MATERIAL SPECIFICATIONS
| Item | Specification | Fill Capacity |
|---|---|---|
| High Performance DOT 3 Motor Vehicle Brake Fluid PM-1-C (US); CPM-1-C (Canada) | WSS-M6C62-A or WSS-M6C65-A1 | 960 ml (2 pt) |
| Metal Brake Parts Cleaner PM-4-A or PM-4-B (US); CPM-4 (Canada) | ||
| Silicone Brake Caliper Grease and Dielectric Compound XG-3-A | ESE-M1C171-A |
MATERIAL SPECIFICATIONS
GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Brake disc minimum thickness | 24 mm (0.944 in) |
| Brake pad maximum taper wear (in any direction) | 3.0 mm (0.118 in) |
| Brake pad minimum thickness | 3.0 mm (0.118 in) |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Brake caliper anchor plate bolts | 175 |
| Brake caliper bleeder screw | 16 |
| Brake caliper guide pin bolts | 50 |
| Brake flexible hose fitting (at caliper) | 20 |
| Brake tube fitting nut | 18 |
TORQUE SPECIFICATIONS
The front brake disc system consists of the following components
- Brake pads
- Brake caliper anchor plate
- Brake caliper
- Brake disc
- Brake disc shield
- Brake flexible hose
When mechanical force is applied by the driver to the brake pedal, the force is converted into hydraulic pressure by the master cylinder. The hydraulic force is directed to the disc brake calipers and transferred to the brake pads. The brake pads are then forced against the brake friction surfaces by the brake caliper pistons. The friction of the brake pads on the brake disc causes the slowing of wheel rotation and the vehicle.
Refer to BRAKE SYSTEM-GENERAL INFORMATION .
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | 2068 | Brake pad anti-rattle spring |
| 2 | Brake caliper dust boot caps (part of kit 2L527) | |
| 3 | Brake caliper guide pin bolts (part of kit 2L527) | |
| 4 | 2B121 LH/2B120 RH | Brake caliper |
| 5 | 2001 | Brake pad kit |
| 6 | Brake caliper dust boots (part of kit 2L527) | |
| 7 | W708519 | Brake caliper anchor plate bolts |
| 8 | 2B540 | Brake caliper anchor plate |
| 9 | 1125 | Brake disc |
| 10 | Brake tube fitting (part of 2263 RH/2264 LH) | |
| 11 | 2B223 | Brake flexible hose retaining clip |
| 12 | 2078 | Brake flexible hose |
| 13 | Bleeder screw cap (part of kit 2208) | |
| 14 | Bleeder screw (part of kit 2208) |
ITEM DESCRIPTION
