Sunroof: Removal & Installation Ford Escape I рестайлинг

Removal and Installation

1. Remove the headliner. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-232240) .
2. Remove the roof opening panel module pin-type retainer and the roof opening panel module. Disconnect the electrical connectors.
3. To install, reverse the removal procedure.

Scheme 5

1. Position the roof opening panel glass to the full OPEN position.
2. Release the 2 air deflector retaining tabs from the roof opening panel frame.
3. Pivot the air deflector and slide the air deflector from the locator to release the air deflector arms.
4. Remove the air deflector.
5. To install, reverse the removal procedure.

Scheme 6

Scheme 7

1. Remove the headliner. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-232240) .
2. Disconnect the roof opening panel front drain hose at the front body pillar.
3. Remove the roof opening panel front drain hose. Disconnect the hose from the roof opening panel frame. Remove the roof opening panel front drain hose.
4. To install, reverse the removal procedure.

Scheme 8

Scheme 9

1. Remove the headliner. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-232240) .
2. Disconnect the roof opening panel rear drain hose.
3. Remove the roof opening panel rear drain hose. Disconnect the roof opening panel rear drain hose from the roof opening panel frame. Remove the roof opening panel rear drain hose.
4. To install, reverse the removal procedure.

1. Remove the headliner. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-232240) .
2. Disconnect the 4 roof opening panel drain hoses.
3. Release the wire harness locators.
4. Remove the 8 roof opening panel frame bolts and remove the roof opening panel frame. To install tighten to 9 Nm (80 lb-in).
5. To install, reverse the removal procedure.
