Removal
- Remove the wheel cover (1130), if so equipped.
- With the weight of the vehicle still on the tires, loosen the lug nuts.
- Raise the vehicle until the wheel and tire assembly clears the floor. For additional information, refer to «JACKING & LIFTING»(ref-210109) article .
- Remove the lug nuts.
- Remove the wheel and tire assembly.
Installation
- Position the wheel and tire assembly on the vehicle.
- Install the lug nuts loosely. Make sure the cone ends of the lug nut face inward.
- Turn the wheel until one lug nut is at the top of the wheel hub bolt circle. Tighten the lug nut until snug. In a crisscross-type pattern, tighten the remaining lug nuts until snug to minimize runout.
- Lower the vehicle.
- Tighten the lug nuts to specification.
- Tighten the wheel nuts to specification.
- Install the wheel cover, if so equipped.
Scheme 1
| WARNING | Aftermarket wheel assemblies may not be compatible with the vehicle. Use of incompatible wheel assemblies can result in equipment failure and possible injury. Use only approved wheel assemblies. |
| WARNING | Use only integral two-piece swiveling lug nuts on vehicles equipped with dual rear wheels. Do not attempt to use cone-shaped one-piece lug nuts on these vehicles. If used, cone-shaped one-piece lug nuts can come loose in vehicle operation. Do not attempt to use past model wheels, which have cone-shaped wheel hub bolt nut seats, on this vehicle. Do not attempt to use present design wheels and lug nuts on past model wheel hubs. Attempted use of intermixed wheels can lead to damage to the wheel mounting system and could result in wheels coming loose. |
- Remove the wheel cover (1130), if so equipped.
- With the weight of the vehicle still on the tires, loosen the lug nuts.
- Raise the vehicle until the wheel and tire assembly clears the floor. For additional information, refer to .
- Remove the lug nuts. Remove the inner and outer wheel and tire assemblies from the rear hub (1109).
- Mount the inner wheel on the rear hub with the wheel dish facing inboard.
- Align the wheel with the small indexing hole, located in the wheel between the wheel hub bolt holes, with the alignment pin in the hole in the rear hub. Refer to the illustration at the beginning of the removal procedure.
- Make sure the wheel is flush with the rear wheel hub mounting surface so there is no gap between the rear hub and the wheel.
- Install the outer rear wheel flush against the inner wheel with the hub alignment locating pin protruding through the wheel index hole.
- Install the lug nuts and tighten until snug.
- With the lug nuts loosely installed, turn the wheel until one lug nut is at the top of the wheel hub bolt circle. Tighten the swiveling lug nut until snug. In a crisscross-type pattern, tighten the remaining lug nuts until snug to minimize runout.
- Lower the vehicle.
- Tighten the lug nuts to specification.
- Tighten the wheel nuts to specification.
- Install the wheel cover, if so equipped.
