Transmission Fluid Level Check

To check the transmission fluid level, refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .

High Transmission Fluid Level

A transmission fluid level that is too high may cause the transmission fluid to become aerated due to the churning action of the rotating internal parts. This will cause erratic control pressure, foaming, loss of transmission fluid from the vent tube and possible transaxle malfunction and/or damage.

Low Transmission Fluid Level

A low transmission fluid level could result in poor transaxle engagement, slipping, malfunction and/or damage. This could also indicate a leak in one of the transaxle seals or gaskets.

Transmission Fluid Condition Check

1. Check the transmission fluid level. For additional information, refer to «AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35»(ref-494559) .
2. Place a drop of transmission fluid on a facial tissue and examine the stain.
3. If evidence of solid material is found, the transmission fluid pan should be removed for further inspection.
4. If transmission fluid contamination or transaxle failure is confirmed by the sediment in the bottom of the transmission fluid pan, repair the transaxle and clean the transmission fluid cooler tubes and the transmission fluid cooler.
5. If the transaxle is to be overhauled or if installing a new transaxle, the transmission fluid cooler must be backflushed. Refer to «AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35»(ref-494559) .

Transmission Fluid Cooler

MATERIAL SPECIFICATIONS

Scheme 53

Scheme 54

Scheme 55

1. Disconnect the front transmission fluid cooler tube assembly and the front transmission fluid cooler inlet tube from the transmission fluid cooler.
2. Remove the transmission fluid screw and the transmission fluid cooler. To install, tighten to 6 Nm (53 lb-in).

Transmission Fluid Cooler - Warmer

MATERIAL SPECIFICATIONS

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-494560) .
2. Drain the engine cooling system. For additional information, refer to «ENGINE COOLING»(ref-494611) .
3. Remove the air cleaner. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-494599) .
4. Remove the air cleaner outlet pipe. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-494599) .
5. Remove the battery tray. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-494597) .
6. Disconnect the TCM electrical connector.
7. Disconnect the 3 battery cable pin-type retainers from the TCM bracket.
8. Remove the TCM bracket nut, TCM and bracket.
9. Remove and discard the rear transmission fluid cooler tube assembly bolt.
10. Disconnect the rear transmission fluid cooler tube assembly from the cooler bypass valve.
11. Inspect the cooler bypass valve to be sure that the transmission fluid cooler tube seals and backing rings were removed with the transmission fluid cooler tubes and are not stuck in the thermal cooler bypass valve. If the transmission fluid cooler tube seals or backing rings are stuck in the cooler bypass valve, remove the seals and backing rings.
12. Remove the rear transmission fluid cooler outlet and inlet tube bolts and disconnect the rear transmission fluid cooler outlet and inlet tubes from the transmission fluid cooler - warmer.
13. Inspect the transaxle case to be sure that the rear transmission fluid cooler outlet and inlet tube seals and backing rings were removed with the rear transmission fluid cooler outlet and inlet tubes and are not stuck in the transaxle case. If the transmission fluid cooler tube seals or backing rings are stuck in the transaxle case, remove the seals and backing rings.
14. Disconnect the 2 coolant hoses from the transmission fluid cooler - warmer.
15. Remove the 2 transmission fluid cooler - warmer bolts and the transmission fluid cooler - warmer.

Scheme 66

Scheme 67

Scheme 68

Scheme 69

1. Install the transmission fluid cooler - warmer and the 2 transmission fluid cooler - warmer bolts. Tighten to 30 Nm (22 lb-ft).
2. Connect the 2 coolant hoses to the transmission fluid cooler - warmer.
3. Inspect the rear transmission fluid cooler tube backing rings and seals for damage and install new backing rings or seals if necessary. Lubricate the transmission fluid cooler tube seals with clean transmission fluid and install the backing rings and seals on the rear transmission fluid cooler tube. Seal Backing ring
4. Connect the rear transmission fluid cooler outlet and inlet tubes to the transmission fluid cooler - warmer and the 2 rear transmission fluid cooler outlet and inlet tube bolts. Tighten to 11 Nm (97 lb-in).
5. Inspect the rear transmission fluid cooler tube assembly backing rings and seals for damage and install new backing rings or seals if necessary. Lubricate the transmission fluid cooler tube assembly seals with clean transmission fluid and install the backing rings and seals on the rear transmission fluid cooler tube assembly. Seal Backing ring
6. Connect the rear transmission fluid cooler tube assembly to the cooler bypass valve.
7. Install a new rear transmission fluid cooler tube assembly bolt. Tighten to 25 Nm (18 lb-ft).
8. Install the TCM, bracket and TCM bracket nut. Tighten to 9 Nm (80 lb-in).
9. Connect the 3 battery cable pin-type retainers to the TCM bracket.
10. Connect the TCM electrical connector.
11. Install the battery tray. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-494597) .
12. Install the air cleaner outlet pipe. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-494599) .
13. Install the air cleaner. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-494599) .
14. Fill and bleed the cooling system. For additional information, refer to «ENGINE COOLING»(ref-494611) .
15. Fill the transmission with fluid and verify correct operation. For additional information, refer to «AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35»(ref-494559) .

Transmission Fluid Cooler Tubes

SPECIAL TOOLS DESCRIPTION CHART Disconnect Tool, Transmission Cooler Line 307-569

Scheme 70

MATERIAL SPECIFICATIONS

Scheme 71
