Glow Plug System - 6.0l Diesel Models -- E-Series Ford Cutaway E350 Super Duty

MATERIAL SPECIFICATIONS

MATERIAL SPECIFICATIONS

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

Scheme 5

The 6.0L diesel engine uses a glow plug system that preheats air in the combustion chamber to improve cold engine starting.

The glow plug system consists of the following components

1. Glow plugs
2. Glow plug control module
3. PCM
4. Engine Oil Temperature (EOT) sensor
5. Barometric Pressure (BARO) sensor

The glow plug monitor system is part of the On-Board Diagnostic (OBD) System.

The glow plug system is electronically controlled by the PCM. If the oil temperature is below 55°C (131°F), the PCM will energize the glow plugs immediately after the key is placed in the ON position. Then, depending on the readings from the EOT sensor and the BARO sensor, the PCM determines how long the glow plugs will be on.

Scheme 6

The glow plugs are located in the cylinder heads, under the glow plug wiring harness.

The glow plugs are self-regulating. If the engine oil temperature is above 55°C (131°F), the PCM will bulb-check the WAIT TO START lamp but not energize the glow plug relay.

The glow plug ON time varies from 0-120 seconds depending on battery voltage, engine oil temperature and barometric pressure.

The glow plug ON time is independent of the wait to start lamp ON time.

The glow plug control monitor system is designed to find failed glow plugs or failed wiring in the glow plug system.

Refer to the INTRODUCTION - GASOLINE MODELS .

Special Tool(s)

SPECIAL TOOL(S) DESCRIPTION CHART Remover/Installer, Glow Plug Connector 303-1114

Scheme 7

Material

MATERIAL SPECIFICATIONS

Removal

No. 2 glow plug

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. Remove the 6 pushpin retainers and the upper air deflector.
2. Remove the 4 power steering reservoir bracket bolts.
3. Remove the power steering fluid indicator and 3 bolts. Remove the power steering reservoir mounting bracket. Install the power steering fluid indicator and position the power steering reservoir aside.
4. Disconnect the coolant hoses from the Air Cleaner (ACL) outlet pipe.
5. Loosen the clamps and remove the ACL outlet pipe.
6. Disconnect the PCM electrical connectors.
7. Remove the bolt and PCM.
8. Using the Glow Plug Connector Remover/Installer, remove the glow plug harness as needed.
9. Remove the glow plug. No. 7 and 8 glow plugs
10. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/cutaway-e350-super-duty/2008-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation-e-series) .
11. Using the Glow Plug Connector Remover/Installer, remove the glow plug harness as needed.
12. Remove the glow plug. No. 1, 3 and 5 glow plugs
13. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/ford/cutaway-e350-super-duty/2008-2012/remont/hoistjack/#jacking-lifting-e-series) .
14. Using the Glow Plug Connector Remover/Installer, remove the glow plug harness as needed.
15. Remove the glow plug. No. 4 and 6 glow plugs
16. Remove the LH exhaust manifold. For additional information, refer to «ENGINE - 6.0L DIESEL»(/ford/cutaway-e350-super-duty/2008-2012/remont/mechanical/#engine-mechanical-60l-diesel-models-e-series) .
17. Using the Glow Plug Connector Remover/Installer, remove the glow plug harness as needed.
18. Remove the glow plug.

Installation

No. 4 and 6 glow plugs

Scheme 14

Scheme 15

Scheme 16

1. Install the glow plug. Tighten to 19 Nm (168 lb-in).
2. Clean and apply clean engine oil to the O-ring seals prior to installation.
3. Using the Glow Plug Connector Remover/Installer, install the glow plug harness.
4. Install the LH exhaust manifold. For additional information, refer to «ENGINE - 6.0L DIESEL»(/ford/cutaway-e350-super-duty/2008-2012/remont/mechanical/#engine-mechanical-60l-diesel-models-e-series) . No. 1, 3 and 5 glow plugs
5. Install the glow plug. Tighten to 19 Nm (168 lb-in).
6. Clean and apply clean engine oil to the O-ring seals prior to installation.
7. Using the Glow Plug Connector Remover/Installer, install the glow plug harness. No. 7 and 8 glow plugs
8. Install the glow plug. Tighten to 19 Nm (168 lb-in).
9. Clean and apply clean engine oil to the O-ring seals prior to installation.
10. Using the Glow Plug Connector Remover/Installer, install the glow plug harness.
11. Install the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/cutaway-e350-super-duty/2008-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation-e-series) . No. 2 glow plug
12. Install the glow plug. Tighten to 19 Nm (168 lb-in).
13. Clean and apply clean engine oil to the O-ring seals prior to installation.
14. Using the Glow Plug Connector Remover/Installer, install the glow plug harness.
15. Install the PCM and bolt. Tighten to 9 Nm (80 lb-in).
16. Connect the PCM electrical connectors.
17. Install the ACL outlet pipe and tighten the clamps.
18. Connect the coolant hoses to the ACL outlet pipe.
19. Remove the power steering fluid indicator. Position the power steering reservoir mounting bracket. Install the 3 bolts and power steering fluid indicator.
20. Install the 4 power steering reservoir bracket bolts.
21. Position the upper air deflector and install the 6 pushpin retainers.

Scheme 17

PARTS DESCRIPTION CHART

Scheme 18

Scheme 19

1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/cutaway-e350-super-duty/2008-2012/remont/charging-system/#battery-battery-mounting-battery-cables) .
2. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/cutaway-e350-super-duty/2008-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation-e-series) .
3. Remove the 2 nuts for the glow plug module. To install, tighten to 8 Nm (71 lb-in).
4. Position the glow plug module and disconnect the glow plug module electrical connectors. Remove the glow plug module.
5. To install, reverse the removal procedure.

SPECIAL TOOL(S) DESCRIPTION CHART Car/Truck Engine Stand 014-00106 or equivalent Installer, Glow Plug Sleeve 303-763 Remover, Glow Plug Sleeve 303-764 Remover/Installer, Glow Plug Connector 303-1114

Scheme 20

Scheme 21

MATERIAL SPECIFICATIONS

Scheme 22

Scheme 23

Scheme 24

1. Remove the engine from the vehicle. For additional information, refer to «ENGINE - 6.0L DIESEL»(/ford/cutaway-e350-super-duty/2008-2012/remont/mechanical/#engine-mechanical-60l-diesel-models-e-series) .
2. Mount the engine on a Car/Truck Engine Stand.
3. Using the Glow Plug Connector Remover/Installer, remove the glow plug harness.
4. Remove the glow plug(s) as needed.
5. Fill the lower portion of the glow plug sleeve with grease to prevent metal from falling into the cylinder.
6. Thread the Glow Plug Sleeve Remover tap into the glow plug sleeve.
7. Install the Glow Plug Sleeve Remover into the threaded sleeve and tighten. Use a wrench to thread the Glow Plug Sleeve Remover into the sleeve until the sleeve is extracted. Discard the glow plug sleeve.
8. Clean the glow plug bore with a stiff wire brush. Use filtered compressed air to remove foreign material from the glow plug recess.

Scheme 25

Scheme 26

Scheme 27

1. Verify that the glow plug bore is completely clean and dry.
2. Apply threadlock sealant to the new glow plug sleeve in the 2 places shown in illustration.
3. Using the Glow Plug Sleeve Installer, install the glow plug sleeve into the glow plug bore until it bottoms.
4. Clean the glow plug sleeve after installation with a nylon brush and solvent. Make sure threadlock sealant is cleaned out before it hardens.
5. Install the glow plug(s) as needed. Tighten to 19 Nm (168 lb-in).
6. Using the Glow Plug Connector Remover/Installer, install the glow plug harness.
7. Remove the engine from the engine stand.
8. Install the engine in the vehicle. For additional information, refer to «ENGINE - 6.0L DIESEL»(/ford/cutaway-e350-super-duty/2008-2012/remont/mechanical/#engine-mechanical-60l-diesel-models-e-series) .
