Power Transfer Unit (Ptu): Other Ford Escape I рестайлинг 2

Transfer Case 6 illustrations ~482 words

Material

ItemSpecification
Motorcraft® SAE 75W-140 Synthetic Rear Axle Lubricant XY-75W140-QL (US); CXY-75W140-1L (Canada)WSL-M2C192-A and GL-5
Silicone Gasket and Sealant TA-30WSE-M4G323-A4

MATERIAL SPECIFICATIONS

Note. New Power Transfer Unit (PTU) lubricant must be added any time the PTU has been submerged in water.

Note. The Power Transfer Unit (PTU) is lubricated for life and is not to be checked unless a leak is suspected or a repair is necessary.

Scheme 22

Scheme 22
Scheme 22
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-344051) .
  2. Remove the drain plug and drain the fluid.
  3. Apply silicone sealant to the drain plug threads and install the drain plug. Tighten to 14 Nm (124 lb-in).
  4. Remove the fill plug and fill the PTU with specified lubricant.
  5. Apply silicone sealant to the fill plug and install the plug. Tighten to 34 Nm (25 lb-ft).

General Equipment

Slide hammer with a 3-jaw puller attachment

GENERAL EQUIPMENT

ItemSpecification
Silicone Gasket and Sealant TA-30WSE-M4G323-A4

MATERIAL SPECIFICATIONS

Scheme 23

Scheme 23
Scheme 23
ItemPart NumberDescription
17034Vent

PART NUMBER DESCRIPTION

ItemSpecification
Motorcraft® SAE 75W-140 Synthetic Rear Axle Lubricant XY-75W140-QL (US); CXY-75W140-1L (Canada)WSL-M2C192-A and GL-5

MATERIAL SPECIFICATIONS

Scheme 24

Scheme 24
Scheme 24
ItemPart NumberDescription
1W500210-SPower Transfer Unit (PTU) heat shield bolts (3 required)
27F496PTU heat shield
37251PTU
4W706822-SPTU-to-transaxle bolts (3 required)
5W500121-SPTU-to-transaxle bolt (M10)
67034Vent tube
7W710926PTU-to-engine bracket bolt (4-cylinder engines) (2 required)
8W500034PTU-to-engine bracket bolt (4-cylinder engines) (4 required)
9W707385PTU-to-engine bracket (4-cylinder engines)
10PTU-to-engine bracket bolts (6-cylinder engines) (6 required)
113K305PTU-to-engine bracket (6-cylinder engines)

PART NUMBER DESCRIPTION

All vehicles

  1. Position the Power Transfer Unit (PTU) to the transaxle.
  2. Install the 3 PTU-to-transaxle bolts. Tighten to 70 Nm (52 lb-ft).
  3. Install the PTU-to-transaxle bolt (M10). Tighten to 47 Nm (35 lb-ft).
  4. Connect the PTU vent tube.
  5. Install the PTU-to-engine bracket and the 6 bracket bolts. Tighten to 48 Nm (35 lb-ft). Hybrid vehicles
  6. Install the exhaust bracket and bolts. Tighten to 25 Nm (18 lb-ft). Vehicles equipped with 2.5L engines and Hybrid
  7. Install the exhaust bracket nuts. Tighten to 36 Nm (27 lb-ft). All vehicles
  8. Install the PTU heat shield and the 3 PTU heat shield bolts. Tighten to 11 Nm (97 lb-in). Vehicles equipped with 3.0L
  9. Install the catalytic converter - 3.0L RH manifold. For additional information, refer to «EXHAUST SYSTEM»(ref-344061) . All vehicles
  10. Install the crossmember brace and the 4 bolts. Tighten to 40 Nm (30 lb-ft).
  11. Install the driveshaft. For additional information, refer to «DRIVESHAFT»(ref-344083) .
  12. Install the front RH intermediate shaft. For additional information, refer to «FRONT DRIVE HALFSHAFTS»(ref-344085) .
  13. Install the exhaust as required. For additional information, refer to «EXHAUST SYSTEM»(ref-344061) .
  14. Fill the PTU. For additional information, refer to «POWER TRANSFER UNIT (PTU) DRAINING AND FILLING»(ref-344082-S01155393472009101600000) .
  15. Check the transaxle fluid level. For additional information, refer to «AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35»(ref-344057) or «AUTOMATIC TRANSAXLE/TRANSMISSION - ELECTRONICALLY CONTROLLED CONTINUOUSLY VARIABLE TRANSMISSION (ECVT)»(ref-344058) .
ItemSpecification
Silicone Gasket and Sealant TA-30WSE-M4G323-A4

MATERIAL SPECIFICATIONS

Scheme 25

Scheme 25
Scheme 25
ItemPart NumberDescription
17H469Input shaft seal
2Helical drive gear (part of 7251)
3Helical idler gear (part of 7251)
4Helical driven gear (part of 7251)
5Power Transfer Unit (PTU) cover (part of 7251)
67251PTU
7W500425PTU cover bolt (12 required)
87034Vent tube
9W707702Vent tube bolt
107H429Intermediate shaft seal

PART NUMBER DESCRIPTION

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27
  1. Using the Driven Gear Oil Seal Installer, install the input shaft seal.
  2. Install the helical gears. Install the drive gear. Use a slight rotation to prevent damaging the inner input seal. Install the idler gear. Install the driven gear.
  3. Apply a 3 mm (0.11 in) bead of silicone sealant to the sealing surface of the PTU cover. Install the PTU cover and tighten the 12 PTU cover bolts in a star pattern. Tighten to 32 Nm (24 lb-ft).
  4. Install the vent tube and the bolt. Tighten to 14 Nm (124 lb-in).
  5. Install the PTU. For additional information, refer to «POWER TRANSFER UNIT (PTU)»(ref-344082-S31668101802009101600000) .
