TIGHTENING TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Inner tie-rod end | 90 |
| Outer tie-rod end nut | 80 |
| Tie-rod end jam nut | 40 |
TIGHTENING TORQUE SPECIFICATIONS
The steering linkage consists of the following components
- Inner tie-rod end
- Steering gear
- Outer tie-rod end
- Steering gear boot
- Front wheel knuckle
The inner and outer tie rods connect the steering gear to the front wheel knuckles. The tie rods are lubricated for life and do not contain grease fittings. The steering linkage is adjustable at the 2 tie-rod ends.
Refer to STEERING SYSTEM .
Scheme 12
| Item | Part Number | Description |
|---|---|---|
| 1 | 3289 | Outer tie-rod end |
| 2 | W712338 | Outer tie-rod nut |
| 3 | W700318 | Tie-rod end jam nut |
| 4 | 3280 | Inner tie-rod end |
| 5 | 3332A | Steering gear boot kit |
| 6 | Steering gear boot clamp, outer (part of 3332A) | |
| 7 | Steering gear boot clamp, inner (part of 3332A) | |
| 8 | 3A500 | Steering gear |
PART DESCRIPTION CHART
