FUEL CHARGING AND CONTROLS - 4.6L (4V) GENERAL SPECIFICATIONS

ItemSpecification
Lubricant Specification
SAE 5W-20 Premium Synthetic Blend Motor Oil, XO-5W20-QSPWSS-M2C153-H

FUEL CHARGING AND CONTROLS - 4.6L (4V) GENERAL SPECIFICATIONS

FUEL CHARGING AND CONTROLS - 4.6L (4V) TORQUE SPECIFICATIONS

DescriptionNm
Battery ground bolt10
Throttle body bolts9
Fuel injection supply manifold bolts10
42-pin engine bulkhead electrical connector bolt6
Ignition coil cover bolts10

FUEL CHARGING AND CONTROLS - 4.6L (4V) TORQUE SPECIFICATIONS

Fuel Charging And Controls

The fuel injection supply manifold

  1. delivers fuel to the fuel injector.
  2. receives fuel from the fuel supply line. The throttle body
  3. controls air supply to the upper intake manifold by positioning the throttle plate.
  4. connects the accelerator cable and, if equipped, the speed control actuator cable to the throttle lever.
  5. is not adjustable.
  6. cannot be cleaned. The fuel injector
  7. is electrically operated by the powertrain control module (PCM).
  8. has an internal solenoid that opens a needle valve to inject fuel into the lower intake manifold.
  9. atomizes the fuel as the fuel is delivered.
  10. is deposit-resistant. Do not clean. The fuel pressure relief valve
  11. is used to inspect and relieve fuel pressure.

Idle Speed Adjustment

Removal And Installation

WARNINGDo not smoke or carry lighted tobacco or open flame of any type when working on or near any fuel related components. Highly flammable mixtures are always present and can ignite. Failure to follow these instructions can result in personal injury.
CAUTIONThe throttle body bore and plate area have a special coating and cannot be cleaned.

Scheme 73

Scheme 73
Scheme 73

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75
Scheme 75
  1. Remove the air cleaner outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/crown-victoria/ii-1997-2011/remont/removal-installation/#intake-air-distribution-filtering) .
  2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/crown-victoria/ii-1997-2011/remont/charging-system/#battery-mounting-and-cables) .
  3. Disconnect the throttle position (TP) sensor and the idle air control (IAC) sensor electrical connectors.
  4. Remove the accelerator control splash shield.
  5. Disconnect the accelerator controls. Disconnect the accelerator cable. Disconnect the speed control cable. Disconnect the return spring.
  6. Remove the four bolts and remove the throttle body.
  7. To install, reverse the removal procedure.
WARNINGDo not smoke or carry lighted tobacco or open flame of any type when working on or near any fuel related components. Highly flammable mixtures are always present and can ignite. Failure to follow these instructions can result in personal injury.

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78

Scheme 79

Scheme 79
Scheme 79

Scheme 80

Scheme 80
Scheme 80

Scheme 81

Scheme 81
Scheme 81

Scheme 82

Scheme 82
Scheme 82

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85
Scheme 85

Scheme 86

Scheme 86
Scheme 86

Scheme 87

Scheme 87
Scheme 87

Scheme 88

Scheme 88
Scheme 88

Scheme 89

Scheme 89
Scheme 89

Scheme 90

Scheme 90
Scheme 90

Scheme 91

Scheme 91
Scheme 91

Scheme 92

Scheme 92
Scheme 92

Scheme 93

Scheme 93
Scheme 93

Scheme 94

Scheme 94
Scheme 94

Scheme 95

Scheme 95
Scheme 95
  1. Remove the upper intake manifold. For additional information, refer to «ENGINE 4.6L (4V)»(ref-209994) .
  2. Raise and support the vehicle. For additional information, refer to «JACKING & LIFTING»(/ford/crown-victoria/ii-1997-2011/remont/hoistjack/#jacking-lifting) .
  3. Disconnect the crankshaft position (CKP) sensor and the power steering pressure sensor electrical connectors.
  4. Disconnect the A/C compressor electrical connector.
  5. Disconnect the engine wiring harness retainers.
  6. Disconnect the oil pressure sensor electrical connector.
  7. Disconnect the power steering electrical connector.
  8. Lower the vehicle.
  9. Disconnect the electrical connector.
  10. Disconnect the fuel hose spring lock coupling. For additional information, refer to «FUEL SYSTEM-GENERAL INFORMATION-NATURAL GAS»(/ford/crown-victoria/ii-1997-2011/remont/fuel-system/#fuel-system-general-information-natural-gas) .
  11. Disconnect the vacuum hose and the electrical connector.
  12. Disconnect the electrical connector and the vacuum hose.
  13. Disconnect the generator electrical connections and the wiring harness retainer.
  14. Disconnect the eight fuel injector electrical connectors.
  15. Remove the bolts and remove the RH ignition coil cover.
  16. Disconnect the RH ignition coil electrical connectors.
  17. Remove the bolts and remove the LH ignition coil cover.
  18. Disconnect the LH ignition coil electrical connectors.
  19. Disconnect the RH radio capacitor electrical connector.
  20. Disconnect the wiring harness retainer from the RH valve cover stud.
  21. Disconnect the electrical connectors.
  22. Disconnect the LH radio capacitor electrical connector and the wiring harness retainer.
  23. Disconnect the wiring harness retainer and the camshaft position (CMP) sensor electrical connector.
  24. Disconnect the electrical connectors and remove the fuel charging wiring harness.
  25. To install, reverse the removal procedure.

Fuel Injection Supply Manifold

ItemSpecification
SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-DSPWSS-M2C153-H

MATERIAL SPECIFICATION

WARNINGDo not smoke or carry lighted tobacco or open flame of any type when working on or near any fuel related components. Highly flammable mixtures are always present and can ignite. Failure to follow these instructions can result in personal injury.
WARNINGFuel in the fuel system remains under high pressure even when the engine is not running. Before working on or disconnecting any of the fuel lines or fuel system components, the fuel system pressure must be relieved. Failure to follow these instructions can result in personal injury.

Scheme 96

Scheme 96
Scheme 96

Scheme 97

Scheme 97
Scheme 97

Scheme 98

Scheme 98
Scheme 98

Scheme 99

Scheme 99
Scheme 99
  1. Disconnect the battery ground cable.
  2. Remove the upper intake manifold. For additional information, refer to «ENGINE 4.6L (2V)»(/ford/crown-victoria/ii-1997-2011/remont/mechanical/#engine-46l-2v) .
  3. Disconnect the fuel line spring lock coupling. For additional information, refer to «FUEL SYSTEM-GENERAL INFORMATION»(/ford/crown-victoria/ii-1997-2011/remont/fuel-system/#fuel-system-general-information) .
  4. Position the wiring harness aside. Disconnect the RH fuel injector electrical connectors. Separate the harness from the RH fuel supply manifold stud bolt.
  5. Disconnect the fuel pressure sensor vacuum hose and the electrical connector.
  6. Position the wiring harness aside. Disconnect the LH fuel injector electrical connectors. Separate the harness from the LH fuel supply manifold stud bolt.
  7. Remove the four bolts and remove the fuel supply manifold.
  8. If necessary, remove the fuel injectors.
  9. To install, reverse the removal procedure. Install new fuel injector O-rings and lubricate with clean engine oil.
