Engine Ignition System - 2.5L: Other Ford Escape I facelift 2

Material

ITEM SPECIFICATION

Scheme 2

1. Disconnect the 4 ignition coil electrical connectors.
2. Remove the 4 bolts and the ignition coils. To install, tighten to 8 Nm (71 lb-in).
3. Inspect the coil seals for rips, nicks or tears. Remove and discard any damaged coil seals. To install, slide the new coil seal onto the coil until fully seated at the top of the coil.
4. To install, reverse the removal procedure. Apply a small amount of dielectric grease to the inside of the ignition coil boots before attaching to the spark plugs.

Scheme 3

1. Remove the ignition coils. For additional information, refer to «IGNITION COIL-ON-PLUG»(ref-344121-S15941854252009101600000) .
2. Remove the spark plugs. To install, tighten to 12 Nm (106 lb-in).
3. Inspect the spark plugs. For additional information, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(ref-344060) .
4. To install, reverse the removal procedure. Adjust the spark plug gap as necessary.
