GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Lubricants and Sealants | |
| SAE 5W-20 Premium Synthetic Blend Engine Oil XO-5W20-QSP | WSS-M2C153-H |
| Motorcraft Premium Gold Engine Coolant VC-7-A (in Oregon VC-7-B) | WSS-M97B51-A1 (yellow color) |
| Motorcraft Silicone Gasket Remover ZC-30 | |
| Motorcraft Metal Surface Prep ZC-31 | |
| Silicone Gasket and Sealant F7AZ-19554-EA | WSE-M4G323-A4 |
| Instant Adhesive E8AZ-19554-A | WSK-M2G402-A4 |
| High Temperature Nickel Anti-Seize Lubricant XL-2 | ESE-M12A4-A |
| Petroleum Jelly | WSD-M1C226-A |
GENERAL SPECIFICATIONS
GENERAL SPECIFICATIONS - 4.6L
| Item | Specification |
|---|---|
| Engine - 4.6L | |
| Displacement | 4.6L(281 CID) |
| Number of cylinders | 8 |
| Bore | 90.2 mm (3.55 in) |
| Stroke | 90.0 mm (3.54 in) |
| Firing order | 1-3-7-2-6-5-4-8 |
| Oil pressure (@ 2000 rpm - hot) | 275.8-517.1 kPa (40-75 psi) |
| Oil capacity (includes filter change) | 5.7L (6.0 qts) |
| Compression ratio | 9.3:1 |
| Cylinder Head and Valve Train | |
| Combustion chamber volume | 51.5-52.5 cc (3.14-3.20 cu in) |
| Valve arrangement (front to rear) - LH | E-I-E-I-E-I-E-I |
| Valve arrangement (front to rear) - RH | I-E-I-E-I-E-I-E |
| Valve guide bore diameter | 7.044-7.015 mm (0.2773-0.2762 in) |
| Valve stem diameter - intake | 6.995-6.975 mm (0.2754-0.2746 in) |
| Valve stem diameter - exhaust | 6.970-6.949 mm (0.2744-0.2736 in) |
| Valve stem-to-guide clearance - intake | 0.020-0.069 mm (0.0008-0.0027 in) |
| Valve stem-to-guide clearance - exhaust | 0.045-0.095 mm (0.0018-0.0037 in) |
| Valve head diameter - intake | 44.5 mm (1.751 in) |
| Valve head diameter - exhaust | 34.0 mm (1.338 in) |
| Valve face runout | 0.05 mm (0.0019 in) |
| Valve face angle | 45.25-45.75 degrees |
| Valve seat width | 1.9-2.1 mm (0.0748-0.0827 in) |
| Valve seat runout (T.I.R.) max. | 0.025 mm (0.0010 in) |
| Valve seat angle | 45.50 degrees |
| Valve spring free length | 49.55 mm (1.9508 in) |
| Valve spring squareness | 2 degrees |
| Valve spring compression pressure | 587.14 N @ 28.02 mm (131.994 lb @ 1.1032 in) |
| Valve spring installed height | 39.7-40.3 mm (1.5630-1.5866 in) |
| Valve spring installed pressure - valve open | 587.165 N @ 27.99 mm (132 lb @ 1.102 in) |
| Valve spring installed pressure - valve closed | 244.652 N @ 39.98 mm (55 lb @ 1.574 in) |
| Roller follower ratio | 1.75:1 |
| Hydraulic Lash Adjuster | |
| Diameter | 16.000-15.9888 mm (0.6299-0.6295 in) |
| Clearance-to-bore | 0.018-0.069 mm (0.0007-0.0027 in) |
| Service limit | 0.016 mm (0.0006 in) |
| Hydraulic leakdown rate | 5-25 seconds (1) |
| Collapsed lash adjuster gap | 0.085-0.450 mm (0.0033-0.0177 in) |
| Camshaft | |
| Theoretical valve lift @ 0 lash | 12.0 mm (0.472 in) |
| Lobe lift | 6.5 mm (0.2560 in) |
| Allowable lobe lift loss | 0 |
| Journal diameter (all) | 26.962-26.936 mm (1.0615-1.0605 in) |
| Camshaft journal bore inside diameter (all) | 27.012-26.987 mm (1.0635-1.0625 in) |
| Camshaft journal-to-bearing clearance | 0.025-0.076 mm (0.0010-0.0030 in) |
| Runout | 0.05 mm (0.002 in) |
| End play | 0.09-0.19 mm (0.0035-0.0075 in) |
| Cylinder Block | |
| Cylinder bore diameter - grade 1 | 90.200-90.213 mm (3.5512-3.5517 in) |
| Cylinder bore diameter - grade 2 | 90.213-90.226 mm (3.5517-3.5522 in) |
| Cylinder bore diameter - grade 3 | 90.226-90.239 mm (3.5522-3.5527 in) |
| Cylinder bore maximum taper | 0.006 mm (0.0002 in) |
| Cylinder bore maximum out-of-round | 0.020 mm (0.0008 in) |
| Main bearing bore inside diameter | 72.401-72.422 mm (2.850-2.851 in) |
| Crankshaft | |
| Main bearing journal diameter | 63.0 mm (2.4803 in) |
| Main bearing journal maximum taper | 0.020 mm (0.0007 in) |
| Main bearing journal maximum out-of-round | 0.05 mm (0.002 in) |
| Main bearing journal-to-cylinder block clearance | 0.027-0.065 mm (0.0011-0.0026 in) |
| Connecting rod journal diameter | 52.988-53.003 mm (2.0861-2.0867 in) |
| Connecting rod journal maximum taper | 0.015 mm (0.0006 in) |
| Connecting rod journal maximum out-of-round | 0.05 mm (0.0020 in) |
| Crankshaft maximum end play | 0.130-0.301 mm (0.0051-0.012 in) |
| Piston and Connecting Rod | |
| Piston diameter - coded red 1 | 90.177-90.197 mm (3.550-3.551 in) |
| Piston diameter - coded blue 2 | 90.190-90.210 mm (3.5507-3.5515 in) |
| Piston diameter - coded yellow 3 | 90.203-90.223 mm (3.513-3.5521 in) |
| Piston-to-cylinder bore clearance | 0.012-0.0026 mm (0.0005-0.001 in) |
| Piston ring end gap - compression (top and bottom) | 0.23-0.49 mm (0.010-0.020 in) |
| Piston ring end gap - oil ring (steel rail) | 0.05-0.66 mm (0.006-0.026 in) |
| Piston ring groove width - compression (top) | 1.520-1.550 mm (0.060-0.610 in) |
| Piston ring groove width - compression (bottom) | 1.520-1.530 mm (0.060-0.0602 in) |
| Piston ring groove width - oil ring | 6.996-7.224 mm (0.275-0.2844 in) |
| Piston ring width - compression | 1.49-1.47 mm (0.0587-0.0579 in) |
| Piston ring width - oil ring rail (2) | 0.473-0.447 mm (0.0186-0.0176 in), 0.483 mm (0.0190 in) max. at ID |
| Piston ring width - oil ring expander | 2.038-1.960 mm (0.080-0.077 in) |
| Piston ring-to-groove clearance - compression | 0.030-0.070 mm (0.0012-0.0028 in) |
| Piston ring-to-groove clearance - oil ring assembly | 0.046-0.196 mm (0.0018-0.0077 in) |
| Piston pin bore diameter | 22.0015-22.004 mm (0.866-0.8663 in) |
| Piston pin diameter | 22.0 mm (0.866 in) |
| Piston pin length | 61.8 mm (2.433 in) |
| Piston pin-to-piston fit | 0.005-0.010 mm (0.0002-0.0004 in) |
| Connecting rod-to-pin clearance | 0.015-0.040 mm (0.0006-0.0016 in) |
| Connecting rod pin bore diameter | 21.959-21.979 mm (0.864-0.865 in) |
| Connecting rod length (center-to-center) | 150.7 mm (5.93 in) |
| Connecting rod maximum allowed bend | 0.038 mm (0.0015 in) per 25 mm (0.984 in) |
| Connecting rod maximum allowed twist (2) | 0.050 mm (0.0019 in) per 25 mm (0.984 in) |
| Connecting rod bearing bore diameter | 56.756-56.876 mm (2.234-2.24 in) |
| Connecting rod bearing-to-crankshaft clearance | 0.027-0.069 mm (0.001-0.0027 in) |
| Connecting rod side clearance (assembled to crank) - standard | 0.015-0.45 mm (0.0006-0.0177 in) |
| Connecting rod side clearance (assembled to crank) - service limit | 0.05 mm (0.02 in) max. |
| (1) Time required for the plunger to leak down 1.6 mm of travel with 222 N force and leak-down fluid in the lash adjuster. (2) The pin bore and crank bearing bore must be parallel and in the same vertical plane within the specified total difference when measured at the ends of a 203 mm bar, 105.5 mm on each side of rod centerline. | |
| (1) | Time required for the plunger to leak down 1.6 mm of travel with 222 N force and leak-down fluid in the lash adjuster. |
| (2) | The pin bore and crank bearing bore must be parallel and in the same vertical plane within the specified total difference when measured at the ends of a 203 mm bar, 105.5 mm on each side of rod centerline. |
GENERAL SPECIFICATIONS - 4.6L
GENERAL SPECIFICATIONS - 5.4L
| Item | Specification |
|---|---|
| Engine - 5.4L | |
| Displacement | 5.4L (330 cu in) |
| Number of cylinders | 8 |
| Bore | 90.2 mm (3.55 in) |
| Stroke | 105.8 mm (4.17 in) |
| Firing order | 1-3-7-2-6-5-4-8 |
| Oil pressure (@ 2000 rpm - hot) | 275.8-517.1 kPa (40-75 psi) |
| Oil capacity (includes filter change) | 5.7 L (6.0 qts) |
| Compression ratio | 9.0:1 |
| Cylinder Head and Valve Train | |
| Combustion chamber volume | 42.45-45.45 cc (2.59-2.77 cu in) |
| Valve arrangement (front to rear) - LH | E-I-E-I-E-I-E-I |
| Valve arrangement (front to rear) - RH | I-E-I-E-I-E-I-E |
| Valve guide bore diameter | 7.044-7.015 mm (0.2773-0.2762 in) |
| Valve stem diameter - intake | 6.995-6.975 mm (0.2754-0.2746 in) |
| Valve stem diameter - exhaust | 6.970-6.949 mm (0.2744-0.2736 in) |
| Valve stem-to-guide clearance - intake | 0.069-0.020 mm (0.0027-0.0008 in) |
| Valve stem-to-guide clearance - exhaust | 0.095-0.045 mm (0.0037-0.0018 in) |
| Valve head diameter - intake | 44.63-44.37 mm (1.7571-1.7469 in) |
| Valve head diameter - exhaust | 36.01 mm (1.4177 in) |
| Valve face runout | 0.05 mm (0.0020 in) |
| Valve face angle | 45.75-45.25 degrees |
| Valve seat width - intake | 1.3-1.5 mm (0.0512-0.0591 in) |
| Valve seat width - exhaust | 2.1-1.9 mm (0.0827-0.0748 in) |
| Valve seat runout (T.I.R.) | 0.025 mm (0.0010 in) |
| Valve seat angle | 45.50 degrees |
| Valve spring free length | 53.37 mm (2.10 in) |
| Valve spring squareness | 2.0 degrees |
| Valve spring compression pressure | 720-800 N (161.862-179.847 lb) @ 28.02 mm (1.10 in) |
| Valve spring installed height | 42.9-42.3 mm (1.6890-1.6654 in) |
| Valve spring installed pressure - valve open | 760 N @ 28.80 mm (170.855 lb @ 1.1339 in) |
| Valve spring installed pressure - valve closed | 302 N @ 42.56 mm (67.8923 lb @ 1.6756 in) |
| Roller follower ratio | 1.75:1 |
| Hydraulic Lash Adjuster | |
| Diameter | 16.000-15.988 mm (0.6299-0.6295 in) |
| Clearance-to-bore | 0.018-0.069 mm (0.0007-0.0027 in) |
| Service limit | 0.016 mm (0.0006 in) |
| Hydraulic leakdown rate | 5-25 seconds (1) |
| Collapsed lash adjuster gap | 0.085-0.450 mm (0.0335-0.0177 in) |
| Camshaft | |
| Theoretical valve lift @ 0 lash - intake | 12.02 mm (0.4732 in) |
| Theoretical valve lift @ 0 lash - exhaust | 12.67 mm (0.4988 in) |
| Lobe lift - intake | 7.1104 mm (0.2799 in) |
| Lobe lift - exhaust | 7.4979 mm (0.2952 in) |
| Allowable lobe lift loss | 0 |
| Journal diameter | 26.962-26.936 mm (1.0615-1.0605 in) |
| Camshaft journal bore inside diameter (cap assembled) | 27.012-26.987 mm (1.0635-1.0625 in) |
| Camshaft journal-to-bearing clearance | 0.076-0.025 mm (0.0030-0.0010 in) |
| Runout (2) | 0.03 mm (0.0012 in) |
| End play | 0.0270-0.0190 mm (0.0011-0.0075 in) |
| Cylinder Block | |
| Cylinder bore diameter - grade 1 | 90.200-90.210 mm (3.5512-3.5516 in) |
| Cylinder bore diameter - grade 2 | 90.210-90.220 mm (3.5516-3.5520 in) |
| Cylinder bore diameter - grade 3 | 90.220-90.230 mm (3.5520-3.5524 in) |
| Cylinder bore maximum taper | 0.006 mm (0.00023 in) |
| Cylinder bore maximum out-of-round | 0.020 mm (0.00079 in) |
| Main bearing bore inside diameter | 72.400-72.424 mm (2.850-2.851 in) |
| Cylinder bore diameter - surface finish (RMS) | 0.2-0.6 microns |
| Crankshaft | |
| Main bearing journal diameter | 67.482-67.504 mm (2.6568-2.6576 in) |
| Main bearing journal maximum taper (straightness) | 0.004 mm (0.0002 in) |
| Main bearing journal maximum out-of-round | 0.0075 mm (0.0003 in) between cross sections |
| Main bearing journal-to-cylinder block clearance | 0.048-0.024 mm (0.0019-0.0009 in) |
| Connecting rod journal diameter | 53.003-52.983 mm (2.0867-2.0859 in) |
| Connecting rod journal maximum taper | 0.004 mm (0.0002 in) |
| Connecting rod journal maximum out-of-round | 0.0075 mm (0.0003 in) between cross sections |
| Crankshaft maximum end play | 0.075-0.377 mm (0.0030-0.0148 in) |
| Piston and Connecting Rod | |
| Piston diameter - grade 1 (at right angle to pin bore) | 90.175-90.165 mm (3.5502-3.5498 in) |
| Piston diameter - grade 2 (at right angle to pin bore) | 90.185-90.175 mm (3.5506-3.5502 in) |
| Piston diameter - grade 3 (at right angle to pin bore) | 90.195-90.185 mm (3.5510-3.5506 in) |
| Piston-to-cylinder bore clearance (at grade size) | 0.005-0.025 mm (-0.0002-0.0001 in) |
| Piston ring end gap - top | 0.15-0.30 mm (0.0006-0.0012 in) |
| Piston ring end gap - intermediate | 0.25-0.50 mm (0.0098-0.0197 in) |
| Piston ring end gap - oil control | 0.15-0.65 mm (0.0059-0.0256 in) |
| Piston ring groove width - top | 1.503-1.505 mm (0.0592-0.0593 in) |
| Piston ring groove width - intermediate | 1.502-1.504 mm (0.0591-0.0592 in) |
| Piston ring groove width - oil control | 3.030-3.050 mm (0.1193-0.1201 in) |
| Piston ring width | 1.5-1.47 mm (0.0591-0.0579 in) |
| Piston ring-to-groove clearance - top | 0.033-0.005 mm (0.0013-0.0002 in) |
| Piston ring-to-groove clearance - intermediate | 0.033-0.005 mm (0.0013-0.0002 in) |
| Piston pin bore diameter | 22.001-22.014 mm (0.8662-0.8667 in) |
| Piston pin diameter | 22.0001-22.0030 mm (0.8662-0.8663 in) |
| Piston pin length | 61.8 mm (2.433 in) |
| Piston pin-to-piston fit (clearance) | 0.005-0.013 mm (0.0002-0.0005 in) |
| Connecting rod-to-pin clearance | 0.009-0.023 mm (0.0004-0.0093 in) |
| Connecting rod pin bore diameter | 22.012-22.024 mm (0.8666-0.8671 in) |
| Connecting rod length (centerline bore-to-bore) | 169.1 mm (6.6575 in) |
| Connecting rod maximum allowed bend | +/- 0.0 mm (+/-0.03 in) |
| Connecting rod maximum allowed twist | +/- 0.0 mm (+/-0.04 in) |
| Connecting rod bearing bore diameter (with assembled liners) | 53.049-53.027 mm (2.0885-2.0877 in) |
| Connecting rod bearing-to-crankshaft clearance | 0.064-0.026 mm (0.0025-0.0010 in) |
| Connecting rod side clearance | 0.475-0.125 mm (0.0187-0.0049 in) |
| (1) Time required for the plunger to leak down 1.6 mm of travel with 222 N force and leak-down fluid in the lash adjuster. (2) Full indicator measurement on all journals when supported on front and rear journals (4 places). | |
| (1) | Time required for the plunger to leak down 1.6 mm of travel with 222 N force and leak-down fluid in the lash adjuster. |
| (2) | Full indicator measurement on all journals when supported on front and rear journals (4 places). |
GENERAL SPECIFICATIONS - 5.4L
TORQUE SPECIFICATIONS
| Description | Nm | Lb-ft | Lb-in |
|---|---|---|---|
| Accelerator cable bracket bolts | 10 | 89 | |
| 42-pin bulkhead connector bolt | 6 | 53 | |
| Camshaft bearing cap bolts | 10 | 89 | |
| Camshaft position sensor bolt | 10 | 89 | |
| Camshaft sprocket bolts (1) | |||
| Connecting rod bolts (1) | |||
| Crankshaft main bearing bolts (cross-mounted) (1) | |||
| Crankshaft main bearing bolts (vertical) (1) | |||
| Crankshaft position sensor bolt | 10 | 89 | |
| Crankshaft pulley bolt (1) | |||
| Crankshaft rear seal retainer plate bolts | 10 | 89 | |
| Cylinder heads bolts (1) | |||
| Cylinder head temperature sensor (CHT) | 26 | 19 | |
| Differential pressure feedback EGR sensor nuts (5.4L) | 10 | 89 | |
| Differential pressure feedback EGR sensor nuts (4.6L) | 4 | 35 | |
| Differential pressure feedback EGR sensor bracket bolts (5.4L) | 10 | 89 | |
| Drive belt idler pulley bolt | 25 | 18 | |
| EGR valve to intake manifold bolts (1) | |||
| Engine front cover bolts (1) | |||
| Exhaust manifold nuts | 25 | 18 | |
| Exhaust manifold studs | 12 | 9 | |
| Exhaust manifold to EGR valve tube fittings (1) | |||
| Exhaust manifold-to-Y-pipe nuts | 40 | 30 | |
| Fan shroud bolts | 6 | 53 | |
| Flexplate bolts | 80 | 59 | |
| Fuel injection supply manifold bracket bolts | 10 | 89 | |
| Generator upper mounting bracket bolts | 10 | 89 | |
| Generator lower mounting bolts | 25 | 18 | |
| Heater inlet tube studs (4.6L) | 25 | 18 | |
| Heater inlet tube studs (5.4L) | 40 | 30 | |
| Ignition coil | 6 | 53 | |
| Lower intake manifold to upper intake manifold bolts (1) | |||
| Upper intake manifold to cylinder head bolts (1) | |||
| Intake manifold tuning valve screws (1) | |||
| Knock sensor | 20 | 15 | |
| Motor mount to cylinder block bolts | 63 | 44 | |
| Motor mount nuts | 90 | 66 | |
| Oil cooler threaded insert | 58 | 43 | |
| Oil filler tube bolt | 10 | 89 | |
| Oil filter | 16 | 12 | |
| Oil filter adapter front bolts (4.6L) | 25 | 18 | |
| Oil filter adapter front nuts (4.6L) | 25 | 18 | |
| Oil filter adapter rear bolt (4.6L) | 48 | 35 | |
| Oil filter adapter front bolts (5.4L) | 25 | 18 | |
| Oil filter adapter rear nut (5.4L) | 48 | 35 | |
| Oil filter adapter studs | 12 | 9 | |
| Oil level indicator tube nut | 25 | 18 | |
| Oil level indicator tube bolt | 10 | 89 | |
| Oil line connector adapter assembly bolt | 25 | 18 | |
| Oil pan bolts (1) | |||
| Oil pan drain plug | 14 | 10 | |
| Oil pressure switch | 14 | 10 | |
| Oil pump bolts | 10 | 89 | |
| Oil pump screen and pickup tube front bolts | 10 | 89 | |
| Oil pump screen and pickup tube spacer | 25 | 18 | |
| Oil pump screen and pickup tube spacer bolt | 25 | 18 | |
| Power steering pressure tube nut | 20 | 15 | |
| Power steering pump bolts | 25 | 18 | |
| Power steering reservoir bracket bolts | 20 | 15 | |
| Lower radiator support bolts | 20 | 15 | |
| Upper radiator support bolts | 20 | 15 | |
| Spark plugs | 18 | 13 | |
| Starter mounting bolts and nut | 25 | 18 | |
| Starter solenoid ground nut | 20 | 15 | |
| Starter solenoid power cable nut | 12 | 9 | |
| Starter solenoid signal lead nut | 6 | 53 | |
| Thermostat housing bolts | 25 | 18 | |
| Throttle body adapter-to-intake manifold bolts | 10 | 89 | |
| Timing chain guide bolts | 10 | 89 | |
| Timing chain hydraulic tensioner bolts | 25 | 18 | |
| Transmission fluid filler tube nut (4.6L) | 10 | 89 | |
| Transmission fluid filler tube nut (5.4L) | 28 | 21 | |
| Transmission fluid cooler tube support bracket nut (4.6L) | 10 | 89 | |
| Transmission fluid cooler tube support bracket nut (5.4L) | 28 | 21 | |
| Transmission-to-engine bolts | 60 | 44 | |
| Torque converter-to-flexplate nuts | 35 | 26 | |
| Valve cover bolts | 10 | 89 | |
| Coolant pump bolts | 25 | 18 | |
| Coolant pump pulley bolts | 25 | 18 | |
| Water temperature sensor | 20 | 15 | |
| (1) Refer to the procedure in this article | |||
| (1) | Refer to the procedure in this article |
TORQUE SPECIFICATIONS
Scheme 75
See also:
• JACKING & LIFTING
• BUMPERS
