Module Communications Network System Ford Crown Victoria II

Communication Devices 38 illustrations ~949 words

The module communications network consists of the following components

  1. standard corporate protocol (SCP) communication network
  2. international standards organization (ISO 9141) communication network
  3. data link connector (DLC)
  4. lighting control module (LCM)
  5. electronic automatic temperature control (EATC) module
  6. driver door module (DDM)
  7. powertrain control module (PCM)
  8. restraint control module (RCM)
  9. anti-lock brake control module
  10. rear air suspension module (RASM)
  11. natural gas vehicle module (NGVM)
  12. variable assist power steering (VAPS) module

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Scheme 1

Scheme 1: Special Tool(s)

Principles of Operation

The diagnostic tool connects to the two networks through the data link connector (DLC). This makes diagnosis and testing of these systems easier by allowing one smart tester to be able to diagnose and control any module on the two networks from one connector. The DLC can be found under the instrument panel between the steering column and the radio.

The ISO 9141 communications network does not permit intermodule communication. When the diagnostic tool communicates to modules on the ISO 9141 communication network, the diagnostic tool must request all information; or initiate module commands.

The ISO 9141 communications network will not function if the wire is shorted to ground or battery voltage. Also, if one of the modules on the ISO 9141 communications network loses power or shorts internally, communications to that module will fail.

The SCP communications network will remain operational even with the severing of one of the bus wires. Communications will also continue if one of the bus wires is shorted to ground or voltage, or if some but not all termination resistors are lost.

The restraint control module (RCM) is connected to the ISO 9141 communication network. The ECS controls the deployment of the air bags based on sensor input. For additional information, refer to AIR BAG RESTRAINT SYSTEMS .

The driver door module (DDM) is connected to the ISO 9141 communication network. The module controls many functions including power windows, power locks and keyless remote entry. For additional information, refer to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .

The lighting control module (LCM) is connected to the ISO 9141 communication network. The LCM controls both interior and exterior lighting, anti-theft functions and warning chimes. For additional information on interior lighting, refer to INTERIOR LIGHTING . For additional information on exterior lighting, refer to EXTERIOR LIGHTING . For additional information on anti-theft, refer to ANTI-THEFT . For additional information on warning chimes, refer to WARNING DEVICES .

The electronic automatic temperature control (EATC) module is connected to the SCP communication network. The EATC module controls automatic climate functions that maintain the vehicle at a constant temperature setting. For additional information, refer to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION .

The powertrain control module (PCM) is connected to the SCP communication network. The PCM controls the engine performance, electronic ignition, emission controls and on-board diagnostics. For additional information, refer to ELECTRONIC ENGINE CONTROLS . The passive anti-theft system (PATS) is integrated into the PCM. The PCM controls the PATS functions as well as illumination of the anti-theft indicator. The illumination command is sent from the PCM through the SCP communications network to the instrument cluster, which in turn sends power to the anti-theft indicator. The PCM stores the ignition key codes and controls engine disable. For additional PATS information, refer to ANTI-THEFT .

The natural gas vehicle module (NGVM) calculates fuel level based on inputs from the fuel tank pressure sensor and the fuel tank temperature sensor. The NGVM then provides a voltage signal to the instrument cluster to drive the fuel gauge. The NGVM also has separate injector drivers to run the injectors at the higher operating pressure of natural gas. The NGVM does not perform any calculations for this function; calibration for the injectors is maintained in the powertrain control module (PCM). For additional information, refer to INSTRUMENT CLUSTER-NATURAL GAS VEHICLE .

The anti-lock brake control module is connected to the SCP communication network. Vehicles not equipped with traction control use the ISO network. The module controls the brake pressure to the four wheels to keep the vehicle under control while braking. For additional information, refer to ANTI-LOCK CONTROL-TRACTION CONTROL & STABILITY ASSIST .

The rear air suspension module (RASM) is connected to the SCP communication network. The RASM controls the rear ride height. Refer to VEHICLE DYNAMIC .

Scheme 2

Scheme 2: Inspection and Verification
  1. Verify the customer concern by operating the system in question.
  2. Visually inspect for obvious signs of electrical damage.
  3. If the concern remains after the inspection, connect diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position. If the diagnostic tool still does not communicate with the vehicle, Go to «PINPOINT TEST M»(/ford/crown-victoria/ii-1997-2011/remont/communication-devices/#module-communications-network-system) .
  4. Go to «PINPOINT TEST PC»(/ford/crown-victoria/ii-1997-2011/remont/communication-devices/#module-communications-network-system) .

Scheme 3

Scheme 3: PINPOINT TEST PC: DATA LINK DIAGNOSTICS NETWORK TEST

Scheme 4

Scheme 4: Symptom Chart

Scheme 5

Scheme 5: PINPOINT TEST A: THE ANTI-LOCK BRAKE SYSTEM (ABS) CONTROL MODULE DOES NOT RESPOND TO THE DIAGNOSTIC

Scheme 6

Scheme 6

Scheme 7

Scheme 7: PINPOINT TEST B: THE ANTI-LOCK BRAKE SYSTEM (ABS) CONTROL MODULE DOES NOT RESPOND TO THE DIAGNOSTIC

Scheme 8

Scheme 8: PINPOINT TEST C: THE DRIVER DOOR MODULE (DDM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 9

Scheme 9: PINPOINT TEST D: THE NATURAL GAS VEHICLE MODULE (NGVM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 10

Scheme 10

Scheme 11

Scheme 11: PINPOINT TEST E: THE ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) MODULE DOES NOT RESPOND TO THE

Scheme 12

Scheme 12: PINPOINT TEST F: THE RESTRAINT CONTROL MODULE (RCM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 13

Scheme 13: PINPOINT TEST G: THE POWERTRAIN CONTROL MODULE (PCM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 14

Scheme 14

Scheme 15

Scheme 15: PINPOINT TEST H: THE REAR AIR SUSPENSION MODULE (RASM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 16

Scheme 16

Scheme 17

Scheme 17: PINPOINT TEST I: THE VARIABLE ASSIST POWER STEERING (VAPS) MODULE DOES NOT RESPOND TO THE DIAGNOSTIC

Scheme 18

Scheme 18

Scheme 19

Scheme 19: PINPOINT TEST J: THE LIGHTING CONTROL MODULE (LCM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 20

Scheme 20: PINPOINT TEST K: NO MODULE/NETWORK COMMUNICATION - ISO 9141 NETWORK

Scheme 21

Scheme 21

Scheme 22

Scheme 22

Scheme 23

Scheme 23

Scheme 24

Scheme 24

Scheme 25

Scheme 25

Scheme 26

Scheme 26: PINPOINT TEST L: NO MODULE/NETWORK COMMUNICATION - SCP NETWORK

Scheme 27

Scheme 27

Scheme 28

Scheme 28

Scheme 29

Scheme 29

Scheme 30

Scheme 30

Scheme 31

Scheme 31

Scheme 32

Scheme 32

Scheme 33

Scheme 33

Scheme 34

Scheme 34

Scheme 35

Scheme 35

Scheme 36

Scheme 36

Scheme 37

Scheme 37

Scheme 38

Scheme 38: PINPOINT TEST M: NO MODULE/NETWORK COMMUNICATION - NO POWER TO THE DIAGNOSTIC TOOL
