Front Suspension System: Component Locations Ford Escape I рестайлинг

Special Tool(s)

SPECIAL TOOLS DESCRIPTION Tie Rod End Remover 211-105 (T85M-3395-A) Front Hub Remover 205-D070 (D93P-1175-B) or equivalent Front Hub Replacer 205-D069 (D93-1175A) or equivalent

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. Remove the brake disc. For additional information, refer to «FRONT DISC BRAKE»(ref-232199) .
2. Remove and discard the wheel hub nut.
3. Using the special tool, separate the outer CV joint spindle from the wheel hub.
4. Remove the cotter pin and the tie-rod end-to-knuckle nut.
5. Using the special tool, separate the tie-rod from the wheel knuckle.
6. Remove the lower ball joint pinch bolt nut and the pinch bolt.
7. Remove the anti-lock brake system (ABS) wheel speed sensor bolt and position the sensor aside.
8. Separate the lower ball joint from the wheel knuckle.
9. Remove the 2 strut-to-knuckle nuts, bolts and the wheel knuckle.

Scheme 13

1. Position the wheel knuckle and install the 2 strut-to-knuckle bolts and nuts. Tighten to 115 Nm (85 lb-ft).
2. Position and align the ball joint stud into the wheel knuckle.
3. Install the lower ball joint pinch bolt and nut. Tighten to 70 Nm (52 lb-ft).
4. Install the ABS wheel speed sensor and the bolt. Tighten to 9 Nm (80 lb-in).
5. Position the tie rod-end into the wheel knuckle and install the tie-rod end-to-knuckle nut and a new cotter pin. Tighten to 55 Nm (41 lb-ft).
6. Using the special tool, insert the half shaft into the wheel hub.
7. Install the wheel hub nut. Tighten to 290 Nm (214 lb-ft).
8. Install the brake disc. For additional information, refer to «FRONT DISC BRAKE»(ref-232199) .
9. Check and, if necessary, align the front end. For additional information, refer to «SUSPENSION SYSTEM-GENERAL INFORMATION»(ref-232234) .

SPECIAL TOOLS DESCRIPTION Tie Rod End Remover 211-105 (T85M-3395-A) Pinion Bearing Cone Remover 205-D002 (D79L-4621-A) or equivalent Pinion Bearing Cup Replacer 205-014 (T60K-4616-A) Handle 205-153 (T80T-4000W) Front Hub Remover 205-D070 (D93P-1175-B) or equivalent Step Plate 205-239 (T86P-1104-A3) or equivalent Step Plate 205-278 (T88T-1175-C) or equivalent Front Hub Replacer 205-D069 (D93-1175A) or equivalent Step Plate 205-D014 (D80L-630-3) or equivalent Wheel Bearing Adapter 205-D015 (D80L-630-4) or equivalent

Scheme 14

Scheme 15
