Multifunction Electronic Modules -- E-Series — Ford Cutaway E350 Super Duty (2008-2012)

TORQUE SPECIFICATIONS

Description	Nm
Smart Junction Box (SJB) nuts	5

TORQUE SPECIFICATIONS

Module Controlled Functions

Note. The Smart Junction Box (SJB) is also known as the Generic Electronic Module (GEM).

The SJB is the only multifunction electronic module on this vehicle.

Smart Junction Box (SJB)

Note. The time out for the battery saver relay and the accessory delay relay (both are controlled by the SJB ) is one minute if the vehicle has less than 80 km (50 miles). Once the vehicle passes the approximate mileage threshold of 80 km (50 miles), the time out for both relays is 10 minutes, as described by the Owner's Literature. For the battery saver relay, refer to INTERIOR LIGHTING . For the accessory delay relay, refer to GLASS, FRAMES AND MECHANISMS .

The SJB controls and provides diagnostic information for the following

Battery saver function
Delayed accessory function
Exterior lighting
Horn
Interior lighting
Power door locks
Remote Keyless Entry (RKE) system/keyless entry keypad
Tire Pressure Monitoring System (TPMS)

The SJB controls multiple vehicle systems including

Locking and unlocking all of the doors
Panic alarm function (horn sounding and parking lamps flashing intermittently in regular intervals)
Single horn chirp confirmation when the lock button is pressed on the RKE transmitter twice within 3 seconds and all of the doors are closed, double horn chirp confirmation if one or more doors are open
Single flash of the parking lamps when the lock button is pressed on the RKE transmitter with all of the doors closed. There is no parking lamp flash if the RKE transmitter LOCK button is pressed and one or more doors are ajar
Turning on the interior lamps when the doors are unlocked using an RKE transmitter
TPMS

The SJB also monitors the door ajar signals to determine if a single (all doors are closed) or double (one or more doors are ajar) horn chirp confirmation is necessary when locking the doors using the RKE transmitter. Also, if all of the doors are closed and the doors are locked using the RKE transmitter, the SJB turns off the interior lamps. If one or more doors are detected open by the door ajar switches, the SJB does not turn off the interior lamps.

Post Crash Alert

With the post crash alert function, if the Restraints Control Module (RCM) determines an impact of severity enough to deploy air bags has occurred (the air bags may or may not be deployed by the RCM ), the RCM sends a message to the IPC over the High Speed Controller Area Network (HS-CAN), which sends the message to the SJB over the Medium Speed Controller Area Network (MS-CAN). The SJB then activates the post crash alert function by cycling the horn on 3 times, then off for 4 seconds, then on 3 times, etc., in this cycle until the battery dies or the function is turned off. The hazard lights also flashes with the horn sounding, but keeps flashing during the horn off cycle.

The post crash alert function can be turned off by

pressing the hazard switch (may need to be pressed more than once).
pressing the RKE transmitter UNLOCK button.
pressing the RKE transmitter PANIC button (may need to be pressed more than once).

This feature acts similar to a perimeter alarm, but the horn cycle is different. The perimeter alarm function cycles the horn on and off, in regular intervals until 2 minutes and 45 seconds have elapsed, the battery dies or the function is turned off. Turning the ignition to the ON position does not deactivate this function.

This vehicle does not have a perimeter alarm.

The post crash alert function cannot be configured off.

Welcome/Farewell Strategy

The welcome/farewell strategy is controlled by the SJB . Please refer to the table below for the new strategy.

Feature	Turn Signals	Headlamps	Park Lamps	Puddle Lamps	Interior (Courtesy) Lamps	Backlighting (Dimmable)
Locking Feedback Lighting	Lock causes a single 400 ms flash. Unlock causes a single long flash.	N/A	N/A	N/A	N/A	N/A
Illuminated Entry (includes Perimeter Lighting)	N/A	Off	On	On	On	On
Interior (Courtesy) Lighting	N/A	Off	On	On	On	On
Interior (Courtesy) Lighting Delay	N/A	Off	On	On	On	On
Illuminated Exit	N/A	Off	On	Off	On	On

NEW WELCOME/FAREWELL STRATEGY

Diagnostic Trouble Code (DTC) Chart

Note. Most powertrain (P-code) DTCs are diagnosed in the INTRODUCTION - GASOLINE MODELS . If the P-code retrieved is not listed below, refer to the INTRODUCTION - GASOLINE MODELS to continue diagnostics.

Note. The Smart Junction Box (SJB) is also known as the Generic Electronic Module (GEM).

Note. Some of these modules utilize a 5-character DTC followed by a 2-character failure-type code. The failure-type code provides information about specific fault conditions such as opens, or shorts to ground. Continuous memory DTCs have an additional 2-character DTC status code suffix to assist in determining DTC history.

DTC	Description	Source	Action
B0001:11	Driver Frontal Stage 1 Deployment Control: Circuit Short To Ground	Restraints Control Module (RCM)	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0001:12	Driver Frontal Stage 1 Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0001:13	Driver Frontal Stage 1 Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0001:1A	Driver Frontal Stage 1 Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0001:2B	Driver Frontal Stage 1 Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0001:4A	Driver Frontal Stage 1 Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:11	Driver Frontal Stage 2 Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:12	Driver Frontal Stage 2 Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:13	Driver Frontal Stage 2 Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:1A	Driver Frontal Stage 2 Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:2B	Driver Frontal Stage 2 Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:4A	Driver Frontal Stage 2 Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0005:11	Collapsible Steering Column Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0005:12	Collapsible Steering Column Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0005:13	Collapsible Steering Column Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0005:1A	Collapsible Steering Column Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0005:2B	Collapsible Steering Column Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0005:4A	Collapsible Steering Column Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:11	Passenger Frontal Stage 1 Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:12	Passenger Frontal Stage 1 Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:13	Passenger Frontal Stage 1 Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:1A	Passenger Frontal Stage 1 Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:2B	Passenger Frontal Stage 1 Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:4A	Passenger Frontal Stage 1 Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0021:11	Left Curtain Deployment Control 1: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0021:12	Left Curtain Deployment Control 1: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0021:13	Left Curtain Deployment Control 1: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0021:1A	Left Curtain Deployment Control 1: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0021:2B	Left Curtain Deployment Control 1: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0021:4A	Left Curtain Deployment Control 1: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:11	Driver Seatbelt Sensor: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:12	Driver Seatbelt Sensor: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:13	Driver Seatbelt Sensor: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:1D	Driver Seatbelt Sensor: Circuit Current Out Of Range	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:2B	Driver Seatbelt Sensor: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:4A	Driver Seatbelt Sensor: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0080:11	Driver Seatbelt Load Limiter Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0080:12	Driver Seatbelt Load Limiter Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0080:13	Driver Seatbelt Load Limiter Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0080:1A	Driver Seatbelt Load Limiter Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0080:2B	Driver Seatbelt Load Limiter Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0080:4A	Driver Seatbelt Load Limiter Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0082:11	Passenger Seatbelt Load Limiter Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0082:12	Passenger Seatbelt Load Limiter Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0082:13	Passenger Seatbelt Load Limiter Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0082:1A	Passenger Seatbelt Load Limiter Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0082:2B	Passenger Seatbelt Load Limiter Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0082:4A	Passenger Seatbelt Load Limiter Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:11	Left Frontal Restraints Sensor: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:4A	Left Frontal Restraints Sensor: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:81	Left Frontal Restraints Sensor: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:93	Left Frontal Restraints Sensor: No Operation	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:96	Left Frontal Restraints Sensor: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:11	Right Frontal Restraints Sensor: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:4A	Right Frontal Restraints Sensor: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:81	Right Frontal Restraints Sensor: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:93	Right Frontal Restraints Sensor: No Operation	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:96	Right Frontal Restraints Sensor: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:09	Occupant Classification System: Component Failures	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:4A	Occupant Classification System: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:63	Occupant Classification System: Circuit/Component Protection Time-Out	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:64	Occupant Classification System: Signal Plausibility Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:68	Occupant Classification System: Event Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00D5:11	Restraint System Passenger Disable Indicator: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00D5:12	Restraint System Passenger Disable Indicator: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00D5:13	Restraint System Passenger Disable Indicator: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00D5:4A	Restraint System Passenger Disable Indicator: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00DF:11	Passenger Restraints Disable Switch: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00DF:12	Passenger Restraints Disable Switch: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00DF:13	Passenger Restraints Disable Switch: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00DF:1D	Passenger Restraints Disable Switch: Circuit Current Out Of Range	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00DF:2B	Passenger Restraints Disable Switch: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00DF:4A	Passenger Restraints Disable Switch: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1031	SDARS Satellite Antenna Open	Satellite Digital Audio Receiver System (SDARS) module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1032	SDARS Satellite Antenna Short	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B106A	TPMS Sensor Pressure Range Bit Incorrect State	Smart Junction Box (SJB)	REFER to WHEELS & TIRES .
B106B	Tire Pressure Sensor Low Battery	SJB	REFER to WHEELS & TIRES .
B106D	Tire Pressure Monitor System (TPMS) Initiators Not Configured	SJB	REFER to WHEELS & TIRES .
B106E	Solid State Driver Disabled Due to Short Circuit	SJB	REFER to SMART JUNCTION BOX (SJB) .
B106F	Module Disabled Due to External Fault	SJB	REFER to SMART JUNCTION BOX (SJB) .
B109E:42	Remote Keyless Entry: General Memory Failure	Instrument Panel Cluster (IPC)	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B109E:51	Remote Keyless Entry: Not Programmed	IPC	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B109E:86	Remote Keyless Entry: Signal Invalid	IPC	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B10D5:13	PATS Antenna: Circuit Open	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D7:05	PATS Key: System Programming Failures	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D7:51	PATS Key: Not Programmed	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D7:55	PATS Key: Not Configured	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D7:87	PATS Key: Missing Message	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D7:8F	PATS Key: Erratic	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D8:00	PATS Key Less Than Minimum Programmed: No Sub Type Information	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D9:87	PATS Transponder: Missing Message	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10DA:51	PATS PCM Identifier: Not Programmed	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10DA:61	PATS PCM Identifier: Signal Calculation Failure	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10DA:86	PATS PCM Identifier: Signal Invalid	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1104	Steering Angle Sensor Signal Error	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1117	Audio Steering Wheel Button Stuck	Audio Control Module (ACM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1193:00	Crash Event Storage Full and Locked: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B119F:01	GPS Antenna: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B119F:13	GPS Antenna: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B11BA:1C	Steering Wheel Audio Switch Pack: Circuit Voltage Out Of Range	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B11BA:63	Steering Wheel Audio Switch Pack: Circuit/Component Protection Time-Out	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B11CD:11	Driver Frontal Airbag Canister Vent: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B11CD:12	Driver Frontal Airbag Canister Vent: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B11CD:13	Driver Frontal Airbag Canister Vent: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B11CD:1A	Driver Frontal Airbag Canister Vent: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B11CD:2B	Driver Frontal Airbag Canister Vent: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B11CD:4A	Driver Frontal Airbag Canister Vent: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1201:1C	Steering Wheel Audio Switch Pack 2: Circuit Voltage Out Of Range	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1201:1C	Steering Wheel Audio Switch Pack 2: Circuit Voltage Out Of Range	Accessory Protocol Interface Module (APIM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1201:63	Steering Wheel Audio Switch Pack 2: Circuit/Component Protection Time-Out	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1201:63	Steering Wheel Audio Switch Pack 2: Circuit/Component Protection Time-Out	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1211:11	Driver Seatbelt Retractor Pretensioner Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1211:12	Driver Seatbelt Retractor Pretensioner Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1211:13	Driver Seatbelt Retractor Pretensioner Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1211:1D	Driver Seatbelt Retractor Pretensioner Deployment Control: Circuit Current Out Of Range	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1211:2B	Driver Seatbelt Retractor Pretensioner Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1211:4A	Driver Seatbelt Retractor Pretensioner Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:11	Driver Seatbelt Buckle Pretensioner Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:12	Driver Seatbelt Buckle Pretensioner Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:13	Driver Seatbelt Buckle Pretensioner Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:1A	Driver Seatbelt Buckle Pretensioner Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:2B	Driver Seatbelt Buckle Pretensioner Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:4A	Driver Seatbelt Buckle Pretensioner Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:11	Passenger Seatbelt Buckle Pretensioner Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:12	Passenger Seatbelt Buckle Pretensioner Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:13	Passenger Seatbelt Buckle Pretensioner Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:1A	Passenger Seatbelt Buckle Pretensioner Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:2B	Passenger Seatbelt Buckle Pretensioner Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:4A	Passenger Seatbelt Buckle Pretensioner Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B121C:01	Hard Drive: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1252:04	USB Port: System Internal Failures	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1252:11	USB Port: Circuit Short To Ground	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1299	Power Supply Sensor Circuit Short to Ground	Parking Aid Module (PAM)	REFER to PARKING AID -- E-SERIES .
B12B8:04	USB Port #2: System Internal Failures	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B12B8:11	USB Port #2: Circuit Short To Ground	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1302	Accessory Delay Relay Coil Circuit Failure	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B1304	Accessory Delay Relay Coil Circuit Short to Battery	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B1317	Battery Voltage High	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1317	Battery Voltage High	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1317	Battery Voltage High	Trailer Brake Control (TBC) module	REFER to AUXILIARY BRAKE SYSTEM -- E-SERIES .
B1318	Battery Voltage Low	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1318	Battery Voltage Low	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1318	Battery Voltage Low	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1318	Battery Voltage Low	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1318	Battery Voltage Low	TBC module	REFER to AUXILIARY BRAKE SYSTEM -- E-SERIES .
B1320	Driver Door Ajar Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1328	Passenger Door Ajar Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1336	Door Ajar RR Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1342	ECU Is Faulted	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1342	ECU Is Faulted	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1342	ECU Is Faulted	PAM	REFER to PARKING AID -- E-SERIES .
B1342	ECU Is Faulted	PCM	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new PCM. REFER to ELECTRONIC ENGINE CONTROLS - GASOLINE ENGINES or ELECTRONIC ENGINE CONTROLS - DIESEL ENGINE .
B1342	ECU Is Faulted	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1342	ECU is Faulted	SJB	DIAGNOSE all other DTCs first. If no other DTCs are present, INSTALL a new SJB . REFER to SMART JUNCTION BOX (SJB) . TEST the system for normal operation.
B1342	ECU Is Faulted	TBC module	REFER to AUXILIARY BRAKE SYSTEM -- E-SERIES .
B1352	Ignition Key-In Circuit Failure	SJB	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1472	Lamp Headlamp Input Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B1485	Brake Pedal Input Short to Battery	SJB	REFER to EXTERIOR LIGHTING .
B1510	Flash to Pass Switch Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B1572	Door Ajar LR Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1578	Lamp Park Input Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B1685	Lamp Dome Input Circuit Failure	SJB	REFER to INTERIOR LIGHTING .
B1688	Lamp Dome Input Circuit Short to Ground	SJB	REFER to INTERIOR LIGHTING .
B1863	Ground ECU Circuit Open	TBC module	REFER to AUXILIARY BRAKE SYSTEM -- E-SERIES .
B1A01:01	Speaker #1: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:01	Speaker #2: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:01	Speaker #3: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:01	Speaker #4: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:01	Speaker #5: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:01	Speaker #6: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A07:01	Speaker #7: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A56:21	Antenna: Signal Amplitude	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A81:09	Internal Trip Switch: Component Failures	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1A89:01	Satellite Antenna: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A89:13	Satellite Antenna: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D19:49	Compact Disc Unit: Internal Electronic Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D19:4B	Compact Disc Unit: Over Temperature	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D78:13	Auxiliary Input: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D79:01	Microphone Input: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D79:01	Microphone Input: General Electrical Failure	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2044	Left Rear Stop Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2045	Left Rear Stop Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2046	Right Rear Stop Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2047	Right Rear Stop Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2048	Left Rear Turn Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2049	Left Rear Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2050	Right Rear Turn Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2051	Right Rear Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2071	Hazard Switch Signal Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2103	Antenna Not Connected	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2212	Panel Dim Switch Out of Range	SJB	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B2274	Phone Transceiver Active Circuit Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2276	Less Than 2 Transmitters Programmed	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2281	Right Turn Switch Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2282	Left Turn Switch Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2384	Audio Reverse Aid Mute Input Ckt. Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2404	Audio Steering Wheel Switch Circuit Fault	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2405	Audio Disc CD Player Thermal Shutdown Fault	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2406	Audio Disc CD Player Internal Fault	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2425	Remote Keyless Entry Out Of Synchronization	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2477	Module Configuration Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B2477	Module Configuration Failure	ACM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	PAM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	SDARS module	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	SJB	REFER to MODULE CONFIGURATION .
B2479	Park Brake Switch Circuit Short to Ground	SJB	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B2498	Headlamp Switch Multiple Signals Input Active	SJB	REFER to EXTERIOR LIGHTING .
B2572	Brake Shift Interlock Output Circuit Failure	SJB	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS .
B2844	Ignition Fault	SJB	REFER to STEERING COLUMN SWITCHES .
B2868	Left Front Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2869	Right Front Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2870	Right Rear Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2871	Left Rear Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2872	Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B287A	Tire Pressure System Fault	SJB	REFER to WHEELS & TIRES .
B2900	VIN Mismatch	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B2924	Audio Button Stuck	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2965	Audio System Speaker Circuit Fault	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2A20	Ignition Stuck In START	SJB	REFER to STEERING COLUMN SWITCHES .
B2A21	One or More Configuration Files Missing Or Corrupt	SJB	REFER to MODULE CONFIGURATION .
B2A22	Headlamp OFF Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A23	High Beam Input Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A24	Turn Signal Input Circuit Failure	SJB	REFER to EXTERIOR LIGHTING .
B2A25	Trim Panel Lock Switch Circuit Failure	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2A27	Right Front Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A28	Right Front Turn Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A29	Left Front Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A2A	Left Front Turn Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A2E	Right Front Lamp Low Beam Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A2F	Right Front Lamp Low Beam Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A30	Left Front Lamp Low Beam Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A31	Left Front Lamp Low Beam Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A32	LED Backlighting Output Circuit Open	SJB	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B2A33	LED Backlighting Output Circuit Short To Ground	SJB	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B2A35	Interior Lighting Output Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B2A36	Interior Lighting Output Circuit Short To Ground	SJB	REFER to INTERIOR LIGHTING .
C1001:01	Vision System Camera: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
C1095	ABS Hydraulic Pump Motor Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1096	ABS Hydraulic Pump Motor Circuit Open	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C110A	ABS Active Circuit Short to Battery	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1115	ABS Power Relay Output Short Circuit to Battery	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1125	Brake Fluid Level Sensor Input Circuit Failure	SJB	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
C1145	Speed Wheel Sensor RF Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1155	Speed Wheel Sensor LF Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1165	Speed Wheel Sensor RR Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1175	Speed Wheel Sensor LR Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1185	ABS Power Relay Output Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1194	ABS Outlet Valve Coil LF Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1198	ABS Inlet Valve Coil LF Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1210	ABS Outlet Valve Coil RF Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1214	ABS Inlet Valve Coil RF Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1222	Speed Wheel Mismatch	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1233	Speed Wheel LF Input Signal Missing	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1234	Speed Wheel RF Input Signal Missing	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1235	Speed Wheel RR Input Signal Missing	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1236	Speed Wheel LR Input Signal Missing	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1237	Speed Wheel Rear Input Signal Missing	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1242	ABS Outlet Valve Coil LR Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1246	ABS Outlet Valve Coil RR Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1250	ABS Inlet Valve Coil LR Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1254	ABS Inlet Valve Coil RR Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1277	Steering Wheel Angle 1 and 2 Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1278	Steering Wheel Angle 1 and 2 Signal Faulted	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1280	Yaw Rate Sensor Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1282	Lateral Accelerometer Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1288	Pressure Transducer Main/Primary Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1329	ABS Outlet Valve Coil RF Circuit Excessive Temperature	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1330	ABS Outlet Valve Coil LR Circuit Excessive Temperature	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1331	ABS Outlet Valve Coil RR Circuit Excessive Temperature	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1332	ABS Outlet Valve Coil LF Circuit Excessive Temperature	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1333	ABS Inlet Valve Coil LR Circuit Excessive Temperature	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1334	ABS Inlet Valve Coil LF Circuit Excessive Temperature	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1335	ABS Inlet Valve Coil RF Circuit Excessive Temperature	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1336	ABS Inlet Valve Coil RR Circuit Excessive Temperature	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1404	Traction Control Valve Rear Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1410	Traction Control Valve LF Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1446	Brake Switch Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1516	Roll Rate Sensor Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1527	Traction Control Rear Valve Circuit Excessive Temperature	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1528	Traction Control LF Valve Circuit Excessive Temperature	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1530	Dynamic Stability Control RF Valve Circuit Excessive Temperature	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1531	Dynamic Stability Control LF Valve Circuit Excessive Temperature	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1699	Left Rear Sensor Circuit Short to Vbat	PAM	REFER to PARKING AID -- E-SERIES .
C1700	Left Rear Sensor Circuit Failure or Blockage	PAM	REFER to PARKING AID -- E-SERIES .
C1701	Left Rear Sensor Circuit Fault	PAM	REFER to PARKING AID -- E-SERIES .
C1702	Right Rear Sensor Circuit Short to Vbat	PAM	REFER to PARKING AID -- E-SERIES .
C1703	Right Rear Sensor Circuit Failure or Blockage	PAM	REFER to PARKING AID -- E-SERIES .
C1704	Right Rear Sensor Circuit Fault	PAM	REFER to PARKING AID -- E-SERIES .
C1705	Left Rear Center Sensor Circuit Short to Vbat	PAM	REFER to PARKING AID -- E-SERIES .
C1706	Left Rear Center Sensor Circuit Failure	PAM	REFER to PARKING AID -- E-SERIES .
C1707	Left Rear Center Sensor Circuit Fault	PAM	REFER to PARKING AID -- E-SERIES .
C1708	Right Rear Center Sensor Circuit Short to Vbat	PAM	REFER to PARKING AID -- E-SERIES .
C1709	Right Rear Center Sensor Circuit Failure	PAM	REFER to PARKING AID -- E-SERIES .
C1710	Right Rear Center Sensor Circuit Fault	PAM	REFER to PARKING AID -- E-SERIES .
C1730	Reference Voltage Out of Range (+5 v)	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1742	Rear Sounder Circuit Failure	PAM	REFER to PARKING AID -- E-SERIES .
C1743	Rear Sounder Circuit Short to Vbatt	PAM	REFER to PARKING AID -- E-SERIES .
C1957	Dynamic Stability Control Valve RF Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1958	Dynamic Stability Control Valve LF Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1963	Stability Control Inhibit Warning	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1991	Module Calibration Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1992	Vehicle Speed Circuit Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
C2770	Longitudinal Acceleration Sensor Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C2780	ECU In Manufacturer Sub-State	SJB	REFER to WHEELS & TIRES .
C279A	Invalid Brake Pressure Transducer Pressure Input Received	TBC module	REFER to AUXILIARY BRAKE SYSTEM -- E-SERIES .
C2806	Trailer Brake Output Circuit Short to Vbatt	TBC module	REFER to AUXILIARY BRAKE SYSTEM -- E-SERIES .
C2807	Trailer Brakes Wiring Circuit Short to Ground	TBC module	REFER to AUXILIARY BRAKE SYSTEM -- E-SERIES .
P0102	Mass or Volume Air Flow A Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0103	Mass or Volume Air Flow A Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0112	Intake Air Temperature Sensor 1 Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0113	Intake Air Temperature Sensor 1 Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0114	Intake Air Temperature Sensor 1 Intermittent/Erratic	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0116	Engine Coolant Temperature Sensor 1 Circuit Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0117	Engine Coolant Temperature Sensor 1 Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0118	Engine Coolant Temperature Sensor 1 Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0121	Throttle/Pedal Position Sensor A Circuit Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0122	Throttle/Pedal Position Sensor A Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0123	Throttle/Pedal Position Sensor A Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0300	Random Misfire Detected	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0301	Cylinder 1 Misfire Detected	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0302	Cylinder 2 Misfire Detected	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0303	Cylinder 3 Misfire Detected	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0304	Cylinder 4 Misfire Detected	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0305	Cylinder 5 Misfire Detected	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0306	Cylinder 6 Misfire Detected	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0307	Cylinder 7 Misfire Detected	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0308	Cylinder 8 Misfire Detected	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0320	Ignition/Distributor Engine Speed Input Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0340	Camshaft Position Sensor A Circuit (Bank 1 or Single Sensor)	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0460:11	Fuel Level Sensor A Circuit: Circuit Short To Ground	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P0460:13	Fuel Level Sensor A Circuit: Circuit Open	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P0500	Vehicle Speed Sensor A	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0503	Vehicle Speed Sensor A Intermittent/Erratic/High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0512	Starter Request Circuit	PCM	REFER to STARTING SYSTEM - GASOLINE ENGINES .
P0563	System Voltage High	PCM	REFER to CHARGING SYSTEM .
P0565	Cruise Control ON Signal	PCM	REFER to CRUISE CONTROL .
P0566	Cruise Control OFF Signal	PCM	REFER to CRUISE CONTROL .
P0567	Cruise Control RESUME Signal	PCM	REFER to CRUISE CONTROL .
P0568	Cruise Control SET Signal	PCM	REFER to CRUISE CONTROL .
P0569	Cruise Control COAST Signal	PCM	REFER to CRUISE CONTROL .
P0572	Brake Switch A Circuit Low	PCM	REFER to CRUISE CONTROL .
P0573	Brake Switch A Circuit High	PCM	REFER to CRUISE CONTROL .
P0578	Cruise Control Multi-Function Input A Circuit Stuck	PCM	REFER to CRUISE CONTROL .
P0579	Cruise Control Multi-Function Input A Circuit Range/Performance	PCM	REFER to CRUISE CONTROL .
P0581	Cruise Control Multi-Function Input A Circuit High	PCM	REFER to CRUISE CONTROL .
P0602	Powertrain Control Module Programming Error	PCM	REFER to MODULE CONFIGURATION .
P0605	Internal Control Module Read Only Memory (ROM) Error	PCM	REFER to MODULE CONFIGURATION .
P0620	Generator Control Circuit	PCM	REFER to CHARGING SYSTEM .
P0623	Generator Lamp Control Circuit	PCM	REFER to CHARGING SYSTEM .
P0623:11	Generator Lamp Control Circuit: Circuit Short To Ground	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P0623:13	Generator Lamp Control Circuit: Circuit Open	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P0623:16	Generator Lamp Control Circuit: Circuit Voltage Below Threshold	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P0623:17	Generator Lamp Control Circuit: Circuit Voltage Above Threshold	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P0625	Generator Field Terminal Circuit Low	PCM	REFER to CHARGING SYSTEM .
P0626	Generator Field Terminal Circuit High	PCM	REFER to CHARGING SYSTEM .
P062F	Internal Control Module EEPROM Error	SJB	REFER to SMART JUNCTION BOX (SJB) .
P0645	Air Conditioning Clutch Relay (A/CCR) Control Circuit	PCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
P0657	Actuator Supply Voltage A Circuit/Open	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P065B	Generator Control Circuit Range/Performance	PCM	REFER to CHARGING SYSTEM .
P0700	Transmission Control System (MIL Request)	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0705	Transmission Range Sensor A Circuit (PRNDL Input)	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0706	Transmission Range Sensor A Circuit Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0708	Transmission Range Sensor A Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0710	Transmission Fluid Temperature Sensor A Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0711	Transmission Fluid Temperature Sensor A Circuit Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0712	Transmission Fluid Temperature Sensor A Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0713	Transmission Fluid Temperature Sensor A Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0715	Turbine/Input Shaft Speed Sensor A Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0717	Turbine/Input Shaft Speed Sensor A Circuit No Signal	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0718	Turbine/Input Shaft Speed Sensor A Circuit Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0720	Output Shaft Speed Sensor Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0721	Output Shaft Speed Sensor Circuit Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0722	Output Shaft Speed Sensor Circuit No Signal	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0730	Incorrect Gear Ratio	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0731	Gear 1 Incorrect Ratio	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0732	Gear 2 Incorrect Ratio	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0733	Gear 3 Incorrect Ratio	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0734	Gear 4 Incorrect Ratio	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0740	Torque Converter Clutch Solenoid Circuit/Open	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0741	Torque Converter Clutch Solenoid Circuit Performance Or Stuck Off	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0742	Torque Converter Clutch Solenoid Circuit Stuck On	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0743	Torque Converter Clutch Solenoid Circuit Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0744	Torque Converter Clutch Solenoid Circuit Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0748	Pressure Control Solenoid A Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0750	Shift Solenoid A	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0751	Shift Solenoid A Performance or Stuck Off	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0752	Shift Solenoid A Stuck On	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0753	Shift Solenoid A Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0755	Shift Solenoid B	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0756	Shift Solenoid B Performance or Stuck Off	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0757	Shift Solenoid B Stuck On	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0758	Shift Solenoid B Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0760	Shift Solenoid C	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0761	Shift Solenoid C Performance or Stuck Off	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0762	Shift Solenoid C Stuck On	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0763	Shift Solenoid C Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0765	Shift Solenoid D	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0766	Shift Solenoid D Performance or Stuck Off	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0767	Shift Solenoid D Stuck On	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0768	Shift Solenoid D Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0770	Shift Solenoid E	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0771	Shift Solenoid E Performance or Stuck Off	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0772	Shift Solenoid E Stuck On	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0773	Shift Solenoid E Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0781	1-2 Shift	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0782	2-3 Shift	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0783	3-4 Shift	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0791	Intermediate Shaft Speed Sensor A Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0793	Intermediate Shaft Speed Sensor A Circuit No Signal	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0794	Intermediate Shaft Speed Sensor A Circuit Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0812:12	Reverse Input Circuit: Circuit Short To Battery	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
P0960	Pressure Control Solenoid A Control Circuit/Open	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0962	Pressure Control Solenoid A Control Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0963	Pressure Control Solenoid A Control Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P0973	Shift Solenoid A Control Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0974	Shift Solenoid A Control Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0976	Shift Solenoid B Control Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0977	Shift Solenoid B Control Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0979	Shift Solenoid C Control Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0980	Shift Solenoid C Control Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0982	Shift Solenoid C Control Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0983	Shift Solenoid D Control Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0985	Shift Solenoid E Control Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P0986	Shift Solenoid E Control Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P1100	Mass Air Flow Sensor Circuit Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1101	Mass Air Flow Sensor Out Of Self Test Range	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1116	Engine Coolant Temperature Sensor Out Of Self Test Range	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1120	Throttle Position Sensor A Out Of Range Low (Ratch Too Low)	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1121	Throttle Position Sensor A Inconsistent With MAF/MAP Sensor	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P1124	Throttle Position Sensor A Out Of Self Test Range	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E or AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P1125	Throttle Position Sensor A Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P1148	Generator 2 Control Circuit	PCM	REFER to CHARGING SYSTEM .
P1149	Generator 2 Monitor Circuit High	PCM	REFER to CHARGING SYSTEM .
P1260	Theft Detected, Vehicle Immobilized	PCM	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
P1351	Ignition Diagnostic Monitor Input Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1352	Ignition Coil A Primary Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1353	Ignition Coil B Primary Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1354	Ignition Coil C Primary Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1355	Ignition Coil D Primary Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1356	Ignition Diagnostic Monitor Indicates Engine Not Turning	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1357	Ignition Diagnostic Monitor Pulsewidth Not Defined	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1358	Ignition Diagnostic Monitor Signal Out Of Self Test Range (No CPU OK)	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1359	Spark Output Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1360	Ignition Coil A Secondary Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1361	Ignition Coil B Secondary Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1362	Ignition Coil C Secondary Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1363	Ignition Coil D Secondary Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1364	Ignition Coil Primary Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1397	System Voltage Out Of Self Test Range	PCM	REFER to CHARGING SYSTEM .
P1460	Wide Open Throttle A/C Cutout Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E or AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P1464	A/C Demand Out Of Self Test Range	PCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
P1502	Vehicle Speed Sensor Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1534:01	Restraint Deployment Indicator Circuit: General Electrical Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P1561	Brake Line Pressure Sensor Circuit	PCM	REFER to AUXILIARY BRAKE SYSTEM -- E-SERIES .
P1572	Brake Pedal Switch Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P1602	Immobilizer/ECM Communication Error	PCM	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
P1622	Immobilizer ID Does Not Match	PCM	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
P1636	Inductive Signature Chip Communication Error	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E or AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P1639	Vehicle ID Block Corrupted, Not Programmed	PCM	REFER to MODULE CONFIGURATION .
P1702	Transmission Range Sensor Circuit Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1703	Brake Switch Out Of Self Test Range	PCM	REFER to CRUISE CONTROL .
P1704	Transmission Range Circuit Not Indicating Park/Neutral During Self Test	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1705	Transmission Range Circuit Not Indicating Park/Neutral During Self Test	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1706:00	High Vehicle Speed Observed in Park: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P1711	Transmission Fluid Temperature Sensor Out Of Self Test Range	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1713	Transmission Fluid Temperature Sensor In Range Failure (	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1714	Shift Solenoid A Inductive Signature	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1715	Shift Solenoid B Inductive Signature	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1718	Transmission Fluid Temperature Sensor In Range Failure (> 250 deg F)	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1728	Transmission Slip	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1740	Torque Converter Clutch Solenoid Inductive Signature	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1741	Torque Converter Clutch Solenoid Control Error	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1742	Torque Converter Clutch Solenoid Circuit Failed On	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1743	Torque Converter Clutch Solenoid Circuit Failed On	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1744	Torque Converter Clutch Solenoid Circuit Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E or AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P1746	Pressure Control Solenoid A Open Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1747	Pressure Control Solenoid A Short Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1760	Pressure Control Solenoid A Short Circuit Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1780	Transmission Control Switch (O/D Cancel) Circuit Out Of Self Test Range	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E or AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P1783	Transmission Overtemperature Condition	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
P1910	Reverse Lamp Control Circuit/Open	PCM	REFER to EXTERIOR LIGHTING .
P1935	Brake Switch/Sensor Signal	PCM	REFER to AUXILIARY BRAKE SYSTEM -- E-SERIES .
P2700	Transmission Friction Element A Apply Time Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P2701	Transmission Friction Element B Apply Time Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P2702	Transmission Friction Element C Apply Time Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P2703	Transmission Friction Element D Apply Time Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
P2704	Transmission Friction Element E Apply Time Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .
PXXXX	All Other DTCs	PCM	REFER to the INTRODUCTION - GASOLINE MODELS .
U0002:88	High Speed CAN Communication Bus Performance: Bus Off	IPC	REFER to MODULE COMMUNICATIONS NETWORK .
U0011:88	Medium Speed CAN Communication Bus Performance: Bus Off	IPC	REFER to MODULE COMMUNICATIONS NETWORK .
U0028	Vehicle Communication Bus A	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0028:08	Vehicle Communication Bus A: Bus Signal/Message Failures	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0028:88	Vehicle Communication Bus A: Bus Off	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0073	Control Module Communication Bus A Off	ABS module	REFER to MODULE COMMUNICATIONS NETWORK .
U0100:00	Lost Communication With ECM/PCM "A": No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0100:00	Lost Communication With ECM/PCM "A": No Sub Type Information	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
U0100:00	Lost Communication With ECM/PCM "A": No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0101:00	Lost Communication with TCM: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0115	Lost Communication With ECM/PCM - Secondary (SPCM)	ABS module	REFER to MODULE COMMUNICATIONS NETWORK .
U0115	Lost Communication With ECM/PCM - Secondary (SPCM)	TBC module	REFER to AUXILIARY BRAKE SYSTEM -- E-SERIES .
U0121	Lost Communication With Anti-Lock Brake System (ABS) Control Module	TBC module	REFER to AUXILIARY BRAKE SYSTEM -- E-SERIES .
U0121:00	Lost Communication With Anti-Lock Brake System (ABS) Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0137:00	Lost Communication With Trailer Brake Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0140	Lost Communication With Body Control Module (GEM)	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140	Lost Communication With Body Control Module (GEM)	PAM	REFER to PARKING AID -- E-SERIES .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	Global Positioning System Module (GPSM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0151	Lost Communication With Restraints Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0151:00	Lost Communication With Restraints Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0151:00	Lost Communication With Restraints Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0155	Lost Communication With Instrument Panel Cluster (IC) Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0155	Lost Communication With Instrument Panel Cluster (IC) Control Module	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155	Lost Communication With Instrument Panel Cluster (IC) Control Module	PAM	REFER to PARKING AID -- E-SERIES .
U0155	Lost Communication With Instrument Panel Cluster (IC) Control Module	SJB	REFER to SMART JUNCTION BOX (SJB) .
U0155	Lost Communication With Instrument Panel Cluster (IC) Control Module	TBC module	REFER to AUXILIARY BRAKE SYSTEM -- E-SERIES .
U0155:00	Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155:00	Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155:00	Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155:00	Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0159	Lost Communication With Parking Assist Control Module (PAM)	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0159:00	Lost Communication With Parking Assist Control Module "A": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0159:00	Lost Communication With Parking Assist Control Module "A": No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0161:00	Lost Communication With Compass Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0162:00	Lost Communication With Navigation Display Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0163:00	Lost Communication With Navigation Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0164:00	Lost Communication With HVAC Control Module: No Sub Type Information	ACM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
U016A:00	Lost Communication With Electric A/C Compressor Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184	Lost Communication With Radio ( ACM )	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184:00	Lost Communication With Radio: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0193	Lost Communication With Digital Audio Control Module ( SDARS )	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0193:00	Lost Communication With "Digital Audio Control Module A": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0196	Lost Communication With Entertainment Control Module - Rear (AUX)	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0196	Lost Communication With Entertainment Control Module - Rear (AUX)	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0196:00	Lost Communication With Entertainment Control Module-Rear "A": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0196:00	Lost Communication With Entertainment Control Module-Rear "A": No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0197	Lost Communication With Telephone Control Module	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0197	Lost Communication With Telephone Control Module	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0197:00	Lost Communication With Telephone Control Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0238	Lost Communication With Digital Audio Control Module "D" (DSP)	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0238:00	Lost Communication With Digital Audio Control Module "D": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0249	Lost Communication With Entertainment Control Module - Rear "B" (RCU)	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0249	Lost Communication With Entertainment Control Module - Rear "B" (RCU)	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0249:00	Lost Communication With Entertainment Control Module - Rear "B": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0249:00	Lost Communication With Entertainment Control Module - Rear "B": No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0253:00	Lost Communication With Accessory Protocol Interface Module: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0255	Lost Communication With Front Controls Interface Module	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0255:00	Lost Communication With Front Display Interface Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0255:00	Lost Communication With Front Display Interface Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0256	Lost Communication With Front Display Interface Module	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0256:00	Lost Communication With Front Controls Interface Module "A": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0256:00	Lost Communication With Front Controls Interface Module "A": No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0300	Internal Control Module Software Incompatibility	PCM	REFER to MODULE CONFIGURATION .
U0300:00	Internal Control Module Software Incompatibility: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0401	Invalid Data Received from ECM/PCM A	TBC module	REFER to AUXILIARY BRAKE SYSTEM -- E-SERIES .
U0401:00	Invalid Data Received from ECM/PCM A: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0401:00	Invalid Data Received from ECM/PCM A: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0401:29	Invalid Data Received from ECM/PCM A: Signal Invalid	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0401:86	Invalid Data Received from ECM/PCM A: Signal Invalid	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0416	Invalid Data Received from Vehicle Dynamics Control Module	TBC module	REFER to AUXILIARY BRAKE SYSTEM -- E-SERIES .
U0422:00	Invalid Data Received From Body Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0422:00	Invalid Data Received From Body Control Module: No Sub Type Information	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0422:55	Invalid Data Received From Body Control Module: Not Configured	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0423:00	Invalid Data Received From Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0423:00	Invalid Data Received From Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0430:00	Invalid Data Received From Tire Pressure Monitor Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0438:55	Invalid Data Received From Trailer Brake Control Module: Not Configured	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0452	Invalid Data Received From Restraints Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0462:68	Invalid Data Received From Compass Module: Event Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U046B:00	Invalid Data Received From Global Positioning System Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0485:00	Invalid Data Received From Radio: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0554:00	Invalid Data Received From Accessory Protocol Interface Module: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U1039	SCP (J1850) Invalid or Missing Data for Primary Id $27	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E .
U2013:63	Switch Pack: Circuit/Component Protection Time-Out	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:09	Control Module Hardware: Component Failures	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:41	Control Module Hardware: General Checksum Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:96	Control Module Hardware: Component Internal Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U201A:51	Control Module Main Calibration Data: Not Programmed	ACM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U2050	No Application Present	ACM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2050	No Application Present	SJB	REFER to SMART JUNCTION BOX (SJB) .
U2051	One or More Calibration Files Missing/Corrupt	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U2051	One or More Calibration Files Missing/Corrupt	ACM	REFER to MODULE CONFIGURATION .
U2051	One or More Calibration Files Missing/Corrupt	PAM	REFER to PARKING AID -- E-SERIES .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	ACM	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	APIM	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	IPC	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U2101:00	Control Module Configuration Incompatible: No Sub Type Information	ACM	REFER to MODULE CONFIGURATION .
U2101:00	Control Module Configuration Incompatible: No Sub Type Information	APIM	REFER to MODULE CONFIGURATION .
U2200:00	Control Module Configuration Memory Corrupt: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U2202	Invalid Configuration Data Received	TBC module	REFER to AUXILIARY BRAKE SYSTEM -- E-SERIES .
U2472	Unexpected Ignition State	SJB	REFER to STEERING COLUMN SWITCHES .
U2473	Unexpected Vehicle Speed (VSS)	SJB	NOTE: Sets during the self-test if vehicle speed exceeds 3 mph (5 kph) or vehicle speed cannot be determined by the SJB . VERIFY the speedometer operates correctly.If the speedometer does not operate correctly, REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .If the speedometer operates correctly, the self-test is carried out while the vehicle is moving. STOP the vehicle and REPEAT the self-test.
U3000:04	Control Module: System Internal Failures	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:09	Control Module: System Component Failures	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:41	Control Module: General Checksum Failure	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:41	Control Module: General Checksum Failure	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:41	Control Module: General Checksum Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3000:42	Control Module: General Memory Failure	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:42	Control Module: General Memory Failure	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:42	Control Module: General Memory Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3000:44	Control Module: Data Memory Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3000:45	Control Module: Program Memory Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:46	Control Module: Calibration/Parameter Memory Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3000:46	Control Module: Calibration/Parameter Memory Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:49	Control Module: Internal Electronic Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:4A	Control Module: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:88	Control Module: Bus Off	APIM	REFER to MODULE COMMUNICATIONS NETWORK .
U3002:62	Vehicle Identification Number: Signal Compare Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U300A:62	Ignition Switch: Signal Compare Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U300A:64	Ignition Switch: Signal Plausibility Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .

NOTE
Sets during the self-test if vehicle speed exceeds 3 mph (5 kph) or vehicle speed cannot be determined by the SJB .

DIAGNOSTIC TROUBLE CODE (DTC) CHART

Special Tool(s)

SPECIAL TOOL(S) DESCRIPTION CHART Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool Flex Probe Kit 300-NUD105-R025DE or equivalent

Scheme 73

Scheme 73: Special Tool(s)

Scheme 74

Scheme 75

Principles of Operation

Note. The Smart Junction Box (SJB) is also known as the Generic Electronic Module (GEM).

The SJB controls various systems (such as exterior lighting, interior lighting, power door locks, anti-theft system, dimmable backlighting and the battery saver feature) by monitoring inputs from switches, sensors and messages sent from other modules on the Medium Speed Controller Area Network (MS-CAN). Based on the inputs received, the SJB activates outputs. For example, the SJB monitors the headlamp switch position. Based on this input, the SJB may provide voltage to the exterior lamps.

Field-Effect Transistor (FET) Protection

A Field-Effect Transistor (FET) is a type of transistor that when used with module software can be used to monitor and control current flow on module outputs. The FET protection strategy is used to prevent module damage in the event of excessive current flow.

The SJB utilizes an FET protective circuit strategy for many of its outputs (for example, a headlamp output circuit). Output loads (current level) are monitored for excessive current (typically short circuits) and are shut down (turns off the voltage or ground provided by the module) when a fault event is detected. A short circuit DTC is stored at the fault event and a cumulative counter is started.

When the demand for the output is no longer present, the module resets the FET circuit protection to allow the circuit to function. The next time the driver requests a circuit to activate that has been shut down by a previous short ( FET protection) and the circuit is still shorted, the FET protection shuts off the circuit again and the cumulative counter advances.

When the excessive circuit load occurs often enough, the module shuts down the output until a repair procedure is carried out. Each FET protected circuit has 3 predefined levels of short circuit tolerance based on the harmful effect of each circuit fault on the FET and the ability of the FET to withstand it. A module lifetime level of fault events is established based upon the durability of the FET . If the total tolerance level is determined to be 600 fault events, the 3 predefined levels would be 200, 400 and 600 fault events.

When each tolerance level is reached, the short circuit DTC that was stored on the first failure cannot be cleared by a command to clear the continuous DTCs. The module does not allow this code to be cleared or the circuit restored to normal operation until a successful self-test proves that the fault has been repaired. After the self-test has successfully completed (no on-demand DTCs present), DTC B106E and the associated DTC (the DTC related to the shorted circuit) automatically clears and the circuit function returns.

When each level is reached, the DTC associated with the short circuit sets along with DTC B106E. These DTCs can be cleared using the module on-demand self-test, then the Clear DTC operation on the scan tool (if the on-demand test shows the fault corrected). The module never resets the fault event counter to zero and continues to advance the fault event counter as short circuit fault events occur.

If the number of short circuit fault events reach the third level, then DTCs B106F and B1342 set along with the associated short circuit DTC. DTC B106F cannot be cleared and the module must be replaced after the repair.

Inspection and Verification

Verify the customer concern.
Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Smart Junction Box (SJB) fuse 5 (10A)
If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
If the cause is not visually evident, connect the scan tool to the Data Link Connector (DLC).
If the scan tool does not communicate with the VCM : Check the VCM connection to the vehicle. Check the scan tool connection to the VCM . Refer to «MODULE COMMUNICATIONS NETWORK»(/ford/cutaway-e350-super-duty/2008-2012/remont/communication-devices/#module-communications-network-e-series) , No Power to The Scan Tool, to diagnose no power to the scan tool.
If the scan tool does not communicate with the vehicle: Verify the ignition key is in the ON position. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(/ford/cutaway-e350-super-duty/2008-2012/remont/communication-devices/#module-communications-network-e-series) to diagnose no response from the PCM.
Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/cutaway-e350-super-duty/2008-2012/remont/communication-devices/#module-communications-network-e-series) . If the network test passes, retrieve and record the continuous memory DTCs.
Clear the continuous DTCs and carry out the self-test diagnostics for the SJB .
If the DTCs retrieved are related to the concern, go to «DTC CHARTS»(/ford/cutaway-e350-super-duty/2008-2012/remont/communication-devices/#multifunction-electronic-modules-e-series__dtc-charts) . For all other DTCs, refer to the «DIAGNOSTIC TROUBLE CODE (DTC) CHART»(/ford/cutaway-e350-super-duty/2008-2012/remont/communication-devices/#multifunction-electronic-modules-e-series__diagnostic-trouble-code-dtc-chart) .
If no DTCs related to the concern are retrieved, GO to «SYMPTOM CHART»(/ford/cutaway-e350-super-duty/2008-2012/remont/communication-devices/#multifunction-electronic-modules-e-series__symptom-chart) .

DTC Charts

DTC	Description	Action
B106E	Solid State Driver Disabled Due to Short Circuit	GO to PINPOINT TEST A .
B106F	Module Disabled Due to External Fault	GO to PINPOINT TEST A .
B1317	Battery Voltage High	GO to PINPOINT TEST B .
B1318	Battery Voltage Low	GO to PINPOINT TEST C .
B2477	Module Configuration Failure	REFER to MODULE CONFIGURATION .
B2A21	One or More Configuration Files Missing Or Corrupt	REFER to MODULE CONFIGURATION .
P062F	Internal Control Module EEPROM Error	INSTALL a new SJB . REFER to SMART JUNCTION BOX (SJB) .
U0155	Lost Communication With Instrument Panel Cluster (IC) Control Module	GO to PINPOINT TEST D .
U2050	No Application Present	CONFIGURE the SJB . REFER to MODULE CONFIGURATION . CLEAR the DTCs. REPEAT the self-test. If DTC U2050 is retrieved again, INSTALL a new SJB . REFER to SMART JUNCTION BOX (SJB) . TEST the system for normal operation.
All other DTCs		REFER to the DIAGNOSTIC TROUBLE CODE (DTC) CHART .

SMART JUNCTION BOX (SJB) DTC CHART

Symptom Chart

Condition	Possible Sources	Action
No communication with the Smart Junction Box (SJB)	Wiring, terminals or connectors SJB	REFER to MODULE COMMUNICATIONS NETWORK , The SJB Does Not Respond To The Scan Tool.

SYMPTOM CHART

Normal Operation

The Smart Junction Box (SJB) controls the output of several vehicle systems by means of solid state drivers. A DTC sets when an overload occurs on any of these drivers. The module also tracks the number of repetitive faults on each of these circuits, and then it compares said number of overloads to 3 progressive thresholds established for each circuit. If the third threshold hase not been met, the DTC for the affected circuit can be cleared by eliminating the fault, clearing the DTCs and then running a self-test.

At the point that each of the first 2 thresholds is met, DTC B106E sets along with a DTC related to the affected circuit. Once the final (third) threshold has been met, the affected output is permanently disabled, and DTC B106F sets, at which time the SJB must be replaced.

DTC B106E (Solid State Driver Disabled Due to Short Circuit) - a continuous DTC that sets when the SJB has disabled an output circuit due to a repetitive fault that overloads said circuit. A corresponding DTC for the circuit in question is also set.
DTC B106F (Module Disabled Due to External Fault) - a continuous DTC that sets when the SJB has permanently disabled one or more output functions due to a repetitive circuit overload. DTC B1342 also sets at this time.

When DTC B1342 is set because the module has reached a third threshold and the SJB has permanently disabled an output, no DTCs can be cleared from the SJB . Using the module self-test to confirm a repair is not possible and a measurement using a digital multimeter of the affected output circuit is required to make sure the fault condition no longer exists.

This pinpoint test is intended to diagnose the following

Output circuit short
SJB

PINPOINT TEST A: DTCs B106E, B106F

A1 REVIEW THE DTCs NOTE: First follow the necessary diagnostics to resolve DTC B106E and any other present DTCs (ignoring B106F). DTC B106E is only present when there is another DTC due to software or circuitry issues that must be resolved before another self-test is run. DTC B106F is only present once the final threshold has been met. Failure to correct the fault condition first may cause damage to the new SJB , resulting in a repeat repair. Review the DTCs from the SJB self-test. Are any other DTCs present, besides B106E, B106F or B1342? Yes: CORRECT the DTCs. REFER to the «SMART JUNCTION BOX (SJB) DTC CHART»(/ford/cutaway-e350-super-duty/2008-2012/remont/communication-devices/#multifunction-electronic-modules-e-series) . After the repair, GO to A2 . No: GO to A2 .
A2 REPEAT THE SJB SELF-TEST Ignition ON. Enter the following diagnostic mode on the scan tool: SJB Self-Test. Clear the DTCs and repeat the SJB self-test. Is DTC B106F or DTC B1342 present? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(/ford/cutaway-e350-super-duty/2008-2012/remont/communication-devices/#multifunction-electronic-modules-e-series__smart-junction-box-sjb) . TEST the system for normal operation. No: The system is operating correctly at this time. The circuit short has been repaired.

Pinpoint Test B: DTC B1317

Refer to appropriate System Wiring Diagrams article for schematic and connector information.

The Smart Junction Box (SJB) monitors the voltage from the battery to determine if it goes above or below specific thresholds and sets DTC B1317 in continuous memory if the SJB detects high battery voltage above 15.5 volts on circuit SDC02.

DTC B1317 (Battery Voltage High) - a continuous memory DTC that sets when the SJB detects battery voltage above 15.5 volts on circuit SDC02.

This pinpoint test is intended to diagnose the following

Charging system concern
SJB

Note. DTC B1317 may be stored in the module memory due to previous battery charging or vehicle jump starting events.

B1 CHECK FOR DTCs B1317, B1676, P0563 OR U3003:17 SET IN OTHER MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: (All Modules) Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676, P0563 (PCM) or U3003:17 set in more than one module? Yes: REFER to «CHARGING SYSTEM»(/ford/cutaway-e350-super-duty/2008-2012/remont/charging-system/#charging-system) to diagnose an overcharging condition. No: GO to B2 .
B2 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2,000 rpm for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 15.5 volts or higher? Yes: REFER to «CHARGING SYSTEM»(/ford/cutaway-e350-super-duty/2008-2012/remont/charging-system/#charging-system) to diagnose an overcharging condition. No: GO to B3 .
B3 RECHECK FOR DTC B1317 Turn the engine off. Ignition ON. Enter the following diagnostic mode on the scan tool: SJB Self-Test. Clear the continuous memory DTCs. Carry out the SJB self-test. Is DTC B1317 present? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(/ford/cutaway-e350-super-duty/2008-2012/remont/communication-devices/#multifunction-electronic-modules-e-series__smart-junction-box-sjb) . TEST the system for normal operation. No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.

Pinpoint Test C: DTC B1318

Refer to appropriate System Wiring Diagrams article for schematic and connector information.

The Smart Junction Box (SJB) monitors the voltage from the battery to determine if it goes above or below specific thresholds and sets DTC B1318 in continuous memory if the SJB detects low battery voltage below 10 volts on circuit SDC02.

DTC B1318 (Battery Voltage Low) - a continuous memory DTC that sets when the SJB detects battery voltage below 10 volts on circuit SDC02.

This pinpoint test is intended to diagnose the following

Wiring, terminals or connectors
High circuit resistance
SJB

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Failure to disconnect the battery when instructed will result in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .

Scheme 76

Scheme 76: PINPOINT TEST C: DTC B1318

Scheme 77

C1 RECHECK THE SJB DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: SJB Self-Test. Clear the DTCs. Repeat the SJB self-test. Is DTC B1318 still present? Yes: GO to C2 . No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.
C2 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0620, P0625, P0626 or P065B set in the PCM? Yes: REFER to «CHARGING SYSTEM»(/ford/cutaway-e350-super-duty/2008-2012/remont/charging-system/#charging-system) . No: GO to C3 .
C3 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «BATTERY, MOUNTING AND CABLES»(/ford/cutaway-e350-super-duty/2008-2012/remont/charging-system/#battery-battery-mounting-battery-cables) , Battery Condition Test. Is the battery OK and fully charged? Yes: GO to C4 . No: REFER to «CHARGING SYSTEM»(/ford/cutaway-e350-super-duty/2008-2012/remont/charging-system/#charging-system) .
C4 CHECK THE SJB VOLTAGE SUPPLY Measure and record the voltage at the battery. Disconnect: SJB C2280G. Ignition ON. Measure the voltage between the SJB C2280G-1, circuit SDC02 (RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: GO to C5 . No: REPAIR the circuit for high resistance. CLEAR the DTC. REPEAT the self-test.
C5 CHECK THE SJB GROUND CIRCUIT Ignition OFF. Disconnect: Negative Battery Cable. Disconnect: SJB C2280D. Measure the resistance between the SJB C2280D-7, 8, 12, 24, circuit GD133 (BK), harness side and ground. Are the resistances less than 5 ohms? Yes: CONNECT the negative battery cable. GO to C6 . No: REPAIR the circuit for high resistance. CONNECT the negative battery cable. TEST the system for normal operation.
C6 CHECK FOR CORRECT SJB OPERATION Disconnect the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(/ford/cutaway-e350-super-duty/2008-2012/remont/communication-devices/#multifunction-electronic-modules-e-series__smart-junction-box-sjb) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

The Smart Junction Box (SJB) and the Instrument Cluster (IC) communicate using the Medium Speed Controller Area Network (MS-CAN). Messages are exchanged between the modules on the MS-CAN .

DTC U0155 (Lost Communication With Instrument Panel Cluster (IC) Control Module) - set by the SJB whenever the ignition status is in run and it receives a Tire Pressure Monitoring System (TPMS) feature is enabled message from the Instrument Panel Cluster (IPC) and then the same message is not received within 5 minutes.

This pinpoint test is intended to diagnose the following

Module communication
SJB
IPC

PINPOINT TEST D: DTC U0155

D1 VERIFY CUSTOMER CONCERN Ignition ON. Verify there is an observable symptom present. Is an observable symptom present? Yes: GO to D2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
D2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the IPC pass the network test? Yes: GO to D3 . No: REFER to «MODULE COMMUNICATIONS NETWORK»(/ford/cutaway-e350-super-duty/2008-2012/remont/communication-devices/#module-communications-network-e-series) .
D3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded SJB DTCs from the self-test. Is DTC B1317 or DTC B1318 recorded? Yes: For DTC B1317, GO to «PINPOINT TEST B»(/ford/cutaway-e350-super-duty/2008-2012/remont/communication-devices/#multifunction-electronic-modules-e-series__pinpoint-test-b-dtc-b1317) . For DTC B1318, GO to «PINPOINT TEST C»(/ford/cutaway-e350-super-duty/2008-2012/remont/communication-devices/#multifunction-electronic-modules-e-series__pinpoint-test-c-dtc-b1318) . No: GO to D4 .
D4 RECHECK THE SJB DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the SJB self-test. Is DTC U0155 still present? Yes: GO to D5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
D5 CHECK FOR DTC U0155/U0155:00 SET IN OTHER MODULES Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0155/U0155:00 set in other modules? Yes: INSTALL a new IPC . REFER to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(/ford/cutaway-e350-super-duty/2008-2012/remont/gauges-instrument-panels/#information-center-instrumentation-message-center-and-warning-chimes-e-series) . No: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(/ford/cutaway-e350-super-duty/2008-2012/remont/communication-devices/#multifunction-electronic-modules-e-series__smart-junction-box-sjb) .

Note. Steering column opening cover removed for clarity.

Scheme 78

Scheme 78: Smart Junction Box (SJB)

Item	Part Number	Description
1		Smart Junction Box (SJB) electrical connectors (2 required) (part of 14405)
2		SJB electrical connectors (3 required) (part of 12A581)
3		SJB electrical connectors (2 required) (part of 14401)
4	W707137-S437	SJB nuts (3 required)
5	15K602	SJB

PARTS DESCRIPTION CHART

Removal

Note. Prior to the replacement of the module, it is necessary to upload the module configuration information to a scan tool. This information must be downloaded into the new Smart Junction Box (SJB) after installation. For additional information, refer to MODULE CONFIGURATION . In the event that As-Built data entry is required ( SJB does not communicate), all Remote Keyless Entry (RKE) devices must be programmed to the new SJB . A minimum of 2 devices are necessary to complete the configuration and turn off the flashing interior lights.

Note. The Tire Pressure Monitoring System (TPMS) functionality is integrated into the SJB .

Note. A new SJB is delivered in a "manufacturing mode" with 8 pre-set DTCs. A successful configuration of the SJB , then a successful TPMS sensor training, then a successful self-test including the clearing of all DTCs is required in order to clear the 8 manufacturing mode DTCs. The 8 manufacturing mode DTCs are: B106D (Tire Pressure Monitor System [ TPMS ] Initiators Not Configured) This DTC is present when the SJB is not configured, even on applications that are not equipped with initiators. B2477 (Module Configuration Failure) B2868 (Left Front Tire Pressure Sensor Fault) B2869 (Right Front Tire Pressure Sensor Fault) B2870 (Right Rear Tire Pressure Sensor Fault) B2871 (Left Rear Tire Pressure Sensor Fault) B2A21 (One or More Configuration Files Missing Or Corrupt) C2780 ( ECU in Manufacturer Sub-State)

Pinpoint Test D

D1 SJB

D3 SJB

Installation

Pinpoint Test D

D1 SJB

D3 SJB

D5 SJB

Multifunction Electronic Modules -- E-Series Ford Cutaway E350 Super Duty

TORQUE SPECIFICATIONS

Module Controlled Functions

Smart Junction Box (SJB)

Post Crash Alert

Welcome/Farewell Strategy

Diagnostic Trouble Code (DTC) Chart

Special Tool(s)

Scheme 73

Scheme 74

Scheme 75

Principles of Operation

Field-Effect Transistor (FET) Protection

Inspection and Verification

DTC Charts

Symptom Chart

Normal Operation

PINPOINT TEST A: DTCs B106E, B106F

Pinpoint Test B: DTC B1317

Pinpoint Test C: DTC B1318

Scheme 76

Scheme 77

PINPOINT TEST D: DTC U0155

Scheme 78

Removal

Pinpoint Test D

Installation

Pinpoint Test D

More articles — Accessories & Equipment

Login / Signup

Enter the code

You have successfully logged in!
