Roof Opening Panel
The roof opening panel consists of the following
- Air deflector
- Roof opening panel glass
- Roof opening panel motor
- Roof opening panel module
- Roof opening panel shield
- Roof opening panel switch (part of the overhead console)
- Roof opening panel drain hoses
The roof opening panel is an electronically operated panel that can be opened or closed by pressing a switch located on the overhead console. It also has a one-touch open feature.
The one-touch open feature is controlled by the roof opening panel module. When the switch is pressed and held for one second, the roof opening panel glass will open to the COMFORT position (approximately 100 mm (4 in) from the full open position). Pressing the switch a second time opens the roof opening panel glass to the full OPEN position.
The roof opening panel can be moved to the full CLOSED position by pushing the switch forward and holding it until the roof opening panel glass is fully closed. When the roof opening panel glass reaches the full CLOSED position, power is removed from the motor, which provides the soft stop feature.
When the roof opening panel glass is in the full CLOSED position, the rear portion can be raised to the VENT position to provide ventilation by pushing the switch forward. The roof opening panel glass can be closed by pushing the switch rearward.
Refer to POWER TOP/SUNROOF for Escape or POWER TOP/SUNROOF for Mariner for schematic and connector information.
Actuating the roof opening panel switch in the forward or rearward direction supplies a ground signal to the roof opening panel module. The roof opening panel module then supplies power and ground to the roof opening panel motor. The vent and soft stop functions are controlled by the roof opening panel module and an internal roof opening panel position switch within the roof opening panel motor. These positions are obtained when an internal motor cam opens the roof opening panel position switch that removes ground to the roof opening panel module.
Possible Causes
- roof opening panel glass adjustment
- roof opening panel glass seals
- roof opening panel glass adjustment
- roof opening panel drain hoses
- roof opening panel glass seals
- roof opening panel glass adjustment
- roof opening panel lifter assemblies
- roof opening panel tracks
- roof opening panel drain channels and guides
- roof opening panel shield
- roof opening panel air deflector
- roof opening panel assembly
- roof opening panel glass adjustment
- roof opening panel tracks
- roof opening panel shield
- roof opening panel motor
- circuit 1173 (BN/OG) open
- circuit (DB) open
- circuit (BK) open
- circuit (WH) open
- circuit (VT) open
- circuit (OG) open or short to ground
- circuit (RD) open or short to ground
- roof opening panel switch
- roof opening panel motor
- roof opening panel module
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
- E1 CHECK CIRCUIT (DB) FOR POWER Key in OFF position. Disconnect: Roof Opening Panel Module Connector. Key in ON position. Measure the voltage between the roof opening panel module connector, pin 6, circuit (DB), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to E2. No : REPAIR the circuit. TEST the system for normal operation.
- E2 CHECK CIRCUIT (BK) FOR AN OPEN Key in OFF position. Measure the resistance between the roof opening panel module connector, pin 4, circuit (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to E3. No : REPAIR the circuit. TEST the system for normal operation.
- E3 CHECK POWER TO THE ROOF OPENING PANEL MOTOR CIRCUIT (OG) Connect: Roof Opening Panel Module Connector. Disconnect: Roof Opening Panel Motor Connector. Key in ON position. While pressing the roof opening panel switch to the OPEN position, measure the voltage between the roof opening panel motor connector, pin 3, circuit (OG), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to E6 . No : GO to E4.
- E4 CHECK CIRCUIT (OG) FOR AN OPEN Key in OFF position. Disconnect: Roof Opening Panel Module Connector. Measure the resistance between the roof opening panel motor connector, pin 3, circuit (OG), harness side and the roof opening panel module connector, pin 8, circuit (OG), harness side. Is the resistance less than 5 ohms? Yes : GO to E5. No : REPAIR the circuit. TEST the system for normal operation.
- E5 CHECK CIRCUIT (OG) FOR A SHORT TO GROUND Measure the resistance between the roof opening panel motor connector, pin 3, circuit (OG), harness side and ground. Is the resistance greater than 10,000 ohms? Yes : GO to E9 . No : REPAIR the circuit. TEST the system for normal operation.
- E6 CHECK VOLTAGE TO THE ROOF OPENING PANEL MOTOR CIRCUIT (RD) While pressing the roof opening panel switch to the CLOSE position, measure the voltage between the roof opening panel motor connector, pin 1, circuit (RD), harness side and ground. Is the voltage greater than 10 volts? Yes : INSTALL a new roof opening panel motor. REFER to «ROOF OPENING PANEL MOTOR»(ref-232187-S28894018862006051600000) . TEST the system for normal operation. No : GO to E7.
- E7 CHECK CIRCUIT (RD) FOR AN OPEN Key in OFF position. Disconnect: Roof Opening Panel Module Connector. Measure the resistance between the roof opening panel module connector, pin 7, circuit (RD), harness side and the roof opening panel motor connector, pin 1, circuit (RD), harness side. Is the resistance less than 5 ohms? Yes : GO to E8. No : REPAIR the circuit. TEST the system for normal operation.
- E8 CHECK CIRCUIT (RD) FOR A SHORT TO GROUND Measure the resistance between the roof opening panel motor connector, pin 1, circuit (RD), harness side and ground. Is the resistance greater than 10,000 ohms? Yes : GO to E9. No : REPAIR the circuit. TEST the system for normal operation.
- E9 CHECK THE ROOF OPENING PANEL SWITCH Disconnect: Roof Opening Panel Switch Connector. Measure the resistance between the roof opening panel switch pins 2 and 3, component side while pressing the roof opening panel switch to the CLOSE position; and between the roof opening panel switch pins 1 and 2, component side while pressing the roof opening panel switch to the OPEN position. Are the resistances less than 5 ohms? Yes : GO to E10. No : INSTALL a new roof opening panel switch. TEST the system for normal operation.
- E10 CHECK CIRCUIT (VT) FOR AN OPEN Disconnect: Roof Opening Panel Module Connector. Connect: Roof Opening Panel Switch Connector. Measure the resistance between the roof opening panel module connector, pin 3, circuit (VT), harness side and ground while pressing the roof opening panel switch to the CLOSE position. Is the resistance less than 5 ohms? Yes : GO to E11. No : REPAIR the circuit. TEST the system for normal operation
- E11 CHECK CIRCUIT (WH) FOR AN OPEN Measure the resistance between the roof opening panel module connector, pin 2, circuit (WH), harness side and ground while pressing the roof opening panel switch to the OPEN position. Is the resistance less than 5 ohms? Yes : INSTALL a new roof opening panel module. REFER to «ROOF OPENING PANEL MODULE»(ref-232187-S07090334892006051600000) . TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.
- circuit (OG/WH) open or short to ground
- circuit (BK) open
- roof opening panel motor
- roof opening panel module
Scheme 22
Scheme 23
Scheme 24
Scheme 25
- F1 CHECK THE ROOF OPENING PANEL POSITION SWITCH FOR A SHORT TO GROUND IN THE CLOSED POSITION Key in ON position. CLOSE the roof opening panel. Key in OFF position. Disconnect: Roof Opening Panel Module Connector. With the roof opening panel in the closed position, measure the resistance between the roof opening panel module connector, pin 1, circuit (OG/WH), harness side and ground. Is the resistance greater than 10,000 ohms? Yes : GO to F3 . No : GO to F2.
- F2 CHECK CIRCUIT (OG/WH) FOR A SHORT TO GROUND Disconnect: Roof Opening Panel Position Switch Connector. Measure the resistance between the roof opening panel module connector, pin 1, circuit (OG/WH), harness side and ground. Is the resistance greater than 10,000 ohms? Yes : INSTALL a new roof opening panel motor. REFER to «ROOF OPENING PANEL MOTOR»(ref-232187-S28894018862006051600000) . TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.
- F3 CHECK THE ROOF OPENING PANEL POSITION SWITCH FOR A SHORT TO GROUND IN THE COMFORT POSITION Key in OFF position. Connect: Roof Opening Panel Module Connector. Key in ON position. OPEN the roof opening panel to the comfort position. Key in OFF position. Disconnect: Roof Opening Panel Module Connector. With the roof opening panel in the comfort position, measure the resistance between the roof opening panel module connector, pin 1, circuit (OG/WH), harness side and ground. Is the resistance greater than 10,000 ohms? Yes : GO to F4. No : INSTALL a new roof opening panel motor. REFER to «ROOF OPENING PANEL MOTOR»(ref-232187-S28894018862006051600000) . TEST the system for normal operation.
- F4 CHECK THE ROOF OPENING PANEL POSITION SWITCH SIGNAL Disconnect: Roof Opening Panel Position Switch Connector. Measure the voltage between the roof opening panel position switch connector, pin 2, circuit (OG/WH), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to F6 . No : GO to F5.
- F5 CHECK CIRCUIT (OG/WH) FOR AN OPEN Measure the resistance between the roof opening panel module connector, pin 1, circuit (OG/WH), harness side and the roof opening panel position switch connector, pin 2, circuit (OG/WH), harness side. Is the resistance less than 5 ohms? Yes : INSTALL a new roof opening panel module. REFER to «ROOF OPENING PANEL MODULE»(ref-232187-S07090334892006051600000) . TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.
- F6 CHECK CIRCUIT (BK) FOR AN OPEN Measure the resistance between the roof opening panel position switch connector, pin 1, circuit (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : INSTALL a new roof opening panel motor. REFER to «ROOF OPENING PANEL MOTOR»(ref-232187-S28894018862006051600000) . TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.
Scheme 26
Scheme 27
- Open the roof opening panel to the VENT position.
- Loosen the 4 roof opening panel glass screws.
- Close the roof opening panel glass.
- Adjust the roof opening panel glass.
- Open the roof opening panel to the VENT position and tighten the 4 roof opening panel glass screws.
Scheme 28
- For additional information, refer to the individual procedures in this article.
Roof Opening Panel Glass
- Open the roof opening panel to the VENT position.
- Remove the 4 roof opening panel glass screws and the roof opening panel glass. To install tighten to 5 Nm (44 lb-in).
- To install, reverse the removal procedure. Verify that the roof opening panel is centered and aligned before tightening the bolts. For additional information, refer to «ROOF OPENING PANEL ALIGNMENT»(ref-232187-S39111506702006051600000) .
Scheme 29
- Remove the roof opening panel glass. For additional information, refer to «ROOF OPENING PANEL GLASS»(ref-232187-S20683830342006051600000) .
- Remove the 2 roof opening panel drain channel screws and the drain channel.
- Remove the roof opening panel shield. Disengage the 4 spring-loaded slide locks. Slide the panel up and forward.
- To install, reverse the removal procedure.
Scheme 30
Scheme 31
- Close the roof opening panel glass.
- Remove the headliner. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-232240) .
- Disconnect the electrical connectors.
- Remove the roof opening panel motor. Remove the 3 roof opening panel motor screws. Remove the roof opening panel motor. To install, tighten to 8 Nm (71 lb-in).
- To install, reverse the removal procedure.
