Removal and Installation
| WARNING | When carrying out maintenance on the starting system, be aware heavy gauge leads are connected to the battery. Make sure protective caps are in place when maintenance is complete. |
Scheme 31
Scheme 32
Scheme 33
Scheme 34
- With the vehicle in NEUTRAL position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-231335) .
- Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-231356) .
- Remove the retaining nut and position the cable bracket aside.
- Remove the starter solenoid protective cap.
- Disconnect the starter motor electrical connections.
- Remove the bolts and the starter.
- To install, reverse the removal procedure. Install the starter bolts finger tight. Tighten the upper bolt. Tighten the lower bolts.
