Wipers and Washers
Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.
SPECIAL TOOL(S)
Scheme 16
Scheme 17
- Verify the customer concern by operating the windshield wiper and washer system to duplicate the condition.
- Visually inspect for the following obvious signs of mechanical or electrical damage. VISUAL INSPECTION CHART
- If the concern is not visually evident, determine the symptom and proceed to «SYMPTOM CHART»(ref-210211-S13770067682005121400000) .
Scheme 18
Pinpoint Tests
| CAUTION | Electronic modules are sensitive to electrical charges. If exposed to these charges, damages may result. |
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
Scheme 31
Scheme 32
- Cycle and park the windshield wipers.
- Verify that the distance between the center of the RH windshield wiper blade (17528) and the cowl top vent panel is within specification.
- Verify that the distance between the center of the LH windshield wiper blade and the cowl top vent panel is within specification.
- If the distance is not within specification, remove the windshield wiper pivot arm (17526) that is not within specification and reposition it to specification; refer to «PIVOT ARM»(ref-210211-S42834647822005121400000)
