Automatic Transaxle/transmission External Controls: Removal & Installation Ford Expedition II

Installation

1. Follow the removal procedure in reverse order.

Scheme 482

1. Remove the transmission control (TC) switch. Remove the TC switch cover. Remove the TC switch.
2. To install, reverse the removal procedure.

Scheme 483

Scheme 484

Scheme 485

Scheme 486

1. Lift the floor shift PRNDL bezel.
2. Disconnect the PRNDL bezel wire harness connector.
3. Remove the shift lever handle and cover. Slide the handle bezel down. Remove the screw. Disconnect the TCS wire harness. Lift assembly from the shifter lever.
4. Remove TCS switch from shift handle. Lift switch from handle body. Route harness through handle passage.
5. To install, reverse the removal procedure.

Scheme 487

Scheme 488

Scheme 489

Scheme 490

Scheme 491

Scheme 492

Scheme 493

Scheme 494

Scheme 495

Scheme 496

1. Lift the floor shift PRNDL bezel.
2. Disconnect the PRNDL bezel wire harness connector.
3. Remove the shift lever handle and cover. Slide the handle bezel down. Remove the screw. Disconnect the TCS wire harness. Lift assembly from the shifter lever.
4. Position the window regulator control panel aside.
5. Remove the screws and the console finish panel.
6. Remove the left side console access panel.
7. Disconnect the transmission shift cable from the transmission selector arm.
8. Remove the transmission shift cable retaining clip from the floor shift mechanism through the console access.
9. Remove the four bolts retaining the floor shift mechanism to the floor.
10. Disconnect the floor shift mechanism wire harness connector.
11. Remove the floor shift mechanism from the console.
12. Remove the brake shift interlock actuator, parking brake release mechanism and harness. Remove the wire harness retainers. Remove the two screws retaining the brake shift interlock assembly.
13. To install, reverse the removal procedure.
