Fuel System - General Information: Component Locations Ford Escape I рестайлинг 2

Fuel System 7 illustrations ~360 words

Special Tool(s)

SPECIAL TOOL REFERENCE Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 5

Scheme 5: Special Tool(s)

SPECIAL TOOL REFERENCE Fuel Pressure Test Kit 310-D009 (D95L-7211A) or equivalent

Scheme 6

Scheme 6: Special Tool(s)
WARNINGDo not smoke, carry lighted tobacco or have an open flame of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGDo not carry personal electronic devices such as cell phones, pagers or audio equipment of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGBefore working on or disconnecting any of the fuel tubes or fuel system components, relieve the fuel system pressure to prevent accidental spraying of fuel. Fuel in the fuel system remains under high pressure, even when the engine is not running. Failure to follow this instruction may result in serious personal injury.
WARNINGAlways disconnect the battery ground cable at the battery when working on an evaporative emission (EVAP) system or fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGWhen handling fuel, always observe fuel handling precautions and be prepared in the event of fuel spillage. Spilled fuel may be ignited by hot vehicle components or other ignition sources. Failure to follow these instructions may result in serious personal injury.

Note. Early build 3.0L engines are equipped with a Schrader valve on the fuel rail. Late build 3.0L engines do not have a Schrader valve.

All vehicles

Pinpoint Test A

A2 Vehicles with 2.5L engine
  1. Vehicles with 2.5L engine
A4 Vehicles with early build 3.0L engine
  1. Vehicles with early build 3.0L engine
A6 Vehicles with late build 3.0L engine
  1. Vehicles with late build 3.0L engine
A8 All vehicles
  1. All vehicles

SPECIAL TOOL REFERENCE Fuel Storage Tanker 164-R3202 or equivalent Wrench, Fuel Tank Sender Unit 310-123

Scheme 7

Scheme 7: Special Tool(s)

Scheme 8

Scheme 8
WARNINGDo not smoke, carry lighted tobacco or have an open flame of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGDo not carry personal electronic devices such as cell phones, pagers or audio equipment of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGWhen handling fuel, always observe fuel handling precautions and be prepared in the event of fuel spillage. Spilled fuel may be ignited by hot vehicle components or other ignition sources. Failure to follow these instructions may result in serious personal injury.
WARNINGAlways disconnect the battery ground cable at the battery when working on an evaporative emission (EVAP) system or fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGBefore working on or disconnecting any of the fuel tubes or fuel system components, relieve the fuel system pressure to prevent accidental spraying of fuel. Fuel in the fuel system remains under high pressure, even when the engine is not running. Failure to follow this instruction may result in serious personal injury.

Scheme 9

Scheme 9

Scheme 10

Scheme 10
  1. Release the fuel system pressure. For additional information, refer to «FUEL SYSTEM PRESSURE RELEASE»(ref-344122-S00319914282009101600000) .
  2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-344091) .
  3. Remove the Fuel Pump (FP) module access cover.
  4. Disconnect the FP module electrical connector.
  5. Disconnect the fuel tube-to-FP module quick connect coupling. For additional information, refer to «QUICK CONNECT COUPLING»(ref-344122-S20213855772009101600000) .
  6. Disconnect the fuel tank filler pipe recirculation tube-to-FP module quick connect coupling. For additional information, refer to «QUICK CONNECT COUPLING»(ref-344122-S20213855772009101600000) .
  7. Connect the Fuel Storage Tanker to the fuel tank filler pipe recirculation tube port on the FP module and remove approximately one-fourth of the fuel (from a completely full tank), lowering the fuel level below the FP module mounting flange.
  8. Install the Fuel Tank Sender Unit Wrench and remove the FP module lock ring.
  9. Position the FP module aside, insert the tube from the Fuel Storage Tanker into the FP module aperture and remove as much fuel as possible from the fuel tank.

SPECIAL TOOL REFERENCE Disconnecting Tool, Spring Lock Coupling 310-S039 (T90T-9550-A) or equivalent

Scheme 11

Scheme 11: Special Tool(s)
