GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Generator, 2.3L | |
| Rating | 75/120 amp (max) @ 1,800 - 6,000 generator rpm, approximately 500 - 2,000 engine rpm |
| Generator pulley ratio | 2.40:1 |
| Voltage regulator type | Electronic internal with generator |
| Generator, 3.0L (Vehicles built to 7/2004) | |
| Rating | 75/120 amp (max) @ 1,800 - 6,000 generator rpm, approximately 500 - 2,000 engine rpm |
| Generator pulley ratio | 2.59:1 |
| Voltage regulator type | Electronic internal with generator |
| Generator, 3.0L (Vehicles built from 7/2004) | |
| Rating | 75/120 amp (max) @ 1,800 - 6,000 generator rpm, approximately 500 - 2,000 engine rpm |
| Generator pulley ratio | 2.70:1 |
| Voltage regulator type | Electronic internal with generator |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Generator B+ terminal nut | 8 |
| Generator bolts | 47 |
| Generator bracket bolts | 47 |
| Generator lower air duct bolt (2.3L) | 4 |
| Generator lower air duct nuts (3.0L) | 4 |
| Generator shield bolt (3.0L) | 4 |
| Generator shield nut (2.3L) | 20 |
| Generator stud (2.3L) | 24 |
| Generator stud (3.0L) | 7 |
| Generator stud nut | 47 |
| Generator upper air duct bolt (3.0L) | 4 |
| Generator upper air duct nuts (2.3L) | 4 |
| Lower splash shield bolts | 8 |
TORQUE SPECIFICATIONS
The charging system consists of the following components
- generator
- integral voltage regulator
The generator maximum output provides 120 amps.
Refer to CHARGING SYSTEM - GENERAL INFORMATION article .
Scheme 1
