CAPACITY
Fluid capacity is approximately 1.6 pints (.75L).
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Adjuster Lock Nut | 19-26 (26-35) | |
| Drag Link Castle Nut | 57-76 (77-103) | |
| Intermediate Shaft Pinch Bolt | 30-40 (40-54) | |
| Outer Tie Rod End-To-Front Spindle Castellated Nut | 66 (90) | |
| Power Steering Gear Race Nut | 55-90 (75-122) | |
| Power Steering Pump Bolts | ||
| Lower | 15-22 (20-30) | |
| Upper | 15-22 (20-30) | |
| Pressure Hose Fitting | 13-17 (17-23) | |
| Reservoir Bracket Bolts-To-Exhaust Manifold | 50-68 (68-92) | |
| Return Hose Fitting | 13-17 (17-23) | |
| Sector Shaft Arm Nut | 173-233 (234-316) | |
| Sector Shaft Housing Cover Bolts | 45-55 (61-75) | |
| Skid Plate Bolts | 10-13 (14-17) | |
| Steering Gear Bolts | 50-68 (68-92) | |
| Steering Gear Sector Shaft Arm-To-Sector Shaft Nut | 203 (275) | |
| Steering Sector Shaft Arm Drag Link-To-Inner Tie Rod End Castellated Nut | 66 (90) | |
| Steering Sector Shaft Arm Drag Link-To-Steering Gear Sector Shaft Arm Castellated Nut | 66 (90) | |
| Steering Sector Shaft Arm Drag Link-To-Steering Idler Arm Castellated Nut | 66 (90) | |
| Steering Idler Arm And Bracket-To-Frame Bolt | 148 (200) | |
| Toe Set Jam Nut | 66 (90) | |
| Valve Housing Bolts | 30-44 (40-60) | |
| Wheel Lug Nuts | ||
| 12 mm Wheel Bolts | 100 (135) | |
| 14 mm Wheel Bolts | 150 (204) | |
| INCH Lbs. (N.m) | ||
| Ball Guide Clamp Bolts | 45-62 (5-7) | |
| Power Steering Fluid Cooler Bolts | 80-107 (9-12) | |
| Steering Gear Race Lock Nut | 15-25 (1.7-2.8) | |
| Upper Reservoir Bracket Bolt | 80-107 (9-12) | |
TORQUE SPECIFICATIONS
