Engine - 6.8l- e350 & e450 Ford Cutaway E350

GENERAL SPECIFICATIONS - SEALANT & LUBRICANTS

GENERAL SPECIFICATIONS - SEALANT & LUBRICANTS

GENERAL SPECIFICATIONS - 6.8L ENGINE

GENERAL SPECIFICATIONS - 6.8L ENGINE

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

Engine Component View

The concept of modularity allows engine designs to share concepts and hardware. The following illustrations represent the modular V10 engine. The four modules are

1. intake module
2. cylinder head module (RH)
3. cylinder head module (LH)
4. lower engine module

Due to the modular design, most out-of-vehicle repairs benefit in reduction of time and labor needed to repair the engine.

The basic engine components consist of

1. single overhead camshafts
2. two valves per cylinder
3. balance shaft
4. sequential multiport fuel injection (SFI)
5. aluminum cylinder heads
6. cast-iron, 90-degree V-cylinder block
7. individual ignition coils for each spark plug
8. two-piece intake manifold system
9. composite-material lower intake manifold
10. large-bore throttle body

Scheme 468

Scheme 469

Scheme 470

Scheme 471

Scheme 472

Refer to ENGINE SYSTEM-GENERAL INFORMATION for basic mechanical concerns or see INTRODUCTION - GASOLINE article for driveability concerns.

Material

MATERIAL SPECIFICATIONS

Removal

Scheme 473

Scheme 474

Scheme 475

Scheme 476

Scheme 477

Scheme 478

Scheme 479

Scheme 480

Scheme 481

Scheme 482

Scheme 483

Scheme 484

Scheme 485

Scheme 486

Scheme 487

Scheme 488

Scheme 489

Scheme 490

1. Relieve the fuel system pressure. For additional information, refer to «FUEL SYSTEM-GENERAL INFORMATION»(/ford/cutaway-e350/2004-2007/remont/fuel-system/#fuel-system-general-information) .
2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/cutaway-e350/2004-2007/remont/charging-system/#battery-mounting-and-cables) .
3. Remove the air cleaner and the air cleaner outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/cutaway-e350/2004-2007/remont/removal-installation/#intake-air-distribution-filtering) .
4. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/cutaway-e350/2004-2007/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
5. Drain the cooling system. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling) .
6. Remove the generator. For additional information, refer to «HEATING & VENTILATION»(/ford/cutaway-e350/2004-2007/remont/heater/#hvac-system-heating-ventilation) .
7. Disconnect the fuel hose spring lock coupling. For additional information, refer to «FUEL SYSTEM-GENERAL INFORMATION»(/ford/cutaway-e350/2004-2007/remont/fuel-system/#fuel-system-general-information) .
8. Compress and slide the hose clamp and disconnect the coolant hose.
9. Disconnect the electronic throttle body (TB) electrical connector.
10. Disconnect the throttle position (TP) sensor electrical connector.
11. Disconnect the positive crankcase ventilation (PCV) hose and engine vacuum harness.
12. Disconnect the PCV coolant hoses.
13. Disconnect the brake booster and evaporative emission hose.
14. Remove the four bolts, the throttle body and adapter as an assembly. Discard the throttle body adapter gasket.
15. Disconnect the heater hose.
16. Disconnect the vacuum connector.
17. Disconnect the fuel rail pressure (FRP) sensor electrical connector.
18. Disconnect the 10 fuel injector electrical connectors.
19. Disconnect the 10 ignition coil electrical connectors.
20. Remove the retaining nut for the transmission fluid indicator and tube.
21. Remove the transmission fluid level indicator tube bracket retaining nut and position the tube aside.
22. Remove the stud bolts and position the RH fuel charge wiring harness aside.
23. Remove the bolts and position the LH fuel charge wiring harness aside.
24. Remove the screws and the 10 coils.
25. Disconnect the pushpin retainer from the intake manifold bracket.
26. Remove the bolts, thermostat housing and thermostat. Remove and discard the O-ring seal.
27. Remove the bolts, the intake manifold and the intake manifold gaskets.
28. Clean and inspect the mating surfaces. Clean the intake manifold mating surface of the cylinder heads with silicone gasket remover and metal surface prep. Follow the directions on the packaging.

Scheme 491

Scheme 492

Scheme 493

Scheme 494

Scheme 495

Scheme 496

Scheme 497

Scheme 498

Scheme 499

1. Install the intake manifold. Position the intake manifold gaskets and the intake manifold, and loosely install the bolts.
2. Install the thermostat housing. Install the thermostat. Install a new O-ring seal.
3. Install the thermostat housing and loosely install the bolts.
4. Tighten the bolts in the sequence shown in two stages. Stage 1: Tighten to 2 Nm (18 lb-in). Stage 2: Tighten to 25 Nm (18 lb-ft).
5. Connect the pushpin retainer to the intake manifold bracket.
6. Install the screws and the 10 coils.
7. Position back the LH fuel charge wiring harness and install the bolts.
8. Position back the RH fuel charging wiring harness and install the stud bolts.
9. Position back the transmission fluid level indicator tube and install the retaining nut.
10. Install the retaining nut on the transmission fluid indicator and tube.
11. Connect the 10 ignition coil electrical connectors.
12. Connect the 10 fuel injector electrical connectors.
13. Connect the fuel rail pressure (FRP) sensor electrical connector.
14. Connect the vacuum connector.
15. Connect the coolant hose.
16. Install the throttle body adapter gasket and the throttle body and adapter as an assembly. Tighten the bolts in two stages. Stage 1: Tighten the bolts to 9 Nm (80 lb-in). Stage 2: Tighten the bolts an additional 90 degrees (1/4 turn).
17. Connect the brake booster and evaporative emission hose.
18. Connect the positive crankcase ventilation (PCV) coolant hose.
19. Connect the heated PCV tube and engine vacuum harness.
20. Connect the throttle position (TP) sensor electrical connector. Push in the red clip.
21. Connect the electronic throttle body (TB) electrical connector. Push in the red clip.
22. Install the upper radiator hose.
23. Connect the fuel hose spring lock couplings. For additional information, refer to «FUEL SYSTEM-GENERAL INFORMATION»(/ford/cutaway-e350/2004-2007/remont/fuel-system/#fuel-system-general-information) .
24. Install the generator. For additional information, refer to «GENERATOR AND REGULATOR»(/ford/cutaway-e350/2004-2007/remont/charging-system/#charging-system-generator-and-regulator) .
25. Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/cutaway-e350/2004-2007/remont/charging-system/#battery-mounting-and-cables) .
26. Install the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/cutaway-e350/2004-2007/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
27. Install the air cleaner assembly and tubes. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/cutaway-e350/2004-2007/remont/removal-installation/#intake-air-distribution-filtering) .
28. Fill the cooling system. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling) .

MATERIAL SPECIFICATIONS

Scheme 500

Scheme 501

Scheme 502

Scheme 503

Scheme 504

Scheme 505

Scheme 506

1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/cutaway-e350/2004-2007/remont/charging-system/#battery-mounting-and-cables) .
2. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/cutaway-e350/2004-2007/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
3. Remove the engine air cleaner and the air cleaner outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/cutaway-e350/2004-2007/remont/removal-installation/#intake-air-distribution-filtering) .
4. Disconnect the positive crankcase ventilation (PCV) valve tube from the LH valve cover and position aside.
5. Remove the bolts and position the LH fuel charge wiring harness aside.
6. Disconnect the five fuel injector electrical connectors.
7. Disconnect the five ignition coil electrical connectors.
8. Disconnect the pushpin retainers from the powertrain control module (PCM) bracket.
9. Lift the fuel charging wiring off the valve cover studs.
10. Loosen the retaining nut.
11. Remove the bolt and position the oil level indicator and tube aside.
12. Disconnect the wiring retainers from the valve cover studs.
13. Remove the LH valve cover. Fully loosen the bolts and remove the valve cover. Clean the valve cover mating surface of the cylinder head with silicone gasket remover and metal surface prep. Follow the directions on the packaging. Discard the valve cover gasket. Clean the valve cover gasket groove with soap and water or a suitable solvent.

Scheme 507

Scheme 508

Scheme 509

Scheme 510

Scheme 511

1. Apply instant gel adhesive completely around the gasket groove in the valve cover. Install the new valve cover gasket.
2. Apply a bead of silicone gasket and sealant in two places where the engine front cover meets the cylinder head.
3. Position the valve cover and the valve cover gasket on the cylinder head and loosely install the bolts.
4. Tighten the bolts in the sequence (Scheme 511)
5. Connect the wiring retainers on the valve cover studs.
6. Position back the oil level indicator and tube. Install the bolt.
7. Tighten the retaining nut.
8. Position the fuel charging wiring onto the valve cover studs.
9. Connect the pushpin retainers to the PCM bracket.
10. Position the LH fuel charge wiring harness and install the bolts.
11. Connect the five fuel injector electrical connectors.
12. Connect the five ignition coil electrical connectors.
13. Connect the PCV valve tube to the LH valve cover.
14. Install the engine air cleaner and engine air cleaner outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/cutaway-e350/2004-2007/remont/removal-installation/#intake-air-distribution-filtering).
15. Install the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/cutaway-e350/2004-2007/remont/exteriorinterior-trim/#interior-trim-and-ornamentation).
16. Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/cutaway-e350/2004-2007/remont/charging-system/#battery-mounting-and-cables).

MATERIAL SPECIFICATIONS

Scheme 512

Scheme 513

Scheme 514

Scheme 515

Scheme 516

Scheme 517

Scheme 518

Scheme 519

Scheme 520

Scheme 521

1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/cutaway-e350/2004-2007/remont/charging-system/#battery-mounting-and-cables) .
2. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/cutaway-e350/2004-2007/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
3. Remove the engine air cleaner and the air cleaner outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/cutaway-e350/2004-2007/remont/removal-installation/#intake-air-distribution-filtering) .
4. Disconnect the electrical connectors.
5. Disconnect the electrical connector position retainers, remove the nut, ground strap and mounting bracket.
6. Disconnect the oil fill tube from the RH valve cover.
7. Remove the bolt and the oil fill tube.
8. Disconnect the positive crankcase ventilation (PCV) electrical connector, tube and remove the PCV valve by rotating counterclockwise.
9. Disconnect the wiring harness retainers from the RH valve cover studs.
10. Remove the pushpin retainers and the splash shield.
11. Disconnect the A/C compressor and the crankshaft position (CKP) sensor connectors and remove the tie-strap.
12. Remove the transmission fluid filler tube nut.
13. Remove the retaining nut and position the transmission fluid indicator and tube aside.
14. Remove the stud bolts and position the RH fuel charge wiring harness aside.
15. Disconnect the five ignition coil electrical connectors.
16. Disconnect the five fuel injector electrical connectors. Lift the fuel charging wiring off the valve cover.
17. Disconnect the electronic throttle body (TB) electrical connector.
18. Position the fuel charging wiring into the passenger compartment.
19. Remove the five bolts and the RH ignition coils.
20. Remove the RH valve cover. Fully loosen the bolts and remove the valve cover. Clean the valve cover mating surface of the cylinder head with silicone gasket remover and metal surface prep. Follow the directions on the packaging. Discard the valve cover gasket. Clean the valve cover gasket groove with soap and water or a suitable solvent.

Scheme 522

Scheme 523

Scheme 524

Scheme 525

Scheme 526

Scheme 527

1. Apply instant gel adhesive completely around the gasket groove in the valve cover. Install the new valve cover gasket.
2. Apply a bead of silicone gasket and sealant in two places where the engine front cover meets the cylinder head.
3. Position the valve cover and the valve cover gasket on the cylinder head and loosely install the bolts.
4. Tighten the bolts in the sequence (Scheme 525)
5. Install the five RH ignition coils and the bolts.
6. Position the fuel charging wiring harness on to the engine.
7. Connect the electronic TB electrical connector.
8. Position the RH fuel charge wiring harness and install the stud bolts.
9. Position back the transmission fluid indicator and tube. Install the retaining nut.
10. Connect the five fuel injector electrical connectors.
11. Connect the five ignition coil electrical connectors.
12. Install the transmission fluid filler tube nut.
13. Connect the A/C compressor and the CKP sensor connectors and install a tie-strap.
14. Position the splash shield and install the pushpin retainers.
15. Connect the wiring harness retainers to the RH valve cover studs.
16. Install the PCV valve by rotating clockwise and connect the PCV tube and electrical connector.
17. Connect the oil fill tube to the RH valve cover.
18. Install the oil fill tube support bracket bolt.
19. Position the mounting bracket, ground strap and install the nut. Connect the electrical connector retainers to the support bracket.
20. Connect the electrical connectors.
21. Install the engine air cleaner and the air cleaner outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/cutaway-e350/2004-2007/remont/removal-installation/#intake-air-distribution-filtering).
22. Install the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/cutaway-e350/2004-2007/remont/exteriorinterior-trim/#interior-trim-and-ornamentation).
23. Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/cutaway-e350/2004-2007/remont/charging-system/#battery-mounting-and-cables).

Special Tool(s)

SPECIAL TOOLS Remover, Crankshaft Vibration Damper 303-009 (T58P-6316-D) Installer, Crankshaft Vibration Damper 303-102 (T74P-6316-B)

Scheme 528

MATERIAL SPECIFICATIONS

Scheme 529

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/cutaway-e350/2004-2007/remont/hoistjack/#jacking-lifting) .
2. Remove the engine cooling fan and fan shroud. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling) .
3. Remove the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE»(/ford/cutaway-e350/2004-2007/remont/accessory-drive-belts/#accessory-drive-system) .
4. Remove the crankshaft pulley bolt.
5. Using the special tool, remove the crankshaft pulley.

Scheme 530

Scheme 531

1. Apply silicone gasket and sealant to the woodruff key slot in the crankshaft pulley.
2. Use the special tool to install the crankshaft pulley.
3. Tighten the crankshaft pulley bolt in four stages. Stage 1: Tighten to 90 Nm (66 lb-ft). Stage 2: Loosen 360 degrees. Stage 3: Tighten to 50 Nm (37 lb-ft). Stage 4: Tighten an additional 90 degrees.
4. Install the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE»(/ford/cutaway-e350/2004-2007/remont/accessory-drive-belts/#accessory-drive-system) .
5. Install the engine cooling fan and the fan shroud. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling) .

SPECIAL TOOLS Installer, Crankshaft Front Seal 303-335 (T88T-6701-A) Remover, Crankshaft Front Seal 303-107 (T74P-6700-A) Installer, Crankshaft Front Seal 303-635 Installer, Crankshaft Vibration Damper 303-102 (T74P-6316-B)

Scheme 532

Scheme 533

Scheme 534

MATERIAL SPECIFICATIONS

Scheme 535

1. Remove the crankshaft pulley. For additional information, refer to «CRANKSHAFT PULLEY»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
2. Using the special tool, remove the crankshaft front seal.

Scheme 536

Scheme 537

1. Lubricate the engine front cover and the crankshaft front seal inner lip with clean engine oil.
2. Using the special tools, install the crankshaft front seal into the engine front cover.
3. Install the crankshaft pulley. For additional information, refer to «CRANKSHAFT PULLEY»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .

MATERIAL SPECIFICATIONS

Scheme 538

Scheme 539

Scheme 540

Scheme 541

Scheme 542

Scheme 543

Scheme 544

Scheme 545

Scheme 546

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/cutaway-e350/2004-2007/remont/hoistjack/#jacking-lifting) .
2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/cutaway-e350/2004-2007/remont/charging-system/#battery-mounting-and-cables) .
3. Remove both of the valve covers. For additional information, refer to «VALVE COVER - LH»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) and «VALVE COVER - RH»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
4. Remove the radiator. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling) .
5. Remove the coolant pump. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling) .
6. Remove the crankshaft front seal. For additional information, refer to «CRANKSHAFT FRONT SEAL»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
7. Remove the top bolts and the lower bolt and position the power steering pump aside.
8. Disconnect the wiring harness from the bracket.
9. Remove the retaining nut. Disconnect the tubes and remove the bracket.
10. Disconnect the crankshaft position (CKP) sensor electrical connector.
11. Remove the drain plug and drain the engine oil.
12. Remove the four front oil pan bolts.
13. Disconnect the camshaft position (CMP) sensor electrical connector.
14. Remove the bolt and the accessory drive belt idler pulley.
15. Remove the bolts.
16. Remove the engine front cover from the front cover-to-cylinder block dowel. Remove the engine front cover gasket. Clean the mating surfaces with silicone gasket remover and metal surface prep. Follow the directions on the packaging. Inspect the mating surfaces.

Scheme 547

Scheme 548

Scheme 549

Scheme 550

1. Apply a bead of silicone gasket and sealant along the cylinder head-to-cylinder block surface and the oil pan-to-cylinder block surface, at the locations (Scheme 550)
2. Install the engine front cover with the engine front cover gasket on the engine front cover-to-cylinder block dowel and loosely install the bolts.
3. Tighten the engine front cover fasteners in sequence in two stages. Stage 1: Tighten fasteners 1 through 5 to 25 Nm (18 lb-ft). Stage 2: Tighten fasteners 6 through 15 to 48 Nm (35 lb-ft).
4. Position the accessory drive belt idler pulley and install the bolt.
5. Connect the CMP electrical connector.
6. Loosely install the bolts, then tighten the bolts in two stages, in the sequence (Scheme 552) Stage 1: Tighten to 20 Nm (15 lb-ft). Stage 2: Tighten an additional 60 degrees.
7. Connect the CKP sensor electrical connector.
8. Install the bracket and connect the tubes. Install the retaining nut.
9. Connect the wiring harness to the bracket.
10. Position the power steering pump and install the bolts.
11. Install the oil drain plug.
12. Install a new crankshaft front seal. For additional information, refer to «CRANKSHAFT FRONT SEAL»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450).
13. Install the valve covers. For additional information, refer to «VALVE COVER - LH»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) and «VALVE COVER - RH»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450).
14. Install the coolant pump. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling).
15. Install the radiator. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling).
16. Fill the engine with clean engine oil.
17. Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/cutaway-e350/2004-2007/remont/charging-system/#battery-mounting-and-cables).

SPECIAL TOOLS Holding Tool, Crankshaft 303-448 (T93P-6303-A) Aligner, Camshaft Position 303-557 (T96T-6256-B) (2 Req'd)

MATERIAL SPECIFICATIONS

Scheme 551

Scheme 552

Scheme 553

Scheme 554

Scheme 555

Scheme 556

Scheme 557

1. Remove the engine front cover. For additional information, refer to «ENGINE FRONT COVER»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
2. Remove the crankshaft sensor ring from the crankshaft.
3. Remove the six bolts and remove the balance shaft bearing caps.
4. Remove the balance shaft.
5. Position the crankshaft with the keyway at the 12 o'clock position.
6. Install and carefully tighten the special tool on the camshafts.
7. Remove the timing chain tensioning system from both timing chains. Remove the bolts. Remove the timing chain tensioners. Remove the timing chain tensioner arms.
8. Remove the LH and RH timing chain and the crankshaft sprockets. Remove the RH timing chain from the camshaft sprocket. Remove the RH timing chain from the crankshaft sprocket. Remove the LH timing chain from the camshaft sprocket. Remove the LH timing chain from the crankshaft sprocket.
9. Remove the timing chain guides. Remove the bolts. Remove the timing chain guides.
10. Remove the bolts, flat washers, camshaft sprockets and right camshaft spacer.

Installation

Scheme 558

Scheme 559

Scheme 560

Scheme 561

Scheme 562

Scheme 563

Scheme 564

Scheme 565

Scheme 566

Scheme 567

Scheme 568

1. Compress the tensioner plunger, using a vise.
2. Install a retaining clip on the tensioner to hold the plunger in during installation.
3. If copper links are not visible, mark two links on one end and one link on the other end, and use as timing marks.
4. Install the RH spacer ring, camshaft gears, flat washers and bolts. Tighten the bolts in two stages. Stage 1: Tighten to 40 Nm (30 lb-ft). Stage 2: Tighten an additional 90 degrees.
5. Install the timing chain guides.
6. Preposition the camshafts. Rotate the LH camshaft with the Camshaft Positioning Tool until the timing mark is approximately at 12 o'clock. Rotate the RH camshaft with the Camshaft Positioning Tool until the timing mark is approximately at 11 o'clock. Tighten the Camshaft Holding Tool to maintain camshaft prepositioning.
7. Position the crankshaft with the special tool, then remove the tool.
8. Install the crankshaft sprocket, marking sure the flange faces forward.
9. Install the lower end of the LH timing chain, aligning the timing marks.
10. Install the LH timing chain on the camshaft sprocket with the two chain (marked) links and the timing marks aligned.
11. Position the LH timing chain tensioner arm on the dowel pin and install the LH timing chain tensioner.
12. Install the RH (outer) timing chain on the crankshaft sprocket.
13. Position the timing chain on the camshaft sprocket. Make sure the two copper-colored (marked) links align with the camshaft sprocket timing mark.
14. Position the LH and RH timing chain tensioner arms on the dowel pins. Position the timing chain tensioners and install the bolts.
15. Remove the retaining clips from the RH and LH timing chain tensioners.
16. Check for correct alignment of all timing marks.
17. Remove the special tools from the camshafts.
18. Install the crankshaft sensor ring on the crankshaft.
19. Lubricate the balance shaft journals with clean engine oil.
20. Using the index mark on the balance shaft, mark the corresponding gear tooth with chalk.
21. Position the balance shaft on the journals.
22. Align the chalk mark on the balance shaft with the camshaft timing mark (Scheme 580)
23. Install the bearing caps in their original locations. Install the bolts and tighten the bolts in the sequence (Scheme 581)
24. Install engine front cover. For additional information, refer to «ENGINE FRONT COVER»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450).

SPECIAL TOOL Compressor, Valve Spring 303-567 (T97P-6565-AH)

Scheme 569

MATERIAL SPECIFICATIONS

Scheme 570

1. Remove the timing drive components. For additional information, refer to «TIMING DRIVE COMPONENTS»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
2. Use the special tool to compress the valve springs and remove the camshaft roller followers.
3. Remove the bolts, the camshaft bearing caps and the camshaft from the cylinder block.

Scheme 571

Scheme 572

1. Lubricate the camshaft journals with clean engine oil.
2. Install the camshaft and the camshaft bearing caps in their original locations onto the cylinder head. Loosely install the 15 bolts.
3. Tighten the bolts in the sequence see scheme 164
4. Use the special tool to compress the valve springs and install the camshaft roller followers.
5. Install the timing drive components. For additional information, refer to «TIMING DRIVE COMPONENTS»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450).

Scheme 573

Scheme 574

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/cutaway-e350/2004-2007/remont/hoistjack/#jacking-lifting) .
2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/cutaway-e350/2004-2007/remont/charging-system/#battery-mounting-and-cables) .
3. Remove the four exhaust Y-pipe flange nuts.
4. Remove the 10 nuts, the exhaust manifold, and the exhaust manifold gasket. Discard the exhaust manifold gasket.
5. Clean and inspect the exhaust manifold. For additional information, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-system-general-information) .
6. To install, reverse the removal procedure. Install a new exhaust manifold gasket.

Scheme 575

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/cutaway-e350/2004-2007/remont/hoistjack/#jacking-lifting) .
2. Remove the nuts.
3. Remove the exhaust manifold nuts and the exhaust manifold. Discard the exhaust manifold gaskets.
4. Clean and inspect the exhaust manifold. For additional information, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-system-general-information) .
5. To install, reverse the removal procedure.

MATERIAL SPECIFICATIONS

Scheme 576

Scheme 577

Scheme 578

1. Drain the engine cooling system. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling) .
2. Drain the engine oil.
3. Disconnect the coolant hoses.
4. Remove the oil filter.
5. Remove the threaded insert and the oil cooler. Inspect the oil cooler.
6. To install, reverse the removal procedure. Fill the engine with clean engine oil before filling the cooling system.

MATERIAL SPECIFICATION

Scheme 579

1. Remove the engine air cleaner and the air cleaner outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/cutaway-e350/2004-2007/remont/removal-installation/#intake-air-distribution-filtering) .
2. Remove the oil level indicator and the nut retaining the oil level indicator tube and bracket assembly.
3. Remove the LH exhaust manifold. For additional information, refer to «EXHAUST MANIFOLD - LH»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
4. Remove the bolt and the oil level indicator tube.
5. Inspect the oil level indicator tube for damage.
6. To install, reverse the removal procedure. Install new O-ring seals and lubricate them with clean engine oil.

SPECIAL TOOLS Modular Engine Lift Bracket 303-F047 (014-00073) or equivalent Heavy Duty Engine Support 303-F070 Lift Bar Adapter, Modular Engine 303-F694

Scheme 580

Scheme 581

MATERIAL SPECIFICATIONS

Scheme 582

Scheme 583

Scheme 584

Scheme 585

Scheme 586

Scheme 587

Scheme 588

Scheme 589

Scheme 590

Scheme 591

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/cutaway-e350/2004-2007/remont/hoistjack/#jacking-lifting) .
2. Remove the intake manifold. For additional information, refer to «INTAKE MANIFOLD»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
3. Remove the engine cooling fan and fan shroud. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling) .
4. Remove the retainers and the shield.
5. Remove the stud bolts and position the heater outlet tube aside.
6. Remove the two transmission-to-engine bolts.
7. Disconnect the oil fill tube from the RH valve cover.
8. Remove the bolt and the oil fill tube.
9. Assemble the special tools.
10. Install the special tools.
11. Install the special tool and support the engine.
12. Drain the engine oil and remove the oil filter.
13. Remove the nut and position the transmission fluid cooler tube support bracket aside.
14. Remove the RH and LH nuts retaining the front engine support insulators to the front engine support bracket.
15. Remove the flywheel inspection plate.
16. Using the special tool, raise the engine.
17. Remove the bolts and partially lower the oil pan.
18. Remove the bolts retaining the oil pump screen cover and pickup tube and allow it to drop into the oil pan. Also remove the tube and spacer and allow it to drop into the oil pan. Remove the oil pan.
19. Clean the mating surfaces for the oil pan and the engine with silicone gasket remover and metal surface prep. Follow the directions on the packaging.

Scheme 592

Scheme 593

Scheme 594

Scheme 595

Scheme 596

Scheme 597

Scheme 598

1. Position the oil pan gasket and the oil pan in the vehicle from the rear of the engine.
2. Install the oil pump screen cover and pickup tube. Install and tighten the spacer. Insert the oil pump screen pickup tube into the oil pump and position the support bracket over the spacer. Install and tighten the bolts.
3. Apply a bead of silicone gasket and sealant at the crankshaft rear seal retainer-to-cylinder block surface, at the locations (Scheme 600)
4. Apply a bead of silicone gasket and sealant at the engine front cover-to-cylinder block surface, at the locations (Scheme 601)
5. Tighten the bolts in the sequence (Scheme 602) Stage 1: Tighten to 2 Nm (18 lb-in). Stage 2: Tighten to 20 Nm (15 lb-ft). Stage 3: Tighten an additional 90 degrees.
6. Lower the engine and remove the special tools.
7. Install the flywheel inspection plate.
8. Position the transmission fluid cooler tube support bracket and install the nut. Tighten to 12 Nm (9 lb-ft).
9. Install a new oil filter. Tighten to 16 Nm (12 lb-ft).
10. Install the engine support insulator nuts.
11. Install the new O-ring seal and the heater outlet tube. Lubricate the O-ring seal with engine coolant.
12. Hand-tighten the heater outlet tube upper stud and install the lower stud. Tighten the studs to 40 Nm (30 lb-ft).
13. Connect the oil fill tube to the RH valve cover.
14. Install the oil fill tube support bracket bolt.
15. Install the transmission-to-engine bolts.
16. Install the shield and the retainers.
17. Install the intake manifold. For additional information, refer to «INTAKE MANIFOLD»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450).
18. Fill the engine with clean engine oil.
19. Install the engine cooling fan and fan shroud. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling).
20. Fill and bleed the engine cooling system. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling).

MATERIAL SPECIFICATIONS

Scheme 599

Scheme 600

Scheme 601

Scheme 602

Scheme 603

1. Remove the left engine support insulator. For additional information, refer to «ENGINE SUPPORT INSULATORS»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/cutaway-e350/2004-2007/remont/charging-system/#battery-mounting-and-cables) .
3. Drain the engine cooling system. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling) .
4. Drain the engine oil.
5. Disconnect the coolant hoses.
6. Remove the oil filter.
7. Remove the threaded insert and the oil cooler. Inspect the oil cooler.
8. Disconnect the oil pressure switch electrical connector.
9. Remove the oil pressure switch.
10. Disconnect the lower radiator hose.
11. Remove the nut, the bolts, the oil filter adapter and the gasket. Discard the gasket.
12. To install, reverse the removal procedure. Install a new oil filter adapter gasket. Fill the engine with clean engine oil before filling the cooling system.

Scheme 604

1. Remove the timing drive components. For additional information, refer to «TIMING DRIVE COMPONENTS»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
2. Remove the oil pan. For additional information, refer to «OIL PAN»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
3. Remove the bolts and the oil pump.

Scheme 605

1. Clean and inspect the mating surfaces.
2. Position the oil pump and loosely install the bolts. Tighten the bolts in the sequence see scheme 212
3. Install the oil pan. For additional information, refer to «OIL PAN»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450).
4. Install the timing drive components. For additional information, refer to «TIMING DRIVE COMPONENTS»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450).

Scheme 606

1. Remove the transmission. For additional information, refer to «AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70W/4R75W»(/ford/cutaway-e350/2004-2007/remont/automatic-trans/#automatic-transmission-4r70w-4r75w) .
2. Remove the bolts and the flexplate.

Scheme 607

1. Position the flexplate and loosely install the bolts. Tighten the bolts in the sequence see scheme 214
2. Install the transmission. For additional information, refer to «AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70W/4R75W»(/ford/cutaway-e350/2004-2007/remont/automatic-trans/#automatic-transmission-4r70w-4r75w).

SPECIAL TOOLS Installer, Crankshaft Rear Oil Seal 303-518 (T95P-6701-DH) Remover, Crankshaft Rear Oil Seal 303-519 (T95P-6701-EH) Installer, Crankshaft Rear Oil Seal 303-516 (T95P-6701-BH) Remover, Crankshaft Rear Oil Slinger 303-514 (T95P-6701-AH) Installer, Crankshaft Rear Oil Slinger 303-517 (T95P-6701-CH) Slide Hammer 100-001 (T50T-100-A)

Scheme 608

Scheme 609

Scheme 610

MATERIAL SPECIFICATION

Scheme 611

Scheme 612

1. Remove the flexplate. For additional information, refer to «FLEXPLATE»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
2. Use the special tools to remove the crankshaft rear oil slinger.
3. Use the special tools to remove the crankshaft rear seal.

Scheme 613

1. Using the special tools, install the crankshaft rear seal.
2. Using the special tools, install the crankshaft rear oil slinger.
3. Install the flexplate. For additional information, refer to «FLEXPLATE»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .

SPECIAL TOOLS Installer, Crankshaft Rear Seal 303-518 (T95P-6701-DH) Remover, Crankshaft Rear Seal 303-519 (T95P-6701-EH) Installer, Crankshaft Rear Seal 303-516 (T95P-6701-BH) Remover, Rear Crankshaft Oil Slinger 303-514 (T95P-6701-AH) Installer, Rear Crankshaft Oil Slinger 303-517 (T95P-6701-CH) Slide Hammer 100-001 (T50T-100-A)

MATERIAL SPECIFICATION

Scheme 614

1. Remove the flexplate. For additional information, refer to «FLEXPLATE»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
2. Using the special tools, remove the crankshaft rear oil slinger.
3. Using the special tools, remove the crankshaft rear seal.
4. Remove the oil pan. For additional information, refer to «OIL PAN»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
5. Remove the bolts and the crankshaft rear seal retainer plate.

Scheme 615

1. Clean and inspect the mating surface.
2. Apply a 4-mm (0.16-in) bead of silicone gasket and sealant around the crankshaft rear seal retainer plate sealing surface.
3. Install the crankshaft rear seal retainer plate and loosely install the six bolts.
4. Tighten the bolts in the sequence see scheme 224
5. Use the special tools to install the rear seal.
6. Using the special tools, install the crankshaft rear oil slinger.
7. Install the oil pan. For additional information, refer to «OIL PAN»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450).
8. Install the flexplate. For additional information, refer to «FLEXPLATE»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450).

SPECIAL TOOLS Modular Engine Lift Bracket 303-F047 (014-00073) or equivalent Heavy Duty Engine Support 303-F070 Lift Bar Adapter, Modular Engine 303-F694

MATERIAL SPECIFICATIONS

Scheme 616

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/cutaway-e350/2004-2007/remont/hoistjack/#jacking-lifting) .
2. Remove the intake manifold. For additional information, refer to «INTAKE MANIFOLD»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
3. Remove the engine cooling fan and fan shroud. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling) .
4. Remove the retainers and the shield.
5. Remove the stud bolts and position the heater outlet tube aside.
6. Remove the two transmission-to-engine bolts.
7. Disconnect the oil fill tube from the RH valve cover.
8. Remove the bolt and the oil fill tube.
9. Assemble the special tools.
10. Install the special tools.
11. Install the special tool and support the engine.
12. Remove the RH and LH nuts retaining the front engine support insulators to the front engine support bracket.
13. Using the special tool, raise the engine.
14. Disconnect the oil pressure switch electrical connector.
15. Remove the oil pressure switch.
16. Remove the bolts and remove the engine mounts from the vehicle.

Scheme 617

1. Position the engine mounts and install the bolts.
2. Install the oil pressure switch.
3. Connect the oil pressure switch electrical connector.
4. Lower the engine and remove the special tools.
5. Install the engine support insulator nuts.
6. Install the new O-ring seal and the heater outlet tube. Lubricate the O-ring seal with engine coolant.
7. Hand-tighten the heater outlet tube upper stud and install the lower stud. Tighten the studs to 40 Nm (30 lb-ft).
8. Connect the oil fill tube to the RH valve cover.
9. Install the oil fill tube support bracket bolt.
10. Install the transmission-to-engine bolts.
11. Install the shield and the retainers.
12. Install the intake manifold. For additional information, refer to «INTAKE MANIFOLD»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
13. Install the engine cooling fan and fan shroud. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling) .
14. Fill and bleed the engine cooling system. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling) .

SPECIAL TOOLS Modular Engine Lift Bracket 303-F047 (014-00073) or equivalent Holding Wrench, Fan Clutch 303-478 (T94T-6312-AH) Wrench, Fan Clutch Hub Nut 303-214 (T83T-6312-B)

Scheme 618

Scheme 619

Scheme 620

Scheme 621

Scheme 622

Scheme 623

Scheme 624

Scheme 625

Scheme 626

Scheme 627

Scheme 628

Scheme 629

Scheme 630

Scheme 631

Scheme 632

Scheme 633

Scheme 634

Scheme 635

Scheme 636

Scheme 637

Scheme 638

Scheme 639

Scheme 640

Scheme 641

Scheme 642

Scheme 643

Scheme 644

Scheme 645

Scheme 646

Scheme 647

Scheme 648

Scheme 649

Scheme 650

Scheme 651

Scheme 652

Scheme 653

Scheme 654

Scheme 655

Scheme 656

Scheme 657

Scheme 658

Scheme 659

Scheme 660

Scheme 661

Scheme 662

1. Recover the air conditioning system. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/cutaway-e350/2004-2007/remont/general-servicing-all-makes/#hvac-system-climate-control-system-general-information).
2. With the vehicle in NEUTRAL, position it on a hoist, For additional information, refer to «JACKING & LIFTING»(/ford/cutaway-e350/2004-2007/remont/hoistjack/#jacking-lifting).
3. Remove the intake manifold. For additional information, refer to «INTAKE MANIFOLD»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450).
4. Remove the front bumper. For additional information, refer to «BUMPERS»(/ford/cutaway-e350/2004-2007/remont/exterior-body-panels/#bumpers).
5. Disconnect the lower radiator hose from the radiator. Disconnect the hose hanger. Disconnect the hose.
6. Remove the pushpin retainers and the splash shield.
7. Disconnect the transmission cooler hoses and drain the fluid into a suitable container.
8. Disconnect the exhaust system from the LH and RH exhaust manifolds.
9. Drain the engine oil.
10. Disconnect the oil cooler hoses and set aside.
11. Remove the oil filter.
12. Loosen the threaded insert and remove and discard the oil cooler.
13. Remove the starter motor solenoid terminal cover.
14. Disconnect the starter motor electrical connections.
15. Remove the starter motor. Remove the stud bolt. Remove the two bolts. Remove the starter.
16. Remove the flexplate inspection cover.
17. Remove the cylinder block opening cover.
18. Remove the four nuts retaining the torque converter to the flexplate. Rotate the crankshaft to access all of the torque converter nuts. Discard the torque converter nuts.
19. Disconnect the shift cable from the mounting bracket and shift linkage.
20. Remove the two transmission-to-engine bolts and position the shifter cable aside.
21. Remove the RH lower transmission-to-engine bolt.
22. Remove the four engine mount nuts.
23. Disconnect the power steering reservoir hose and the power steering pressure tube at the power steering pump. Allow the fluid to drain into a drain pan.
24. Remove the nut and position the transmission fluid cooler support bracket aside.
25. Remove the valance panel. For additional information, refer to «FRONT END BODY PANELS»(/ford/cutaway-e350/2004-2007/remont/exterior-body-panels/#body-panel-system-front-end-body-panels).
26. Disconnect the upper radiator hose and the degas hose from the radiator.
27. Remove the fan blade assembly and fan clutch. Use the special tool to hold the coolant pump pulley. Using the special tool, remove the fan blade and the fan clutch.
28. Disconnect the degas hose retainer from the fan shroud.
29. Remove the fan shroud, fan and fan clutch. Remove the bolts. Lift the fan shroud, fan and fan clutch from the vehicle.
30. Remove the bolts and the radiator support brackets.
31. Remove the radiator from the vehicle.
32. Disconnect the A/C pressure cutoff switch electrical connector.
33. Disconnect the compressor suction tube.
34. Disconnect the condenser core refrigerant tubes. Disconnect the compressor discharge tube. Disconnect the condenser-to-evaporator tube.
35. Remove the A/C condenser core. Remove the bolts. Remove the A/C condenser brackets. Remove the A/C condenser core.
36. Set the hood latch aside. Remove the hood latch bolts. Disengage the cable routing clip.
37. Remove the bolts and set the power steering reservoir aside.
38. Remove the nuts and the battery feed cable at the power distribution box.
39. Set aside the battery feed wiring harness to the power distribution box. Disengage the routing clips.
40. If equipped, disconnect the air temperature sensor electrical connector.
41. Disconnect the front impact severity sensor electrical connector.
42. Disconnect the horn electrical connector.
43. Remove the eight bolts and the upper radiator support.
44. Remove the pin-type retainers and the RH and LH air deflectors.
45. Set aside the LH side of the headlamp dash panel junction wiring harness. Remove the screw. Disengage the routing clips.
46. Set aside the RH side of the headlamp dash panel junction wiring harness. Disconnect the electrical connector. Remove the screw. Disengage the routing clips.
47. Remove the 12 bolts and the lower radiator support.
48. Disconnect the lower radiator hose from the oil filter adapter water inlet and set aside.
49. Disconnect the engine wiring harness from the powertrain control module (PCM) bracket.
50. Disconnect the PCM electrical connectors. Position the engine wiring on the engine.
51. Disconnect the engine wiring harness electrical connectors.
52. Disconnect the electrical connectors, remove the nut, ground strap and mounting bracket.
53. Remove the engine oil filler tube support strap bolt.
54. Remove the fluid level indicator and disconnect the attachments at the transmission fluid filler tube. Remove the fluid level indicator. Disconnect the rear heater hose hanger.
55. Disconnect the evaporative emission canister purge valve electrical connector.
56. Disconnect the HO2S electrical connector and remove the transmission fluid filler tube.
57. Release the wiring retainers from the heater outlet tube bracket. Release the knock sensor electrical connector retainer. Release the engine harness routing clip retainer.
58. Disconnect the hose from the heater outlet tube.
59. Remove the heater outlet tube studs.
60. Remove the heater outlet tube.
61. Release the transmission wiring harness connector retainer from the bracket. Disconnect the transmission wiring harness and the LH and RH heated oxygen sensor (HO2S) electrical connectors.
62. Remove the four upper transmission-to-engine bolts and the fuel line, and the LH HO2S brackets.
63. Install the special tool see scheme 307
64. Support the transmission with a jack.
65. Remove the engine from the vehicle.

SPECIAL TOOLS Remover, Crankshaft Vibration Damper 303-009 (T58P-6316-D) Remover, Crankshaft Front Seal 303-107 (T74P-6700-A) Remover/Installer, Cylinder Head 303-567 (T97T-6565-AH) Compressor, Valve Spring 303-567 (T97P-6565-AH) Spacer, Valve Spring 303-382 (T91P-6565-AH) Engine Lift Bracket Set 303-DS086 (D93P-6001-A) Modular Engine Lift Bracket 303-F047 (014-00073) or equivalent

Scheme 663

Scheme 664

Scheme 665

MATERIAL SPECIFICATIONS

Scheme 666

Scheme 667

Scheme 668

Scheme 669

Scheme 670

Scheme 671

Scheme 672

Scheme 673

Scheme 674

Scheme 675

Scheme 676

Scheme 677

Scheme 678

Scheme 679

Scheme 680

Scheme 681

Scheme 682

Scheme 683

Scheme 684

Scheme 685

Scheme 686

Scheme 687

1. Remove the engine. For additional information, refer to «Engine»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
2. Remove the bolts and the flexplate.
3. Lower the engine onto wooden blocks.
4. Remove the special tool.
5. Install the special tool.
6. Install the special tool.
7. Mount the engine on a suitable work stand.
8. Remove the special tool.
9. Remove the special tool.
10. Remove the RH engine mount.
11. Remove the cylinder block drain plugs and drain the coolant into a suitable container.
12. Disconnect the LH radio frequency interference capacitor and cylinder head temperature (CHT) sensor electrical connectors.
13. Disconnect the camshaft position (CMP) electrical connector.
14. Disconnect the RH radio frequency interference capacitor electrical connector.
15. Disconnect the knock sensor (KS) electrical connector, if equipped.
16. Disconnect the crankshaft position (CKP) sensor electrical connector.
17. Disconnect the oil pressure switch electrical connector.
18. Disconnect all of the harness routing clips and connector retainers. Remove the engine control sensor wiring harness.
19. Remove the nuts and the two radio interference capacitors.
20. Remove the positive crankcase ventilation (PCV) valve tube from the LH valve cover and position aside.
21. Remove the nut attaching the oil level indicator tube to the front of the engine.
22. Remove the bolt attaching the oil level indicator tube to the rear of the engine.
23. Position the oil level indicator tube aside.
24. Remove the LH valve cover. Fully loosen the bolts and remove the valve cover. Clean the valve cover mating surface of the cylinder head with silicone gasket remover and metal surface prep. Follow the directions on the packaging. Inspect the valve cover gasket. If the gasket is damaged, remove and discard the gasket. Clean the valve cover gasket groove with soap and water or a suitable solvent.
25. Remove the RH valve cover. Fully loosen the bolts and remove the valve cover. Clean the valve cover mating surface of the cylinder head with silicone gasket remover and metal surface prep. Follow the directions on the packaging. Inspect the valve cover gasket. If the gasket is damaged, remove and discard the gasket. Clean the valve cover gasket groove with soap and water or a suitable solvent.
26. Remove the bolt and the idler pulley.
27. Remove the water pump pulley. Remove the bolts. Remove the water pump pulley.
28. Remove and discard the crankshaft pulley bolt. Use the special tool to remove the crankshaft pulley.
29. Using the special tool, remove the crankshaft front seal.
30. Remove the power steering pump.
31. Remove the four oil pan bolts.
32. Remove the fasteners.
33. Remove the engine front cover from the cylinder block.
34. Remove the crankshaft sensor ring from the crankshaft.
35. Remove the six bolts and remove the balance shaft bearing caps.
36. Remove the balance shaft.
37. Remove the 10 spark plugs.
38. Install the special tool between the valve spring coils to prevent valve stem seal damage.
39. Use the special tool to compress the valve springs and remove the camshaft roller followers.
40. Position the crankshaft with the keyway at the 12 o'clock position.
41. Remove the timing chain tensioning system from both timing chains. Remove the bolts. Remove the timing chain tensioners. Remove the timing chain tensioner arms.
42. Remove the RH and LH timing chains and the crankshaft sprocket(s). Remove the RH timing chain from the camshaft sprocket. Remove the RH timing chain from the crankshaft sprocket. Remove the LH timing chain from the camshaft sprocket. Remove the LH timing chain from the crankshaft sprocket.
43. Remove both timing chain guides. Remove the bolts. Remove the timing chain guides.
44. Remove the RH exhaust manifold. Remove the nuts. Remove the RH exhaust manifold. Remove the RH exhaust manifold gasket.
45. Remove the LH exhaust manifold. Remove the nuts. Remove the LH exhaust manifold. Remove the LH exhaust manifold gasket.
46. Clean and inspect the exhaust manifolds. For additional information, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-system-general-information) .
47. Install the special tools on both ends of the cylinder head.
48. Remove the hydraulic lash adjusters.
49. Remove the bolts and the RH cylinder head. Discard the cylinder head gasket. Discard the cylinder head bolts.
50. Remove the bolts and the RH cylinder head. Discard the cylinder head gasket. Discard the cylinder head bolts.
51. Clean the cylinder head-to-cylinder block mating surfaces of both the cylinder head and the cylinder block. Remove any large deposits of silicone or gasket material with a plastic scraper. Apply silicone gasket remover, following package directions, and allow to set for several minutes. Remove the silicone gasket remover with a plastic scraper. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep, following package directions, to remove any remaining traces of oil or coolant, and to prepare the surfaces to bond with the new gasket. Do not attempt to make the metal shiny. Some staining of the metal surface is normal.
52. Support the cylinder head on a bench with the head gasket side up. Inspect all areas of the deck face with a straightedge, paying particular attention to the oil pressure feed area. The cylinder head must not have depressions deeper than 0.0254 mm (0.001 in) across a 38.1 mm (1.5 in) square area or scratches more than 0.0254 mm (0.001 in).

SPECIAL TOOLS Installer, Connecting Rod 303-442 (T93P-6136-A) Remover, Crankshaft Vibration Damper 303-009 (T58P-6316-D) Remover/Installer, Cylinder Head (2 sets req'd) 303-572 (T97T-6000-A) Compressor, Valve Spring 303-567 (T97P-6565-AH) Compressor Spacer, Valve Spring 303-382 (T91P-6565-AH) Remover, Crankshaft Front Oil Seal 303-107 (T74P-6700-A) Modular Engine Lift Bracket 303-F047 (014-00073) or equivalent Remover, Crankshaft Rear Oil Slinger 303-514 (T95P-6701-AH) Slide Hammer 100-001 (T50T-100-A) Remover, Crankshaft Rear Oil Seal 303-519 (T95P-6701-EH) Engine Lift Bracket Set 303-DS086 (D93P-6001-A)

Scheme 688

MATERIAL SPECIFICATIONS

Scheme 689

Scheme 690

Scheme 691

Scheme 692

Scheme 693

Scheme 694

Scheme 695

Scheme 696

Scheme 697

Scheme 698

Scheme 699

Scheme 700

Scheme 701

Scheme 702

Scheme 703

Scheme 704

Scheme 705

Scheme 706

1. Remove the engine. For additional information, refer to «Engine»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
2. Remove the bolts and the flexplate.
3. Using the special tools, remove the crankshaft rear slinger.
4. Using the special tools, remove the crankshaft rear seal.
5. Remove the bolts and the crankshaft rear seal retainer plate.
6. Lower the engine onto wooden blocks.
7. Remove the special tool.
8. Install the special tool.
9. Install the special tool.
10. Mount the engine on a suitable work stand.
11. Remove the special tool.
12. Remove the special tool.
13. Remove the RH and LH engine mounts.
14. Remove the cylinder block drain plugs and drain the coolant into a suitable container.
15. Disconnect the LH radio frequency interference capacitor and cylinder head temperature (CHT) sensor electrical connectors.
16. Disconnect the camshaft position (CMP) sensor electrical connector.
17. Disconnect the RH radio frequency interference capacitor electrical connector.
18. Disconnect the knock sensor electrical connector, if equipped.
19. Disconnect the crankshaft position (CKP) sensor electrical connector.
20. Disconnect the oil pressure switch electrical connector.
21. Disconnect all of the harness routing clips and connector retainers. Remove the engine control sensor wiring harness.
22. Remove the nuts and the two radio interference capacitors.
23. Remove the crankcase ventilation tube from the LH valve cover.
24. Remove the nut attaching the oil level indicator tube to the front of the engine.
25. Remove the bolt attaching the oil level indicator tube to the rear of the engine.
26. Position the oil level indicator tube aside.
27. Remove the LH valve cover. Fully loosen the bolts and remove the valve cover. Clean the valve cover mating surface of the cylinder head with silicone gasket remover and metal surface prep. Follow the directions on the packaging. Inspect the valve cover gasket. If the gasket is damaged, remove and discard the gasket. Clean the valve cover gasket groove with soap and water or a suitable solvent.
28. Remove the RH valve cover. Fully loosen the bolts and remove the valve cover. Clean the valve cover mating surface of the cylinder head with silicone gasket remover and metal surface prep. Follow the directions on the packaging. Inspect the valve cover gasket. If the gasket is damaged, remove and discard the gasket. Clean the valve cover gasket groove with soap and water or a suitable solvent.
29. Remove the bolt and the idler pulley.
30. Remove the water pump pulley. Remove the bolts. Remove the water pump pulley.
31. Remove and discard the crankshaft pulley bolt. Use the special tool to remove the crankshaft pulley.
32. Use the special tool to remove the crankshaft front oil seal.
33. Remove the power steering pump.
34. Remove the bolts.
35. Remove the fasteners.
36. Remove the engine front cover from the cylinder block.
37. Remove the crankshaft sensor ring from the crankshaft.
38. Remove the six bolts and remove the balance shaft bearing caps.
39. Remove the balance shaft.
40. Remove the 10 spark plugs.
41. Install the special tool between the valve spring coils to prevent valve stem seal damage.
42. Use the special tool to compress the valve springs and remove the camshaft roller followers.
43. Remove the special tool.
44. Position the crankshaft with the keyway at the 12 o'clock position.
45. Remove the timing chain tensioning system from both timing chains. Remove the bolts. Remove the timing chain tensioners. Remove the timing chain tensioner arms.
46. Remove the RH and LH timing chains and the crankshaft sprocket(s). Remove the RH timing chain from the camshaft sprocket. Remove the RH timing chain from the crankshaft sprocket. Remove the LH timing chain from the camshaft sprocket. Remove the LH timing chain from the crankshaft sprocket.
47. Remove both timing chain guides. Remove the bolts. Remove the timing chain guides.
48. Remove the RH exhaust manifold. Remove the nuts. Remove the RH exhaust manifold. Remove the RH exhaust manifold gasket.
49. Remove the LH exhaust manifold. Remove the nuts. Remove the LH exhaust manifold. Remove the LH exhaust manifold gasket.
50. Clean and inspect the exhaust manifolds. For additional information, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-system-general-information) .
51. Install the special tools on both ends of the cylinder head.
52. Remove the hydraulic lash adjusters.
53. Remove the bolts and the RH cylinder head. Discard the cylinder head gasket. Discard the cylinder head bolts.
54. Clean the cylinder head-to-cylinder block mating surfaces of both the cylinder head and the cylinder block. Remove any large deposits of silicone or gasket material with a plastic scraper. Apply silicone gasket remover, following package directions, and allow to set for several minutes. Remove the silicone gasket remover with a plastic scraper. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep, following package directions, to remove any remaining traces of oil or coolant, and to prepare the surfaces to bond with the new gasket. Do not attempt to make the metal shiny. Some staining of the metal surface is normal.
55. Support the cylinder head on a bench with the head gasket side up. Inspect all areas of the deck face with a straightedge, paying particular attention to the oil pressure feed area. The cylinder head must not have depressions deeper than 0.0254 mm (0.001 in) across a 38.1 mm (1.5 in) square area or scratches more than 0.0254 mm (0.001 in).
56. Remove the bolts and nut retaining the oil filter adapter to the cylinder block. Remove the oil filter adapter and clean the gasket surface.
57. Remove the bolts.
58. Remove the water pump from the cylinder block.
59. Remove the bolts and the A/C compressor.
60. Before removing the pistons, inspect the top of the cylinder bores. If necessary, remove the ridge or carbon deposits from each cylinder using a cylinder ridge reamer, following the manufacturer's instructions.
61. Remove the bolts, the oil pan and the oil pan gasket.
62. Remove the bolts, the oil pump screen cover and tube and the spacer.
63. Remove the oil pump. Remove the bolts. Remove the oil pump.
64. Remove the bolts and the connecting rod caps. Rotate the crankshaft so that the connecting rod is a bottom dead center. Remove and discard the bolts.
65. Remove the piston and rod assembly. Using the special tool, guide the piston and rod assembly out of the cylinder.
66. Repeat the previous steps until all 10 piston and rod assemblies have been removed from the cylinder block.
67. Remove and discard the 12 cross-mounted bolts.
68. Remove and discard the bolts.
69. Remove the main bearing cap dowel pins.
70. Remove the main bearing caps, the lower crankshaft main bearings and the thrust washer.
71. Remove the crankshaft and the crankshaft main bearings from the cylinder block.

SPECIAL TOOLS Aligner, Camshaft Position (2 req'd) 303-557 (T96T-6256-B) Compressor, Valve Spring 303-567 (T97P-6565-AH) Compressor Spacer, Valve Spring 303-382 (T91P-6565-AH) Installer, Valve Stem Oil Seal 303-383 (T91P-6571-A)

MATERIAL SPECIFICATIONS

Disassembly

Scheme 707

Scheme 708

Scheme 709

Scheme 710

1. Remove the hydraulic lash adjusters.
2. Install the special tool between the valve spring coils to prevent valve stem seal damage.
3. Using the special tool, compress the valve springs.
4. Remove the valves. Remove the valve spring retainer keys. Remove the valve spring retainers. Remove the valve springs. Remove the valves.
5. Remove the valve stem seals.
6. Remove the bolts, the bearing caps and the camshaft.
7. Clean and inspect the camshaft bearing caps. One of the bearing caps contains an oil flow restriction groove. Make sure the groove is free of foreign material.

Scheme 711

Scheme 712

Scheme 713

Scheme 714

Scheme 715

Scheme 716

1. Check the cylinder head for distortion. For additional information, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-system-general-information).
2. Clean the cylinder head sealing surfaces. Remove any large deposits of silicone or gasket material with a plastic scraper. Apply silicone gasket remover, following package directions, and allow to set for several minutes. Remove the silicone gasket remover with a plastic scraper. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep, following package directions, to remove any remaining traces of oil or coolant, and to prepare the surfaces to bond with the new gasket. Do not attempt to make the metal shiny. Some staining of the metal surfaces is normal.
3. Lubricate the camshaft journals with clean engine oil.
4. Install the camshaft and the camshaft bearing caps in their original locations. Lubricate the camshaft bearing caps with clean engine oil. Position the camshaft bearing caps. Install the bolts loosely.
5. Tighten the bolts in the sequence see scheme 423
6. Install the valves in the valve guides located in the cylinder head.
7. Use the special tools to install the valve stem seals.
8. Install the valve springs and the valve spring retainers onto the valves.
9. Install the special tool between the valve spring coils to prevent valve stem seal damage.
10. Use the special tool to compress the valve springs. Install the valve spring retainer keys.
11. Install the hydraulic lash adjusters in their original locations.
12. Remove the special tool, unless the cylinder head is to be installed in-vehicle.

MATERIAL SPECIFICATION

Scheme 717

Scheme 718

Scheme 719

1. Remove the clips.
2. Remove the piston pin from the piston and connecting rod assembly.
3. Remove the connecting rod from the piston.
4. Clean and inspect the piston and connecting rod. For additional information, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-system-general-information) .

Scheme 720

Scheme 721

1. Position the connecting rod in the piston.
2. Lubricate the piston pin and pin bore with clean engine oil.
3. Install the piston pin in the piston and connecting rod assembly.
4. Install the piston pin retaining clips in the piston.

MATERIAL SPECIFICATIONS

Scheme 722

Scheme 723

Scheme 724

Scheme 725

1. Remove the four fuel rail bolts.
2. Remove the bolts from the fuel pressure regulator (FPR). Remove the fuel rail and injectors as an assembly.
3. Remove the fuel injectors from the fuel rail.
4. Remove and discard the O-ring seals from each fuel injector.
5. Separate the upper and lower intake manifolds. Remove the bolts. Discard the intake manifold gasket.
6. Using a metal surface prep, clean and inspect the upper and lower manifold internal passengers and mating surfaces.
7. Allow the upper and lower intake manifolds to dry completely.

Scheme 726

Scheme 727

1. Position a new lower intake manifold gasket and the upper intake manifold on the lower intake manifold and loosely install the bolts.
2. Tighten the bolts in two stages, using the sequence (Scheme 743) Stage 1: Tighten to 2 Nm (18 lb-in). Stage 2: Tighten to 10 Nm (89 lb-in).
3. Install new O-ring seals on each fuel injector.
4. Install the fuel injectors into the fuel rail.
5. Position the fuel rail. Install the bolts for the FPR sensor.
6. Install the four fuel rail bolts.

SPECIAL TOOLS Aligner, Camshaft Position 303-557 (T96T-6256-B) (2 Req'd) Guides, Connecting Rod 303-442 (T93P-6136-A) Installer, Crankshaft Vibration Damper 303-102 (T74P-6316-B) Installer, Crankshaft Front Seal 303-335 (T88T-6701-A) Compressor, Valve Spring 303-567 (T97P-6565-AH) Compressor Spacer, Valve Spring 303-382 (T91P-6565-AH) Remover/Installer, Cylinder Head 303-572 (T97T-6000-A) Installer, Crankshaft Seal 303-635 Piston Ring Compressor 303-D032 (D81L-6002-C) or equivalent Holding Tool, Crankshaft 303-448 (T93P-6303-A) Modular Engine Lift Bracket 303-F047 (014-00073) or equivalent Installer, Crankshaft Rear Seal 303-518 (T95P-6701-DH) Installer, Crankshaft Rear Seal 303-516 (T95P-6701-BH) Installer, Crankshaft Rear Oil Slinger 303-517 (T95P-6701-CH) Alignment Pins, Cylinder Head 303-1040 (SR-015486)

Scheme 728

Scheme 729

Scheme 730

MATERIAL SPECIFICATIONS

Scheme 731

Scheme 732

Scheme 733

Scheme 734

Scheme 735

Scheme 736

Scheme 737

Scheme 738

Scheme 739

Scheme 740

Scheme 741

Scheme 742

Scheme 743

Scheme 744

Scheme 745

Scheme 746

Scheme 747

Scheme 748

Scheme 749

Scheme 750

Scheme 751

Scheme 752

Scheme 753

Scheme 754

Scheme 755

Scheme 756

Scheme 757

Scheme 758

Scheme 759

Scheme 760

Scheme 761

1. Record the main bearing code found on the front of the engine block.
2. Record the main bearing code found on the back of the crankshaft.
3. Using the data recorded earlier and the Bearing Select Fit Chart, Standard Bearings chart, determine the required bearing grade for each main bearing. Read the first letter of the engine block main bearing code and the first letter of the crankshaft main bearing code. Read down the column below the engine block main bearing code letter, and across the row next to the crankshaft main bearing code letter, until the two intersect. This is the required bearing grade for the number one crankshaft main bearing. As an example, if the engine block code letter is "F" and the crankshaft code letter is "D," the correct bearing grade for this main bearing is a "2." Repeat this process for the remaining four main bearings.
4. If oversize bearings are being used, use the procedure in 3 and the Bearing Select Fit Chart (Scheme 749), Oversize Bearings chart to determine the required bearing grade for each main bearing.
5. Install the crankshaft upper main bearings into the cylinder block and lubricate them with clean engine oil.
6. Install the crankshaft into the cylinder block and onto the upper crankshaft main bearings.
7. Push the crankshaft rearward and install the rear upper crankshaft thrust washer at the back of the No. 6 main boss.
8. Push the crankshaft forward and install the front upper crankshaft thrust washer at the front of the No. 6 main boss.
9. Install the lower crankshaft thrust washer to the back side of the No. 6 main bearing cap, with oil grooves facing the crankshaft surface, and install the No. 6 rear main bearing cap.
10. Install the No. 1 through No. 5 crankshaft lower main bearings into the main bearing caps. Locate the main bearing caps on the cylinder block and, keeping the cap as square as possible, alternately draw the cap down evenly using the cap fasteners.
11. Install the bolts.
12. Install the 10 dowel pins so that the flat sides face the crankshaft. Install the cross-mounted bolts.
13. Tighten fasteners 1 through 12 in two stages, in the sequence (Scheme 751) Stage 1: Tighten to 40 Nm (30 lb-ft). Stage 2: Tighten an additional 90 degrees.
14. Tighten fasteners 13 through 24 in two stages, in the sequence see scheme 461 Stage 1: Tighten to 30 Nm (22 lb-ft). Stage 2: Tighten an additional 90 degrees.
15. Using the special tools, install the piston and connecting rod assembly.
16. Once the connecting rod is seated on the crankshaft journal, remove the connecting rod guide tools.
17. Install the connecting rod bearings, position the connecting rod cap and loosely install the two new bolts.
18. Tighten the connecting rod bolts in the sequence see scheme 463 Stage 1: Tighten to 43 Nm (32 lb-ft). Stage 2: Tighten an additional 105 degrees.
19. Rotate the crankshaft and repeat the procedure to position each connecting rod at bottom dead center until all bolts are tightened to specification.
20. Install the oil filter adapter.
21. Install the front engine support insulators.
22. Position the oil pump and install the bolts loosely. Tighten the bolts in the sequence see scheme 465
23. Rotate the crankshaft to position the keyway at 12 o'clock.
24. Install the head gasket over the dowel pins.
25. Install the special tool.
26. Install the special tool.
27. Install the cylinder head on the head gasket. Remove the special tool and loosely install the bolt.
28. Remove the special tool.
29. Tighten the bolts in the sequence see scheme 472 Stage 1: Tighten to 40 Nm (30 lb-ft). Stage 2: Tighten an additional 90 degrees. Stage 3: Tighten an additional 90 degrees.
30. Position the oil level indicator and install the nut attaching the oil level indicator tube to the front of the engine.
31. Install the bolt attaching the oil level indicator tube to the rear of the engine.
32. Install the left and right exhaust manifold gaskets and exhaust manifolds. Loosely install the nuts. Tighten the nuts in the sequence see scheme 475
33. Compress the tensioner plunger, using a vise.
34. Install a retaining clip on the tensioner to hold the plunger in during installation.
35. Remove the tensioner from the vise.
36. If the copper links are not visible, mark two links on one end and one link on the other end to use as timing marks.
37. Install the timing chain guides.
38. Rotate the LH camshaft sprocket until the timing mark is approximately at 12 o'clock. Rotate the RH camshaft until the timing mark is approximately at 11 o'clock.
39. Position the crankshaft with the special tool.
40. Remove the special tool.
41. Install the crankshaft sprocket, making sure the flange faces forward.
42. Install the lower end of the LH (inner) timing chain, aligning the timing marks.
43. Position the timing chain on the LH camshaft sprocket with the two copper (marked) chain links and the camshaft sprocket timing mark aligned.
44. Position the RH (outer) timing chain on the crankshaft sprocket.
45. Position the RH timing chain on the camshaft sprocket. Make sure the two copper (marked) links align with the camshaft sprocket timing mark.
46. As a post-check, verify timing mark alignment.
47. Position the LH timing chain tensioner arm on the dowel pin and install the LH timing chain tensioner.
48. Remove the retaining clip from the LH timing chain tensioner.
49. Position the RH timing chain tensioner arm on the dowel pin and install the RH timing chain tensioner.
50. Remove the retaining clip from the RH timing chain tensioner.
51. Lubricate the balance shaft journals with clean engine oil.
52. Using the index mark on the balance shaft, mark the corresponding teeth on the gear with chalk.
53. Position the balance shaft on the journals.
54. Align the chalk mark on the balance shaft with the camshaft timing mark (Scheme 763)
55. Install the bearing caps in their original locations and install the bolts. Tighten the bolts in the sequence see scheme 495
56. Position the piston of the cylinder being serviced at the bottom of the stroke and the camshaft lobe at base circle.
57. Install the special tool between the valve spring coils to prevent valve stem seal damage.
58. Install the camshaft roller followers. Install the special tool. Compress the valve spring. Install the camshaft roller followers in their original locations.
59. Position the crankshaft sensor ring.
60. Apply a bead of silicone gasket and sealant along the cylinder head-to-block surface and the oil pan-to-cylinder block surface as specified.
61. Install a new engine front cover gasket onto the engine front cover, then position the engine front cover on the front cover to cylinder block dowel.
62. Tighten the engine front cover fasteners in sequence in two stages. Stage 1: Tighten fasteners 1 through 5 to 25 Nm (18 lb-ft). Stage 2: Tighten fasteners 6 through 15 to 48 Nm (35 lb-ft).
63. Install the belt idler pulley and tighten the bolt.
64. Position the oil pump screen and pickup tube. Install and tighten the spacer. Insert the oil pump screen pickup tube into the oil pump and position the support bracket over the spacer. Install and tighten the bolts.
65. Inspect the oil pan. Clean the mating surface for the oil pan with silicone gasket remover and metal surface prep. Follow the directions on the packaging.
66. Apply silicone gasket and sealant at the rear oil seal retainer-to-cylinder block sealing surface.
67. Apply silicone gasket and sealant at the engine front cover-to-cylinder block sealing surface.
68. Install the oil pan. Tighten the bolts in the sequence (Scheme 769) Stage 1: Tighten to 2 Nm (18 lb-in). Stage 2: Tighten to 20 Nm (15 lb-ft). Stage 3: Tighten an additional 90 degrees.
69. Install the oil drain plug.
70. Install the water pump. Lubricate the new O-ring seal, using engine coolant, and install the O-ring seal onto the coolant pump. Position the coolant pump into the cylinder block. Install the coolant pump retaining bolts.
71. Lubricate the engine front cover and the crankshaft front seal inner lip with clean engine oil.
72. Using the special tool, install the crankshaft front seal.
73. Apply silicone gasket and sealant to the woodruff key slot on the crankshaft pulley.
74. Using the special tool, install the crankshaft pulley.
75. Tighten the crankshaft pulley bolt in four stages. Stage 1: Tighten to 90 Nm (66 lb-ft). Stage 2: Loosen 360 degrees. Stage 3: Tighten to 50 Nm (37 lb-ft). Stage 4: Tighten an additional 90 degrees.
76. Position the coolant pump pulley on the coolant pump and install the bolts.
77. Apply instant gel adhesive completely around the gasket groove in the valve covers. Install the new valve cover gaskets.
78. Apply silicone gasket and sealant in two places where the engine front cover meets the cylinder head.
79. Position the valve covers.
80. Tighten the bolts in the sequence (Scheme 776)
81. Install the engine control sensor wiring harness. Connect all of the harness routing clips and connector retainers.
82. Connect the LH radio frequency interference capacitor and cylinder head temperature (CHT) sensor electrical connectors.
83. Connect the camshaft position (CMP) electrical connector.
84. Connect the RH radio frequency interference capacitor electrical connector.
85. Connect the knock sensor electrical connector, if equipped.
86. Connect the crankshaft position (CKP) sensor electrical connector.
87. Connect the oil pressure switch electrical connector.
88. Attach the special tool.
89. Remove the engine from the engine stand.
90. Inspect the rear seal retainer plate. Clean the mating surface for the rear seal retainer plate with silicone gasket remover and metal surface prep. Follow the directions on the packaging.
91. Apply a 4-mm (0.16-in) bead of silicone gasket and sealant around the rear oil seal retainer sealing surface.
92. Install the retainer plate. Tighten the bolts in two stages. Stage 1: Tighten the retainer plate bolts to 10 Nm (89 lb-in), in the sequence see scheme 525 Stage 2: Tighten the oil pan bolts to 20 Nm (15 lb-ft), then tighten an additional 90 degrees.
93. Using the special tools, install a new crankshaft rear seal.
94. Using the special tools, install the crankshaft rear oil slinger.
95. Install the flexplate in the following sequence.

SPECIAL TOOLS Modular Engine Lift Bracket 303-F047 (014-00073) or equivalent Holding Wrench, Fan Clutch 303-478 (T94T-6312-AH) Holding Wrench, Fan Pulley 303-214 (T83T-6312-B) Installer Set, Teflon Seal 211-D027 (D90P-3517-A) or equivalent

Scheme 762

MATERIAL SPECIFICATION

Scheme 763

Scheme 764

Scheme 765

Scheme 766

Scheme 767

Scheme 768

Scheme 769

Scheme 770

Scheme 771

Scheme 772

Scheme 773

Scheme 774

Scheme 775

Scheme 776

Scheme 777

Scheme 778

Scheme 779

Scheme 780

Scheme 781

Scheme 782

Scheme 783

Scheme 784

Scheme 785

1. Position the engine in the vehicle.
2. Remove the floor crane and the jack supporting the transmission.
3. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/cutaway-e350/2004-2007/remont/hoistjack/#jacking-lifting) .
4. Position the shifter cable support bracket and install the two transmission-to-engine bolts.
5. Install the RH lower transmission-to-engine bolt.
6. Install the shift cable to the mounting bracket and shift linkage.
7. Install four new nuts to retain the torque converter to the flexplate. Rotate the crankshaft to access all of the torque converter nuts.
8. Install the cylinder block opening cover.
9. Install the flexplate inspection cover.
10. Install the four engine mount nuts.
11. Install the starter motor. Position the starter. Install the two bolts. Install the stud bolt.
12. Connect the starter motor electrical connections.
13. Install the starter motor solenoid terminal cover.
14. Mount the exhaust system to the LH and RH exhaust manifolds.
15. Position a new oil cooler on the oil filter adapter and install the threaded insert.
16. Install a new oil filter.
17. Connect the oil cooler hoses.
18. Position the transmission fluid cooler tube support bracket and install the nut.
19. Using the special tool, install a new Teflon® seal on the power steering pressure tube.
20. Connect the power steering pressure tube and the power steering reservoir hose to the power steering pump.
21. Install and tighten the oil drain plug.
22. Position the fuel line and the LH heated oxygen sensor (HO2S) brackets. Install the four upper transmission-to-engine bolts.
23. Connect the transmission wiring harness and the LH and RH HO2S electrical connectors. Install the transmission wiring harness connector retainer in the bracket.
24. Insert the heater outlet tube over the new seals.
25. Install the heater outlet tube studs.
26. Position the transmission fluid filler tube in the vehicle. Connect the HO2S electrical connector.
27. Connect the hose to the heater outlet tube.
28. Install the wiring retainers in the heater outlet tube bracket. Install the knock sensor electrical connector retainer. Install the engine harness routing clip retainer.
29. Connect the evaporative emission canister purge valve electrical connector.
30. Connect the attachments to the transmission fluid filler tube and install the fluid level indicator. Connect the rear heater hose hanger. Install the fluid level indicator.
31. Install the engine oil filler tube support strap bolt.
32. Position the mounting bracket, install the ground strap and nut, and connect the electrical connectors to the bracket.
33. Connect the engine wiring harness electrical connectors.
34. Connect the powertrain control module (PCM) electrical connectors.
35. Connect the engine wiring harness to the PCM bracket.
36. Connect the lower radiator hose to the oil filter adapter coolant inlet.
37. Position the lower radiator support and install the twelve bolts.
38. Install the RH side of the headlamp dash panel junction wiring harness. Connect the electrical connector. Install the screw. Insert the routing clips.
39. Install the LH side of the headlamp dash panel junction wiring harness. Install the screw. Insert the routing clips.
40. Position the RH and LH air deflectors and install the pin-type retainers.
41. Position the upper radiator support and install the eight bolts.
42. Connect the horn electrical connector.
43. Connect the front impact severity sensor electrical connector.
44. If equipped, connect the air temperature sensor electrical connector.
45. Route the battery feed wiring harness to the power distribution box and insert the routing clips.
46. Install the battery feed cable to the power distribution box.
47. Install the power steering reservoir.
48. Install the hood latch. Install the hood latch. Insert the cable routing clip.
49. Install the A/C condenser core. Position the A/C condenser core in the vehicle. Position the A/C condenser brackets. Install the bolts.
50. Connect the condenser core refrigerant tubes. Connect the condenser to evaporator tube. Connect the compressor discharge tube.
51. Connect the compressor suction tube.
52. Connect the A/C pressure cutoff switch electrical connector.
53. Position the radiator in the vehicle.
54. Position the radiator support brackets and install the bolts.
55. Position the fan shroud and the fan and fan clutch in the vehicle, and install the bolts.
56. Insert the degas hose retainer in the fan shroud.
57. Install the fan blade assembly and fan clutch. Install the fan blade and the fan clutch. Using the special tool, hold the coolant pump pulley. Using the special tool, tighten the fan clutch nut.
58. Connect the upper radiator hose and the degas hose to the radiator.
59. Install the valance panel. For additional information, refer to «FRONT END BODY PANELS»(/ford/cutaway-e350/2004-2007/remont/exterior-body-panels/#body-panel-system-front-end-body-panels) .
60. Connect the transmission cooler tubes.
61. Position the splash shield and install the pushpin retainers.
62. Connect the lower radiator hose to the radiator. Connect the hose. Connect the hose hanger.
63. Install the front bumper. For additional information, refer to «BUMPERS»(/ford/cutaway-e350/2004-2007/remont/exterior-body-panels/#bumpers) .
64. Fill the engine with clean engine oil.
65. Install the intake manifold. For additional information, refer to «INTAKE MANIFOLD»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450) .
66. Fill all fluids to the correct levels. Fill the transmission with clean transmission fluid. For additional information, refer to «AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT»(/ford/cutaway-e350/2004-2007/remont/automatic-trans/#automatic-transmission-5r110w-torqshiftr) . Fill the power steering system with clean fluid. For additional information, refer to «STEERING SYSTEM-GENERAL INFORMATION»(/ford/cutaway-e350/2004-2007/remont/manual-power-steering/#steering-system-general-information) .
67. Start the engine and check for leaks. Stop the engine and recheck the fluid levels.
68. Evacuate and recharge the air conditioning system. For additional information, refer to «CLIMATE CONTROL SYSTEM-GENERAL INFORMATION»(/ford/cutaway-e350/2004-2007/remont/general-servicing-all-makes/#hvac-system-climate-control-system-general-information) .

SPECIAL TOOLS Installer, Crankshaft Vibration Damper 303-102 (T74P-6316-B) Installer, Crankshaft Front Oil Seal 303-635 Holding Tool, Crankshaft 303-448 (T93P-6303-A) Remover/Installer, Cylinder Head 303-572 (T97T-6000-A) Engine Lift Bracket Set 303-DS086 (D93P-6001-A) Modular Engine Lift Bracket 303-F047 (014-00073) or equivalent Strap Wrench 303-D055 (D85L-6000-A) Compressor, Valve Spring 303-567 (T97P-6565-AH) Spacer, Valve Spring Compressor 303-382 (T91P-6565-AH) Installer, Crankshaft Front Oil Seal 303-335 (T88T-6701-A) Alignment Pins, Cylinder Head 303-1040 (SR-015486)

Scheme 786

MATERIAL SPECIFICATIONS

Scheme 787

Scheme 788

Scheme 789

Scheme 790

Scheme 791

Scheme 792

Scheme 793

Scheme 794

Scheme 795

Scheme 796

1. Install the head gaskets over the dowel pins.
2. Install the special tool.
3. Remove the special tool and loosely install cylinder head bolts.
4. Tighten the cylinder head bolts in three stages in the sequence see scheme 590 Stage 1: Tighten the bolts to 40 Nm (30 lb-ft). Stage 2: Tighten the bolts an additional 90 degrees. Stage 3: Tighten the bolts an additional 90 degrees.
5. Tighten the cylinder head bolts in three stages in the sequence see scheme 591 Stage 1: Tighten the bolts to 40 Nm (30 lb-ft). Stage 2: Tighten the bolts an additional 90 degrees. Stage 3: Tighten the bolts an additional 90 degrees.
6. Remove the lifting handles from both ends of the cylinder head.
7. Install the hydraulic lash adjusters in their original locations.
8. Using new gaskets, install the RH exhaust manifolds. Tighten the nuts in the sequence see scheme 594
9. Using new gaskets, install the LH exhaust manifold. Tighten the nuts in the sequence see scheme 595
10. Compress the tensioner plunger, using a vise.
11. Install a retaining clip on the tensioner to hold the plunger during installation.
12. Remove the tensioner from the vise.
13. If the copper links are not visible, mark two links on one end and one link on the other end, and use as timing marks.
14. Install the timing chain guides.
15. Preposition the camshafts. Rotate the LH camshaft until the timing mark is approximately at 12 o'clock. Rotate the RH camshaft until the timing mark is approximately at 11 o'clock.
16. Position the crankshaft so the number one cylinder is at TDC with the special tool.
17. Remove the crankshaft holding tool.
18. Install the crankshaft sprocket, making sure the flange faces forward.
19. Position the lower end of the LH (inner) timing chain on the crankshaft sprocket, aligning the timing mark on the outer flange of the crankshaft sprocket with the single copper (marked) link on the chain.
20. Position the timing chain on the camshaft sprocket with the camshaft sprocket timing mark positioned between the two copper (marked) chain links.
21. Position the LH timing chain tensioner arm on the dowel pin and install the LH timing chain tensioner.
22. Remove the retaining clip from the LH timing chain tensioner.
23. Position the lower end of the RH (outer) timing chain on the crankshaft sprocket, aligning the timing mark on the outer flange of the crankshaft sprocket with the single copper (marked) link on the chain.
24. Install the RH timing chain on the camshaft sprocket. Make sure the camshaft sprocket timing mark is positioned between the two copper (marked) chain links.
25. Position the RH timing chain tensioner arm on the dowel pin and install the RH timing chain tensioner.
26. Remove the retaining clip from the RH timing chain tensioner.
27. As a post-check, verify correct alignment of all timing marks.
28. Install the special tool between the valve spring coils to prevent valve stem seal damage.
29. Install the camshaft roller followers. Install the special tool. Compress the valve spring. Install the camshaft roller followers in their original locations.
30. Install the 10 spark plugs. Tighten the spark plugs to 18 Nm (13 lb-ft).
31. Using the index mark on the balance shaft, mark the corresponding gear tooth with chalk.
32. Position the balance shaft on the journals.
33. It may be necessary to use an inspection mirror to see the marks. Align the chalk mark on the balance shaft with the camshaft timing mark see scheme 616
34. Install the bearing caps in their original location. Install the bolts and tighten the bolts in the sequence see scheme 617
35. Install the crankshaft sensor ring on the crankshaft.
36. Apply a bead of silicone gasket and sealant along the cylinder head-to-cylinder block surface and the oil pan-to-cylinder block surface, at the locations see scheme 619
37. Install a new front cover gasket on the engine front cover. Position the engine front cover. Install the fasteners.
38. Tighten the engine front cover fasteners in sequence in three stages. Stage 1: Tighten fasteners 1 through 5 to 25 Nm (18 lb-ft). Stage 2: Tighten fasteners 6 and 7 to 48 Nm (35 lb-ft). Stage 3: Tighten fasteners 8 through 15 to 48 Nm (35 lb-ft).
39. Loosely install the bolts, then tighten in two stages, in the sequence see scheme 622 Stage 1: Tighten to 20 Nm (15 lb-ft). Stage 2: Tighten an additional 90 degrees.
40. Position the belt idler pulley and install the bolt.
41. Lubricate the engine front cover and the crankshaft front seal inner lip with clean engine oil.
42. Using the special tools, install the crankshaft front seal.
43. Apply silicone gasket and sealant to the Woodruff key slot on the crankshaft pulley.
44. Use the special tool to install the crankshaft pulley.
45. Tighten the new crankshaft bolt in four stages. Stage 1: Tighten to 90 Nm (66 lb-ft). Stage 2: Loosen 360 degrees. Stage 3: Tighten to 50 Nm (37 lb-ft). Stage 4: Tighten an additional 90 degrees.
46. Position the coolant pump pulley on the coolant pump and install the bolts.
47. Position the power steering pump and install the bolts.
48. Apply instant gel adhesive completely around the gasket groove in the LH valve cover. Install the new valve cover gasket.
49. Apply silicone gasket and sealant in two places where the engine front cover meets the cylinder head.
50. Position the LH valve cover and gasket on the cylinder head and install the bolts loosely.
51. Tighten the bolts in the sequence see scheme 634
52. Apply instant gel adhesive completely around the gasket groove in the RH valve cover. Install the new valve cover gasket.
53. Apply silicone gasket and sealant in two places where the engine front cover meets the cylinder head.
54. Position the RH valve cover and gasket on the cylinder head and install the bolts loosely.
55. Tighten the bolts in the sequence see scheme 638
56. Position the oil level indicator tube.
57. Install the bolt attaching the oil level indicator tube to the rear of the engine.
58. Install the nut attaching the oil level indicator tube to the front of the engine.
59. Connect the crankcase vent tube to the valve cover.
60. Install the radio frequency interference capacitors.
61. Roughly position the engine control sensor wiring harness and mount it on the valve cover studs.
62. Connect the crankshaft position (CKP) sensor electrical connector.
63. Connect the oil pressure switch electrical connector.
64. Connect the knock sensor electrical connector, if equipped.
65. Connect the RH radio frequency interference capacitor electrical connector.
66. Connect the camshaft position (CMP) sensor electrical connector.
67. Connect the LH radio frequency interference capacitor and cylinder head temperature (CHT) sensor electrical connectors.
68. Install the cylinder block drain plugs.
69. Install the RH engine mount. Tighten the bolts to 63 Nm (46 lb-ft).
70. Install the special tool.
71. Install the special tool.
72. Install the special tool and remove the engine from the work stand.
73. Lower the engine onto wooden blocks.
74. Remove the special tool.
75. Remove the special tool.
76. Install the special tool and raise the engine.
77. Position the flexplate and loosely install the bolts. Tighten the bolts in the sequence see scheme 657
78. Install the engine. For additional information refer to «Engine»(/ford/cutaway-e350/2004-2007/remont/mechanical/#engine-68l-e350-e450).

See also:
• ENGINE SYSTEM-GENERAL INFORMATION
• INTRODUCTION - GASOLINE
• FUEL SYSTEM-GENERAL INFORMATION
• BATTERY, MOUNTING AND CABLES
• INTAKE AIR DISTRIBUTION & FILTERING
• INTERIOR TRIM AND ORNAMENTATION
• ENGINE COOLING
• HEATING & VENTILATION
• GENERATOR AND REGULATOR
• JACKING & LIFTING
• ACCESSORY DRIVE
• AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70W/4R75W
• CLIMATE CONTROL SYSTEM-GENERAL INFORMATION
• BUMPERS
• FRONT END BODY PANELS
• AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT
• STEERING SYSTEM-GENERAL INFORMATION
• CRANKSHAFT PULLEY
