SPECIFICATIONS
| Specification | Application |
|---|
| Compressor Type | Ford FS-10 10-Cyl. |
| Compressor Belt Tension | (1) |
| System Oil Capacity | (2) (3) |
| Refrigerant (R-134a) Capacity | (3) |
| System Operating Pressures |
| High Side | 125-230 (8.8-16.2 kg/cm 2 ) |
| Low Side | 25-45 (1.8-3.2 kg/cm 2 ) |
| (1) Belt tension is automatically adjusted by tensioner pulley. (2) Use YN-12c PAG Refrigerant Oil (Part No. F7AZ-19589-DA). (3) See underhood specification label. |
| (1) | Belt tension is automatically adjusted by tensioner pulley. |
| (2) | Use YN-12c PAG Refrigerant Oil (Part No. F7AZ-19589-DA). |
| (3) | See underhood specification label. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Compressor Bolts | 15-22 (20-30) |
| Manifold & Tube Bolt | 14-18 (18-24) |
| Steering Column Support Nuts | 10-12 (14-16) |
| INCH Lbs. (N.m) |
| Accumulator-Drier Bracket Bolt | 80-100 (9-11) |
| Auxiliary A/C-Heater System |
| Assembly Bolts | 46-64 (5-7) |
| Outlet Line-To-Evap. Case | 71 (8) |
| Refrig. Line Peanut Fittings | 71 (8) |
| Climate Control Assembly Screws | 18-26 (2-3) |
| Condenser Bracket Bolt | 66-92 (8-10) |
| Condenser Line Nuts | 61-82 (7-9) |
| Front Fender Splash Shield Bolts | 91-123 (10-14) |
| Heater Core Bracket Screws | 13-22 (1.5-3) |
| Heater Core Outlet Bracket Screws | 13-22 (1.5-3) |
| Instrument Panel |
| Brace Bolts | 62 (7) |
| Finish Panel Bolts | 18-22 (2-3) |
| Reinforcement Bolts | 53-72 (6-8) |
| Retaining Bolts | 18-22 (2-3) |
| Panel-To-Cowl Nuts | 52-72 (6-8) |
| Passenger Side Air Bag Module Screws | 72-92 (8-10) |
| Rear Console Bolts | 92-122 (10-14) |
| Steering Column Cover Bolts | 18-22 (2-3) |
| Steering Column Cover Reinforcement Nuts | 92-122 (10-14) |
Automatic A/C-Heater System Vacuum Diagram (Navigator). Scheme 1
Scheme 1: Automatic A/C-Heater System Vacuum Diagram (Navigator)
Automatic A/C-Heater System Wiring Diagram (Expedition & Navigator - 1 Of 3). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (Expedition & Navigator - 1 Of 3)
Automatic A/C-Heater System Wiring Diagram (Expedition & Navigator - 2 Of 3). Scheme 3
Scheme 3: Automatic A/C-Heater System Wiring Diagram (Expedition & Navigator - 2 Of 3)
Automatic A/C-Heater System Wiring Diagram (Expedition & Navigator - 3 Of 3). Scheme 4
Scheme 4: Automatic A/C-Heater System Wiring Diagram (Expedition & Navigator - 3 Of 3)
