Engine Cooling System - (Except Hybrid): Other Ford Escape I рестайлинг 2

Cooling System (Mechanical) 10 illustrations ~408 words

2.5L

Note. Black arrows indicate hot, white arrows indicate cold.

Scheme 15

Scheme 15: 2.5L
Scheme 15: 2.5L
ItemPart NumberDescription
18A080Degas bottle
28C633Degas bottle-to-radiator hose
38W005Degas bottle overflow hose
48501Coolant pump
56010Engine block
68575Thermostat housing
78B273Lower radiator hose
88005Radiator
98B274Upper radiator hose
108A582Coolant bypass hose
119D475EGR valve assembly
128K556Coolant adapter assembly
1318K580Heater outlet hose
1418K579Heater inlet hose
1518A458Heater assembly
166049Cylinder head
176051Head gasket
188C362Bleed valve

ITEM DESCRIPTION

3.0L

Note. Black arrows indicate hot, white arrows indicate cold.

Scheme 16

Scheme 16: 3.0L
Scheme 16: 3.0L
ItemPart NumberDescription
18A080Degas bottle
28C633Degas bottle-to-radiator hose
38W005Radiator overflow hose
46010Engine block
588585Coolant pump housing
68B274Upper radiator hose
78005Radiator
88B273Lower radiator hose
96050Cylinder head
106083Head gasket
118A544Thermostat housing
129N271Coolant inlet pipe
138A505Coolant inlet tube
1418K579Heater inlet hose
1518K580Heater outlet hose
1618458Heater assembly

ITEM DESCRIPTION

Material

ItemSpecification
Motorcraft® Premium Gold Engine Coolant with Bittering Agent (bittered in US only) VC-7-B (US); CVC-7-A (Canada); or equivalent (yellow color)WSS-M97B51-A1

MATERIAL SPECIFICATIONS

Thermostat

A new thermostat should be installed only after the following tests and checks have been carried out

  1. Pinpoint Test A, B or C
  2. Thermostat Visual Inspection
ItemSpecification
Motorcraft® Premium Gold Engine Coolant with Bittering Agent (bittered in US only) VC-7-B (US); CVC-7-A (Canada); or equivalent (yellow color)WSS-M97B51-A1

ITEM SPECIFICATIONS

ItemSpecification
Premium Cooling System Flush VC-1ESR-M14P7-A

ITEM SPECIFICATIONS

WARNINGAlways allow the engine to cool before opening the cooling system. Do not unscrew the coolant pressure relief cap when the engine is operating or the cooling system is hot. The cooling system is under pressure; steam and hot liquid can come out forcefully when the cap is loosened slightly. Failure to follow these instructions may result in serious personal injury.

Note. To remove rust, sludge and other foreign material from the cooling system, use cooling system flush that is safe for use with aluminum radiators. For additional information, refer to SPECIFICATIONS . This cleaning restores cooling system efficiency and helps prevent overheating. A pulsating or reversed direction of flushing water will loosen sediment more quickly than a steady flow in the normal coolant flow direction. In severe cases where cleaning solvents will not clean the cooling system efficiently, it will be necessary to use the pressure flushing method using cooling system flusher. Dispose of old coolant and flushing water contaminated with antifreeze and cleaning chemicals in accordance with local, state or federal laws.

  1. Add Premium Cooling System Flush to the cooling system and follow the directions on the package.
  2. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-344113-S11679489632009101600000) .
  3. Remove the radiator. For additional information, refer to «RADIATOR - 2.5L»(ref-344113-S03174507612009101600000) or «RADIATOR - 3.0L (4V)»(ref-344113-S04039187802009101600000) .
  4. Backflush the radiator with the radiator in an upside-down position with a high-pressure hose in the lower hose location.
  5. Remove the thermostat. For additional information, refer to «THERMOSTAT HOUSING - 2.5L»(ref-344113-S33327052982009101600000) or «THERMOSTAT - 3.0L (4V)»(ref-344113-S22710032342009101600000) .
  6. Backflush the engine. Position the high-pressure water hose into the engine through the engine return and backflush the engine.
  7. Install the thermostat. For additional information, refer to «THERMOSTAT HOUSING - 2.5L»(ref-344113-S33327052982009101600000) or «THERMOSTAT - 3.0L (4V)»(ref-344113-S22710032342009101600000) .
  8. Install the radiator. For additional information, refer to «RADIATOR - 2.5L»(ref-344113-S03174507612009101600000) or «RADIATOR - 3.0L (4V)»(ref-344113-S04039187802009101600000) .
  9. Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-344113-S11679489632009101600000) .

Block Heater

2.5L

Scheme 17

Scheme 17: Block Heater
Scheme 17: Block Heater
ItemPart NumberDescription
114A199Block heater electrical connector
26A051Block heater

ITEM DESCRIPTION

3.0L

Scheme 18

Scheme 18
Scheme 18
ItemPart NumberDescription
114A199Block heater electrical connector
26A051Block heater

ITEM DESCRIPTION

Thermostat Housing - 2.5L

Note. The thermostat and thermostat housing are serviced as an assembly.

Scheme 19

Scheme 19: Thermostat Housing - 2.5L
Scheme 19: Thermostat Housing - 2.5L
ItemPart NumberDescription
1W527362Heater hose clamp
218C553Heater hose
3W527372Radiator hose clamp
48B273Radiator hose
5W500015Thermostat housing bolt (3 required)
68575Thermostat housing
78K530Gasket

ITEM DESCRIPTION

ItemSpecification
Motorcraft® Premium Gold Engine Coolant with Bittering Agent (bittered in US only) VC-7-B (US); CVC-7-A (Canada); or equivalent (yellow color)WSS-M97B51-A1

ITEM SPECIFICATION

Scheme 20

Scheme 20
Scheme 20
ItemPart NumberDescription
1W527375Lower radiator hose clamp
28B273Lower radiator hose
3W500015Thermostat housing cover bolts (2 required)
48K528Thermostat housing cover
5N806807O-ring seal
68575Thermostat

ITEM DESCRIPTION

ItemSpecification
Motorcraft® Premium Gold Engine Coolant with Bittering Agent (bittered in US only) VC-7-B (US); CVC-7-A (Canada); or equivalent (yellow color)WSS-M97B51-A1

ITEM SPECIFICATIONS

Scheme 21

Scheme 21
Scheme 21
ItemPart NumberDescription
1W500221Coolant pump pulley bolt (3 required)
28509Coolant pump pulley
3W500015Coolant pump bolt (3 required)
48501Coolant pump
58507Coolant pump O-ring seal

ITEM DESCRIPTION

Coolant Pump Housing - 3.0L (4V)

Coolant Hoses

Scheme 22

Scheme 22: Coolant Pump Housing - 3.0L (4V)
Scheme 22: Coolant Pump Housing - 3.0L (4V)
ItemPart NumberDescription
1W532958Heater hose clamp
218K580Heater outlet hose
3W532958Heater hose clamp
418K579Heater inlet hose
5W525871Lower radiator hose clamp
68B273Lower radiator hose
7W525872Upper radiator hose clamp
88B274Upper radiator hose

ITEM DESCRIPTION

Coolant Pump Housing

Scheme 23

Scheme 23
Scheme 23
ItemPart NumberDescription
1W705764Coolant pump housing nut (2 required)
2W707643Coolant pump housing bolt
3W713511Coolant pump housing stud (2 required)
48C387Gasket
58565O-ring seal
6W503281Coolant pump housing bolt (2 required)
78B858Coolant pump housing
8W503281Coolant inlet pipe housing bolt (2 required)
98255O-ring seal

ITEM DESCRIPTION

ItemSpecification
Motorcraft® Premium Gold Engine Coolant with Bittering Agent (bittered in US only) VC-7-B (US); CVC-7-A (Canada); or equivalent (yellow color)WSS-M97B51-A1

ITEM SPECIFICATIONS

Scheme 24

Scheme 24
Scheme 24
ItemPart NumberDescription
1W503281Coolant inlet pipe bolts
28594Coolant inlet pipe
38255O-ring seal
4W527485Coolant inlet pipe clamp (2 required)
58B573Coolant inlet pipe hose

ITEM DESCRIPTION
