Fuel Charging System & Fuel Control System - 5.4l (2v) -- E-Series Ford Econoline E250

SPECIFICATIONS

MATERIAL SPECIFICATIONS

TORQUE SPECIFICATIONS

Sequential Multi-Port Fuel Injection (SFI)

The fuel charging and controls system consists of the following

1. Fuel injectors
2. Fuel rail and fuel pressure relief valve
3. Throttle Body (TB)
4. TB spacer

The fuel charging and controls system is

1. a Sequential Multi-Port Fuel Injection (SFI) system.
2. Pulse Width Modulated (PWM)
3. Mass Air Flow (MAF) controlled.

Fuel is metered into each intake port in a sequential firing order. Fuel injectors pulse to follow engine firing order, in accordance with engine demand, on a tuned intake manifold.

The basic fuel requirement of the engine is determined from the data supplied to the PCM by the MAF sensor, which measures the amount of air being drawn into the engine.

The various sensors detect any changes in the operating conditions and send signals to the PCM. This permits the PCM to control the opening duration (pulse width) of the fuel injectors and maintain optimum exhaust emission control and engine performance for all operating conditions.

Fuel Injectors

The 8 fuel injectors

1. are electronically operated by the PCM.
2. atomize the fuel as the fuel is delivered.
3. each have an internal solenoid that opens a needle valve, which injects fuel into the intake port in the cylinder head.
4. are deposit resistant.

For removal and installation, refer to FUEL RAIL AND FUEL INJECTOR - EXPLODED VIEW and FUEL RAIL .

Fuel Pressure Relief Valve

The fuel pressure relief valve is located on the fuel rail and is used to relieve fuel pressure from the fuel system and for diagnostic testing.

Fuel Pump (FP) Control Module

The Fuel Pump (FP) control module

1. receives signals from the PCM.
2. controls the duty cycle of the FP.

Fuel Rail

Note. The fuel injectors and the fuel rail must be handled with extreme care to prevent damage to sealing areas and sensitive fuel-metering orifices.

The fuel rail

1. receives fuel from the fuel supply tube.
2. delivers fuel to the fuel injectors.

For removal and installation, refer to FUEL RAIL AND FUEL INJECTOR - EXPLODED VIEW and FUEL RAIL .

Throttle Body (TB)

The TB

1. controls air supply to the intake manifold by electronically positioning the throttle plate.
2. is not adjustable.

Refer to THROTTLE BODY .

Throttle Body (TB) Spacer

The TB spacer

1. increase intake manifold plenum volume.
2. are designed to enhance low to mid-range power and torque while improving throttle response and fuel economy.

Refer to THROTTLE BODY - SPACER .

Fuel Charging and Controls

Refer to the INTRODUCTION - GASOLINE MODELS .

Scheme 9

Removal

1. Remove the Air Cleaner (ACL) assembly and ACL outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/econoline-e250/2012-2013/remont/removal-installation/#intake-air-distribution-system-intake-air-filtering-system) .
2. Disconnect the Electronic Throttle Control (ETC) electrical connector.
3. Disconnect the Throttle Position (TP) sensor electrical connector.
4. Remove the 4 bolts and the Throttle Body (TB). Discard the TB gasket.

Installation

1. Install a new TB gasket, position the TB and tighten the 4 bolts in 2 stages. Stage 1: Tighten to 9 Nm (80 lb-in). Stage 2: Tighten an additional 90 degrees.
2. Connect the TP sensor electrical connector. Push back the red clip.
3. Connect the ETC electrical connector. Push back the red clip.
4. Install the ACL assembly and ACL outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/econoline-e250/2012-2013/remont/removal-installation/#intake-air-distribution-system-intake-air-filtering-system) .

Scheme 10

1. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/econoline-e250/2012-2013/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
2. If a new Throttle Body (TB) spacer is being installed, remove the TB. For additional information, refer to «THROTTLE BODY»(/ford/econoline-e250/2012-2013/remont/fuel-system/#fuel-charging-system-fuel-control-system-54l-2v-e-series) .
3. If necessary, remove the Air Cleaner (ACL) assembly and ACL outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/econoline-e250/2012-2013/remont/removal-installation/#intake-air-distribution-system-intake-air-filtering-system) .
4. If necessary, disconnect the Electronic Throttle Control (ETC) electrical connector and wiring harness retainer.
5. If necessary, disconnect the Throttle Position (TP) sensor electrical connector.
6. Disconnect the Evaporative Emission (EVAP) purge valve tube quick connect coupling.
7. Disconnect the brake booster and intake manifold vacuum connectors.
8. Remove the 4 bolts and the TB and TB spacer as an assembly. Discard the TB spacer gasket.

1. Install a new TB spacer gasket, position the TB and TB spacer assembly and tighten the 4 bolts in 2 stages. Stage 1: Tighten to 9 Nm (80 lb-in). Stage 2: Tighten an additional 90 degrees.
2. Connect the brake booster and intake manifold vacuum connectors.
3. Connect the EVAP purge valve tube quick connect coupling.
4. If a new TB spacer is being installed, install the TB. For additional information, refer to «THROTTLE BODY»(/ford/econoline-e250/2012-2013/remont/fuel-system/#fuel-charging-system-fuel-control-system-54l-2v-e-series) .
5. If necessary, connect the TP sensor electrical connector. Push back the red clip.
6. If necessary, connect the ETC electrical connector. Push back the red clip.
7. If necessary, install the ACL assembly and ACL outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/econoline-e250/2012-2013/remont/removal-installation/#intake-air-distribution-system-intake-air-filtering-system) .
8. Install the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/econoline-e250/2012-2013/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .

Scheme 11

1. For additional information, refer to the appropriate procedures in this information .

MATERIAL SPECIFICATIONS

Removal and Installation

Note. Fuel injection equipment is manufactured to very precise tolerances and fine clearances. It is therefore essential that absolute cleanliness is observed when working with these components. Always install plugs to any open orifices or tubes. Failure to follow these instructions may result in fuel injection component damage.

Note. When reusing liquid or vapor tube connectors, make sure to use compressed air to remove any foreign material from the connector retaining clip area before separating from the tube. Failure to follow these instructions may result in fuel or vapor leaks and connector damage.

1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/econoline-e250/2012-2013/remont/charging-system/#battery-battery-mounting-battery-cables) .
2. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/econoline-e250/2012-2013/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
3. Relieve the fuel pressure. For additional information, refer to Pressure Relief in «FUEL SYSTEM - GENERAL INFORMATION»(/ford/econoline-e250/2012-2013/remont/fuel-system/#fuel-system-general-information) .
4. Remove the Air Cleaner (ACL) and the ACL outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/econoline-e250/2012-2013/remont/removal-installation/#intake-air-distribution-system-intake-air-filtering-system) .
5. Disconnect the fuel supply tube quick connect coupling. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(/ford/econoline-e250/2012-2013/remont/fuel-system/#fuel-system-general-information) .
6. Disconnect the quick connect couplings and remove the PCV tube. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(/ford/econoline-e250/2012-2013/remont/fuel-system/#fuel-system-general-information) .
7. Disconnect the 8 fuel injector electrical connectors.
8. Remove the 4 fuel rail bolts. To install, tighten to 10 Nm (89 lb-in).
9. Separate the fuel rail from the 8 fuel injectors and remove the fuel rail.
10. Remove the 8 fuel injectors from the intake manifold. Remove and discard the fuel injector O-ring seals.

1. The fuel injectors are serviced with the fuel rail. For additional information, refer to «FUEL RAIL AND FUEL INJECTOR - EXPLODED VIEW»(/ford/econoline-e250/2012-2013/remont/fuel-system/#fuel-charging-system-fuel-control-system-54l-2v-e-series) and «FUEL RAIL»(/ford/econoline-e250/2012-2013/remont/fuel-system/#fuel-charging-system-fuel-control-system-54l-2v-e-series) .

Scheme 12

Note. The Fuel Pump (FP) control module is located on the LH frame rail to the rear of the spare tire.

1. Disconnect the FP control module electrical connector.
2. Remove the 2 bolts and the FP control module. To install, tighten to 10 Nm (89 lb-in).
3. To install, reverse the removal procedure.
