Engine Controls - Electronic Engine Controls: Other Ford Escape III

Camshaft Position (CMP) Sensor - 2.5L

MATERIAL SPECIFICATIONS

Scheme 38

1. NOTE: The O-ring seals are to be reused unless damaged. Visual check.

Scheme 39

1. Apply the specified lubricant to the specified component. Material: Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil. Tighten to 9 Nm (80 lb-in).

Crankshaft Position (CKP) Sensor - 1.6L GTDI

SPECIAL TOOLS Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 40

Scheme 41

Scheme 42

1. To install, tighten to 8 Nm (71 lb-in).

Crankshaft Position (CKP) Sensor - 2.0L GTDI

SPECIAL TOOLS Crank Sensor Alignment Tool 303-1521 Timing Peg, Crankshaft TDC 303-507 Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Crankshaft Position (CKP) Sensor - 2.5L

SPECIAL TOOLS Crank Sensor Alignment Tool 303-1521 Timing Peg, Crankshaft TDC 303-507 Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Powertrain Control Module (PCM)

SPECIAL TOOLS Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Heated Oxygen Sensor (HO2S) - 1.6L GTDI

SPECIAL TOOLS Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A)

MATERIAL SPECIFICATIONS

Scheme 43

Scheme 44

1. Remove the battery tray. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
2. Apply the specified chemical with a spray can. Penetrating and Lock Lubricant (US); Penetrating Fluid (Canada) XL-1 (US); CXC-51-A (Canada). Special Tool(s): Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A).

Scheme 45

1. Apply the specified lubricant to the specified component. High Temperature Nickel Anti-Seize Lubricant XL-2. Special Tool(s): Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A). Calculate the correct torque wrench setting for the following torque. Refer to the Torque Wrench Adapter Formulas illustration. Tighten to 48 Nm (35 lb-ft).
2. Install the battery tray. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .

Heated Oxygen Sensor (HO2S) - 2.0L GTDI

SPECIAL TOOLS Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A)

MATERIAL SPECIFICATIONS

Scheme 46

Scheme 47

Scheme 48

1. Remove the cowl panel. Refer to «FRONT END BODY PANELS»(ref-569581) .
2. Disconnect the Type I quick connect coupling. Refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-569597)
3. Disconnect the Type VI quick connect coupling. Refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-569597) .
4. Apply the specified chemical with a spray can. Penetrating and Lock Lubricant (US); Penetrating Fluid (Canada) XL-1 (US); CXC-51-A (Canada). Special Tool(s): Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A).

Scheme 49

1. Apply the specified lubricant to the specified component. High Temperature Nickel Anti-Seize Lubricant XL-2. Special Tool(s): Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A). Calculate the correct torque wrench setting for the following torque. Refer to the Torque Wrench Adapter Formulas illustration. Tighten to 48 Nm (35 lb-ft).
2. Connect the Type VI quick connect coupling. Refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-569597) .
3. Connect the Type I quick connect coupling. Refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-569597) Tighten to 5 Nm (44 lb-in). Tighten to 5 Nm (44 lb-in).

Heated Oxygen Sensor (HO2S) - 2.5L

SPECIAL TOOLS Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A)

MATERIAL SPECIFICATIONS

Scheme 50

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
2. Apply the specified chemical with a spray can. Penetrating and Lock Lubricant (US); Penetrating Fluid (Canada) XL-1 (US); CXC-51-A (Canada). Special Tool(s): Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A).

Catalyst Monitor Sensor - 1.6L GTDI

SPECIAL TOOLS Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A)

MATERIAL SPECIFICATIONS

Catalyst Monitor Sensor - 2.0L GTDI

SPECIAL TOOLS Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A)

MATERIAL SPECIFICATIONS

Catalyst Monitor Sensor - 2.5L

SPECIAL TOOLS Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A)

MATERIAL SPECIFICATIONS

Variable Camshaft Timing (VCT) Oil Control Solenoid - 1.6L GTDI

MATERIAL SPECIFICATIONS

Scheme 51

Scheme 52

Scheme 53

1. Position aside the air induction tube. Remove the stud/nut. Remove the nut.
2. NOTE: The O-ring seals are to be reused unless damaged. NOTE: Note the position of the components before removal. Visual check.
