Exterior Lighting: Removal & Installation Ford Econoline E150

Exterior Lights 24 illustrations ~611 words

Removal

WARNINGThe halogen bulb contains gas under pressure. The bulb may shatter if the glass envelope is scratched or if the bulb is dropped. Handle the bulb carefully. Grasp the bulb only by its base. Avoid touching the glass envelope. Failure to follow these instructions may result in personal injury.

Note. The headlamp bulb should not be removed from the headlamp until just before a replacement bulb is installed. Removing the bulb for an extended period of time may affect headlamp bulb performance. Contaminants may enter the headlamp where they can settle on the lens and reflector. Never turn on the headlamps with the bulb removed from the headlamp.

Scheme 33

Scheme 33
Scheme 33
  1. Remove the headlamp. For additional information, refer to «LAMP ASSEMBLY - HEADLAMP, AERODYNAMIC»(ref-210191-S05561568902005121400000) .
  2. Remove the headlamp bulb. Rotate the headlamp bulb retainer counterclockwise one-eighth turn. Remove the headlamp bulb.

Installation

CAUTIONBulbs No. 9004 and No. 9007 look similar, but are not interchangeable.

Scheme 34

Scheme 34
Scheme 34
  1. Install the headlamp bulb. Install the headlamp bulb. Rotate the headlamp bulb retainer clockwise one-eighth turn.
  2. Install the headlamp. For additional information, refer to «LAMP ASSEMBLY - HEADLAMP, AERODYNAMIC»(ref-210191-S05561568902005121400000) .

Removal and Installation

Note. RH shown; LH similar.

Scheme 35

Scheme 35: Removal and Installation
Scheme 35: Removal and Installation

Scheme 36

Scheme 36
Scheme 36
  1. Remove the headlamp door screws and remove the headlamp door.
  2. Remove the screws and remove the retaining ring.
  3. Disconnect the electrical connector and remove the headlamp.
  4. To install, reverse the removal procedure. If necessary, adjust the headlamps. For additional information, refer to «HEADLAMP ADJUSTMENT»(ref-210191-S19671009012005121400000) .

Note. RH shown; LH similar.

Scheme 37

Scheme 37: Removal
Scheme 37: Removal
  1. Pull up on the headlamp mounting clips to release the headlamp.
  2. Remove the headlamp assembly. Pull the headlamp assembly forward. Disconnect the electrical connector.

Scheme 38

Scheme 38: Installation
Scheme 38: Installation

Scheme 39

Scheme 39
Scheme 39
  1. Install the headlamp assembly. Connect the electrical connector. Install the headlamp assembly.
  2. Push down the two headlamp mounting clips to secure the headlamp. If necessary, adjust the headlamps. For additional information, refer to «HEADLAMP ADJUSTMENT»(ref-210191-S19671009012005121400000) .

Scheme 40

Scheme 40: Removal and Installation
Scheme 40: Removal and Installation

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43
  1. Remove the rear hi-mount lamp screws.
  2. Remove the screws retaining the lens to the interior lamp door (cargo lamp).
  3. Remove the interior lamp door (cargo lamp) screws.
  4. Remove the two bulb sockets and remove the rear hi-mount lamp assembly.
  5. To install, reverse the removal procedure.

Scheme 44

Scheme 44: Removal and Installation
Scheme 44: Removal and Installation

Scheme 45

Scheme 45
Scheme 45
  1. Remove the rear hi-mount lamp screws.
  2. Remove the rear hi-mount lamp.
  3. Disconnect the electrical connectors.
  4. To install, reverse the removal procedure.

Note. RH shown; LH similar.

Scheme 46

Scheme 46: Removal and Installation
Scheme 46: Removal and Installation

Scheme 47

Scheme 47
Scheme 47
  1. Remove the parking lamp screws.
  2. Pull the parking lamp forward and disconnect the electrical connector.
  3. To install, reverse the removal procedure.

Note. RH shown; LH similar.

Scheme 48

Scheme 48: Removal and Installation
Scheme 48: Removal and Installation

Scheme 49

Scheme 49
Scheme 49
  1. Remove the rear lamp screws.
  2. Pull the rear lamp forward.
  3. Disconnect the electrical connectors.
  4. To install, reverse the removal procedure.

Scheme 50

Scheme 50: Removal and Installation
Scheme 50: Removal and Installation

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54
  1. Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-210181) .
  2. Pull headlamp knob to HEAD position.
  3. Insert a small screwdriver onto clip and pull clip and knob outward, removing headlamp knob.
  4. Remove headlamp switch bezel by turning it counterclockwise.
  5. On vehicles with tilt column, position steering wheel in full down position.
  6. On vehicles with column shift, set parking brake and position shift lever to the lowest position.
  7. Remove audio unit. For additional information, refer to «AUDIO UNIT»(ref-210184) .
  8. Remove 2 screws above instrument cluster.
  9. Remove instrument panel finish panel by pulling it straight back from instrument panel to release clips. Disconnect cigarette lighter and power point electronic connectors.
  10. Remove the headlamp switch bolts.
  11. Disconnect the electrical connector and remove the headlamp switch.
  12. To install, reverse the removal procedure.

Scheme 55

Scheme 55: Removal
Scheme 55: Removal

Scheme 56

Scheme 56
Scheme 56
  1. Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-210181) .
  2. Disconnect the brake pedal position (BPP) switch electrical connector.
  3. Remove the BPP switch. Remove the self-locking pin. Remove the brake master cylinder push rod spacer. Remove the BPP switch from the brake master cylinder push rod. Remove the brake master cylinder push rod bushing. Remove the brake master cylinder push rod spacer.
  1. To install, reverse the removal procedure.
