Rear View Mirror System Ford Crown Victoria II

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

Rear View Mirrors

The exterior mirrors have the following features

1. exterior mirror motor
2. fold-away type
3. controlled by the exterior mirror control switch
4. heated exterior mirror glass

There are two types of interior rear view mirrors available

1. manual day/night interior rear view mirror
2. auto-dimming interior rear view mirror

The available automatic dimming feature

1. functions mainly at night with limited function at dawn or dusk.
2. will change from normal to non-glare mode when headlight glare reaches the auto-dimming interior rear view mirror. The auto-dimming interior mirror measures the brightness of the light from the rear of the vehicle. It automatically makes a correction in the reflective properties of the mirror and reduces the glare.
3. automatically adjusts the sensitivity of the auto-dimming interior mirror. From the non-glare mode, the auto-dimming interior mirror returns to normal after a short delay. The delay begins when the glare goes away and eliminates readjustment of the auto-dimming interior mirror as traffic moves behind or around the vehicle.
4. function may be disabled by pressing the auto-dimming interior mirror-mounted MIRROR switch. A small indicator lamp is located on the RH side of the switch.
5. will automatically lock the auto-dimming interior mirror into the normal state whenever the transmission is placed in the REVERSE mode to provide a clear view when backing up.

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Scheme 1

Scheme 2

1. Verify the customer concern by operating the system.
2. Visually inspect for obvious signs of mechanical or electrical damage.
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the concern is not visually evident, verify the symptom and refer to the «SYMPTOM CHART»(/ford/crown-victoria/ii-1997-2011/remont/mirrors/#rear-view-mirror-system) .

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/crown-victoria/ii-1997-2011/remont/charging-system/#battery-mounting-and-cables) .
2. Remove the front door trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/crown-victoria/ii-1997-2011/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
3. Position the water shield aside.
4. Remove the pin-type retainer.
5. Through the door opening, disconnect the power exterior rear view mirror electrical connector.
6. Remove the 3 nuts and the exterior rear view mirror.
7. To install, reverse the removal procedure.

Scheme 14

Scheme 15

1. Push in the upper edge of the exterior rear view mirror glass to the maximum travel.
2. Gently pull outward until the exterior rear view mirror glass is released. If equipped, disconnect the mirror glass electrical connector.
3. To install, reverse the removal procedure.

Scheme 16

Scheme 17

Scheme 18

1. Push in the upper edge of the exterior rear view mirror glass to the maximum travel and gently pull outward until the exterior rear view mirror glass is released. If equipped, disconnect the mirror glass electrical connector.
2. Remove the exterior rear view mirror motor screws.
3. Disconnect the electrical connectors.
4. Remove the motor.
5. To install, reverse the removal procedure.

Scheme 19

Scheme 20

1. Position the exterior mirror glass in the full down position.
2. Using a suitable tool, release the 2 locking tabs from the exterior mirror cover.
3. Position the exterior mirror glass in the full in position.
4. Using a suitable tool, release the locking tab and remove and exterior mirror cover.

Installation

1. Position the exterior mirror cover on the exterior mirror.
2. Place a hand against the back of the exterior mirror cover and press the cover in place until it is fully seated.

Scheme 21

Removal

Scheme 22

1. If equipped, disconnect the electrical connector and position wire harness aside.
2. Insert a small flat-blade screwdriver into the slot at the base of the interior rear view mirror. Hold the interior rear view mirror and pull the screwdriver downward and rearward until the interior rear view mirror snaps away from the interior rear view mirror bracket.

Scheme 23

Scheme 24

1. Using the special tool, firmly slide the interior rear view mirror onto the interior rear view mirror bracket until it engages. There should be an audible click when the interior rear view mirror spring clip engages with the mirror bracket.
2. If equipped, connect the electrical connector and place the wire harness clip into the slot at the top of the interior rear view mirror base.

Scheme 25

Scheme 26

1. Lift the front of the window regulator switch plate from the front door trim panel and position the switch plate aside.
2. Disconnect the exterior mirror control switch electrical connector.
3. Release the 2 locking tabs and remove the exterior rear view mirror control switch.
4. To install, reverse the removal procedure.
