TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Lower arm forward bolt | 115 |
| Lower arm rearward bolt | 150 |
| Lower ball joint nut | 63 |
| Stabilizer bar bushing bracket bolts | 70 |
| Stabilizer bar link nuts | 63 |
| Strut rod nut | 103 |
| Strut-to-knuckle nuts and bolts | 115 |
| Strut upper bushing nuts | 47 |
| Tie-rod end nut | 80 |
| Wheel hub nut | 300 |
| Wheel speed sensor bolt | 9 |
| Wheel speed sensor harness bolt | 15 |
TORQUE SPECIFICATIONS
The front suspension consists of the following components
- Wheel bearings
- Wheel hubs
- Wheel studs
- Lower arms
- Springs
- Stabilizer bar
- Stabilizer bar bushings
- Stabilizer bar links
- Struts
- Wheel knuckles
The front suspension utilizes a MacPherson strut system.
This suspension system incorporates a strut assembly that takes the place of the upper arm and ball joint. The strut carries out the function of a shock absorber and is encompassed by a coil spring. The strut and spring assembly supports the weight of the vehicle and is also the pivot point for the steering knuckle. This system uses a lower control arm and ball joint for the lower (unloaded) pivot point of the steering knuckle.
Refer to SUSPENSION SYSTEM-GENERAL INFORMATION .
Scheme 17
| Item | Part Number | Description |
|---|---|---|
| 1 | W705967 | Wheel hub nut |
| 2 | W705833 | Tie-rod end nut |
| 3 | W520213 | Lower ball joint nut |
| 4 | W709618 | Lower ball joint pinch bolt |
| 5 | W711999 | Strut-to-knuckle nuts (2 required) |
| 6 | W711998 | Strut-to-knuckle bolts (2 required) |
| 7 | 3K171 LH/3K170 RH | Wheel knuckle |
| 8 | W500749 | Lower arm forward bolt |
| 9 | W714402 | Lower arm rearward bolt |
| 10 | 3A424 LH/3A423 RH | Lower arm |
| 11 | 3C293 | Wheel speed sensor bolt |
ITEM DESCRIPTION CHART
Scheme 18
| Item | Part Number | Description |
|---|---|---|
| 1 | W714268 | Lower stabilizer bar link nut |
| 2 | 5K483 | Stabilizer bar link |
| 3 | W506441 | Stabilizer bar bushing bracket bolts (2 required) |
| 4 | 5486 | Stabilizer bar bushing bracket |
| 5 | 5493A | Stabilizer bar bushing |
| 6 | 5482 | Stabilizer bar |
| 7 | W714268 | Upper stabilizer bar link nut |
ITEM DESCRIPTION CHART
