PCM Location
| Item | Description | Comments |
|---|
| 1 | PCM | |
LH Engine Sensor Locations - 1.6L GTDI
| Item | Description | Comments |
|---|
| 1 | Intake camshaft VCT oil control solenoid | |
| 2 | MAP sensor | |
| 3 | Front KS | |
| 4 | Rear KS | |
| 5 | ECT sensor | |
| 6 | Intake camshaft CMP sensor | |
| 7 | IAT sensor | |
| 8 | MAPT sensor | |
RH Engine Sensor Locations - 1.6L GTDI
| Item | Description | Comments |
|---|
| 1 | Exhaust CMP sensor | |
| 2 | HO2S | |
| 3 | CMS | |
| 4 | Turbocharger bypass valve solenoid | |
| 5 | Electrically controlled turbocharger bypass valve | |
| 6 | CKP sensor | |
| 7 | Wastegate actuator | |
| 8 | Exhaust camshaft VCT oil control solenoid | |
LH Engine Sensor Locations - 2.0L GTDI
| Item | Description | Comments |
|---|
| 1 | Exhaust VCT oil control solenoid | |
| 2 | Intake VCT oil control solenoid | |
| 3 | FRP sensor | |
| 4 | Front KS | |
| 5 | MAP sensor | |
| 6 | MAPT sensor | |
| 7 | Rear KS | |
| 8 | IAT sensor | |
| 9 | Intake CMP sensor | |
| 10 | Exhaust CMP sensor | |
RH Engine Sensor Locations - 2.0L GTDI
| Item | Description | Comments |
|---|
| 1 | Turbocharger bypass valve solenoid | |
| 2 | ECT sensor | |
| 3 | HO2S | |
| 4 | CMS | |
| 5 | Turbocharger wastegate regulating valve solenoid | |
| 6 | CKP sensor | |
| 7 | Wastegate actuator | |
| 8 | CHT sensor | |
Scheme 36
Scheme 36: LH Engine Sensor Locations - 2.5L
| Item | Description | Comments |
|---|
| 1 | CHT sensor | |
| 2 | VCT oil control solenoid | |
| 3 | KS | |
| 4 | MAP sensor | |
| 5 | MAF sensor | |
| 6 | CMP sensor | |
Scheme 37
Scheme 37: RH Engine Sensor Locations - 2.5L
| Item | Description | Comments |
|---|
| 1 | CMS | |
| 2 | HO2S | |
| 3 | CKP sensor | |
