MATERIAL SPECIFICATIONS
GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Firing order | 1-3-4-2 |
| Spark plug | AYSF-32-YPC |
| Spark plug gap | 1.08-1.18 mm (0.042-0.046 in) |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Ignition coil bolts | 8 |
| Spark plugs | 12 |
TORQUE SPECIFICATIONS
The Electronic Ignition (El) system is a coil-on-plug ignition system. The coil-on-plug ignition system consists of the
- coil-on-plugs.
- spark plugs.
- Crankshaft Position (CKP) sensor.
- Camshaft Position (CMP) sensor.
The coil-on-plugs
- change low voltage signals from the PCM to high voltage pulses.
- supply the high voltage pulses to the spark plugs.
- are connected directly to each spark plug.
- have replaceable coil boots.
The spark plugs
- change high voltage pulses into a spark which ignites the fuel and air mixture.
The CKP sensor
- is a variable reluctance sensor.
- is triggered by a 36-minus-1 tooth trigger wheel mounted on the crankshaft.
- provides base timing and crankshaft speed (RPM) to the PCM.
The CMP sensor
- is a variable reluctance sensor.
- provides camshaft rotational location information to the PCM.
Refer to the INTRODUCTION - GASOLINE MODELS .
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | 14A464 | Ignition coil electrical connector (4 required) |
| 2 | W500215 | Ignition coil bolt (4 required) |
| 3 | 12A366 | Ignition coil (4 required) |
| 4 | 12A402 | Coil boot (4 required) |
| 5 | 12405 | Spark plug (4 required) |
ITEM DESCRIPTION
