Removal and Installation
- Remove the lower instrument panel center finish panel. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-344092) .
- Press the retaining tabs and remove the parking aid switch.
- To install, reverse the removal procedure.
Scheme 20
| Item | Part Number | Description |
|---|---|---|
| 1 | Electrical connectors (part of 14405) | |
| 2 | Parking Aid Module (PAM) screws (2 required) | |
| 3 | 15T850 | PAM |
| 4 | 15A866 | Parking aid speaker |
PART NUMBER DESCRIPTION CHART
- Upload the PAM configuration information to the scan tool. For additional information, refer to Programmable Module Installation (PMI) in «MODULE CONFIGURATION»(ref-344078) .
- Remove the RH rear quarter trim panel.
- If replacing the parking aid speaker only, proceed as follows: Disconnect the electrical connector. Disengage the clips. Remove the parking aid speaker.
- If replacing the PAM, proceed as follows: Disconnect the electrical connector. Remove the 2 screws. Remove the PAM.
- To install, reverse the removal procedure. Download the configuration information to the PAM. For additional information, refer to PMI in «MODULE CONFIGURATION»(ref-344078) .
Scheme 21
| Item | Part Number | Description |
|---|---|---|
| 1 | Electrical connectors (part of 15K868) | |
| 2 | 131302 | Parking aid sensors |
PART NUMBER DESCRIPTION CHART
- With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-344051) .
- Remove the rear bumper cover. For additional information, refer to «BUMPERS»(ref-344129) .
- Press the retaining tabs and remove the parking aid sensor(s). Disconnect the electrical connectors.
- To install, reverse the removal procedure.
