Scheme 50

Scheme 51

The evaporative emission (EVAP) system

1. prevents hydrocarbon emissions from reaching the atmosphere.
2. stores fuel vapors in the evaporative emissions (EVAP) canister that are generated during vehicle operation or hot soak, until they can be consumed by the engine during normal engine operation.
3. routes the stored fuel vapors to the engine during engine operation.
4. is controlled by the powertrain control module (PCM) which uses various sensor inputs to calculate the desired amount of EVAP purge flow. The PCM regulates the purge flow, induced by the application of intake manifold vacuum, by varying the duty cycle applied to the canister purge valve.
5. has an evaporative emission test port for test purposes.

The fuel vapors are routed

1. from the fuel tank through the fuel vapor vent valves.
2. to the evaporative emissions (EVAP) canister through a vapor line.
3. to the engine when the evaporative emission (EVAP) canister purge valve is opened by the powertrain control module (PCM).

The fuel tank pressure (FTP) sensor

1. monitors the pressure levels in the fuel tank.
2. communicates the pressure reading to the PCM during the OBD II leak test.

The evaporative emissions (EVAP) canister

1. is located along the LH frame rail for vehicles with rear fuel tanks or on the rear crossmember for vehicles with a midship fuel tank.
2. contains activated carbon.
3. stores fuel vapors.

The fuel tank filler cap

1. relieves system vacuum below 3.5 kPa (15.09 inches H 2 O).

The canister vent solenoid

1. is normally open.
2. seals the EVAP system for the OBD II leak and pressure tests.
3. is mounted to the EVAP canister.
4. is repaired as a separate item.

The evaporative emission canister purge valve

1. is normally closed.
2. regulates the purging of the EVAP canister.
3. is controlled by the powertrain control module (PCM).

The evaporative emission (EVAP) system test port

1. is located near the EVAP canister purge valve.
2. is used to connect the Evaporative Emission System Leak Tester to the EVAP system.

The stripped chassis

1. test port is separate from the valve.
2. test port is fastened to the transmission fluid indicator tube.

See INTRODUCTION - GASOLINE and/or INTRODUCTION -- 6.0L DIESEL articles.

Special Tool(s)

SPECIAL TOOL Worldwide Diagnostic System (WDS) Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool

Scheme 52

1. Connect the scan tool and select the output test mode.
2. If PID monitors are not active, select PIDs.
3. Select the fuel tank pressure (FTP) and the volts (V) parameter identification (PID) for monitoring.
4. Select the ALL OFF mode.
5. Close the canister vent solenoid by pushing the START button on the scan tool.

SPECIAL TOOL VACUTEC Smoke Machine Fuel EVAP Emissions System Tester 218-0002 or equivalent

Scheme 53

Phase 1 - Leak Verification

1. Connect the Rotunda Smoke Machine Leak Tester to the evaporative emission (EVAP) test port. For additional information, refer to the manufacturer's instructions.
2. Close the canister vent solenoid. For additional information, refer to «CANISTER VENT SOLENOID CLOSING PROCEDURE»(/ford/cutaway-e350/2004-2007/remont/auxiliary-emission-control-systems/#evaporative-emissions) .
3. Using the Rotunda Smoke Machine, pressurize the EVAP system.
4. Monitor the indicator flag on the Smoke Machine Tester. If the measurement is below the indicator flag, the system has passed the leak test and the test procedure is complete. If the measurement is above the indicator flag the system has failed the leak test. Proceed to Phase 2.

Phase 2 - System Leak Check

1. Introduce smoke from the Rotunda Smoke Machine into the EVAP system. For additional information, refer to the manufacturer's instructions.
2. Use the halogen light provided with the Smoke Machine to look for smoke coming from the EVAP system. This will indicate a leak point.
3. Repair any leaks as necessary.
4. Repeat the leak test until the system passes.

SPECIAL TOOL Worldwide Diagnostic System (WDS) Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool

Procedure

Drive Cycle Recommendations

Note. The following procedure is designed to execute and complete the evaporative emission repair verification drive cycle and to clear the Ford P1000, inspection and maintenance (I/M) readiness code. When the ambient air temperature is below 4.4°C (40°F) or above 37.8°C (100°F), or the altitude is above 2,438 meters (8,000 feet), the EVAP monitor will not run. If the P1000 must be cleared in these conditions, the powertrain control module (PCM) must detect them once (twice on some applications) before the EVAP monitor can be bypassed and the P1000 cleared. The EVAP bypassing procedure is described in the following drive cycle.

1. Most OBD II monitors will complete more readily using a steady foot driving style during cruise or acceleration modes. Operating the throttle in a smooth fashion will minimize the time necessary for monitor completion.
2. Fuel tank level should be between one-half and three-quarters full with three-quarters full being the most desirable.
3. The evaporative monitor can only operate during the first 30 minutes of engine operation. When executing the procedure for this monitor, stay in part throttle mode and drive in a smooth fashion to minimize fuel slosh. Drive Cycle Preparation NOTE: For best results, follow each of the following steps as accurately as possible.
4. Install the scan tool. Turn the key ON with the engine OFF. Cycle the key off, then on. Select the appropriate vehicle and engine qualifier. Clear all diagnostic trouble codes (DTCs) and carry out a PCM reset.
5. Begin to monitor the following PIDs: ECT, EVAPDC, FLI (if available) and TP MODE. Press Diagnostic Data Link, PCM, PID/Data monitor and record, press trigger to select each PID, then start.
6. Start the engine without returning the key to the OFF position. Preparation for Monitor Entry WARNING: Strict observance of posted speed limits and attention to driving conditions are mandatory when proceeding through the following drive cycle.
7. Idle the vehicle for 15 seconds. Drive at 64 km/h (40 mph) until the ECT is at least 76.7°C (170°F).
8. Is IAT above 4.4°C (40°F) and below 37.8°C (100°F)? If not, continue with the following steps but note that the EVAP Monitor Bypass portion of the drive cycle (Step 13 ) will be required to bypass the EVAP monitor and clear the P1000.
9. Cruise at 64 km/h (40 mph) for 60 seconds.
10. Cruise at 72 to 104 km/h (45 to 65 mph) for 10 minutes.
11. Bring the vehicle to a stop. Idle with the transmission in DRIVE (for automatic transmission) or NEUTRAL (for manual transmission) for two minutes.
12. Using the scan tool, check for pending codes. Conduct normal repair procedures for any pending code concerns. Rerun any incomplete monitor.
13. Park the vehicle for a minimum of eight hours. Repeat Steps 5 through 12 .

Material

MATERIAL SPECIFICATION

Removal and Installation

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/cutaway-e350/2004-2007/remont/hoistjack/#jacking-lifting) .
2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/cutaway-e350/2004-2007/remont/charging-system/#battery-mounting-and-cables) .
3. Remove the spare tire.
4. Disconnect the evaporative emissions (EVAP) hose and tube.
5. Disconnect the EVAP canister vent solenoid electrical connector and harness retainer.
6. Remove the heat shield bolt.
7. Remove the bolts and the heat shield.
8. Remove the bolts.
9. Disconnect the EVAP tube from the EVAP canister.
10. Separate and remove the EVAP canister from the bracket.
11. To install, reverse the removal procedure. Carry out the evaporative emission system leak test. For additional information, refer to «EVAPORATIVE EMISSION SYSTEM LEAK TEST»(/ford/cutaway-e350/2004-2007/remont/auxiliary-emission-control-systems/#evaporative-emissions) . Carry out the evaporative emission repair verification drive cycle. For additional information, refer to «EVAPORATIVE EMISSION REPAIR VERIFICATION DRIVE CYCLE»(/ford/cutaway-e350/2004-2007/remont/auxiliary-emission-control-systems/#evaporative-emissions) .

Scheme 60

Scheme 61

1. Disconnect the battery ground cable. For additional information refer to «BATTERY, MOUNTING AND CABLES»(/ford/cutaway-e350/2004-2007/remont/charging-system/#battery-mounting-and-cables) .
2. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/cutaway-e350/2004-2007/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) . .
3. Disconnect the evaporative emission (EVAP) canister purge valve electrical connector and the EVAP hoses.
4. Press the tab and remove the EVAP canister purge valve.
5. To install, reverse the removal procedure. Carry out the evaporative emission system leak test. For additional information, refer to «EVAPORATIVE EMISSION SYSTEM LEAK TEST»(/ford/cutaway-e350/2004-2007/remont/auxiliary-emission-control-systems/#evaporative-emissions) . Carry out the evaporative emission repair verification drive cycle. For additional information, refer to «EVAPORATIVE EMISSION REPAIR VERIFICATION DRIVE CYCLE»(/ford/cutaway-e350/2004-2007/remont/auxiliary-emission-control-systems/#evaporative-emissions) .

Scheme 62

1. Remove the fuel tank. For additional information, refer to «FUEL TANK & LINES»(/ford/cutaway-e350/2004-2007/remont/fuel-system/#fuel-tank-fuel-lines) .
2. Remove the fuel vapor vent valve. Disconnect the evaporative emission (EVAP) canister tube. Press down and rotate the fuel vapor vent valve counterclockwise and remove from the fuel tank.
3. To install, reverse the removal procedure. Carry out the evaporative emission system leak test. For additional information, refer to «EVAPORATIVE EMISSION SYSTEM LEAK TEST»(/ford/cutaway-e350/2004-2007/remont/auxiliary-emission-control-systems/#evaporative-emissions) . Carry out the evaporative emission repair verification drive cycle. For additional information, refer to «EVAPORATIVE EMISSION REPAIR VERIFICATION DRIVE CYCLE»(/ford/cutaway-e350/2004-2007/remont/auxiliary-emission-control-systems/#evaporative-emissions) .

Scheme 63

Scheme 64

Scheme 65

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/cutaway-e350/2004-2007/remont/hoistjack/#jacking-lifting) .
2. Disconnect the electrical connector and the hoses and remove the fuel tank pressure sensor.
3. Disconnect the fuel tank pressure sensor electrical connector.
4. Press down and rotate the fuel pressure sensor counterclockwise and remove from the fuel tank. All fuel tanks
5. To install, reverse the removal procedure. Carry out the evaporative emission system leak test. For additional information, refer to «EVAPORATIVE EMISSION SYSTEM LEAK TEST»(/ford/cutaway-e350/2004-2007/remont/auxiliary-emission-control-systems/#evaporative-emissions) . Carry out the evaporative emission repair verification drive cycle. For additional information, refer to «EVAPORATIVE EMISSION REPAIR VERIFICATION DRIVE CYCLE»(/ford/cutaway-e350/2004-2007/remont/auxiliary-emission-control-systems/#evaporative-emissions) .

MATERIAL SPECIFICATION

1. Remove the evaporative emission canister. For additional information, refer to «EVAPORATIVE EMISSION CANISTER»(/ford/cutaway-e350/2004-2007/remont/auxiliary-emission-control-systems/#evaporative-emissions) .
2. Disconnect the electrical connector and the evaporative emissions hose and remove the canister vent solenoid.
3. To install, reverse the removal procedure. Carry out the evaporative emission system leak test. For additional information, refer to «EVAPORATIVE EMISSION SYSTEM LEAK TEST»(/ford/cutaway-e350/2004-2007/remont/auxiliary-emission-control-systems/#evaporative-emissions) . Carry out the evaporative emission repair verification drive cycle. For additional information, refer to «EVAPORATIVE EMISSION REPAIR VERIFICATION DRIVE CYCLE»(/ford/cutaway-e350/2004-2007/remont/auxiliary-emission-control-systems/#evaporative-emissions) .
