaks.
ItemSpecification
MERCON® V Automatic Transmission FluidXT-5-QM, XT-5-DMMERCON® V
MERCON® Multi-Purpose (ATF) Transmission FluidXT-2-QDXMERCON®

MATERIALS

Scheme 470

Scheme 470: Removal
Scheme 470: Removal

Scheme 471

Scheme 471
Scheme 471

Scheme 472

Scheme 472
Scheme 472

Scheme 473

Scheme 473
Scheme 473
  1. Put the vehicle in NEUTRAL and position on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-209881) .
  2. Remove the bolts and the skid plate (4x4 vehicles).
  3. Remove three fasteners and position the air deflector aside.
  4. If not done previously, carry out the transmission fluid cooler flow test procedure. For additional information, refer to «AUTOMATIC TRANSMISSION - 4R100»(ref-209910) .
  5. Remove the fluid cooler tubes, as necessary.
  6. Remove the fluid cooler tubes, as necessary.
  7. Remove the fluid cooler tubes, as necessary.
  8. Remove the fluid cooler tubes, as necessary.

Scheme 474

Scheme 474: Installation
Scheme 474: Installation

Scheme 475

Scheme 475
Scheme 475

Scheme 476

Scheme 476
Scheme 476

Scheme 477

Scheme 477
Scheme 477
  1. Install the fluid cooler tube(s).
  2. Install the fluid cooler tube(s).
  3. Install the fluid cooler tube(s).
  4. Install the fluid cooler tube(s).
  5. Position the air deflector and install the fasteners.
  6. Position the skid plate and install the bolts (4x4 vehicles).
  7. Fill the transmission with the specified type and quantity of transmission fluid. For additional information, refer to «AUTOMATIC TRANSMISSION - 4R100»(ref-209910) .
  8. Fill the transmission with the specified type and quantity of transmission fluid. For additional information, refer to «AUTOMATIC TRANSMISSION - 4R70W»(ref-209911) .
  9. Check for leaks.
  10. If equipped with air suspension, reactivate the system by turning on the air suspension switch.
ItemSpecification
MERCON® Multi-Purpose (ATF) Transmission FluidXT-2-QDXMERCON®

MATERIALS

Scheme 478

Scheme 478: Removal
Scheme 478: Removal

Scheme 479

Scheme 479
Scheme 479
  1. Put the vehicle in NEUTRAL and position on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-209881) .
  2. If not done previously, carry out the transmission fluid cooler flow test procedure. For additional information, refer to «AUTOMATIC TRANSMISSION - 4R100»(ref-209910) .
  3. Remove the fluid cooler tube from the front cooler line case fitting.
  4. Remove the fluid cooler tube from the rear cooler line case fitting.
  5. Remove and discard the front cooler line case fitting, and the two rubber-coated sealing washers.
  6. Remove and discard the rear cooler line case fitting, and the two rubber-coated sealing washers.
  7. Remove the cooler bypass valve (CBV) assembly from the transmission.

Scheme 480

Scheme 480: Installation
Scheme 480: Installation

Scheme 481

Scheme 481
Scheme 481
  1. Install the new rubber-coated sealing washers and the new cooler line case fittings. Install one rubber-coated sealing washer on each cooler line case fitting. Install both cooler line case fittings into the CBV assembly fittings. Install one rubber-coated sealing washer on each cooler line case fitting.
  2. Install the CBV assembly.
  3. Install the fluid cooler tubes in the front and rear cooler line case fittings.
  4. Fill the transmission with the specified type and quantity of transmission fluid. For additional information, refer to «AUTOMATIC TRANSMISSION - 4R100»(ref-209910) .
  5. Check for leaks.
  6. If equipped with air suspension, reactivate the system by turning on the air suspension switch.
