Supplemental Inflatable Restraint System Ford Crown Victoria II

DESCRIPTION & OPERATION

The Supplemental Restraint System (SRS), also known as air bag system, is designed to provide increased accident protection for driver and passenger by deploying air bags in a front-end or side (lateral) collision. The air bags, stored in center of steering wheel, in instrument panel above glove box and instrument panel above glove box and in driver"s and passenger"s front seat back, deploy in about 40 milliseconds after crash sensors close. Air bag system is designed to be used with 3-point seat belts.

During a front-end collision, the air bag Restraints Control Module (RCM), using input from front impact crash sensor, discriminates between an event that warrants air bag and seat belt pretensioner deployment and an event that does not. Using inputs from passenger seat occupant classification sensor, if equipped, driver seat track position sensor and seat belt switches in conjunction with front impact crash sensor inputs, RCM determines which air bags to deploy and at what deployment rate. In a crash of sufficient force, the RCM signals the air bag modules and seat belt pretensioners to simultaneously deploy.

During a side or lateral collision, the RCM, using inputs from right and/or left side crash sensor, discriminates between an event that warrants air bag deployment and an event that does not. In a collision of sufficient force, the RCM signals the right and/or left seat air bag module(s) to deploy.

Air bag system includes the following components: Restraints Control Module (RCM) or also known as air bag monitor, safing sensor (located inside the RCM), back-up power supply (also located inside the RCM), dual-stage driver-side air bag module, dual-stage passenger-side air bag module, driver and passenger seat belt pretensioners and seat belt switches, driver seat track position sensor, passenger seat occupant classification sensor, if equipped, right- and left-side air bag modules and crash sensors, if equipped, AIR BAG warning light, front crash sensor, ignitor assemblies (located in air bag modules), clockspring and associated wiring harnesses. See COMPONENT LOCATIONS .

COMPONENT LOCATIONS

RESTRAINT SYSTEM COMPONENT LOCATIONS

Scheme 32

Scheme 33

Scheme 34

SYSTEM OPERATION CHECK

1. When checking air bag system operation (also known as prove out system), and upon completion of each diagnostic test, check for faults in air bag system. To check system, turn ignition switch to RUN position. If AIR BAG warning light illuminates for 6 seconds and then goes out, air bag system is functioning properly and no faults exist.
2. If a fault is detected in air bag system during initial system check, AIR BAG warning light will flash a code sequence, indicating a fault in system. Count number of flashes after fault code has cycled twice. Number of flashes represents a code number used to diagnose air bag system. See «DIAGNOSTICS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__diagnostics) . If AIR BAG warning light either fails to light or stays on continuously, go to «DIAGNOSTIC SYMPTOMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table.
3. If a system fault exists and AIR BAG warning light fails to light, an audible tone will be heard, indicating AIR BAG warning light is out and service is required.

AIR BAG SAFETY PRECAUTIONS

Observed these precautions when servicing the air bag system

1. Disable air bag system before servicing any air bag system, steering column or instrument panel components. Failure to do so may result in accidental air bag deployment and personal injury. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-activating-air-bag-system) .
2. Wait one minute after disabling air bag system before working on vehicle. Back-up power supply holds a deployment charge for about one minute after battery is disconnected. Servicing air bag system before one minute may cause accidental air bag deployment and possible personal injury.
3. Because driver-side and passenger-side front air bags each have 2 deployment stages, it is possible that one stage has deployed, but not the other. If a front air bag module has deployed, in is mandatory that the module be remotely deployed prior to disposal. See «DISPOSAL PROCEDURES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disposal-procedures) .
4. Because of critical system operating requirements, DO NOT dissemble or attempt to repair crash sensors, clockspring, restraints control module, seat belt pretensioner or air bag modules. Repairs are made by replacement only.
5. Always wear safety glasses whenever servicing an air bag equipped vehicle or handling an air bag.
6. When carrying a live air bag module, ensure air bag module and trim cover are pointed away from your body. This minimizes chance of injury in event of an accidental deployment.
7. When placing a live air bag module on a bench or other surface, always face air bag module and trim cover facing up and away from surface. This will reduce motion of module if it is accidentally deployed.
8. After deployment, air bag surface may contain deposits of sodium hydroxide, which may irritate skin. Sodium hydroxide is a product of gas generant combustion. Always wear gloves and safety glasses when handling a deployed air bag. Wash your hands using mild soap and water. Follow correct disposal procedures. See «DISPOSAL PROCEDURES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disposal-procedures) .
9. If scrapping a vehicle with an undeployed air bag module, air bag must be deployed. See «DISPOSAL PROCEDURES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disposal-procedures) .
10. If a part is replaced and NEW part does not correct condition, reinstall original part and perform diagnostic procedure again.
11. Never probe connectors on air bag module. Doing so may cause air bag deployment and/or personal injury.
12. Instruction to disconnect always refers to connector. DO NOT remove component from vehicle if instructed to disconnect.
13. After any servicing, ensure AIR BAG warning light does not indicate any fault codes. See «SYSTEM OPERATION CHECK»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__system-operation-check) .
14. Replace air bag module if trim cover (deployment door) is marred or damaged. DO NOT repaint trim cover. Paint may degrade cover material. Replace air bag module as necessary. See «SCRAPPED VEHICLE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__scrapped-vehicle-seats-installed) under DISPOSAL PROCEDURES.
15. If vehicle is involved in collision in which center tunnel area is damaged, inspect RCM mounting bracket for deformation. If damaged, RCM must be replaced whether or not air bags have deployed. Additionally, ensure RCM mounting area is restored to its original condition.

DISABLING & ACTIVATING AIR BAG SYSTEM

Note. When battery is disconnected, certain memory circuits will lose data. When battery is reconnected, it may be necessary to perform appropriate computer relearn procedure. See COMPUTER RELEARN .

DISABLING SYSTEM

Note. There are 3 different disabling procedures. Please read and perform appropriate procedure.

General Disabling Procedure

This procedure should only be used when removing and installing air bag system components or when necessary to deactivate the system to facilitate other maintenance.

1. Record pre-set radio frequencies for reprogramming, if equipped. Disconnect negative battery cable. Also, disconnect any auxiliary batteries and power supplies, if equipped. Wait at least one minute for back-up power supply to deplete stored energy.
2. Remove steering column opening lower finish panel and reinforcement. Remove left lower instrument panel insulator. Disconnect lower clockspring harness connector, located at base of steering column. Connect Air Bag Simulator (418-F403) to harness side of lower clockspring connector.
3. Remove passenger-side air bag module. See «DUAL-STAGE PASSENGER-SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__dual-stage-passenger-side-air-bag-module) under REMOVAL & INSTALLATION. Connect Air Bag Simulator (418-F403) to passenger-side air bag vehicle harness connector (in place of air bag module).
4. Connect negative battery cable. Move and tilt front seats to highest and most forward position. Disconnect negative battery cable. Wait at least one minute for back-up power supply to deplete stored energy. CAUTION: Removing side air bag bridge resistor can cause low resistance fault. AIR BAG warning light illumination and erroneous Diagnostic Trouble Code (DTC) will result. Some models are not equipped with side air bags. Side air bag bridge resistors are installed in place of side air bags on these models. Do not remove side air bag bridge resistors unless directed.
5. On models equipped with side air bags, push in tab on right side air bag module connector and disconnect connector. Install Air Bag Simulator (418-F088/105-R0012) on harness side of side air bag module connector. Repeat procedure for left side air bag module.
6. On all models, access and disconnect right front seat belt pretensioner connector. See «SEAT BELT PRETENSIONER»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Connect Air Bag Simulator (418-F088/105-R0012) to harness side of right front seat belt pretensioner connector (in place of pretensioner).
7. Access and disconnect left front seat belt pretensioner connector. Connect Air Bag Simulator (418-F088/105-R0012) to harness side of left front seat belt pretensioner connector (in place of pretensioner).
8. Connect negative battery cable. With air bag simulators installed at all deployable devices, perform system operation check. See «SYSTEM OPERATION CHECK»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__system-operation-check) . Disconnect negative battery cable. Wait at least one minute for back-up power supply to deplete stored energy.

Diagnostics Disabling Procedure (Seats Removed)

This procedure should only be used when diagnosing/repairing seat side air bag problems, or when diagnosing/repairing any in-seat or seat mounted component of a seat equipped with a seat side air bag.

1. Record pre-set radio frequencies for reprogramming, if equipped. Disconnect negative battery cable. Wait at least one minute for back-up power supply to deplete stored energy.
2. Remove driver-side air bag module. See «DUAL-STAGE DRIVER-SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Connect Air Bag Simulators (418-F395) to clockspring electrical connectors, located at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-simulator-seats-installed) .
3. Remove passenger-side air bag module. See «DUAL-STAGE PASSENGER-SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__dual-stage-passenger-side-air-bag-module) under REMOVAL & INSTALLATION. Connect Air Bag Simulator (418-F403) to passenger-side air bag vehicle harness connector (in place of air bag). Remove front seats. See «FRONT SEAT»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. CAUTION: Removing side air bag bridge resistor can cause low resistance fault. AIR BAG warning light illumination and erroneous Diagnostic Trouble Code (DTC) will result. Some models are not equipped with side air bags. Side air bag bridge resistors are installed in place of side air bags on these models. Do not remove side air bag bridge resistors unless directed.
4. On models equipped with side air bags, install Air Bag Simulators (418-F088/105-R0012) on harness side of right and left side air bag module harness connectors. On all models, access and disconnect right front seat belt pretensioner connector. See «SEAT BELT PRETENSIONER»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Connect Air Bag Simulator (418-F088/105-R0012) to harness side of right front seat belt pretensioner connector (in place of pretensioner).
5. Access and disconnect left front seat belt pretensioner connector. Connect Air Bag Simulator (418-F088/105-R0012) to harness side of left front seat belt pretensioner connector (in place of pretensioner). Reconnect negative battery cable.

Diagnostics Disabling Procedure (Seats Installed)

This procedure should only be used when diagnosing/repairing a problem that is not related to a seat equipped with a seat side air bag.

1. Record pre-set radio frequencies for reprogramming, if equipped. Disconnect negative battery cable. Wait at least one minute for back-up power supply to deplete stored energy.
2. Remove driver-side air bag module. See «DUAL-STAGE DRIVER-SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Connect Air Bag Simulators (418-F395) to clockspring electrical connectors, located at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-simulator-seats-installed) .
3. Remove passenger-side air bag module. See «DUAL-STAGE PASSENGER-SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__dual-stage-passenger-side-air-bag-module) under REMOVAL & INSTALLATION. Connect Air Bag Simulator (418-F403) to passenger-side air bag vehicle harness connector (in place of air bag). CAUTION: Removing side air bag bridge resistor can cause low resistance fault. AIR BAG warning light illumination and erroneous Diagnostic Trouble Code (DTC) will result. Some models are not equipped with side air bags. Side air bag bridge resistors are installed in place of side air bags on these models. Do not remove side air bag bridge resistors unless directed.
4. On models equipped with side air bags, disconnect right and left-side air bag module harness connectors. Install Air Bag Simulators (418-F088/105-R0012) on harness side of right and left side air bag module harness connectors. On all models, access and disconnect right front seat belt pretensioner connector. See «SEAT BELT PRETENSIONER»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Connect Air Bag Simulator (418-F088/105-R0012) to harness side of right front seat belt pretensioner connector (in place of pretensioner).
5. Access and disconnect left front seat belt pretensioner connector. Connect Air Bag Simulator (418-F088/105-R0012) to harness side of left front seat belt pretensioner connector (in place of pretensioner). Reconnect negative battery cable.

General Activating Procedure (Seats Installed)

1. Disconnect negative battery cable. Wait at least one minute for back-up power supply to deplete stored energy. Disconnect air bag simulators from seat belt pretensioner harness connectors and reconnect seat belt pretensioners.
2. Remove air bag simulators from left and right side air bag harness connectors and reconnect connectors, if necessary. Connect negative battery cable. Move and tilt front seats to their lowest and most rearward position. Disconnect negative battery cable. Wait at least one minute for back-up power supply to deplete stored energy.
3. Disconnect air bag simulator from passenger-side air bag module harness connector, reconnect and install passenger-side air bag module. Disconnect air bag simulator from lower clockspring harness connector. Reconnect lower clockspring harness connector, install insulator, reinforcement and steering column lower finish panel. Reconnect negative battery cable. Perform system operation check. See «SYSTEM OPERATION CHECK»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__system-operation-check) . Reprogram pre-set radio frequencies and set clock.

Diagnostics Activation Procedure (Seats Removed)

1. Disconnect negative battery cable. Wait at least one minute for back-up power supply to deplete stored energy. Remove air bag simulators from left and right front seat belt pretensioner harness connectors and reconnect connectors. Install components removed to access seat belt pretensioners.
2. Install front seat(s). Remove air bag simulators from left and right side air bag harness connectors and reconnect connectors. Remove air bag simulator from passenger-side air bag harness connector. Install passenger-side air bag module.
3. Remove air bag simulators from upper clockspring harness connectors and install driver-side air bag module. Connect negative battery cable. Perform system operation check. See «SYSTEM OPERATION CHECK»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__system-operation-check) . Perform computer relearn procedure. See «COMPUTER RELEARN»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__computer-relearn-seats-installed) . Reprogram pre-set radio frequencies and set clock.

General Activation Procedure (Seats Installed)

1. Disconnect negative battery cable. Wait at least one minute for back-up power supply to deplete stored energy. Remove air bag simulators from left and right front seat belt pretensioner harness connectors and reconnect connectors. Install components removed to access seat belt pretensioners.
2. Remove air bag simulators from left and right side air bag harness connectors and reconnect connectors, if necessary. Remove air bag simulator from passenger-side air bag harness connector and reconnect connectors. Install instrument panel relay cover.
3. Remove air bag simulator from upper clockspring harness connector and install driver-side air bag module. Connect negative battery cable. Perform system operation check. See «SYSTEM OPERATION CHECK»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__system-operation-check) . Perform computer relearn procedure. See «COMPUTER RELEARN»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__computer-relearn-seats-installed) . Reprogram pre-set radio frequencies and set clock.

COMPUTER RELEARN (SEATS INSTALLED)

When battery is disconnected and reconnected, some abnormal drive symptoms may occur while vehicle relearns its adaptive strategy. Vehicle may need to be driven for approximately 10 miles or more to relearn strategy.

AIR BAG SIMULATOR (SEATS INSTALLED)

Air Bag Simulators (418-F088/105-R0012, 418-F403, 418-F088 and 418-F395) or equivalent are required to perform diagnosis and testing of the air bag system. (Scheme 35) An air bag simulator is a 2-ohm resistor, with appropriate connector, used to simulate an air bag module. DO NOT short-circuit air bag module connections with a zero-ohm jumper wire. If zero-ohm jumper is used, a Light Flash Code (LFC) will be displayed.

Scheme 35

DISPOSAL PROCEDURES

Note. Disposal of undeployed air bag may violate federal, state and/or local laws. If scrapping vehicle, air bags must be deployed while mounted in vehicle. If this is not possible, remove air bag and deploy remotely. If air bag cannot be deployed, contact vehicle manufacturer for further instructions.

Air bag disposal may be necessary in following situations

1. Scrapping vehicle with deployed air bag or pretensioner.
2. Scrapping vehicle with live air bag or pretensioner.
3. Disposal of a live but electrically faulty air bag module or pretensioner.
4. Disposal of a deployed air bag module or pretensioner.

AIR BAG & PRETENSIONER DISPOSAL PROCEDURES

DEPLOYED AIR BAG OR PRETENSIONER (SEATS INSTALLED)

Dispose of deployed air bag module as any other part. Air bag module components are not reusable.

UNDEPLOYED AIR BAG OR PRETENSIONER-FAULTY UNIT (SEATS INSTALLED)

If an undeployed air bag module or seat belt pretensioner is diagnosed as faulty, remove faulty device and return intact to Ford Motor Company for proper disposal. Return carton for warranty claim credit. Air bag must be packaged and shipped according to U.S. Department of Transportation procedures. Retain replacement packaging including label. DO NOT deploy air bag.

SCRAPPED VEHICLE (SEATS INSTALLED)

Note. Do not dispose of undeployed air bag modules or seat belt pretensioners without first deploying unit. If this is not possible through procedure outlined, contact vehicle manufacturer for further instructions. Because driver and passenger-side front air bags each have 2 deployment stages, it is possible that one stage has deployed, but not the other. If a front air bag module has deployed, in is mandatory that the module be remotely deployed prior to disposal.

If vehicle is to be scrapped, undeployed air bag module(s) or seat belt pretensioner(s) must first be deployed. Use the following procedure for remote deployment of air bag module or seat belt pretensioner.

Remote Deployment Of Dual-stage Driver-side AIR Bag (Seats Installed)

This procedure is to be used when a vehicle with a live dual-stage driver-side air bag module is to be scrapped.

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove driver-side air bag module. See «DUAL-STAGE DRIVER-SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION.
2. Cut harness connectors off of clockspring wire harness, leaving enough wire to make a deployment harness. Remove sheathing from cut wires. Strip insulation from all 4 wire ends of cut wire harness. Using ohmmeter, measure resistance between harness connector and wire end, on each cut wires. If resistance is less than 5 ohms, connect cut wire harness connectors to driver-side air bag module. (Scheme 36) If resistance is more than 5 ohms, use another connector.
3. Twist one wire from each pair together to make one pair. (Scheme 37) Obtain 2 wires, each at least 20 gauge and 20 feet (6.09 m) or longer. Place air bag module to be deployed on flat surface in an open outdoor area with trim cover (deployment side) facing up.
4. Connect one end of each 20-foot wire to end of each twisted wire splice. With 20-foot wire fully extended, deploy device by touching loose ends of both wires to 12-volt battery terminals. If successful, a loud noise will be heard and bag material will be visible. Allow at least 10 minutes for cooling before handling device.
5. Device is now inoperative and may be disposed of as any other part to be scrapped. If device does not deploy, device is faulty. Contact vehicle manufacturer for further instructions on disposal procedures.

Scheme 36

Scheme 37

Remote Deployment Of Dual-stage Passenger-side AIR Bag (Seats Installed)

This procedure is to be used when a vehicle with a live dual-stage passenger-side air bag module is to be scrapped.

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove passenger-side air bag module. See «DUAL-STAGE PASSENGER-SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__dual-stage-passenger-side-air-bag-module) under REMOVAL & INSTALLATION. Cut and strip 4 wires near passenger-side air bag module electrical connector. Twist one wire from each pair together to make one pair. (Scheme 38)
2. Obtain 2 wires, each at least 20 gauge and 20 feet (6.09 m) or longer. Place device to be deployed on flat surface in an open outdoor area with trim cover (deployment side) facing up.
3. Connect one end of each 20-foot wire to end of each twisted wire splice. With 20-foot wire fully extended, deploy air bag by touching loose ends of both wires to 12-volt battery terminals. If successful, a loud noise will be heard and bag material will be visible. Allow at least 10 minutes for cooling before handling device.
4. Air bag is now inoperative and may be disposed of as any other part to be scrapped. If air bag does not deploy, air bag is faulty. Contact vehicle manufacturer for further instructions on disposal procedures.

Scheme 38

Remote Deployment Of Side AIR Bag (Seats Installed)

This procedure is to be used when a vehicle with a live air bag module is to be scrapped.

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove appropriate side air bag module. See «SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__side-air-bag-module) under REMOVAL & INSTALLATION.
2. Cut and strip wires near side air bag module electrical connector. (Scheme 39) Obtain 2 wires, each at least 20 gauge and 20 feet (6.09 m) or longer. Place air bag to be deployed on flat surface in an open outdoor area with trim cover (deployment side) facing up.
3. Connect one end of each 20-foot wire to end of each twisted wire splice. With 20-foot wire fully extended, deploy air bag by touching loose ends of both wires to 12-volt battery terminals. If successful, a loud noise will be heard and bag material will be visible. Allow at least 10 minutes for cooling before handling device.
4. Air bag is now inoperative and may be disposed of as any other part to be scrapped. If air bag does not deploy, air bag is faulty. Contact vehicle manufacturer for further instructions on disposal procedures.

Scheme 39

Remote Deployment Of Seat Belt Pretensioners (Seats Installed)

This procedure is to be used when a vehicle with a live left or right pretensioner is to be scrapped.

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
2. Remove pretensioners. See «SEAT BELT PRETENSIONER»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. With pretensioners removed, cut pretensioner connector from wiring harness near pretensioner. Strip 1" of insulation from wire ends. Obtain 2 wires, each at least 20 gauge and 20 feet long. Connect one end of each 20-foot wire to one end of each pretensioner wire. (Scheme 40) WARNING: Seat belt pretensioner can ricochet when deployed. Personal injury may result. When placing a live pretensioner on a bench or other surface, always position pretensioner so that moveable parts do not contact surface. This will reduce motion of pretensioner, if accidentally deployed.
3. Place pretensioner on a flat surface in remote area (such as parking lot or field) in such a way that moving parts are not contacting surface. Remain at least 20 feet away from pretensioner. Deploy pretensioner by touching loose ends of both wires to 12-volt battery terminals.
4. If successful, a loud noise will be heard. Allow at least 10 minutes for cooling before approaching pretensioner. Pretensioner is now inoperative. If pretensioner does not deploy, pretensioner is faulty. Contact vehicle manufacturer for further instructions on disposal procedures.

Scheme 40

POST-COLLISION INSPECTION

When a vehicle has been involved in a collision, certain components of the passive restraint system must be inspected or replaced. See AIR BAG/SRS COMPONENT INSPECTION & REPLACEMENT TABLES article in the GENERAL INFORMATION section.

REMOVAL & INSTALLATION

CLOCKSPRING

Removal

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions). Clockspring is located on steering column between steering wheel and combination switch. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
2. Ensure front wheels are in straight-ahead position. Remove driver-side air bag module and steering wheel. See «STEERING WHEEL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__steering-wheel). Apply 2 strips of masking tape across clockspring to prevent accidental rotation. (Scheme 41) Place steering column in full down position. Twist tilt wheel handle and shank and remove.
3. Remove 4 screws and lower steering column shroud. Position ignition lock cylinder in RUN position. Using small drift, push upward on lock cylinder release tab while pulling clock cylinder outward. (Scheme 42) Remove upper steering column shroud.
4. Release voice-activated cellular phone microphone retaining tab and remove microphone, if equipped. Remove passive anti-theft transmitter retaining screw and remove transmitter. Remove key-in warning indicator switch.
5. Remove clockspring electrical connectors from retaining bracket. Disconnect remaining clockspring connector. Separate clockspring wiring harness from harness retainers and side of steering column. Pry clockspring retaining clips loose and remove clockspring. (Scheme 43)

Installation

1. If installing NEW clockspring, remove locking mechanism pull ring. If installing existing clockspring, remove tape applied during removal procedure. If clockspring rotor has moved or if unsure of clockspring rotor position, center clockspring. See «CLOCKSPRING CENTERING»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clockspring-centering) under ADJUSTMENTS. Maintain clockspring centered position. NOTE: Slight turning of clockspring is allowable during installation to properly align clockspring to steering column.
2. With flats of clockspring aligned to flats on steering column, slide clockspring onto steering column and engage retaining tabs. Route clockspring wiring harness down side of steering column and engage harness retainers. Remove air bag simulator from lower clockspring harness connector and reconnect connectors. Attach clockspring connectors to connector retaining bracket.
3. To complete installation, reverse removal procedure. DO NOT install driver-side air bag module at this time. Tighten fasteners to specification. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications) . Install Air Bag Simulators (418-F395) on both upper clockspring connectors, located on top of clockspring.
4. Connect negative battery cable. With air bag simulators installed at all remaining deployable devices, perform system operation check. See «SYSTEM OPERATION CHECK»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__system-operation-check) . Install driver-side air bag module. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

Scheme 41

Scheme 42

Scheme 43

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove 2 steering wheel back cover plugs.
2. Remove 2 driver-side air bag module retaining bolts. Pull air bag module away from steering wheel. Number air bag electrical connectors on back of module for reassembly reference. Disconnect air bag electrical connectors and release wiring harness retainer. Disconnect horn switch electrical connector. (Scheme 44) Remove air bag module.
3. Remove air bag simulator from lower clockspring harness connector and reconnect connector. Install 2 Air Bag Simulators (418-F395) to upper clockspring electrical connectors. Connect negative battery cable. perform system operation check. See «SYSTEM OPERATION CHECK»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__system-operation-check). Disconnect negative battery cable. Wait at least one minute for back-up power supply to deplete stored energy. CAUTION: It is possible to connect air bag module connectors improperly. Damage to air bag module electrical connectors may result. Air bag module electrical connectors are unique and cannot be reversed when connected to driver-side air bag module. Match electrical connector key to keyway in air bag module. Do not force electrical connector into air bag module.
4. To install, reverse removal procedure. Use reference numbers on air bag electrical connectors to ensure proper connections. Tighten air bag module bolts to specification. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications). With air bag simulators installed at all remaining deployable devices, perform system operation check. See «SYSTEM OPERATION CHECK»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__system-operation-check). Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

Scheme 44

DUAL-STAGE PASSENGER-SIDE AIR BAG MODULE

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions). The passenger-side air bag module is mounted in right side of instrument panel, above glove box. Disconnect negative battery cable. Wait at least one minute for back-up power supply to deplete stored energy.
2. Pull out on right instrument panel trim panel and release clips. Slide trim panel slightly to right, align keyway and remove trim panel. Disconnect defroster switch and clock connectors from trim panel. Open glove box and disconnect glove box isolator. Push in on glove box door tabs and fully lower glove box door.
3. Working through glove box opening, remove 2 passenger-side air bag module mounting bolts. (Scheme 45) Remove 2 passenger-side air bag module mounting bolts from front of instrument panel (trim panel area). (Scheme 46) Place one hand in glove box opening and push passenger-side air bag module out of instrument panel.
4. Disconnect passenger-side air bag module harness connector and remove module from vehicle. Install Air Bag Simulator (418-F403) on passenger-side air bag harness connector (in place of air bag). Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
5. To install, reverse removal procedure. Tighten passenger-side air bag module mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications). Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

Scheme 45

Scheme 46

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions) . The front crash sensor is located on upper radiator support, next to hood latch. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Open hood. Remove pin-type retainers and upper radiator deflector. Remove front crash sensor mounting screws. Disconnect front crash sensor electrical connector and remove sensor.
2. To install, reverse removal procedure. Tighten fasteners to specification. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications) . Connect negative battery cable. With air bag simulators installed at all deployable devices, perform system operation check. See «SYSTEM OPERATION CHECK»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__system-operation-check) . Activate air bag system. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-activating-air-bag-system) .

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions) . Move appropriate seat to full forward position. On models not equipped with side air bags, disconnect negative battery cable. On models equipped with side air bags, disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. On all models, remove rear seat track covers and mounting nuts.
2. On models equipped with power seats, reconnect negative battery cable. On all models, move seat to full rearward position. Remove front seat track covers and mounting bolts. Disconnect negative battery cable. Disconnect front seat harness connectors. Remove seat from vehicle.
3. To install, reverse removal procedure. Tighten front seat mounting nuts and bolts to specification. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications) . On models equipped with side air bags, DO NOT activate air bag system at this time. Remove air bag simulator from affected front seat side air bag harness connector and reconnect connectors. With air bag simulators installed at all remaining deployable devices, perform system operation check. See «SYSTEM OPERATION CHECK»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__system-operation-check) . Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions). Disconnect negative battery cable. Set parking brake. Using Radio Removal Tool (T87P-19061-A), pull out radio unit from instrument panel. Disconnect radio electrical connectors and antenna cable and remove radio. Unsnap left and right instrument panel moldings, disconnect appropriate electrical connectors and remove moldings.
2. Place gearshift lever in "1" position. Tilt steering wheel to full down position. Remove 8 instrument panel cluster finish panel retaining screws and pull cluster finish panel away from instrument panel. (Scheme 47) Disconnect electrical connectors and remove instrument panel cluster finish panel.
3. Remove 2 bolts and move parking brake release handle aside. Remove lower steering column cover. Remove 5 screws and instrument panel steering column opening cover reinforcement. Disconnect transmission range indicator cable, remove cable retaining bolt and position cable out of way.
4. On models equipped with electronic instrument cluster, loosen forward steering column mounting nuts. Loosen aft steering column mounting nuts. Allow steering column to drop down enough to remove instrument cluster. On all models, remove 4 instrument cluster retaining screws. Pull instrument cluster out and disconnect electrical connectors. Remove instrument cluster. To install, reverse removal procedure. Tighten fasteners to specification. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications).

Scheme 47

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions) . LCM is located under left side of instrument panel. Disconnect negative battery cable.
2. Remove 3 push pins, disconnect courtesy light and remove left instrument panel sound insulator. On models equipped with adjustable accelerator pedal, remove accelerator cable from accelerator pedal and shaft. Using pliers, remove adjustable cable from brake pedal. Disconnect adjustable pedal driver motor electrical connector. Remove 2 nuts and accelerator pedal and shaft. On all models, remove 2 LCM mounting screws. Release LCM locking tab and lower LCM. Disconnect LCM electrical connectors and remove LCM. To install, reverse removal procedure.

OCCUPANT CLASSIFICATION SENSOR (OCS)

Note. OCS is found only on right front seat. In addition, OCS is not installed on all models. A white tag having the letters "OCS" will appear under the front of right front seat, identifying seat equipped with OCS. OCS system components (seat cushion foam pad, bladder with pressure sensor and electronic control unit) are calibrated to each other. OCS system components are not to be installed separately. If OCS component requires being replaced, all components must replaced as an assembly. If replacing front passenger seat trim cushion trim cover only, OCS must be zeroed.

An original equipment OCS will have electrical connectors that can be disconnected at OCS pressure sensor and OCS electronic control module. Also, OCS will have seat cushion foam pad that is not attached to bladder and pressure sensor assembly. A service part OCS will have electrical disconnect deterrents at OCS pressure sensor and OCS electronic control module.

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions). On models not equipped with side air bags, disconnect negative battery cable. Wait at least one minute. On models equipped with side air bags, disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
2. On all models, remove right front seat. See «FRONT SEAT»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Release J-clips, located at bottom rear of seat back. On models equipped with heated seats, disconnect seat heater electrical connector. On models equipped with side air bags, disconnect side air bag electrical connector. Remove seat back mounting bolts, pivot bolt and seat back. (Scheme 48)& (Scheme 49). Disconnect appropriate seat track electrical connectors.
3. Remove seat belt buckle mounting nut. Pull seat belt buckle through seat cushion opening. Release J-clips adjacent to seat track. Remove seat track mounting bolts and seat track. On models equipped with manual seat recliner, remove seat recliner handle. On all models, remove pin-type retainers and separate remaining seat cushion trim cover "J" clips from seat cushion frame. Separate Velcro strips and position seat cushion trim cover out of way. NOTE: Mark holes in seat cushion frame used to retain OCS electronic control unit for reassembly reference.
4. On models equipped with original equipment OCS, remove seat cushion pad from seat cushion frame. Remove pin-type retainers holding OCS bladder to seat cushion frame. (Scheme 50) Disconnect OCS electronic control unit electrical connectors. (Scheme 51) On models equipped with service part OCS, cut OCS harness tie straps.
5. On all models, use 7/32" (5 mm) drill bit to drill out rivets retaining electronic control unit to seat cushion frame. Bend and release retaining tab holding pressure sensor in place. Slide pressure sensor off bracket. On models equipped with original equipment OCS, feed pressure sensor and hose through seat cushion support assembly. On models equipped with service part OCS, feed pressure sensor and hose, OCS wiring harness electrical connector and electronic control unit through seat cushion support assembly. On all models, remove OCS. WARNING: Foreign objects between OCS components and seat cushion frame and support assembly may cause air bags to improperly deploy. Personal injury may result. Ensure OCS components, seat cushion frame and support assembly are free of any foreign objects during reassembly. CAUTION: Improper routing of OCS components can cause binding or pinching of components. Damage to OCS components may result. Failure to route OCS components through correct seat cushion support opening can cause OCS component failure and air bag system malfunction. Ensure OCS components are properly routed during reassembly. NOTE: When installing new OCS, a prepaid return postcard is included with new part. The serial number for the new part and Vehicle Identification Number (VIN) must be recorded on postcard, and sent to Ford Motor Co. Fill out the necessary information on the OCS traceability card and return it with the complete inoperative OCS unit. When returning the inoperative OCS unit, include: seat cushion foam pad, bladder, OCS ECU, pressure sensor (transducer), hose, electrical connectors and wire harness (service part OCS unit only). When installing service part OCS, main seat wire harness pressure sensor electrical connector is not used. When installing service part OCS, feed pressure sensor and hose, OCS wiring harness electrical connector and electronic control unit through largest hole in front of seat cushion support assembly.

To install, reverse removal procedure. Tighten front seat mounting bolts to specification. See TORQUE SPECIFICATIONS . Route OCS components through correct seat cushion support opening. Tie strap all loose wire harnesses and electrical components safely out of way. Activate air bag system. See ACTIVATING SYSTEM under DISABLING & ACTIVATING AIR BAG SYSTEM. Zero OCS sensor. See ZERO OCCUPANT CLASSIFICATION SENSOR (OCS) under DIAGNOSTICS. Perform system operation check. See SYSTEM OPERATION CHECK .

Scheme 48

Scheme 49

Scheme 50

Scheme 51

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions). RCM is located on center tunnel, under instrument panel. On models equipped with center console, set parking brake and place gear shift lever in Neutral position. On all models, disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
2. Release ashtray retaining tabs and remove ashtray. Remove ashtray bracket retaining screws, located under instrument panel center stack. Slide ashtray bracket forward, releasing bracket retainers, and position ashtray bracket out of way.
3. On models equipped with center console, pull out on center console gauge assembly finish panel and position assembly aside. Pull up on center console finish panel to release retaining clips and rotate finish panel out of way. Carefully remove shift cable socket from the shifter ball. (Scheme 52) Push in on shift cable release tab and separate shift cable from shifter assembly.
4. Push in on shift interlock cable release tab and separate shift interlock cable from shifter assembly. (Scheme 53) Remove RCM mounting bolts and remove RCM. (Scheme 54) Disconnect RCM electrical connector locking clip and disconnect connector.
5. To install, reverse removal procedure. Tighten RCM mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications). Reconnect negative battery cable. With air bag simulators installed at all deployable devices, perform system operation check. See «SYSTEM OPERATION CHECK»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__system-operation-check). Activate air bag system. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-activating-air-bag-system).

Scheme 52

Scheme 53

Scheme 54

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions) . The seat belt switches are integrated with front seat belt buckle assembly.
2. Remove appropriate front seat to access seat belt buckle. See «FRONT SEAT»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect seat belt buckle electrical connector. Remove seat belt buckle mounting nut. Remove seat belt buckle through seat cushion opening.
3. To install, reverse removal procedure. Tighten seat belt buckle mounting nut to specification. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications) . Ensure center passenger seat belt is not twisted and is correctly routed along side of seat.

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions) . Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
2. Release 2 tabs and open front seat shoulder strap guide cover. Remove guide retaining nut. Remove seat belt lower anchor bolt cover and anchor bolt. Remove screw and shoulder belt guide. Using Torx Bit (501-010), remove pretensioner mounting bolt. Pivot bottom of pretensioner up and release retaining tab. Remove pretensioner.
3. To install, reverse removal procedure. Tighten fasteners to specification. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications) . Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove left front seat. See «FRONT SEAT»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system).
2. Remove sensor mounting bolt and disconnect connector. (Scheme 55) On models with power seats, press sensor tab inward to release sensor. Remove magnet assembly mounting bolt. Slide magnet assembly rearward. On all models, remove seat track position sensor.
3. To install, reverse removal procedure. Tighten seat track position sensor mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications). Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

Scheme 55

SIDE AIR BAG MODULE

Note. Front seat back trim covers cannot be repaired, they must be replaced (cleaning is permissible).

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove appropriate front seat. See «FRONT SEAT»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Remove seat back trim cover retaining screws, located at bottom of trim cover. Pull seat back trim cover outward at bottom of cover, and slide upward to release retaining hooks. Release seat back trim cover J-clips.
2. Remove side air bag module mounting nuts. (Scheme 56) Position side air bag module and deployment chute away from mounting bracket and seat back frame. Position seat back trim cover and foam pad away from seat back frame.
3. Pull side air bag module mounting studs back through deployment chute openings and remove side air bag module from deployment chute. (Scheme 57) Slide side air bag module electrical connector locking clips. Release 2 retaining tabs and disconnect side air bag electrical connector. Remove side air bag module.

Note. If installing new side air bag module, use new mounting nuts. If reusing side air bag module, reuse mounting nuts.

1. Connect electrical connector to side air bag module. Position side air bag module into deployment chute with alignment pin offset to top, and electrical connector to bottom of seat back. Ensure side air bag module mounting studs and alignment pin have come through deployment chute stud openings. Position side air bag module on seat back frame and install mounting nuts. Tighten side air bag module mounting nuts to specification. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications) .
2. To complete installation, reverse removal procedure. DO NOT activate air bag system at this time. Ensure deployment chute does not have any wrinkles or folds where it contacts seat back frame mounting bracket.
3. Connect negative battery cable. With air bag simulators installed at all remaining air bag system deployable devices, perform system operation check. See «SYSTEM OPERATION CHECK»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__system-operation-check) . Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

Scheme 56

Scheme 57

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove crash sensor mounting bolts. Disconnect crash sensor electrical connector and remove sensor. (Scheme 58)
2. To install, reverse removal procedure. DO NOT activate air bag system at this time. Tighten side crash sensor mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications). Connect negative battery cable. With air bag simulators installed at all deployable devices, perform system operation check. See «SYSTEM OPERATION CHECK»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__system-operation-check). Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

Scheme 58

STEERING WHEEL

1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__air-bag-safety-precautions) . Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove driver-side air bag module. See «DUAL-STAGE DRIVER-SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) . Disconnect clockspring electrical connector.
2. Remove and discard steering wheel retaining bolt. Reference mark steering wheel hub to steering wheel shaft to ensure proper alignment during installation. Using Steering Wheel Puller (205-116), remove steering wheel. Route clockspring wiring harness through steering wheel as wheel is lifted off shaft.

To install, reverse removal procedure. Install NEW steering wheel retaining bolt and tighten to specification. See TORQUE SPECIFICATIONS . Activate air bag system. See DISABLING & ACTIVATING AIR BAG SYSTEM .

CLOCKSPRING CENTERING

While holding clockspring outer housing stationary, turn rotor counterclockwise until slight resistance is felt (end of travel). Turn clockspring rotor clockwise 3 turns. DO NOT allow clockspring to move from this position.

WIRE REPAIR

To repair damage to sensor wiring and wiring harnesses, note following conditions and go to REPAIR PROCEDURE .

1. All wire splice connections must be staggered at least 2" (50 mm) apart.
2. Use proper size, waterproof butt-splice connectors on any exposed wiring.
3. Use heat shrink nylon splice to prevent water, salt, condensation and heat from affecting the wiring repair.
4. Use transparent splice connectors to allow inspection of finished splice.

REPAIR PROCEDURE

Insert pre-stripped wire ends into proper size waterproof butt-splice connector, and crimp connector using appropriate crimping pliers. (Scheme 59) Using heat gun, hair dryer or match, heat splice until it shrinks and adhesive oozes from each end of tubing. Connection is now waterproofed.

Scheme 59

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

DIAGNOSTICS

Note. Unless otherwise specified, New Generation STAR (NGS) tester (418-F052), Worldwide Diagnostic System (WDS) tester (418- F224), or equivalent tester will be referred to as scan tool.

SELF-DIAGNOSTICS

During vehicle operation, the Restraints Control Module (RCM) detects and stores both intermittent and hard failure codes in non-volatile memory. The RCM will also display a 2-digit Light Flash Code (LFC) on the AIR BAG warning light. For example, a fault Code 32 will be displayed in following manner: Flash-flash-flash, one-second pause, flash-flash, 3-second pause. Cycle will repeat.

Diagnostic Trouble Codes (DTCs) can be retrieved with the New Generation Star (NGS) tester, Worldwide Diagnostic System (WDS) tester or equivalent scan tool, using the retrieve/clear continuous codes option. If no DTCs are present, scan tool tester will display SYSTEM PASSED message. Once a fault code is logged in RCM memory, it will stay in memory until 254 ignition cycles have been recorded or until scan tool is used to erase the DTCs.

The on-demand self-test can be used to verify there are no electrical faults within air bag system. During this test RCM will check each electrical component in system. If fault is detected, DTC is displayed on scan tool with brief description of fault. Faults detected during self-test are not stored in memory, unless same fault was detected during normal vehicle operation. Self-test should be run after service to verify operation.

Coded fault feature is prioritized so that if 2 or more different faults occur at same time, highest priority fault indication will be shown until corrected using appropriate diagnostic test procedure.

If a system fault exists and AIR BAG warning light is malfunctioning, a series of 5 sets of 5 beeps will sound, indicating service is needed. Number of beeps does not indicate a fault code.

DIAGNOSTIC PROCEDURE

1. Retrieve all DTCs stored in RCM memory by executing RETRIEVE/CLEAR CONTINUOUS DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) .
2. Run on-demand self-test to determine what DTCs are currently being sensed by RCM. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) .
3. If stored DTCs are different than current DTCs, always repair current DTCs first.
4. If different continuous DTCs are displayed from memory than on-demand self-test, repair on-demand self-test codes first then repair continuous codes.
5. If no DTCs are retrieved and symptoms are observed, refer to diagnostic symptoms table. See «DIAGNOSTIC SYMPTOMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table.

INSPECTION & VERIFICATION

1. If AIR BAG warning light is ON, visually inspect for obvious mechanical and electrical damage of following components prior to performing diagnostic tests: Damaged bracket on restraints control module or front crash sensor. Blown fuse(s). Damaged wiring harness. Loose or corroded connectors. Damaged shorting bars. Open or short circuits or loosely mounted sensors. If damage is not visually evident, use scan tool to retrieve Diagnostic Trouble Codes (DTCs) and perform on-demand self-test. See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) .

USING SCAN TOOL

1. Connect scan tool to Data Link Connector (DLC), located under instrument panel, to retrieve continuous diagnostic trouble codes (DTCs) and run self-test diagnostics.
2. If self-test is passed and no DTCs are retrieved, go to diagnostic symptoms table. See «DIAGNOSTIC SYMPTOMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table.
3. If DTCs are retrieved, go to diagnostic trouble code identification table to continue diagnostics. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table.
4. If RCM cannot be accessed by scan tool, go to «TEST Y: NO COMMUNICATION WITH RCM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__test-y-no-communication-with-rcm) under «DIAGNOSTIC TESTS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) to continue diagnostics.

RETRIEVING FAULT CODES

Connect scan tool to Data Link Connector (DLC), located under left-side of instrument panel. Turn ignition switch to RUN position. Follow manufacturer's instructions for scan tool being used. All continuous DTCs will be displayed on scan tool screen. Record DTCs displayed for reference. See DIAGNOSTIC TROUBLE CODE IDENTIFICATION table. When DTCs are cleared, they cannot be retrieved.

CLEARING FAULT CODES

1. Connect scan tool to Data Link Connector (DLC), located under left-side of instrument panel. Turn ignition switch to RUN position. Follow manufacturer's instructions for scan tool being used.
2. The scan tool will retrieve DTCs again after clearing DTCs, and if any remain they will be displayed. Hard DTCs will be re-displayed after clearing DTCs since they cannot be cleared from RCM memory.

ON-DEMAND SELF-TEST

Connect scan tool to Data Link Connector (DLC), located under left-side of instrument panel. Turn ignition switch to RUN position. Follow manufacturer's instructions for scan tool being used. Restraints Control Module (RCM) will run on-demand self-test and display on-demand DTCs on tester screen.

BIT-MAPPED DIAGNOSTIC TROUBLE CODES

Many of the continuous on-demand Diagnostic Trouble Codes (DTCs) that can be present in Restraints Control Module (RCM) are bit-mapped DTCs that utilize Parameter Identifications (PIDs), also known as flagged faults. Bit-mapped DTCs are conceptually different from the previous style of DTCs.

Previously, DTCs identified a specific concern for a given component and pointed to a particular diagnostic path. In the diagnostic path, PIDs are sometimes used to determine the root cause. Bit-mapped DTCs DO NOT identify the specific concern. A bit-mapped DTC identifies the component(s) in which the concern exists. The next level (PIDs or flagged faults) identifies the specific concern.

A scan tool must be used to view PIDs (flagged faults) of a bit-mapped DTC. Once a scan tool has retrieved a bit-mapped DTC, the scan tool will provide the option to flag that DTC. When the option to flag the DTC is available, it must be carried out to identify the specific concern that is present. When the flag option has been carried out, the scan tool will then display the PIDs for that DTC, including the status or state that exists (on-demand DTC) or existed (continuous DTC).

To view and flag bit-mapped DTCs, follow the following steps

1. Connect scan tool to Data Link Connector (DLC), located under left-side of instrument panel.
2. Turn ignition switch to RUN position.
3. Follow manufacturer's instructions for the scan tool being used.
4. Perform on-demand self-test or retrieve continuous DTCs.
5. Select DTC and the FLAG option on scan tool. Scan tool will now display PIDs related to the DTC. Record all flagged faults.

PID/DATA MONITOR & RECORD

PID/Data Monitor and Record option allows technician to read the state of several Parameter IDs (PIDs) to aid in diagnosing the system. To retrieve PIDs, connect scan tool to Data Link Connector (DLC), located under instrument panel, and follow scan tool manufacturer"s instructions. PIDs are updated continuously on scan tool display.

Principles Of Operation

RCM must be programmed as part of the repair procedure. If this procedure is not followed, the RCM will not function correctly and may set a number of Diagnostic Trouble Codes (DTCs), including DTC B2477, which indicates that necessary data has not been programmed into the RCM.

Modules that need to be programmed should not be exchanged between vehicles. In most cases the parameter values or settings are unique to that vehicle, and if not set correctly, will cause concerns or faults.

If the RCM and Powertrain Control Module (PCM) do not contain the correct information, the scan tool will either request "As Built" data or display a list of items that will be required to manually configure. The scan tool will program the RCM based on the data that is entered.

It is not longer necessary to command the scan tool to gather module option content from the old module. The scan tool automatically obtains any available module option content from the old module during the vehicle identification routine that runs when the scan tool is initially connected to the vehicle. It is important that you connect the scan tool to the vehicle and obtain configuration data prior to removing module.

ZERO OCCUPANT CLASSIFICATION SENSOR (OCS)

Ensure front passenger seat is empty. Connect scan tool to Data Link Connector (DLC). See USING SCAN TOOL . Use scan tool to trigger active command and zero OCS. If scan tool is not available, zeroing will occur during normal driving conditions. Perform system operation check. See SYSTEM OPERATION CHECK .

DIAGNOSTIC SYMPTOMS

DIAGNOSTIC TROUBLE CODE IDENTIFICATION

TEST A: AIR BAG WARNING LIGHT ON CONTINUOUSLY-RCM DISCONNECTED OR INOPERATIVE

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Description

During normal operation, the AIR BAG warning light will be continuously illuminated for 6 seconds after the ignition switch is placed in RUN position and after 3 cycles of Light Flash Code (LFC), if a fault exists. Be sure to cycle ignition switch and look for a continuous AIR BAG warning light without LFC.

Restraints Control Module (RCM) will communicate Diagnostic Trouble Codes (DTCs) to the scan tool through the Data Link Connector (DLC). If the scan tool displays NO COMMUNICATION when retrieving continuous DTCs, go to TEST Y: NO COMMUNICATION WITH RCM .

Possible Causes

An AIR BAG warning light that is continuously illuminated may be caused by disconnected RCM, damaged battery or ignition circuit, loss of ground circuit to RCM, damaged wiring, terminals, or connectors, worn or damaged shorting bar or camming beam, inoperative RCM or damaged scan tool.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If continuous DTCs were retrieved, go to step 3. If on-demand DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. If no DTCs were retrieved, go to next step.
2. Check RCM connection Turn ignition switch to OFF position. Deactivate air bag system. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-activating-air-bag-system). Access RCM. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Ensure RCM connector C310B is fully connected and Red clip is inserted. If RCM connector C310B is fully connected and Red clip is engaged, go to next step. If RCM connector C310B is not fully connected or Red clip is not engaged, repair/replace as necessary. Go to step 9.
3. Check RCM Turn ignition switch to OFF position. Deactivate air bag system. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-activating-air-bag-system). Access RCM and disconnect RCM connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Inspect component side of RCM connector C310B for worn or damaged camming beam. (Scheme 60) If camming beam is in good condition, go to next step. If camming beam is not in good condition, replace RCM. Go to step 9.
4. Check RCM harness connector Inspect harness side of RCM connector C310B for worn or damaged shorting bar. If shorting bar is in good condition, go to next step. If shorting bar is not in good condition, repair or replace connector. Go to step 9.
5. Check ignition circuit for open Turn ignition switch to RUN position. Measure voltage between ground and RCM connector C310B, terminal No. 1 (Dark Blue/Light Green wire, circuit No. 964). (Scheme 61) If voltage is 9-16 volts, go to next step. If voltage is not 9-16 volts, repair open in Dark Blue/Light Green wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 9.
6. Check ground circuit for open Turn ignition switch to OFF position. Measure resistance between ground and RCM connector C310B, terminal No. 10 (Black wire, circuit No. 57). If resistance is less than 5 ohms, go to next step. If resistance is more than 5 ohms, repair open in Black wire. Go to step 9.
7. Check circuit for short to ground Reconnect RCM harness connector C310B. On models with analog instrument cluster, access instrument cluster and disconnect instrument cluster module harness connector C2220B. See «INSTRUMENT CLUSTER»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. On models with digital instrument cluster, access instrument cluster and disconnect warning light module harness connector C2222, located near instrument cluster. On models with analog instrument cluster, measure resistance between ground and harness side of instrument cluster module connector C2220B, terminal No. 12 (Black/Yellow wire, circuit No. 608). (Scheme 62) On models with digital instrument cluster, measure resistance between ground and harness side of warning light module connector C2222, terminal No. 1 (Black/Yellow wire). (Scheme 63) On all models, if resistance is less than one megohm, go to next step. If resistance is more than one megohm, repair or replace instrument cluster. Go to step 9.
8. Check RCM for short to ground Disconnect RCM harness connector C310B. Measure resistance between ground and component side of RCM connector C310B, pin No. 9. (Scheme 64) If resistance is less than one megohm, replace RCM and go to next step. If resistance is more than one megohm, repair open in Black/Yellow wire and go to next step.
9. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

TEST B: AIR BAG WARNING LIGHT CIRCUIT OPEN OR SHORT TO GROUND (DTC B1869)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

AIR BAG warning light is designed to illuminate for 6 seconds when ignition switch is turned to RUN position. The initial 6-second illumination is normal and is called prove-out. The AIR BAG warning light is then used to warn vehicle operator that there is a fault in the air bag system.

Restraints Control Module (RCM) monitors AIR BAG warning light for open and short to ground conditions. If RCM detects open or short to ground in AIR BAG warning light circuit, it will store Diagnostic Trouble Code (DTC) B1869 in memory. If RCM detects AIR BAG warning light failure in addition to another air bag system failure, the secondary air bag warning system will be activated.

AIR BAG warning light inoperative condition could be caused by damaged wiring, terminals or connectors, faulty RCM, faulty AIR BAG warning light or instrument cluster module malfunction.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC B1869 was retrieved during on-demand self-test and AIR BAG warning light does not illuminate, go to next step. If DTC B1869 was retrieved during on-demand self-test and AIR BAG warning light does illuminate, go to step 8. If DTC B1869 was not retrieved, fault is intermittent. Go to step 10.
2. Check circuit No 640 Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. On models with analog instrument cluster, access instrument cluster and disconnect instrument cluster module harness connector C2220B. See «INSTRUMENT CLUSTER»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. On models with digital instrument cluster, access instrument cluster and disconnect warning light module harness connector C2222, located near instrument cluster. On all models, turn ignition switch to ON position. On models with analog instrument cluster, measure voltage between ground and harness side of instrument cluster module connector C2220B, terminal No. 7 (Red/Yellow wire, circuit No. 640). (Scheme 62) On models with digital instrument cluster, measure voltage between ground and harness side of warning light module connector C2222, terminal No. 8 (Red/Yellow wire). (Scheme 63) On models with analog instrument cluster, if voltage is 9-16 volts, go to next step. On models with digital instrument cluster, if voltage is 9-16 volts, go to step 6. On all models, if voltage is not 9-16 volts, repair Red/Yellow wire as necessary. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 11.
3. Check instrument cluster AIR BAG warning light circuit for open Turn ignition switch to OFF position. Measure resistance between component side of instrument cluster module connector C2220B, terminals No. 6 and 11. If resistance is less than 500 ohms, go to step 6. If resistance is more than 500 ohms, go to next step.
4. Check AIR BAG warning light bulb Remove AIR BAG warning light bulb from instrument cluster. Visually inspect bulb. If bulb is damaged or the filament is open, replace bulb and go to next step. If bulb is okay, replace instrument cluster module. Go to step 11.
5. Check instrument cluster AIR BAG warning light circuits Measure resistance between component side of instrument cluster module connector C2220B, terminals No. 7 and 12. If resistance is less than 500 ohms, fault is corrected. Go to step 11. If resistance is more than 500 ohms, replace instrument cluster. Go to step 11.
6. Check circuit No. 608 for open Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access and disconnect RCM connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. On models with analog instrument cluster, measure resistance between ground and harness side of instrument cluster module connector C2220B, terminal No. 12 (Black/Yellow wire, circuit No. 608). (Scheme 62) On models with digital instrument cluster, measure resistance between ground and harness side of warning light module connector C2222, terminal No. 1 (Black/Yellow wire). (Scheme 63) On all models, if resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Black/Yellow wire. Go to step 11. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
7. Confirm RCM fault Reconnect RCM and instrument cluster connectors. Perform on-demand self-test. If DTC B1869 was retrieved during on-demand self-test, replace RCM. Go to step 11. If DTC B1869 was not retrieved during on-demand self-test, go to step 11.
8. Check circuit No. 608 for short to ground Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. On models with analog instrument cluster, access instrument cluster and disconnect instrument cluster module harness connector C2220B. See «INSTRUMENT CLUSTER»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. On models with digital instrument cluster, access instrument cluster and disconnect warning light module harness connector C2222, located near instrument cluster. On models with analog instrument cluster, measure resistance between ground and harness side of instrument cluster module connector C2220B, terminal No. 12 (Black/Yellow wire, circuit No. 608). (Scheme 62) On models with digital instrument cluster, measure resistance between ground and harness side of warning light module connector C2222, terminal No. 1 (Black/Yellow wire). (Scheme 63) On all models, if resistance is less than one megohm, go to next step. If resistance is more than one megohm, repair or replace instrument cluster. Go to step 11.
9. Check for RCM short to ground Access and disconnect RCM connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between ground and component side of RCM connector C310B, terminal No. 9. If resistance is less than 800 ohms, replace RCM. Go to step 11. If resistance is more than 800 ohms, repair short to ground in Black/Yellow wire. Go to step 11.
10. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC B1869 was retrieved during on-demand self-test, go to step 2. If DTC B1869 was not retrieved during on-demand self-test, check for cause of intermittent short to ground or open in Black/Yellow wire (circuit No. 608). See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
11. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST C: AIR BAG WARNING LIGHT CIRCUIT SHORT TO BATTERY (DTC B1870)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

AIR BAG warning light is designed to illuminate for 6 seconds when ignition switch is turned to RUN position. The initial 6-second illumination is normal and is called prove-out. The AIR BAG warning light is then used to warn vehicle operator that there is a fault in the air bag system.

Restraints Control Module (RCM) monitors AIR BAG warning light for short to battery voltage conditions. If RCM detects short to battery voltage in AIR BAG warning light circuit, it will store Diagnostic Trouble Code (DTC) B1870 in memory. If RCM detects AIR BAG warning light failure in addition to another air bag system failure, the secondary air bag warning will be activated.

AIR BAG warning light short to battery could be caused by damaged wiring, terminals or connectors, or an faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Turn ignition switch to OFF position. Perform system operation check. See «SYSTEM OPERATION CHECK»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__system-operation-check) . Turn ignition switch to OFF position. Turn ignition switch to RUN position. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC B1870 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC B1870 was not retrieved, fault is intermittent. Go to step 4 .
2. Check for AIR BAG warning light Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Turn ignition switch to RUN position. If AIR BAG warning light illuminates and stays illuminated, replace RCM. If AIR BAG warning light does not illuminate and stay illuminated, go to next step.
3. Check for short to battery Turn ignition switch to OFF position. On models equipped with analog instrument cluster, disconnect instrument cluster connector C2220B. On models equipped with digital instrument cluster, disconnect warning light module connector C2222. On all models, reconnect RCM connector C310B. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B1870 was retrieved during on-demand self-test, repair short to battery in Black/Yellow wire (circuit No. 608). See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) . Go to step 5 . If DTC B1870 was not retrieved, replace instrument cluster. Go to step 5 .
4. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC B1870 was retrieved during on-demand self-test, go to step 2 . If DTC B1870 was not retrieved during on-demand self-test, check for cause of intermittent short to battery in Black/Yellow wire (circuit No. 608). See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) . Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
5. Check for additional DTCs Refer to continuous DTCs recorded in step 1 . If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST D: AIR BAG TONE WARNING INDICATOR CIRCUIT SHORT TO BATTERY (DTC B1891)

Note. Before preceding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) monitors its connection to Lighting Control Module (LCM) at RCM connector C310B, terminal No. 11 (Light Blue/Black wire). This connection is used to signal a chime if AIR BAG warning light is inoperative and another air bag system fault exists. If RCM detects a short battery on connection to LCM, it will store Diagnostic Trouble Code (DTC) B1891 in memory and flash Code 53 on AIR BAG warning light.

Air bag tone warning indicator circuit short to battery could be caused by short to battery in Light Blue/Black wire, damaged or inoperative LCM or faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC B1891 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC B1891 was not retrieved, fault is intermittent. Go to step 4.
2. Check air bag tone warning indicator circuit Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Access LCM and disconnect connector C2145A. See «LIGHTING CONTROL MODULE (LCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310B, terminal No. 11 (Light Blue/Black wire, circuit No. 1083). (Scheme 61) If voltage is less than 0.2 volt, go to next step. If voltage is more than 0.2 volt, repair short to battery in Light Blue/Black wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 5.
3. Check air bag tone warning indicator Turn ignition switch to OFF position. Reconnect LCM connector C2145A. Connect fused jumper wire between ground and harness side of RCM connector C310B, terminal No. 11 (Light Blue/Black wire). Turn ignition switch to RUN position. If air bag warning tone is heard, replace RCM. Go to step 5. If air bag warning tone is not heard, replace LCM. Go to step 5.
4. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC B1891 was retrieved during on-demand self-test, go to step 2. If DTC B1891 was not retrieved during on-demand self-test, check for cause of intermittent short to battery in Light Blue/Black wire (circuit No. 1083). See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
5. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST E: AIR BAG TONE WARNING INDICATOR CIRCUIT SHORT TO GROUND OR OPEN (DTC B1892)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) monitors its connection to Lighting Control Module (LCM) at RCM connector C310B, terminal No. 11 (Light Blue/Black wire). This connection is used to signal a chime if AIR BAG warning light is inoperative and another air bag system fault exists. If RCM detects a short to ground or open on connection to LCM, it will store Diagnostic Trouble Code (DTC) B1892 in memory and flash Code 53 on AIR BAG warning light.

Air bag tone warning indicator circuit shorted to ground or open could be caused by short to ground or open in Light Blue/Black wire, damaged or inoperative LCM or faulty RCM.

Scheme 65

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC B1892 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC B1892 was not retrieved, fault is intermittent. Go to step 5.
2. Check air bag tone warning indicator circuit for short to ground Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Access LCM and disconnect connector C2145A. See «LIGHTING CONTROL MODULE (LCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between harness side of RCM connector C310B, terminals No. 11 (Light Blue/Black wire, circuit No. 1083) and No. 10 (Black wire, circuit No. 57). (Scheme 61) If resistance is more than one megohm, go to next step. If resistance is less than one megohm, repair short to ground in Light Blue/Black wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 6.
3. Check air bag tone warning indicator circuit for open Measure resistance between harness side of RCM connector C310B, terminal No. 11 and harness side of LCM connector C2145A, terminal No. 17 (Light Blue/Black wire). (Scheme 61)& (Scheme 65). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Light Blue/Black wire. Go to step 6.
4. Check air bag tone warning indicator Reconnect LCM connector C2145A. Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310B, terminal No. 11 (Light Blue/Black wire). In voltage is less than 0.2 volt, replace LCM. Go to step 6. If voltage is more than 0.2 volt, replace RCM. Go to step 6.
5. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC B1892 was retrieved during on-demand self-test, go to step 2. If DTC B1892 was not retrieved during on-demand self-test, check for cause of intermittent short to ground or open in Light Blue/Black wire (circuit No. 1083). See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
6. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST F: GROUND RESISTANCE TOO HIGH OR RCM NOT MOUNTED TO VEHICLE PROPERLY (DTC B1921)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) monitors resistance between ground connections at its housing and reference ground at RCM connector C310B, terminal No. 10. If RCM detects a difference in resistance, it will store Diagnostic Trouble Code (DTC) B1921 in memory and flash Code 14 on AIR BAG warning light.

Resistance difference between RCM housing ground and terminal ground could be caused by improper tightening of RCM mounting bolts, faulty damaged, terminals or connectors or faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC B1921 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC B1921 was not retrieved, fault is intermittent. Go to step 5.
2. Check RCM mounting & bracket Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Inspect RCM mounting and ensure retaining bolts are fully seated and tightened properly. Remove RCM and visually inspect mounting bracket and mounting surface for damage, corrosion or dirt. If problems are found, repair mounting surface as necessary. Go to next step. If no problems were found. Go to step 6.
3. Install RCM & perform on-demand self-test Clean mounting surface and bolts. Install RCM. Tighten mounting bolts to specification. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications). Perform on-demand self-test. If DTC B1921 was retrieved during on-demand self-test, go to next step. If DTC B1921 was not retrieved during on-demand self-test, fault is corrected. Go to step 6.
4. Check ground circuit for high resistance Measure resistance between harness side of RCM connector C310B, terminal No. 10 (Black wire, circuit No. 57) and RCM case. (Scheme 61) If resistance is less than 5 ohms, replace RCM. Go to step 6. If resistance is more than 5 ohms, repair open in Black wire. Go to step 6.
5. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC B1921 was retrieved during on-demand self-test, go to step 2. If DTC B1921 was not retrieved during on-demand self-test, check for cause of intermittent short to ground or open in Black wire (circuit No. 57). See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
6. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST G: OCCUPANT CLASSIFICATION SENSOR (OCS) CIRCUIT FAULT (DTC B2290)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) monitors Occupant Classification Sensor (OCS) circuits for faults. If RCM detects low resistance, open circuit, short to battery or short to ground, it will store Diagnostic Trouble Code (DTC) B2290 in memory and flash Code 16 on AIR BAG warning light.

OCS circuit fault could be caused by damaged wiring, terminals or connectors, faulty OCS system or faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Retrieve, flag and record any continuous Diagnostic Trouble Codes (DTCs). See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Flag DTC B2290. See «BIT-MAPPED DIAGNOSTIC TROUBLE CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__bit-mapped-diagnostic-trouble-codes) under DIAGNOSTICS. Retrieve and record any flagged DTCs. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. Retrieve and record any flagged DTCs. If flagged fault "?" was retrieved during on-demand self-test, multiple faults exist and all steps of diagnostic procedure must be performed. On models equipped with original part OCS, if DTC B2290 was retrieved during on-demand self-test, fault is hard. For communication (COMM) fault, go to next step. For internal (INT) fault, replace OCS system. See «OCCUPANT CLASSIFICATION SENSOR (OCS)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__occupant-classification-sensor-ocs) under REMOVAL & INSTALLATION. Go to step 20. For calibration fault, replace OCS system. Go to step 20. For OCS pressure sensor fault, go to step 11. If DTC B2290 was not retrieved during on-demand self-test, fault is intermittent. Go to step 19. On models equipped with service part OCS, if DTC B2290 was retrieved during on-demand self-test, fault is hard. For communication (COMM) fault, go to next step. For internal (INT) fault, replace OCS system. See «OCCUPANT CLASSIFICATION SENSOR (OCS)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__occupant-classification-sensor-ocs) under REMOVAL & INSTALLATION. Go to step 20. For calibration fault, replace OCS system. Go to step 20. For OCS pressure sensor fault, replace OCS system. Go to step 20. If DTC B2290 was not retrieved during on-demand self-test, fault is intermittent. Go to step 19.
2. Check seat wiring & connectors Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Visually inspect all OCS system and seat wiring harnesses and connectors. If wiring harnesses and connectors are okay, go to next step. If wiring harnesses and connectors are damaged, repair as necessary. Go to step 20.
3. Check ignition circuit for open Access and disconnect OCS connector C3043 from OCS Electronic Control Unit (ECU). See «OCCUPANT CLASSIFICATION SENSOR (OCS)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__occupant-classification-sensor-ocs) under REMOVAL & INSTALLATION. Turn ignition switch to RUN position. Position front seat in vehicle and reconnect seat floor harness connectors. Turn ignition switch to RUN position. Measure voltage between ground and harness side of OCS connector C3043, terminal No. 4 (Dark Blue/Light Green wire, circuit No. 964). (Scheme 66) If voltage is more than 10 volts, go to next step. If voltage is less than 10 volts, repair open in Dark Blue/Light Green wire. Go to step 20. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system).
4. Check ground circuit for open Turn ignition switch to OFF position. Measure resistance between ground and OCS connector C3043, terminal No. 9 (Pink/Orange wire, circuit No. 676). If resistance is less than 5 ohms, go to next step. If resistance is more than 5 ohms, repair open in Pink/Orange wire. Go to step 20.
5. Check for short to battery between OCS electronic control unit & RCM Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Turn ignition switch to RUN position. Measure voltage between ground and harness side of OCS connector C3043, terminal No. 5 (Dark Green/Violet wire). Measure voltage between ground and harness side of OCS connector C3043, terminal No. 10 (Dark Blue/Orange wire). If voltage is less than 0.2 volt in both circuits, go to next step. If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire. Go to step 20.
6. Check for short to ground between OCS electronic control unit & RCM Turn ignition switch to OFF position. Measure resistance between ground and harness side of OCS connector C3043, terminal No. 5 (Dark Green/Violet wire, circuit No. 1556). Measure resistance between ground and harness side of OCS connector C3043, terminal No. 10 (Dark Blue/Orange wire, circuit No. 1557). If resistance is more than one megohm in both circuits, go to next step. If resistance is less than one megohm in either circuit, repair short to ground in appropriate wire. Go to step 20.
7. Check circuit for open between OCS electronic control unit & RCM Turn ignition switch to OFF position. Measure resistance between harness side of RCM connector C310A, terminal No. 1 and harness side of OCS connector C3043, terminal No. 5 (Dark Green/Violet wire). (Scheme 61)& (Scheme 66). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Dark Green/Violet wire. Go to step 20.
8. Check circuit for open between OCS electronic control unit & RCM Measure resistance between harness side of RCM connector C310A, terminal No. 2 and harness side of OCS connector C3043, terminal No. 10 (Dark Blue/Orange wire). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Dark Blue/Orange wire. Go to step 20.
9. Check circuit for short between OCS electronic control unit & RCM Measure resistance between harness side of OCS connector C3043, terminals No. 5 (Dark Green/Violet wire) and No. 10 (Dark Blue/Orange wire). If resistance is more than one megohm, go to next step. If resistance is less than one megohm, repair short between Dark Green/Violet and Dark Blue/Orange wires. Go to step 20. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
10. Confirm RCM fault Install known good RCM. Ensure both RCM connectors are connected. Connect OCS harness connector C3043. Turn ignition switch to ON position. Zero OCS. See «ZERO OCCUPANT CLASSIFICATION SENSOR (OCS)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__zero-occupant-classification-sensor-ocs) under DIAGNOSTICS. Perform on-demand self-test. Flag DTC B2290. Retrieve and record any flagged faults. If DTC B2290 was retrieved during on-demand self-test and "?" was flagged by scan tool, perform entire diagnostic test. Replace entire OCS system. Go to step 20. If DTC B2290 was not retrieved during on-demand self-test, fault is corrected. Go to step 20.
11. Check seat wiring & connectors Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Visually inspect all OCS system and seat wiring harnesses and connectors. If wiring harnesses and connectors are okay, go to next step. If wiring harnesses and connectors are damaged, repair as necessary. Go to step 20.
12. Check circuits for short to battery Access and disconnect both RCM connectors. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Access and disconnect OCS connector C3042 from OCS pressure sensor. See «OCCUPANT CLASSIFICATION SENSOR (OCS)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__occupant-classification-sensor-ocs) under REMOVAL & INSTALLATION. Position front seat in vehicle and reconnect seat floor harness connectors. Turn ignition switch to RUN position. Measure voltage between ground and harness side of OCS pressure sensor connector C3042, terminals No. 1 (Red/White wire, circuit No. 1568), No.2 (Tan/Black wire, circuit No. 1570) and No. 3 (Gray/Light Blue wire, circuit No. 1569). (Scheme 67) If voltage is more than 0.2 volt in any circuit, repair short to battery in appropriate wire. Go to step 20. If voltage is less than 0.2 volt in all circuits, go to next step.
13. Check circuits for short to ground Turn ignition switch to OFF position. Measure resistance between ground and harness side of OCS pressure sensor connector C3042, terminals No. 1 (Red/White wire), No.2 (Tan/Black wire) and No. 3 (Gray/Light Blue wire). If resistance is more than one megohm, go to next step. If resistance is less than one megohm, repair short to ground in appropriate circuit. Go to step 20.
14. Check circuit for open between OCS pressure sensor & OCS Electronic Control Unit (ECU) Disconnect OCS ECU harness connector C3043. Measure resistance between harness side of OCS ECU connector C3043, terminal No. 3 and harness side of OCS pressure sensor connector C3042, terminal No. 1 (Red/White wire). (Scheme 66)& (Scheme 67). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Red/White wire. Go to step 20.
15. Check circuit for open between OCS pressure sensor & OCS Electronic Control Unit (ECU) Measure resistance between harness side of OCS ECU connector C3043, terminal No. 3 and harness side of OCS pressure sensor connector C3042, terminal No. 1 (Gray/Light Blue wire). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Gray/Light Blue wire. Go to step 20.
16. Check circuit for open between OCS pressure sensor & OCS Electronic Control Unit (ECU) Measure resistance between harness side of OCS ECU connector C3043, terminal No. 1 and harness side of OCS pressure sensor connector C3042, terminal No. 2 (Tan/Black wire). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Tan/Black wire. Go to step 20.
17. Check circuits for short Measure resistance between harness side of OCS pressure sensor connector C3042, terminal No. 1 (Red/White wire) and No. 2 (Tan/Black wire). Measure resistance between harness side of OCS pressure sensor connector C3042, terminal No. 1 (Red/White wire) and No. 3 (Gray/Light Blue wire). Measure resistance between harness side of OCS pressure sensor connector C3042, terminal No. 2 (Red/White wire) and No. 3 (Gray/Light Blue wire). If resistance is more than one megohm between all circuits, go to next step. If resistance is less one megohm between any circuit, repair short between appropriate wires. Go to step 20. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
18. Check OCS Install NEW OCS system service kit. Reconnect RCM connectors. Zero OCS. See «ZERO OCCUPANT CLASSIFICATION SENSOR (OCS)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__zero-occupant-classification-sensor-ocs) under DIAGNOSTICS. Turn ignition switch to ON position. Perform on-demand self-test. Flag DTC B2290. Retrieve and record any flagged faults. If flagged fault "?" was retrieved during on-demand self-test, multiple faults exist and all steps of diagnostic procedure must be performed. If DTC B2290 was retrieved during on-demand self-test, replace RCM. Go to step 20. If DTC B2290 was retrieved during on-demand self-test, fault is corrected. Go to step 20.
19. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Turn ignition switch to ON position. Perform on-demand self-test. If flagged fault "?" was retrieved during on-demand self-test in step 1, multiple faults exist and all steps of diagnostic procedure must be performed. On models equipped with original part OCS, if DTC B2290 was retrieved during on-demand self-test, fault is hard. For communication (COMM) fault, go to step 2. For internal (INT) fault, replace OCS system. See «OCCUPANT CLASSIFICATION SENSOR (OCS)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__occupant-classification-sensor-ocs) under REMOVAL & INSTALLATION. Go to next step. For calibration fault, replace OCS system. Go to next step. For OCS pressure sensor fault, go to step 11. On models equipped with service part OCS, if DTC B2290 was retrieved during on-demand self-test, fault is hard. For communication (COMM) fault, go to step 2. For internal (INT) fault, replace OCS system. See «OCCUPANT CLASSIFICATION SENSOR (OCS)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__occupant-classification-sensor-ocs) under REMOVAL & INSTALLATION. Go to next step. For calibration fault, replace OCS system. Go to next step. For OCS pressure sensor fault, replace OCS system. Go to next step. If DTC B2290 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
20. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

Scheme 66

Scheme 67

TEST H: RESTRAINT SYSTEM-SEAT BELT PRETENSIONER STATUS (DTC B2292)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) checks all seat belt pretensioners for faults. If RCM detects low resistance, open circuit, short to battery or short to ground, it will store Diagnostic Trouble Code (DTC) B2292 in memory and flash Code 33 or 34 on AIR BAG warning light.

A seat belt pretensioner status fault could be caused by damaged wiring, terminals or connectors, faulty seat belt pretensioner or faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve, flag and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. Flag DTC B2292. See «BIT-MAPPED DIAGNOSTIC TROUBLE CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__bit-mapped-diagnostic-trouble-codes) under DIAGNOSTICS. Retrieve and record any flagged faults. If DTC B2292 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC B2292 was not retrieved, fault is intermittent. Go to step 18.
2. Check pretensioner Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2292 was retrieved during on-demand self-test, use flagged faults recorded in step 1 to find appropriate step. If flagged fault of "?" was recorded, multiple faults exist. Entire test must be carried out before replacing RCM. For left seat belt pretensioner (DF-PTR) with low resistance (LOWRES) fault, go to next step. For DF-PRT with open circuit (O-CIR) fault, go to step 4. For DF-PRT with short to battery (STB) fault, go to step 6. For DF-PRT with short to ground (STG) fault, go to step 8. For right seat belt pretensioner (PF-PTR) with low resistance (LOWRES) fault, go to step 10. For PF-PRT with open circuit (O-CIR) fault, go to step 11. For PF-PRT with short to battery (STB) fault, go to step 13. For PF-PRT with short to ground (STG) fault, go to step 15. If DTC B2292 was not retrieved during on-demand self-test, use flagged faults recorded in step 1 to find appropriate step. If flagged fault of "?" was recorded, multiple faults exist. Entire test must be carried out before replacing seat belt pretensioner. If a fault was flagged against DF-PRT, replace left seat belt pretensioner. Go to step 19. If a fault was flagged against PF-PRT, replace right seat belt pretensioner. Go to step 19.
3. Check left pretensioner circuit for low resistance Turn ignition switch to OFF position. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect left seat belt pretensioner simulator from harness connector. Measure resistance between harness side of RCM connector C310A, terminals No. 4 (Light Green/Black wire, circuit No. 1080) and No. 3 (Light Green/Red wire, circuit No. 1079). (Scheme 61) If resistance is less than 10 k/ohms, repair short between Light Green/Black and Light Green/Red wires. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 19. If resistance is more than 10 k/ohms, go to step 17.
4. Check circuit for open Turn ignition switch to OFF position. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect left seat belt pretensioner simulator from harness connector. Measure resistance in Light Green/Red wire (circuit No. 1079) between harness side of RCM connector C310A, terminal No. 3 and harness side of left seat belt pretensioner connector. (Scheme 61) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Light Green/Red wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 19.
5. Check circuit for open Measure resistance in Light Green/Black wire (circuit No. 1079) between harness side of RCM connector C310A, terminal No. 4 and harness side of left seat belt pretensioner connector. If resistance is less than 0.5 ohm, go to step 17. If resistance is more than 0.5 ohm, repair open in Light Green/Black wire. Go to step 19.
6. Check circuit for short to battery Turn ignition switch to OFF position. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect left seat belt pretensioner simulator from harness connector. Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310A, terminal No. 3 (Light Green/Red wire, circuit No. 1079). (Scheme 61) If voltage is less than 0.2 volt, go to next step. If voltage is more than 0.2 volt, repair short to battery in Light Green/Red wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 19.
7. Check circuit for short to battery Measure voltage between ground and harness side of RCM connector C310A, terminal No. 4 (Light Green/Black wire, circuit No. 1080). If voltage is less than 0.2 volt, go to step 17. If voltage is more than 0.2 volt, repair short to battery in Light Green/Black wire. Go to step 19.
8. Check circuit for short to ground Turn ignition switch to OFF position. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect left seat belt pretensioner simulator from harness connector. Measure resistance between ground and harness side of RCM connector C310A, terminal No. 3 (Light Green/Red wire, circuit No. 1079). (Scheme 61) If resistance is more than one megohm, go to next step. If resistance is less than one megohm, repair short to ground in Light Green/Red wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 19.
9. Check circuit for short to ground Measure resistance between ground and harness side of RCM connector C310A, terminal No. 4 (Light Green/Black wire, circuit No. 1080). If resistance is more than one megohm, go to step 17. If resistance is less than one megohm, repair short to ground in Light Green/Black wire. Go to step 19.
10. Check right pretensioner circuit for low resistance Turn ignition switch to OFF position. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect right seat belt pretensioner simulator from harness connector. Measure resistance between harness side of RCM connector C310A, terminals No. 7 (Yellow/Black wire, circuit No. 1082) and No. 6 (Yellow/Red wire, circuit No. 1081). (Scheme 61) If resistance is less than 10 k/ohms, repair short between Yellow/Black and Yellow/Red wires. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 19. If resistance is more than 10 k/ohms, go to step 17.
11. Check circuit for open Turn ignition switch to OFF position. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect right seat belt pretensioner simulator from harness connector. Measure resistance in Yellow/Red wire (circuit No. 1081) between harness side of RCM connector C310A, terminal No. 6 and harness side of right seat belt pretensioner connector. (Scheme 61) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Yellow/Red wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 19.
12. Check circuit for open Measure resistance in Yellow/Black wire (circuit No. 1082) between harness side of RCM connector C310A, terminal No. 7 and harness side of right seat belt pretensioner harness connector. (Scheme 61) If resistance is less than 0.5 ohm, go to step 17. If resistance is more than 0.5 ohm, repair open in Yellow/Black wire. Go to step 19.
13. Check circuit for short to battery Turn ignition switch to OFF position. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect right seat belt pretensioner simulator from harness connector. Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310A, terminal No. 6 (Yellow/Red wire, circuit No. 1081). (Scheme 61) If voltage is less than 0.2 volt, go to next step. If voltage is more than 0.2 volt, repair short to battery in Yellow/Red wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 19.
14. Check circuit for short to battery Measure voltage between ground and harness side of RCM connector C310A, terminal No. 7 (Yellow/Black wire, circuit No. 1082). If voltage is less than 0.2 volt, go to step 17. If voltage is more than 0.2 volt, repair short to battery in Yellow/Black wire. Go to step 19.
15. Check circuit for short to ground Turn ignition switch to OFF position. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect right seat belt pretensioner simulator from harness connector. Measure resistance between ground and harness side of RCM connector C310A, terminal No. 6 (Yellow/Red wire, circuit No. 1081). (Scheme 61) If resistance is more than one megohm, go to next step. If resistance is less than one megohm, repair short to ground in Yellow/Red wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 19.
16. Check circuit for short to ground Measure resistance between ground and harness side of RCM connector C310A, terminal No. 7 (Yellow/Black wire, circuit No. 1082). If resistance is more than one megohm, go to next step. If resistance is less than one megohm, repair short to ground in Yellow/Black wire. Go to step 19. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
17. Confirm RCM Fault Turn ignition switch to OFF position. Reconnect seat belt pretensioner simulator. Reconnect both RCM connectors. Turn ignition switch to RUN position. Perform on-demand self-test. Flag DTC B2292. Retrieve and record any flagged faults. If DTC B2292 was retrieved during on-demand self-test and "?" was flagged by scan tool, carry out entire test before replacing RCM. Replace RCM. Go to step 19. If DTC B2292 was not retrieved during on-demand self-test, fault is corrected. Go to step 19.
18. Check for intermittent fault Turn ignition to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. Flag DTC B2292. If DTC B2292 was retrieved during on-demand self-test, check for causes of intermittent fault at or near affected seat belt pretensioner harness connector. Repair any intermittent faults found and go to next step. If intermittent fault was not found, refer to recorded flagged faults for appropriated test. If flagged fault "?" was retrieved during on-demand self-test, multiple faults exist and all steps of diagnostic procedure must be performed before replacing RCM. For left seat belt pretensioner (DF-PRT) with low resistance (LOWRES) fault, go to step 3. For left seat belt pretensioner (DF-PRT) with open circuit (O-CIR) fault, go to step 4. For left seat belt pretensioner (DF-PRT) with short to battery (STB) fault, go to step 6. For left seat belt pretensioner (DF-PRT) with short to ground (STG) fault, go to step 8. For right seat belt pretensioner (PF-PRT) with low resistance (LOWRES) fault, go to step 10. For right seat belt pretensioner (PF-PRT) with open circuit (O-CIR) fault, go to step 11. For right seat belt pretensioner (PF-PRT) with short to battery (STB) fault, go to step 13. For right seat belt pretensioner (PF-PRT) with short to ground (STG) fault, go to step 15. If DTC B2292 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
19. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST I: RESTRAINT SYSTEM-AIR BAG STATUS (DTC B2293)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) checks all front air bag circuits for faults. If RCM detects low resistance, open circuit, short to battery or short to ground, it will store Diagnostic Trouble Code (DTC) B2293 in memory and flash Code 19 or 21 on AIR BAG warning light.

A front air bag status fault could be caused by faulty wiring, terminals or connectors, faulty driver-side air bag sub-harness, faulty clockspring, faulty air bag module or faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. Flag DTC B2293. Retrieve and record any flagged faults. If DTC B2293 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC B2293 was not retrieved, fault is intermittent. Go to step 38.
2. Check driver-side & passenger-side air bag modules Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2293 was retrieved during on-demand self-test, use flagged faults recorded in step 1 to find appropriate step. If flagged fault of "?" was recorded, multiple faults exist. Entire test must be carried out before replacing RCM. For driver-side air bag module squib No. 1 (D-ABAG) with short to ground (STG) fault, go to next step. For driver-side air bag module squib No. 1 (D-ABAG) with short to battery (STB) fault, go to step 5. For driver-side air bag module squib No. 1 (D-ABAG) with open circuit (O-CIR), go to step 7. For driver-side air bag module squib No. 1 (D-ABAG) with low resistance (LOWRES), go to step 11. For passenger-side air bag module squib No. 1 (P-ABAG) with short to ground (STG), go to step 14. For passenger-side air bag module squib No.1 (P-ABAG) with short to battery (STB), go to step 15. For passenger-side air bag module squib No. 1 (P-ABAG) with open circuit (O-CIR), go to step 16. For passenger-side air bag module squib No. 1 (P-ABAG) with low resistance (LOWRES), go to step 18. For driver-side air bag module squib No. 2 (D-ABAG2 with short to ground (STG) fault, go to step 20. For driver-side air bag module squib No. 2 (D-ABAG2) with short to battery (STB) fault, go to step 22. For driver-side air bag module squib No. 2 (D-ABAG2) with open circuit (O-CIR), go to step 24. For driver-side air bag module squib No. 2 (D-ABAG2) with low resistance (LOWRES), go to step 28. For passenger-side air bag module squib No. 2 (P-ABAG2) with short to ground (STG), go to step 31. For passenger-side air bag module squib No. 2 (P-ABAG2) with short to battery (STB), go to step 32. For passenger-side air bag module squib No. 2 (P-ABAG2) with open circuit (O-CIR), go to step 33. For passenger-side air bag module squib No. 2 (P-ABAG2) with low resistance (LOWRES), go to step 35. If DTC B2293 was not retrieved during on-demand self-test and If flagged fault of "?" was recorded, multiple faults exist. Entire test must be carried out before replacing air bag module. If fault was flagged against driver-side air bag module, replace driver-side air bag module. Go to step 39. If fault was flagged against passenger-side air bag module, replace passenger-side air bag module. Go to step 39.
3. Check circuit for short to ground between RCM & driver-side air bag module Turn ignition switch to OFF position. Access RCM and disconnect connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect driver-side air bag module squib No. 1 simulator from harness connector. Measure resistance between ground and harness side of RCM connector C310B, terminal No. 3 (Gray/Orange wire, circuit No. 614). (Scheme 61) Measure resistance between ground and harness side of RCM connector C310B, terminal No. 2 (Gray/White wire, circuit No. 615). If resistance is less than one megohm, repair short to ground in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to next step. If resistance is more than one megohm, go to step 37. NOTE: Due to shorting bar in connector, fault can exist in either circuit. Do not remove or defeat shorting bars.
4. Check circuit for short to ground between RCM & clockspring Disconnect lower clockspring harness connector C218B. See «CLOCKSPRING»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clockspring) under REMOVAL & INSTALLATION. Measure resistance between ground and harness side of RCM connector C310B, terminal No. 3 (Gray/Orange wire). Measure resistance between ground and harness side of RCM connector C310B, terminal No. 2 (Gray/White wire). If resistance is less than one megohm, repair short to ground in appropriate wire. Go to step 39. If resistance is more than one megohm, replace clockspring. Go to step 39.
5. Check circuit for short to battery between RCM & driver-side air bag module Turn ignition switch to OFF position. Access RCM and disconnect connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect driver-side air bag module squib No. 1 simulator from harness connector. Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310B, terminal No. 3 (Gray/Orange wire, circuit No. 614). (Scheme 61) Measure voltage between ground and harness side of RCM connector C310B, terminal No. 2 (Gray/White wire, circuit No. 615). If voltage is less than 0.2 volt in both circuits, go to step 37. If voltage is more than 0.2 volt in either circuit, go to next step. NOTE: Due to shorting bar in connector, fault can exist in either circuit. Do not remove or defeat shorting bars.
6. Check circuit for short to battery between RCM & clockspring Turn ignition switch to OFF position. Disconnect lower clockspring harness connector C218B. See «CLOCKSPRING»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clockspring) under REMOVAL & INSTALLATION. Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310B, terminal No. 3 (Gray/Orange wire). Measure voltage between ground and harness side of RCM connector C310B, terminal No. 2 (Gray/White wire). If voltage is less than 0.2 volt in both circuits, replace clockspring. Go to step 39. If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39.
7. Check circuit for open between RCM & driver-side air bag module Turn ignition switch to OFF position. Access RCM and disconnect connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect driver-side air bag module squib No. 1 simulator from harness connector. Measure resistance in Gray/Orange wire (circuit No. 614) between harness side of RCM connector C310B, terminal No. 3 and harness side of driver-side air bag module squib No. 1 connector. (Scheme 61) If resistance is less than 0.5 ohm, go to step 9. If resistance is more than 0.5 ohm, go to next step.
8. Check circuit for open between RCM & clockspring Disconnect lower clockspring harness connector C218B. See «CLOCKSPRING»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clockspring) under REMOVAL & INSTALLATION. Measure resistance between harness side of RCM connector C310B, terminal No. 3 and harness side of lower clockspring connector C218B, terminal No. 1 (Gray/Orange wire). (Scheme 61)& (Scheme 68). If resistance is less than 0.5 ohm, replace clockspring. Go to step 39. If resistance is more than 0.5 ohm, repair open in Gray/Orange wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39.
9. Check circuit for open between RCM & driver-side air bag module Measure resistance in Gray/White wire (circuit No. 615) between harness side of RCM connector C310B, terminal No. 2 and harness side of driver-side air bag module squib No. 1 connector. If resistance is less than 0.5 ohm, go to step 37. If resistance is more than 0.5 ohm, go to next step.
10. Check circuit for open between RCM & clockspring Disconnect lower clockspring harness connector C218B. See «CLOCKSPRING»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clockspring) under REMOVAL & INSTALLATION. Measure resistance between RCM connector C310B, terminal No. 2 and harness side of lower clockspring connector C218B, terminal No. 2 (Gray/White wire). (Scheme 61)& (Scheme 68). If resistance is less than 0.5 ohm, replace clockspring. Go to step 39. If resistance is more than 0.5 ohm, repair open in Gray/Orange wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39.
11. Check circuit for low resistance RCM & driver-side air bag module Turn ignition switch to OFF position. Disconnect driver-side air bag module squib No. 1 simulator from harness connector. Measure resistance between Gray/Orange wire (circuit No. 614) and Gray/White wire (circuit No. 615) on harness side of driver-side air bag module squib No. 1 connector. If resistance is less than 800 ohms, go to next step. If resistance is more than 800 ohms, go to step 37.
12. Check for low resistance between RCM circuits Access RCM and disconnect connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between component side of RCM connector C310B, pins No. 2 and 3. (Scheme 64) If resistance is less than 800 ohms, go to step 37. If resistance is more than 800 ohms, go to next step.
13. Check circuit for low resistance between RCM & clockspring Reconnect RCM connector C310B. Access and disconnect lower clockspring harness connector C218B. See «CLOCKSPRING»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clockspring) under REMOVAL & INSTALLATION. Measure resistance between harness side of lower clockspring harness connector C218B, terminals No. 1 (Gray/Orange wire) and No. 2 (Gray/White wire) If resistance is more than 800 ohms, replace clockspring. Go to step 39. If resistance is less than 800 ohms, repair short between Gray/Orange and Gray/White wires. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39. NOTE: Due to shorting bar in connector, fault can exist in either circuit. Do not remove or defeat shorting bars.
14. Check circuit for short to ground between RCM & passenger-side air bag module Turn ignition switch to OFF position. Access RCM and disconnect connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect passenger-side air bag simulator from harness connector. Measure resistance between ground and harness side of RCM connector C310B, terminal No. 6 (Light Blue/Orange wire, circuit No. 607). (Scheme 61) Measure resistance between ground and harness side of RCM connector C310B, terminal No. 5 (Pink/Black wire, circuit No. 616). If resistance is less than one megohm in either circuit, repair short to ground in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39. If resistance is more than one megohm in both circuits, go to step 37. NOTE: Due to shorting bar in connector, fault can exist in either circuit. Do not remove or defeat shorting bars.
15. Check circuit for short to battery between RCM & passenger-side air bag module Turn ignition switch to OFF position. Access RCM and disconnect connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect passenger-side air bag simulator from harness connector. Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310B, terminal No. 6 (Light Blue/Orange wire, circuit No. 607). (Scheme 61) Measure voltage between ground and harness side of RCM connector C310B, terminal No. 5 (Pink/Black wire, circuit No. 616). If voltage is less than 0.2 volt in both circuits, go to step 37. If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39.
16. Check circuit for open between RCM & passenger-side air bag module Turn ignition switch to OFF position. Access RCM and disconnect connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect passenger-side air bag simulator from harness connector. Measure resistance between harness side of RCM connector C310B, terminal No. 6 and harness side of passenger-side air bag module connector C256, terminal No. 1 (Light Blue/Orange wire, circuit No. 607). (Scheme 61)& (Scheme 68). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Light Blue/Orange wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39.
17. Check circuit for open between RCM & passenger-side air bag module Measure resistance between harness side of RCM connector C310B, terminal No. 5 and harness side of passenger-side air bag module connector C256, terminal No. 2 (Pink/Black wire, circuit No. 616). If resistance is less than 0.5 ohm, go to step 37. If resistance is more than 0.5 ohms, repair open in Pink/Black wire. Go to step 39.
18. Check circuit for low resistance between RCM & passenger-side air bag module Turn ignition switch to OFF position. Disconnect passenger-side air bag simulator from harness connector. Measure resistance between harness side of passenger-side air bag module connector C256, terminals No.1 (Light Blue/Orange wire, circuit No. 607) and No. 2 (Pink/Black wire, circuit No. 616). (Scheme 68) If resistance is less than 800 ohms, go to next step. If resistance is more than 800 ohms, repair short between Light Blue/Orange and Pink/Black wires. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39.
19. Check RCM circuits for low resistance Access RCM and disconnect connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between component side of RCM connector C310B, pins No. 6 and 5. (Scheme 64) If resistance is less than 800 ohms, go to step 37. If resistance is more than 800 ohms, repair short between Light Blue/Orange and Pink/Black wires. Go to step 39.
20. Check circuit for short to ground between RCM & driver-side air bag module Turn ignition switch to OFF position. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect driver-side air bag module squib No. 2 simulator from harness connector. Measure resistance between ground and harness side of RCM connector C310A, terminal No. 11 (Yellow/White wire, circuit No. 1516). (Scheme 61) Measure resistance between ground and harness side of RCM connector C310A, terminal No. 12 (Red/Orange wire, circuit No. 1517). (Scheme 61) If resistance is less than one megohm in either circuit, go to next step. If resistance is more than one megohm in both circuits, go to step 37. NOTE: Due to shorting bar in connector, fault can exist in either circuit. Do not remove or defeat shorting bars.
21. Check circuit for short to ground between RCM & clockspring Disconnect lower clockspring harness connector C218B. See «CLOCKSPRING»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clockspring) under REMOVAL & INSTALLATION. Measure resistance between ground and harness side of RCM connector C310A, terminal No. 11 (Yellow/White wire). Measure resistance between ground and harness side of RCM connector C310A, terminal No. 12 (Red/Orange wire). If resistance is less than one megohm in either circuit, repair short to ground in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39. If resistance is more than one megohm in both circuits, replace clockspring. Go to step 39.
22. Check circuit for short to battery between RCM & driver-side air bag module Turn ignition switch to OFF position. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect driver-side air bag module squib No. 2 simulator from harness connector. Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310A, terminal No. 11 (Yellow/White wire, circuit No. 1516). (Scheme 61) Measure voltage between ground and harness side of RCM connector C310A, terminal No. 12 (Red/Orange wire, circuit No. 1517). If voltage is less than 0.2 volt in both circuits, go to step 33. If voltage is more than 0.2 volt in either circuit, go to next step.
23. Check circuit for short to battery between RCM & clockspring Turn ignition switch to OFF position. Disconnect lower clockspring harness connector C218B. See «CLOCKSPRING»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clockspring) under REMOVAL & INSTALLATION. Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310A, terminal No. 11 (Yellow/White wire). Measure voltage between ground and harness side of RCM connector C310A, terminal No. 12 (Red/Orange wire). If voltage is less than 0.2 volt in both circuits, replace clockspring. Go to step 39. If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39.
24. Check circuit for open between RCM & driver-side air bag module Turn ignition switch to OFF position. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect driver-side air bag module squib No. 2 simulator from harness connector. Measure resistance in Yellow/White wire (circuit No. 1516) between harness side of RCM connector C310A, terminal No. 11 and harness side of driver-side air bag module squib No. 2 connector. If resistance is less than 0.5 ohm, go to step 26. If resistance is more than 0.5 ohm, go to next step.
25. Check circuit for open between RCM & clockspring Disconnect lower clockspring harness connector C218B. See «CLOCKSPRING»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clockspring) under REMOVAL & INSTALLATION. Measure resistance between harness side of RCM connector C310A, terminal No. 11 and harness side of lower clockspring connector C218B, terminal No. 3 (Yellow/White wire). If resistance is less than 0.5 ohm, replace clockspring. Go to step 39. If resistance is more than 0.5 ohm, repair open in Yellow/White wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39.
26. Check circuit for open between RCM & driver-side air bag module Measure resistance in Red/Orange wire (circuit No. 1517) between harness side of RCM connector C310A, terminal No. 12 and harness side of driver-side air bag module squib No. 2 harness connector. If resistance is less than 0.5 ohm, go to step 37. If resistance is more than 0.5 ohm, go to next step.
27. Check circuit tor open between RCM & clockspring Disconnect lower clockspring harness connector C218B. See «CLOCKSPRING»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clockspring) under REMOVAL & INSTALLATION. Measure resistance between harness side of RCM connector C310A, terminal No. 12 and harness side of lower clockspring connector C218B, terminal No. 4 (Red/Orange wire). (Scheme 61)& (Scheme 68). If resistance is less than 0.5 ohm, replace clockspring. Go to step 39. If resistance is more than 0.5 ohm, repair open in Red/Orange wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39.
28. Check circuit for low resistance between RCM & driver-side air bag module Turn ignition switch to OFF position. Disconnect driver-side air bag module squib No. 2 simulator from harness connector. Measure resistance between Yellow/White wire (circuit No. 1516) and Red/Orange wire (circuit No. 1517) on harness side of driver-side air bag module squib No. 2 connector. If resistance is less than 800 ohms, go to next step. If resistance is more than 800 ohms, go to step 37.
29. Check RCM circuits for low resistance Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between component side of RCM connector C310A, pins No. 11 and 12. (Scheme 64) If resistance is less than 800 ohms, go to step 37. If resistance is more than 800 ohms, go to next step.
30. Check circuit for low resistance between RCM & driver-side air bag module Reconnect RCM connector C310A. Disconnect lower clockspring harness connector C218B. See «CLOCKSPRING»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clockspring) under REMOVAL & INSTALLATION. Measure resistance between harness side of lower clockspring connector C218B, terminals No. 3 (Yellow/White wire) and No. 4 (Red/Orange wire). (Scheme 68) If resistance is less than 800 ohms, replace clockspring. Go to step 39. If resistance is more than 800 ohms, repair short between Yellow/White and Red/Orange wires. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39.
31. Check circuit for short to ground between RCM & passenger-side air bag module Turn ignition switch to OFF position. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect passenger-side air bag simulator from harness connector. Measure resistance between ground and harness side of RCM connector C310A, terminal No. 20 (Red/White wire, circuit No. 1518). Measure resistance between ground and harness side of RCM connector C310A, terminal No. 21 (Light Green/Red wire, circuit No. 1519). (Scheme 61) If resistance is less than one megohm in either circuit, repair short to ground in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39. If resistance is more than one megohm in both circuits, go to step 37. NOTE: Due to shorting bar in connector, fault can exist in either circuit. Do not remove or defeat shorting bars.
32. Check circuit for short to battery between RCM & passenger-side air bag module Turn ignition switch to OFF position. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect passenger-side air bag simulator from harness connector. Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310A, terminal No. 20 (Red/White wire, circuit No. 1518). (Scheme 61) Measure voltage between ground and harness side of RCM connector C310A, terminal No. 21 (Light Green/Red wire, circuit No. 1519). If voltage is less than 0.2 volt in both circuits, go to step 37. If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39.
33. Check circuit for open between RCM & passenger-side air bag module Turn ignition switch to OFF position. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect passenger-side air bag simulator from harness connector. Measure resistance between harness side of RCM connector C310A, terminal No. 20 and harness side of passenger-side air bag module connector C256, terminal No. 3 (Red/White wire, circuit No. 1518). (Scheme 61)& (Scheme 68). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Red/White wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39.
34. Check circuit for open between RCM & passenger-side air bag module Measure resistance between harness side of RCM connector C310A, terminal No. 21 and harness side of passenger-side air bag module connector C256, terminal No. 4 (Light Green/Red wire, circuit No. 1518). If resistance is less than 0.5 ohm, go to step 37. If resistance is more than 0.5 ohm, repair open in Light Green/Red wire. Go to step 39.
35. Check circuit for low resistance between RCM & passenger-side air bag module Turn ignition switch to OFF position. Disconnect passenger-side air bag simulator from harness connector. Measure resistance between harness side of passenger-side air bag module connector C256, terminal No. 3 (Red/White wire, circuit No. 1518) and No. 4 (Light Green/Red wire, circuit No. 1519). (Scheme 68) If resistance is more than 800 ohms, go to next step. If resistance is less than 800 ohms, go to step 37.
36. Check for low resistance between RCM circuits Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between component side of RCM connector C310A, pins No. 20 and 21. (Scheme 64) If resistance is less than 800 ohms, go to next step. If resistance is more than 800 ohms, repair short between Red/White and Light Green/Red wires. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 39. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
37. Confirm RCM Fault Turn ignition switch to OFF position. Reconnect all air bag module simulators. Reconnect RCM connectors. Turn ignition switch to RUN position. Perform on-demand self-test. Flag DTC B2293. Retrieve and record any flagged faults. If DTC B2293 was retrieved during on-demand self-test and "?" was flagged by scan tool, carry out entire test before replacing RCM. Replace RCM. Go to step 39. If DTC B2293 was not retrieved during on-demand self-test, fault is corrected. Go to step 39.
38. Check for intermittent fault Turn ignition to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. Flag DTC B2293. If DTC B2293 was retrieved during on-demand self-test, check for causes of intermittent fault at or near affected air bag module harness connector. Repair any intermittent faults found and go to next step. If intermittent fault was not found, refer to recorded flagged faults for appropriate test. If flagged fault "?" was retrieved during on-demand self-test, multiple faults exist and all steps of diagnostic procedure must be performed before replacing RCM. For driver-side air bag module squib No. 1 (D-ABAG) with short to ground (STG) fault, go to step 3. For driver-side air bag module squib No. 1 (D-ABAG) with short to battery (STB) fault, go to step 5. For driver-side air bag module squib No. 1 (D-ABAG) with open circuit (O-CIR), go to step 7. For driver-side air bag module squib No. 1 (D-ABAG) with low resistance (LOWRES), go to step 11. For passenger-side air bag module squib No. 1 (P-ABAG) with short to ground (STG), go to step 14. For passenger-side air bag module squib No.1 (P-ABAG) with short to battery (STB), go to step 15. For passenger-side air bag module squib No. 1 (P-ABAG) with open circuit (O-CIR), go to step 16. For passenger-side air bag module squib No. 1 (P-ABAG) with low resistance (LOWRES), go to step 18. For driver-side air bag module squib No. 2 (D-ABAG2 with short to ground (STG) fault, go to step 20. For driver-side air bag module squib No. 2 (D-ABAG2) with short to battery (STB) fault, go to step 22. For driver-side air bag module squib No. 2 (D-ABAG2) with open circuit (O-CIR), go to step 24. For driver-side air bag module squib No. 2 (D-ABAG2) with low resistance (LOWRES), go to step 28. For passenger-side air bag module squib No. 2 (P-ABAG2) with short to ground (STG), go to step 31. For passenger-side air bag module squib No. 2 (P-ABAG2) with short to battery (STB), go to step 32. For passenger-side air bag module squib No. 2 (P-ABAG2) with open circuit (O-CIR), go to step 33. For passenger-side air bag module squib No. 2 (P-ABAG2) with low resistance (LOWRES), go to step 35. If DTC B2293 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
39. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

Scheme 68

TEST J: RESTRAINT SYSTEM-SIDE AIR BAG STATUS (DTC B2295)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS . Diagnostic tests or repairs are not to be performed on seat components with front seats installed in vehicle. Prior to diagnosis or repair of any seat component, remove front seats and ensure appropriate air bag simulators are installed at side air bag connectors. See FRONT SEAT under REMOVAL & INSTALLATION.

Restraints Control Module (RCM) checks all side air bag circuits for faults. If RCM detects low resistance, open circuit, short to battery or short to ground, it will store DTC B2295 in memory and flash Code 22 or 23 on AIR BAG warning light.

A side air bag status fault could be caused by faulty wiring, terminals or connectors, faulty side air bag module or faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Retrieve and record any continuous Diagnostic Trouble Codes (DTCs). See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. Flag DTC B2295. See «BIT-MAPPED DIAGNOSTIC TROUBLE CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__bit-mapped-diagnostic-trouble-codes) under DIAGNOSTICS. Retrieve and record any flagged faults. On models not equipped without side air bag modules if DTC B2295 was retrieved during on-demand self-test, fault is hard. Go to next step. On models equipped with side air bag modules, go to step 3. If DTC B2295 was not retrieved during on-demand self-test, fault is intermittent. Go to step 27.
2. Check right & left side bridge resistors Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove right and left-side bridge resistors, located under front seats. Install left-side bridge resistor onto right-side bridge resistor harness connector, and right-side bridge resistor onto left-side bridge resistor harness connector. Turn ignition switch to RUN position. Perform on-demand self-test. Flag DTC B2295. If DTC B2295 transferred between left- and right-sides, replace faulty bridge resistor. If DTC B2295 did not transfer between left- and right-sides, and if flagged fault of "?" was recorded, multiple faults exist. Entire test must be carried out before replacing RCM. If DTC B2295 did not transfer between left- and right-sides, use flagged faults recorded in step 1 to find appropriate step. For left side air bag module (DFSIDE) with short to battery (STB) fault, go to step 4. For left side air bag module (DFSIDE) with short to ground (STG) fault, go to step 5. For left side air bag module (DFSIDE) with an open circuit (O-CIR), go to step 6. For left side air bag module (DFSIDE) with low resistance (LOWRES), go to step 8. For right side air bag module (PFSIDE) with a short to battery (STB), go to step 10. For right side air bag module (PFSIDE) with a short to ground (STG), go to step 11. For right side air bag module (PFSIDE) with an open circuit (O-CIR), go to step 12. For right side air bag module (PFSIDE) with low resistance (LOWRES), go to step 14.
3. Check right & left side air bag modules Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2295 was retrieved during on-demand self-test, use flagged faults recorded in step 1 to find appropriate step. If flagged fault of "?" was recorded, multiple faults exist. Entire test must be carried out before replacing RCM. For left side air bag module (DFSIDE) with short to battery (STB) fault, go to next step. For left side air bag module (DFSIDE) with short to ground (STG) fault, go to step 5. For left side air bag module (DFSIDE) with an open circuit (O-CIR), go to step 6. For left side air bag module (DFSIDE) with low resistance (LOWRES), go to step 8. For right side air bag module (PFSIDE) with a short to battery (STB), go to step 10. For right side air bag module (PFSIDE) with a short to ground (STG), go to step 11. For right side air bag module (PFSIDE) with an open circuit (O-CIR), go to step 12. For right side air bag module (PFSIDE) with low resistance (LOWRES), go to step 14. If DTC B2295 was not retrieved during on-demand self-test and if flagged fault of "?" was recorded, multiple faults exist. Entire test must be carried out before replacing air bag module. If DTC B2295 was not retrieved during on-demand self-test, use flagged faults recorded in step 1 to find appropriate step. For left side air bag module (DFSIDE) with short to battery (STB) fault, go to step 16. For left side air bag module (DFSIDE) with short to ground (STG) fault, go to step 17. For left side air bag module (DFSIDE) with an open circuit (O-CIR), go to step 18. For left side air bag module (DFSIDE) with low resistance (LOWRES), go to step 20. For right side air bag module (PFSIDE) with a short to battery (STB), go to step 21. For right side air bag module (PFSIDE) with a short to ground (STG), go to step 22. For right side air bag module (PFSIDE) with an open circuit (O-CIR), go to step 23. For right side air bag module (PFSIDE) with low resistance (LOWRES), go to step 25. NOTE: Due to shorting bar in connector, fault can exist in either circuit. Do not remove or defeat shorting bars.
4. Check circuits for short to battery between RCM & left side air bag module Turn ignition switch to OFF position. Disconnect left side air bag simulator. Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310A, terminal No. 15 (White/Light Blue wire, circuit No. 1257). (Scheme 61) Measure voltage between ground and harness side of RCM connector C310A, terminal No. 16 (Brown/Light Blue wire, circuit No. 1258). If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 28. If voltage is less than 0.2 volt in both circuits, go to step 26. NOTE: Due to shorting bar in connector, fault can exist in either circuit. Do not remove or defeat shorting bars.
5. Check circuits for short to ground between RCM & left side air bag module Turn ignition switch to OFF position. Disconnect left side air bag simulator. Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between ground and harness side of RCM connector C310A, terminal No. 15 (White/Light Blue wire, circuit No. 1257). (Scheme 61) Measure resistance between ground and harness side of RCM connector C310A, terminal No. 16 (Brown/Light Blue wire, circuit No. 1258). If resistance is less than one megohm in either circuit, repair short to ground in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 28. If resistance is more than one megohm in both circuits, go to step 26.
6. Check circuit between RCM & left side air bag module for open Disconnect left side air bag simulator. Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance in White/Light Blue wire (circuit No. 1257) between and harness side of RCM connector C310A, terminal No. 15 and harness side of left side air bag connector. (Scheme 61) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in White/Light Blue wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 28.
7. Check circuit between RCM & left side air bag module for open Measure resistance in Brown/Light Blue wire (circuit No. 1258) between and harness side of RCM connector C310A, terminal No. 16 and harness side of left side air bag connector. If resistance is less than 0.5 ohm, go to step 26. If resistance is more than 0.5 ohm, repair open in Brown/Light Blue wire. Go to step 28.
8. Check circuits for low resistance between RCM & left side air bag module Disconnect left side air bag simulator. Measure resistance between White/Light Blue wire (circuit No. 1257) and Brown/Light Blue wire (circuit No. 1258) on harness side of left side air bag connector. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). If resistance is more than 800 ohms, go to step 26. If resistance is less than 800 ohms, go to next step.
9. Check RCM circuits for low resistance Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between component side of RCM connector No C310A, pins No. 15 and 16. (Scheme 64) If resistance is less than 800 ohms, go to step 26. If resistance is more than 800 ohms, repair low resistance between White/Light Blue and Brown/Light Blue wires. Go to step 28. NOTE: Due to shorting bar in connector, fault can exist in either circuit. Do not remove or defeat shorting bars.
10. Check circuits for short to battery between RCM & right side air bag module Disconnect right side air bag simulator. Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310A, terminal No. 23 (White/Yellow wire, circuit No. 1259). (Scheme 61) Measure voltage between ground and harness side of RCM connector C310A, terminals No. 24 (Brown/Yellow wire, circuit No. 1260). If voltage is more than 0.2 volt on either circuit, repair short to battery in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 28. If voltage is less than 0.2 volt on both circuits, go to step 26. NOTE: Due to shorting bar in connector, fault can exist in either circuit. Do not remove or defeat shorting bars.
11. Check circuits for short to ground between RCM & right side air bag module Turn ignition switch to OFF position. Disconnect right side air bag simulator. Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between ground and harness side of RCM connector C310A, terminal No. 23 (White/Yellow wire, circuit No. 1259). (Scheme 61) Measure resistance between ground and harness side of RCM connector C310A, terminal No. 24 (Brown/Yellow wire, circuit No. 1260). If resistance is less than one megohm in either circuit, repair short to ground in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 28. If resistance is more than one megohm in both circuits, go to step 26.
12. Check circuit for open between RCM & right side air bag module Disconnect right side air bag simulator. Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance in White/Yellow wire (circuit No. 1259) between and harness side of RCM connector C310A, terminal No. 23 and harness side of right side air bag connector. (Scheme 61) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in White/Yellow wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 28.
13. Check circuit for open between RCM & right side air bag module Measure resistance in Brown/Yellow wire (circuit No. 1260) between harness side of RCM connector C310A, terminal No. 24 and harness side of right side air bag connector. (Scheme 61) If resistance is less than 0.5 ohm, go to step 26. If resistance is more than 0.5 ohm, repair open in Brown/Yellow wire. Go to step 28.
14. Check circuits for low resistance between RCM & right side air bag module Disconnect right side air bag simulator. Measure resistance between White/Yellow wire (circuit No. 1259) and Brown/Yellow wire (circuit No. 1260) on harness side of right side air bag connector. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). If resistance is less than 800 ohms, go to next step. If resistance is more than 800 ohms, go to step 26.
15. Check RCM circuits for low resistance Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between component side of RCM connector C310A, pins No. 23 and 24. (Scheme 64) If resistance is less than 800 ohms, go to step 26. If resistance is more than 800 ohms, repair low resistance between White/Yellow and Brown/Yellow wires. Go to step 28. NOTE: Due to shorting bar in connector, fault can exist in either circuit. Do not remove or defeat shorting bars.
16. Check left side air bag wiring harness for short to battery Access and disconnect left side air bag connector at air bag module. See «SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__side-air-bag-module) under REMOVAL & INSTALLATION. Disconnect left side air bag simulator. Position left front seat in vehicle (DO NOT activate air bag system at this time). Reconnect left front under-seat harness connectors to left front seat. Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310A, terminal No. 15 (White/Light Blue wire, circuit No. 1257). (Scheme 61) Measure voltage between ground and harness side of RCM connector C310A, terminal No. 16 (Brown/Light Blue wire, circuit No. 1258). If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire and replace left front in-seat air bag module wiring harness. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 28. If voltage is less than 0.2 volt in both circuits, replace left side air bag module. Go to step 28. NOTE: Due to shorting bar in connector, fault can exist in either circuit. Do not remove or defeat shorting bars.
17. Check left side air bag wiring harness for short to ground Turn ignition switch to OFF position. Access and disconnect left side air bag connector at air bag module. See «SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__side-air-bag-module) under REMOVAL & INSTALLATION. Disconnect left side air bag simulator. Position left front seat in vehicle (DO NOT activate air bag system at this time). Reconnect left front under-seat harness connectors to left front seat. Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between ground and harness side of RCM connector C310A, terminal No. 15 (White/Light Blue wire, circuit No. 1257). (Scheme 61) Measure resistance between ground and harness side of RCM connector C310A, terminals No. 16 (Brown/Light Blue wire, circuit No. 1258). If resistance is less than one megohm in either circuit, repair short to ground in appropriate wire and replace left front in-seat air bag module wiring harness. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 28. If resistance is more than one megohm in both circuits, replace left side air bag module. Go to step 28.
18. Check left side air bag wiring harness for open Access and disconnect left side air bag connector at air bag module. See «SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__side-air-bag-module) under REMOVAL & INSTALLATION. Disconnect left side air bag simulator. Position left front seat in vehicle (DO NOT activate air bag system at this time). Reconnect left front under-seat harness connectors to left front seat. Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance in White/Light Blue wire (circuit No. 1257) between an d RCM connector C310A, terminal No. 15 and harness side of left side air bag connector. (Scheme 61) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, replace left front in-seat air bag module harness. Go to step 28.
19. Check left side air bag wiring harness for open Measure resistance in Brown/Light Blue wire (circuit No. 1258) between and harness side of RCM connector C310A, terminal No. 16 and harness side of left side air bag connector. If resistance is less than 0.5 ohm, replace left side air bag module. Go to step 28. If resistance is more than 0.5 ohm, replace left front in-seat air bag module harness. Go to step 28.
20. Check left side air bag wiring harness for low resistance Access and disconnect left side air bag connector at air bag module. See «SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__side-air-bag-module) under REMOVAL & INSTALLATION. Disconnect left side air bag simulator. Position left front seat in vehicle (DO NOT activate air bag system at this time). Reconnect left front under-seat harness connectors to left front seat. Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between White/Light Blue wire (circuit No. 1257) and Brown/Light Blue wire (circuit No. 1258) on harness side of left side air bag connector. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). If resistance is more than 800 ohms, replace left side air bag module. Go to step 28. If resistance is less than 800 ohms, replace left front in-seat air bag module harness. Go to step 28. NOTE: Due to shorting bar in connector, fault can exist in either circuit. Do not remove or defeat shorting bars.
21. Check right side air bag wiring harness for short to battery Access and disconnect right side air bag connector at air bag module. See «SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__side-air-bag-module) under REMOVAL & INSTALLATION. Disconnect right side air bag simulator. Position right front seat in vehicle (DO NOT activate air bag system at this time). Reconnect right front under-seat harness connectors to right front seat. Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310A, terminal No. 23 (White/Yellow wire, circuit No. 1259). (Scheme 61) Measure voltage between ground and harness side of RCM connector C310A, terminal No. 24 (Brown/Yellow wire, circuit No. 1260). If voltage is more than 0.2 volt in either circuit, repair short to battery and replace left front in-seat air bag module harness. Go to step 28. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). If voltage is less than 0.2 volt in both circuits, replace right side air bag module. Go to step 28. NOTE: Due to shorting bar in connector, fault can exist in either circuit. Do not remove or defeat shorting bars.
22. Check right side air bag wiring harness for short to ground Access and disconnect right side air bag connector at air bag module. See «SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__side-air-bag-module) under REMOVAL & INSTALLATION. Disconnect right side air bag simulator. Position right front seat in vehicle (DO NOT activate air bag system at this time). Reconnect right front under-seat harness connectors to right front seat. Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between ground and harness side of RCM connector C310A, terminal No. 23 (White/Yellow wire, circuit No. 1259). (Scheme 61) Measure resistance between ground and harness side of RCM connector C310A, terminal No. 24 (Brown/Yellow wire, circuit No. 1260). If resistance is less than one megohm in either circuit, repair short to ground and replace right front in-seat air bag module harness. Go to step 28. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). If resistance is more than one megohm in both circuits, replace right side air bag module. Go to step 28.
23. Check right side air bag wiring harness for open Access and disconnect right side air bag connector at air bag module. See «SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__side-air-bag-module) under REMOVAL & INSTALLATION. Disconnect right side air bag simulator. Position right front seat in vehicle (DO NOT activate air bag system at this time). Reconnect right front under-seat harness connectors to right front seat. Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance in White/Yellow wire (circuit No. 1259) between harness side of RCM connector C310A, terminal No. 23 and harness side of right side air bag connector. (Scheme 61) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, replace right front in-seat air bag module harness. Go to step 28.
24. Check right side air bag wiring harness for open Measure resistance in Brown/Yellow wire (circuit No. 1260) between harness side of RCM connector C310A, terminal No. 24 and harness side of right side air bag connector. If resistance is less than 0.5 ohm, replace right side air bag module. Go to step 28. If resistance is more than 0.5 ohm, replace right front in-seat air bag module harness. Go to step 28.
25. Check right side air bag wiring harness for low resistance Access and disconnect right side air bag connector at air bag module. See «SIDE AIR BAG MODULE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__side-air-bag-module) under REMOVAL & INSTALLATION. Disconnect right side air bag simulator. Position right front seat in vehicle (DO NOT activate air bag system at this time). Reconnect right front under-seat harness connectors to right front seat. Access and disconnect RCM connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between White/Yellow wire (circuit No. 1259) and Brown/Yellow wire (circuit No. 1260) on harness side of right side air bag connector. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). If resistance is more than 800 ohms, replace right side air bag module. Go to step 28. If resistance is less than 800 ohms, replace right front in-seat air bag module harness. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
26. Confirm RCM fault Turn ignition switch to OFF position. Reconnect all air bag module simulators. Reconnect RCM connectors. Turn ignition to RUN position. Perform on-demand self-test. Retrieve and record any flagged faults. Flag DTC B2295. If DTC B2295 was retrieved during on-demand self-test and "?" was flagged by scan tool, carry out entire test before replacing RCM. Replace RCM. Go to step 28. If DTC B2295 was not retrieved during on-demand self-test, fault is corrected. Go to step 28.
27. Check for intermittent fault Turn ignition to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. Flag DTC B2295. If DTC B2295 was retrieved during on-demand self-test, check for causes of intermittent fault at or near affected side air bag module harness connector. Repair any intermittent faults found and go to next step. If intermittent fault was not found, refer to recorded flagged faults for appropriate test. If flagged fault "?" was retrieved during on-demand self-test, multiple faults exist and all steps of diagnostic procedure must be performed before replacing RCM. For left side air bag module (DFSIDE) with short to battery (STB) fault, go to step 4. For left side air bag module (DFSIDE) with short to ground (STG) fault, go to step 5. For left side air bag module (DFSIDE) with an open circuit (O-CIR), go to step 6. For left side air bag module (DFSIDE) with low resistance (LOWRES), go to step 8. For right side air bag module (PFSIDE) with a short to battery (STB), go to step 10. For right side air bag module (PFSIDE) with a short to ground (STG), go to step 11. For right side air bag module (PFSIDE) with an open circuit (O-CIR), go to step 12. For right side air bag module (PFSIDE) with low resistance (LOWRES), go to step 14. If DTC B2295 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
28. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST K: RESTRAINT SYSTEM-CRASH SENSOR STATUS (DTC B2296)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) checks front and side crash sensor circuits for faults. If RCM detects low resistance, open circuit, short to battery or short to ground, it will store DTC B2296 in memory and flash Code 42, 43 or 44 on AIR BAG warning light.

An front or side crash sensor status fault could be caused by faulty wiring, terminals or connectors, faulty sensor, incorrect sensor mounting or faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Retrieve, flag and record any continuous Diagnostic Trouble Codes (DTCs). See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. Flag DTC B2296. See «BIT-MAPPED DIAGNOSTIC TROUBLE CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__bit-mapped-diagnostic-trouble-codes) under DIAGNOSTICS. Retrieve and record any flagged faults. If DTC B2296 was retrieved during on-demand self-test, fault is hard. If flagged fault of "?" was recorded, multiple faults exist and entire test must be carried out. For left side crash sensor with mounting/communications (COMM) fault, go to next step. For left side crash sensor with internal (INT) fault, replace left side air bag sensor. See «SIDE CRASH SENSOR»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Go to step 34. For right side crash sensor with mounting/communications (COMM) fault, go to step 12. For right side crash sensor with internal (INT) fault, replace right side air bag sensor and go to step 34. For front crash sensor with mounting/communication (COMM) fault, go to step 22. For front crash sensor with an internal (INT) fault, replace front crash sensor. See «FRONT CRASH SENSOR»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Go to step 34. If DTC B2296 was not retrieved during on-demand self-test, fault is intermittent. Go to step 33.
2. Check left side crash sensor mounting Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access left side crash sensor. See «SIDE CRASH SENSOR»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Inspect sensor mounting and ensure mounting bolts are fully seated and tightened correctly. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications). Remove left side crash sensor. Visually inspect sensor mounting bracket for damage, corrosion or dirt. If any problems were found, clean, tighten or repair mounting surface as necessary. Reinstall sensor and go to step 34. If no problems were found, go to next step.
3. Repeat on-demand self-test Clean and repair mounting surface as necessary. Clean sensor mounting bolts. Install left side crash sensor. Flag DTC B2296. Retrieve and record any flagged faults. If DTC B2296 was retrieved during on-demand self-test, go to next step. If DTC B2296 was not retrieved during on-demand self-test, fault is corrected. Go to step 34.
4. Check left side crash sensor ground circuit for high resistance Turn ignition switch to OFF position. Disconnect left side crash sensor harness connector. Measure resistance in Brown/Light Green wire (circuit No. 1262) between left side crash sensor case ground and harness side of left side crash sensor connector. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). If resistance is less than 100 ohms, go to step 6. If resistance is more than 100 ohms, go to next step.
5. Clean left side crash sensor mounting & repeat on-demand self-test Remove left side crash sensor. Clean and repair mounting surface as necessary. Clean sensor mounting bolts. Install left side crash sensor. Perform on-demand self-test. Flag DTC B2296. Retrieve and record any flagged faults. If DTC B2296 was retrieved during on-demand self-test, go to next step. If DTC B2296 was not retrieved during on-demand self-test, fault is corrected. Go to step 34.
6. Check left side crash sensor circuits for short to ground between RCM & sensor Turn ignition switch to OFF position. Access RCM and disconnect both harness connectors. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between ground and White/Light Green wire (circuit No. 1261) on harness side of left side crash sensor connector. Measure resistance between ground and Brown/Light Green wire (circuit No. 1262) on harness side of left side crash sensor connector. If resistance is more than one megohm in both circuits, go to next step. If resistance is less than one megohm in either circuit, repair short to ground in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 34.
7. Check left side crash sensor circuits for short to battery between RCM & sensor Turn ignition switch to RUN position. Measure voltage between ground and White/Light Green wire on harness side of left side crash sensor connector. Measure voltage between ground and Brown/Light Green wire on harness side of left side crash sensor connector. If voltage is less than 0.2 volt in both circuits, go to next step. If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire. Go to step 34.
8. Check left side crash sensor circuit for open between RCM & sensor Turn ignition switch to OFF position. Measure resistance in White/Light Green wire between harness side of RCM connector C310A, terminal No. 13 and harness side of left side crash sensor harness connector. (Scheme 61) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in White/Light Green wire. Go to step 34.
9. Check left side crash sensor circuit for open between RCM & sensor Measure resistance in Brown/Light Green wire between harness side of RCM connector C310A, terminal No. 14 and harness side of left side crash sensor harness connector. If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Brown/Light Green wire. Go to step 34.
10. Check for short between left side crash sensor circuits Measure resistance between harness side of RCM connector C310A, terminal No. 13 (White/Light Green wire) and Brown/Light Green wire on left side crash sensor harness connector. If resistance is more than one megohm, go to next step. If resistance is less than one megohm, repair short between White/Light Green and Brown/Light Green wires. Go to step 34.
11. Check left side crash sensor Reconnect both RCM connectors. Install a known-good left side crash sensor. Turn ignition switch to RUN position. Perform on-demand self-test. Flag DTC B2296. Retrieve and record any flagged faults. If any faults were flagged against left side crash sensor, go to step 32. If no faults were flagged against left side crash sensor, fault is corrected. Go to step 34.
12. Check right side crash sensor mounting Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access right side crash sensor. See «SIDE CRASH SENSOR»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Inspect sensor mounting and ensure mounting bolts are fully seated and tightened correctly. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications). Remove right side crash sensor. Visually inspect sensor mounting bracket for damage, corrosion or dirt. If any problems were found, clean tighten or repair mounting surface as necessary. Reinstall sensor and go to step 34. If no problems were found, go to next step.
13. Repeat on-demand self-test Clean and repair mounting surface as necessary. Clean sensor mounting bolts. Install right side crash sensor. Ensure ignition switch is in OFF position. Perform on-demand self-test. Flag DTC B2296. Retrieve and record any flagged faults. If DTC B2296 was retrieved during on-demand self-test, go to next step. If DTC B2296 was not retrieved during on-demand self-test, fault is corrected. Go to step 34.
14. Check right side crash sensor ground circuit for high resistance Ensure ignition switch is in OFF position. Disconnect right side crash sensor harness connector. Measure resistance in Brown wire (circuit No. 1264) between in right side crash sensor case ground and harness side of right side crash sensor connector. If resistance is less than 100 ohms, go to step 16. If resistance is more than 100 ohms, go to next step.
15. Clean right side crash sensor mounting & repeat on-demand self-test Remove right side crash sensor. Clean and repair mounting surface as necessary. Clean sensor mounting bolts. Install right side crash sensor. Ensure ignition switch is in OFF position. Perform on-demand self-test. Flag DTC B2296. Retrieve and record any flagged faults. If DTC B2296 was retrieved during on-demand self-test, go to next step. If DTC B2296 was not retrieved during on-demand self-test, fault is corrected. Go to step 34.
16. Check right side crash sensor circuits for short to ground between RCM & sensor Turn ignition switch to OFF position. Access RCM and disconnect both connectors. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance between ground and White wire (circuit No. 1263) on harness side of right side crash sensor connector. Measure resistance between ground and Brown wire (circuit No. 1264) on harness side of right side crash sensor connector. If resistance is more than one megohm in both circuits, go to next step. If resistance is less than one megohm in either circuit, repair short to ground in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 34.
17. Check right side crash sensor circuits for short to battery between RCM & sensor Turn ignition switch to RUN position. Measure voltage between ground and White wire on harness side of right side crash sensor connector. Measure voltage between ground and Brown wire on harness side of right side crash sensor connector. If voltage is less than 0.2 volt in both circuits, go to next step. If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire. Go to step 34.
18. Check right side crash sensor circuit for open between RCM & sensor Turn ignition switch to OFF position. Measure resistance in White wire between harness side of RCM connector C310A, terminal No. 17 and harness side of right side crash sensor harness connector. (Scheme 61) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in White wire. Go to step 34.
19. Check right side crash sensor circuit for open between RCM & sensor Measure resistance in Brown wire between harness side of RCM connector C310A, terminal No. 18 and harness side of right side crash sensor harness connector. If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Brown wire. Go to step 34.
20. Check for short between right side crash sensor circuits Measure resistance between harness side of RCM connector C310A, terminal No. 17 (White wire) and right side crash sensor harness connector Brown wire. If resistance is more than one megohm, go to next step. If resistance is less than one megohm, repair short between White and Brown wires. Go to step 34.
21. Check right side crash sensor Reconnect RCM connectors. Install a known-good right side crash sensor. Turn ignition switch to RUN position. Perform on-demand self-test. Flag DTC B2296. Retrieve and record any flagged faults. If any faults were flagged against right side crash sensor, go to next step. If no faults were flagged against right side crash sensor, fault is corrected. Go to step 34.
22. Check front crash sensor mounting Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access front crash sensor. See «FRONT CRASH SENSOR»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Inspect sensor mounting and ensure mounting bolts are fully seated and tightened correctly. See «TORQUE SPECIFICATIONS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__torque-specifications). Remove front crash sensor. Visually inspect sensor mounting bracket for damage, corrosion or dirt. If any problems were found, clean tighten or repair mounting surface as necessary. Reinstall sensor and go to step 34. If no problems were found, go to next step.
23. Repeat on-demand self-test Clean and repair mounting surface as necessary. Clean sensor mounting bolts. Install front crash sensor. Ensure ignition switch is in OFF position. Perform on-demand self-test. Flag DTC B2296. Retrieve and record any flagged faults. If DTC B2296 was retrieved during on-demand self-test, go to next step. If DTC B2296 was not retrieved during on-demand self-test, fault is corrected. Go to step 34.
24. Check front crash sensor ground circuit for high resistance Ensure ignition switch is in OFF position. Disconnect front crash sensor harness connector. Measure resistance in Violet/Light Green wire (circuit No. 618) between front crash sensor case ground and harness side of front crash sensor connector. If resistance is less than 100 ohms, go to step 26. If resistance is more than 100 ohms, go to next step.
25. Clean front crash sensor mounting & repeat on-demand self-test Remove front crash sensor. Clean and repair mounting surface as necessary. Clean sensor mounting bolts. Install front crash sensor. Ensure ignition switch is in OFF position. Perform on-demand self-test. Flag DTC B2296. Retrieve and record any flagged faults. If DTC B2296 was retrieved during on-demand self-test, go to next step. If DTC B2296 was not retrieved during on-demand self-test, fault is corrected. Go to step 34.
26. Check front crash sensor circuits for short to ground between RCM & sensor Turn ignition switch to OFF position. Access RCM and disconnect both connectors. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Measure resistance in Pink/Orange wire (circuit No. 617) between ground and harness side of front crash sensor connector. Measure resistance in Violet/Light Green wire (circuit No. 618) between ground and harness side of front crash sensor connector. If resistance is more than one megohm in both circuits, go to next step. If resistance is less than one megohm in either circuit, repair short to ground in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 34.
27. Check front crash sensor circuits for short to battery between RCM & sensor Turn ignition switch to RUN position. Measure voltage in Pink/Orange wire between ground and harness side of front crash sensor connector. Measure voltage in Violet/Light Green wire between ground and harness side of front crash sensor connector. If voltage is less than 0.2 volt in both circuits, go to next step. If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire. Go to step 34.
28. Check front crash sensor circuit for open between RCM & sensor Measure resistance in Pink/Orange wire between harness side of RCM connector C310A, terminal No. 25 and harness side of front crash sensor harness connector. (Scheme 61) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Pink/Orange wire. Go to step 34.
29. Check front crash sensor circuit for open between RCM & sensor Measure resistance in Violet/Light Green wire between harness side of RCM connector C310A, terminal No. 26 and harness side of front crash sensor harness connector. If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Violet/Light Green wire. Go to step 34.
30. Check for short between front crash sensor circuits Measure resistance between harness side of RCM connector C310A, terminal No. 25 (Pink/Orange wire) and Violet/Light Green wire on harness side of front crash sensor harness connector. If resistance is more than one megohm, go to next step. If resistance is less than one megohm, repair short between Pink/Orange and Violet/Light Green wires. Go to step 34.
31. Check front crash sensor Reconnect RCM connectors. Install a known-good front crash sensor. Turn ignition switch to RUN position. Perform on-demand self-test. Retrieve and record any flagged faults. If any faults were flagged against front crash sensor, go to next step. If no faults were flagged against front crash sensor, fault is corrected. Go to step 34. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
32. Confirm RCM fault Turn ignition to OFF position. Reconnect all crash sensor connectors. Reconnect both RCM connectors. Turn ignition switch to ON position. Perform on-demand self-test. Flag DTC B2296. Retrieve and record any flagged faults. If DTC B2296 was retrieved during on-demand self-test and "?" was flagged by scan tool, carry out entire test before replacing RCM. Replace RCM. Go to step 34. If DTC B2296 was not retrieved during on-demand self-test, fault is corrected. Go to step 34.
33. Check for intermittent fault Turn ignition to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. Flag DTC B2296. If DTC B2296 was retrieved during on-demand self-test, fault is hard. If flagged fault "?" was retrieved during on-demand self-test, multiple faults exist and all steps of diagnostic procedure must be performed before replacing RCM. For left side crash sensor with mounting/communications (COMM) fault, go to step 2. For left side crash sensor with internal (INT) fault, replace left side air bag sensor. See «SIDE CRASH SENSOR»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Go to step 34. For right side crash sensor with mounting/communications (COMM) fault, go to step 12. For right side crash sensor with internal (INT) fault, replace right side air bag sensor and go to step 34. For front crash sensor with mounting/communication (COMM) fault, go to step 22. For front crash sensor with an internal (INT) fault, replace front crash sensor. See «FRONT CRASH SENSOR»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Go to step 34. If DTC B2296 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
34. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST L: LEFT SEAT BELT BUCKLE CIRCUIT OPEN (DTC B2432)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) checks left seat belt circuits for faults. If RCM detects an open circuit, it will store Diagnostic Trouble Code (DTC) B2432 in memory and flash Code 51 on AIR BAG warning light.

A left seat belt buckle switch open circuit fault could be caused by damaged wiring, terminals or connectors, faulty seat belt buckle switch or a faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC B2432 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC B2432 was not retrieved, fault is intermittent. Go to step 8.
2. Check circuit for open between left front seat & RCM Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect left front seat floor connector C311. Measure resistance between harness side of RCM connector C310A, terminal No. 5 and vehicle harness side of front seat floor connector, terminal No. 10 (Brown/Light Blue wire, circuit No. 85). (Scheme 61)& (Scheme 69). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Brown/Light Blue wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 9.
3. Check circuit for open between left front seat & RCM Measure resistance between harness side of RCM connector C310A, terminal No. 9 and vehicle harness side of left front seat floor connector C311, terminal No. 4 (Tan/Black wire, circuit No. 1558). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Tan/Black wire. Go to step 9.
4. Check circuit for open between left front seat & seat belt buckle switch Disconnect left front seat belt buckle switch connector. Measure resistance in Brown/Light Blue wire between seat harness side of left front seat floor connector C311, terminal No. 10 and seat harness side of left front seat belt buckle switch connector. (Scheme 70) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohms, repair open in Brown/Light Blue wire. Go to step 9.
5. Check circuit for open between left front seat switch Measure resistance in Tan/Black wire between seat harness side of left front seat floor connector C311, terminal No. 4 and seat harness side of left front seat belt buckle switch connector. If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohms, repair open in Tan/Black wire. Go to step 9.
6. Check seat belt buckle switch Reconnect RCM connector C310A. Install known-good seat belt buckle. See «SEAT BELT BUCKLE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Position left front seat in vehicle. Reconnect left front seat floor connector C311. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2432 was retrieved during on-demand self-test, go to next step. If DTC B2432 was not retrieved, fault is corrected. Go to step 9. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
7. Confirm RCM Fault Turn ignition switch to OFF position. Reinstall original seat belt buckle. Connect RCM harness connector C310A. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2432 was retrieved during on-demand self-test, replace RCM. Go to step 9. If DTC B2432 was not retrieved during on-demand self-test, fault is corrected. Go to step 9.
8. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC B2432 was retrieved during on-demand self-test, go to step 2. If DTC B2432 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
9. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

Scheme 69

Scheme 70

TEST M: LEFT SEAT BELT BUCKLE CIRCUIT SHORT TO BATTERY (DTC B2433)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) checks left seat belt circuits for faults. If RCM detects a short to battery, it will store Diagnostic Trouble Code (DTC) B2433 in memory and flash Code 51 on AIR BAG warning light.

A left seat belt buckle switch short to battery fault could be caused by damaged wiring, terminals, connectors or a faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC B2433 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC B2433 was not retrieved, fault is intermittent. Go to step 5.
2. Check circuit for short to battery between left front seat & RCM Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect left front seat floor connector C311. Turn ignition switch to RUN position. Measure voltage between ground and vehicle harness side of front seat floor connector, terminal No. 10 (Brown/Light Blue wire, circuit No. 85). (Scheme 69) Measure voltage between ground and vehicle harness side of front seat floor connector, terminal No. 4 (Tan/Black wire, circuit No. 1558). If voltage is less than 0.2 volt in both circuits, go to next step. If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 6.
3. Check circuit for short to battery between left front seat & seat belt buckle switch Turn ignition switch to OFF position. Reconnect left front seat floor connector C311. Disconnect left front seat belt buckle switch connector. Turn ignition switch to RUN position. Measure voltage in Tan/Black wire between ground and seat harness side of seat belt buckle switch connector. Measure voltage in Brown/Light Blue wire between ground and seat harness side of left front seat belt buckle switch connector. If voltage is less than 0.2 volt in both circuits, go to next step. If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire. Go to step 6. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
4. Confirm RCM Fault Turn ignition switch to OFF position. Reconnect RCM connector C310A. Reconnect left front seat belt buckle switch connector. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2433 was retrieved during on-demand self-test, replace RCM. Go to step 6. If DTC B2433 was not retrieved during on-demand self-test, fault is corrected. Go to step 6.
5. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC B2433 was retrieved during on-demand self-test, go to step 2. If DTC B2433 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
6. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST N: LEFT SEAT BELT BUCKLE CIRCUIT SHORT TO GROUND (DTC B2434)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) checks left seat belt circuits for faults. If RCM detects a short to ground, it will store Diagnostic Trouble Code (DTC) B2434 in memory and flash Code 51 on AIR BAG warning light.

A left seat belt buckle switch short to ground fault could be caused by damaged wiring, terminals, connectors, faulty seat belt buckle switch or a faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC B2434 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC B2434 was not retrieved, fault is intermittent. Go to step 6.
2. Check circuit for short to ground between left front seat & RCM Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect left front seat floor connector C311. Measure resistance between ground and vehicle harness side of front seat floor connector, terminal No. 10 (Brown/Light Blue wire, circuit No. 85). (Scheme 69) If resistance is more than one megohm, go to next step. If resistance is less than one megohm, repair short to ground in Brown/Light Blue wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 7.
3. Check circuit for short to ground between left front seat belt buckle switch & RCM Reconnect left front seat floor connector C311. Disconnect left front seat belt buckle switch connector. Measure resistance in Brown/light Blue wire between ground and seat harness side of left front seat belt switch connector. If resistance is more than one megohm, go to next step. If resistance is less than one megohm, repair short to ground in Brown/Light Blue wire. Go to step 7.
4. Check seat belt buckle switch Turn ignition switch to OFF position. Reconnect RCM connector C310A. Install known-good left seat belt buckle. See «SEAT BELT BUCKLE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Position front seat in vehicle. Reconnect left front seat floor connector C311. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2434 was retrieved during on-demand self-test, go to next step. If DTC B2434 was not retrieved during on-demand self-test, fault is corrected. Go to step 7. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
5. Confirm RCM Fault Turn ignition switch to OFF position. Reinstall original left seat belt buckle. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2434 was retrieved during on-demand self-test, replace RCM. Go to step 7. If DTC B2434 was not retrieved during on-demand self-test, fault is corrected. Go to step 7.
6. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC B2434 was retrieved during on-demand self-test, go to step 2. If DTC B2434 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
7. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST O: LEFT SEAT BELT BUCKLE CIRCUIT RESISTANCE OUT OF RANGE (DTC B2435)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) checks left seat belt circuits for faults. If RCM detects a resistance out of range fault, it will store Diagnostic Trouble Code (DTC) B2435 in memory and flash Code 51 on AIR BAG warning light.

A left seat belt buckle switch resistance out of range fault could be caused by damaged wiring, terminals, connectors, faulty seat belt buckle switch or a faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC B2435 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC B2435 was not retrieved, fault is intermittent. Go to step 8.
2. Check circuit for open between left front seat & RCM Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect left front seat floor connector C311. Measure resistance between harness side of RCM connector C310A, terminal No. 5 and vehicle harness side of left seat floor connector C311, terminal No. 10 (Brown/Light Blue wire, circuit No. 85). (Scheme 61)& (Scheme 69). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Brown/Light Blue wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 9.
3. Check circuit for open between left front seat & RCM Measure resistance between harness side of RCM connector C310A, terminal No. 9 and vehicle harness side of left seat floor connector C311, terminal No. 11 (Tan/Black wire, circuit No. 1558) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Tan/Black wire. Go to step 9.
4. Check circuit for open between left front seat & seat belt buckle switch Turn ignition switch to OFF position. Disconnect left front seat belt buckle switch connector. Measure resistance in Brown/Light Blue wire between seat harness side of left seat floor connector C311, terminal No. 10 and harness side of left front seat belt buckle switch connector. (Scheme 70) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Brown/Light Blue wire. Go to step 9.
5. Check circuit for open between left front seat & seat belt buckle switch Measure resistance in Tan/Black wire between seat harness side of left seat floor connector C311, terminal No. 4 and harness side of left front seat belt buckle switch connector. If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Tan/Black wire. Go to step 9.
6. Check left front seat belt buckle switch Turn ignition switch to OFF position. Reconnect RCM connector C310A. Install known-good left seat belt buckle. See «SEAT BELT BUCKLE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Position left front seat in vehicle. Reconnect left seat floor connector C311. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2435 was retrieved during on-demand self-test, go to next step. If DTC B2435 was not retrieved during on-demand self-test, fault is corrected. Go to step 9. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
7. Confirm RCM Fault Turn ignition switch to OFF position. Reinstall original left seat belt buckle. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2435 was retrieved during on-demand self-test, replace RCM. Go to step 9. If DTC B2435 was not retrieved during on-demand self-test, fault is corrected. Go to step 9.
8. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC B2435 was retrieved during on-demand self-test, go to step 2. If DTC B2435 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
9. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST P: RIGHT SEAT BELT BUCKLE CIRCUIT OPEN (DTC B2436)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) checks right seat belt circuits for faults. If RCM detects an open circuit, it will store Diagnostic Trouble Code (DTC) B2436 in memory and flash Code 52 on AIR BAG warning light.

A right seat belt buckle switch open circuit fault could be caused by damaged wiring, terminals or connectors, faulty seat belt buckle switch or a faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC B2436 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC B2436 was not retrieved, fault is intermittent. Go to step 8.
2. Check circuit for open between right front seat & RCM Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect right front seat floor connector C312. Measure resistance between harness side of RCM connector C310A, terminal No. 10 and vehicle harness side of right seat floor connector C312, terminal No. 10 (Red/Black wire, circuit 1514). (Scheme 61)& (Scheme 69). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Red/Black wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 9.
3. Check circuit for open between right front seat & RCM Measure resistance between harness side of RCM connector C310A, terminal No. 9 and vehicle harness side of right seat floor connector C312, terminal No. 1 (Tan/Black wire, circuit No. 1558). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Tan/Black wire. Go to step 9.
4. Check circuit for open between right front seat & seat belt buckle switch Disconnect right front seat belt buckle switch connector. Measure resistance in Red/Black wire between seat harness side of right seat floor connector C312, terminal No. 10 and harness side of right front seat belt buckle switch connector. (Scheme 70) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohms, repair open in Red/Black wire. Go to step 9.
5. Check circuit for open between right front seat & seat belt buckle switch Measure resistance in Tan/Black wire between seat harness side of right seat floor connector C312, terminal No. 1 and harness side of right front seat belt buckle switch connector. If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohms, repair open in Tan/Black wire. Go to step 9.
6. Check seat belt buckle switch Reconnect RCM connector C310A. Install known-good seat belt buckle. See «SEAT BELT BUCKLE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Reconnect right front seat belt buckle switch connector. Position right front seat in vehicle. Reconnect right seat floor harness connector C312. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2436 was retrieved during on-demand self-test, go to next step. If DTC B2436 was not retrieved, fault is corrected. Go to step 9. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
7. Confirm RCM Fault Turn ignition switch to OFF position. Reinstall original seat belt buckle. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2436 was retrieved during on-demand self-test, replace RCM. Go to step 9. If DTC B2436 was not retrieved during on-demand self-test, fault is corrected. Go to step 9.
8. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC B2436 was retrieved during on-demand self-test, go to step 2. If DTC B2436 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
9. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST Q: RIGHT SEAT BELT BUCKLE CIRCUIT SHORT TO BATTERY (DTC B2437)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) checks right seat belt circuits for faults. If RCM detects a short to battery, it will store Diagnostic Trouble Code (DTC) B2437 in memory and flash Code 52 on AIR BAG warning light.

A right seat belt buckle switch short to battery fault could be caused by damaged wiring, terminals, connectors or a faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC B2437 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC B2437 was not retrieved, fault is intermittent. Go to step 5.
2. Check circuit for short to battery between right front seat & RCM Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect right front seat floor connector C312. Turn ignition switch to RUN position. Measure voltage between ground and vehicle harness side of right seat floor connector C312, terminal No. 10 (Red/Black wire, circuit No. 1514). (Scheme 69) Measure voltage between ground and vehicle harness side of right seat floor connector C312, terminal No. 1 (Tan/Black wire, circuit No. 1558). If voltage is less than 0.2 volt in both circuits, go to next step. If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 6.
3. Check circuit for short to battery between right front seat belt buckle switch & RCM Turn ignition switch to OFF position. Reconnect right seat floor connector C312. Disconnect right seat belt buckle switch connector. Turn ignition switch to RUN position. Measure voltage in Tan/Black wire between ground and harness side of right seat belt switch harness connector. Measure voltage in Red/Black wire between ground and harness side of right seat belt switch harness connector. If voltage is less than 0.2 volt in both circuits, go to next step. If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire. Go to step 6. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
4. Confirm RCM Fault Turn ignition switch to OFF position. Reconnect RCM connector C310A. Reconnect right front seat belt buckle connector. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2437 was retrieved during on-demand self-test, replace RCM. Go to step 6. If DTC B2437 was not retrieved during on-demand self-test, fault is corrected. Go to step 6.
5. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC B2437 was retrieved during on-demand self-test, go to step 2. If DTC B2437 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
6. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST R: RIGHT SEAT BELT BUCKLE CIRCUIT SHORT TO GROUND (DTC B2438)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) checks right seat belt circuits for faults. If RCM detects a short to ground, it will store Diagnostic Trouble Code (DTC) B2438 in memory and flash Code 52 on AIR BAG warning light.

A right seat belt buckle switch short to ground fault could be caused by damaged wiring, terminals, connectors, faulty seat belt buckle switch or a faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC B2438 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC B2438 was not retrieved, fault is intermittent. Go to step 6.
2. Check circuit for short to ground between right front seat & RCM Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect right front seat floor connector C312. Measure resistance between ground and vehicle harness side of right seat floor connector C312, terminal No. 10 (Red/Black wire, circuit No. 1514). (Scheme 69) If resistance is more than one megohm, go to next step. If resistance is less than one megohm, repair short to ground in Red/Black wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 7.
3. Check circuit for short to ground between right front seat belt buckle switch & RCM Reconnect right front seat floor harness connector C312. Disconnect right front seat belt buckle switch connector. Measure resistance in Red/Black wire between ground and seat harness side of right seat belt buckle connector. If resistance is less than one megohm, go to next step. If resistance is more than one megohm, repair short to ground in Red/Black wire. Go to step 7.
4. Check seat belt buckle switch Turn ignition switch to OFF position. Reconnect RCM connector C310A. Install known-good right seat belt buckle. See «SEAT BELT BUCKLE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Position front seat in vehicle. Reconnect right front seat floor connector C312. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2438 was retrieved during on-demand self-test, go to next step. If DTC B2438 was not retrieved during on-demand self-test, fault is corrected. Go to step 7. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
5. Confirm RCM Fault Turn ignition switch to OFF position. Reinstall original right seat belt buckle. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2438 was retrieved during on-demand self-test, replace RCM. Go to step 7. If DTC B2438 was not retrieved during on-demand self-test, fault is corrected. Go to step 7.
6. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC B2438 was retrieved during on-demand self-test, go to step 2. If DTC B2438 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
7. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST S: RIGHT SEAT BELT BUCKLE CIRCUIT RESISTANCE OUT OF RANGE (DTC B2439)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) checks right seat belt circuits for faults. If RCM detects a resistance out of range fault, it will store Diagnostic Trouble Code (DTC) B2439 in memory and flash Code 52 on AIR BAG warning light

A right seat belt buckle switch resistance out of range fault could be caused by damaged wiring, terminals, connectors, faulty seat belt buckle switch or a faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC B2439 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC B2439 was not retrieved, fault is intermittent. Go to step 8.
2. Check circuit for open between right front seat & RCM Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect right front seat floor connector C312. Measure resistance between RCM connector C310A, terminal No. 10 and vehicle harness side of right seat floor harness connector C312, terminal No. 10 (Red/Black wire, circuit No. 1514). (Scheme 61)& (Scheme 69). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Red/Black wire. Go to step 9.
3. Check circuit for open between right front seat & RCM Measure resistance between RCM connector C310A, terminal No. 9 and vehicle harness side of right seat floor harness connector C312, terminal No. 1 (Tan/Black wire, circuit No. 1558). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Tan/Black wire. Go to step 9.
4. Check circuit for open between right front seat belt buckle switch & RCM Disconnect right front seat belt buckle switch connector. Measure resistance in Red/Black wire between seat harness side of right seat floor harness connector C312, terminal No. 10 and right front seat belt buckle switch connector. (Scheme 70) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Red/Black wire. Go to step 9.
5. Check circuit for open between right front seat belt buckle switch & RCM Measure resistance in Tan/Black wire between seat harness side of right seat floor harness connector C312, terminal No. 1 and right front seat belt buckle switch connector. If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Tan/Black wire. Go to step 9.
6. Check seat belt buckle switch Turn ignition switch to OFF position. Reconnect RCM connector C310A. Install known-good right seat belt buckle. See «SEAT BELT BUCKLE»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Position right seat in vehicle. Reconnect right seat floor harness connector C312. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2439 was retrieved during on-demand self-test, go to next step. If DTC B2439 was not retrieved during on-demand self-test, fault is corrected. Go to step 9. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
7. Confirm RCM Fault Turn ignition switch to OFF position. Reinstall original right seat belt buckle. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC B2439 was retrieved during on-demand self-test, replace RCM. Go to step 9. If DTC B2439 was not retrieved during on-demand self-test, fault is corrected. Go to step 9.
8. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC B2439 was retrieved during on-demand self-test, go to step 2. If DTC B2439 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
9. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST T: INCORRECT VEHICLE IDENTIFICATION (DTC C1414)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) communicates with front crash sensor to determine if sensor is correct version for vehicle. If RCM detects a version conflict, it will store Diagnostic Trouble Code (DTC) C1414 in memory and flash Code 15 on AIR BAG warning light.

RCM monitors connector C310B, terminals No. 7 and 8 to detect vehicle identification code. If RCM detects an unexpected condition at either terminal, it will store DTC C1414 in memory and flash Code 15 on AIR BAG warning light.

Incorrect vehicle identification fault could be caused by damaged wiring, terminals or connectors, incorrect sensor for vehicle, incorrect Occupant Classification Sensor (OCS) for vehicle or incorrect RCM for vehicle.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. Flag DTC C1414. See «BIT-MAPPED DIAGNOSTIC TROUBLE CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__bit-mapped-diagnostic-trouble-codes) under DIAGNOSTICS. Retrieve and record any flagged faults. If DTC C1414 was retrieved during on-demand self-test, fault is hard. If flagged fault of "?" was recorded, multiple faults exist and entire test must be carried out. RCM version conflicts with OCS module version, go to next step. RCM version conflicts with hard wire vehicle identification, go to step 4. RCM version conflicts with front crash sensor, go to step 6 If DTC C1414 was not retrieved, fault is intermittent. Go to step 9.
2. Visually inspect circuits Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect both connectors. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Access and disconnect OCS module harness connector C3043. See «OCCUPANT CLASSIFICATION SENSOR (OCS)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__occupant-classification-sensor-ocs) under REMOVAL & INSTALLATION. Visually inspect Dark Green/Violet and Dark Blue/Orange wires in OCS module harness connector and RCM connector C310A for damage, corrosion or dirt. Inspect component side of OCS module and RCM connectors damage, corrosion or dirt. If problems are found, repair as necessary. Go to step 10. If no problems are found, go to next step.
3. Check OCS part number Check part number on OCS module against part number listen in master parts catalog. If part number on OCS module matches part number listed in master parts catalog, go to step 8. If part number on OCS module does not match part number listed in master parts catalog, replace OCS system. Go to step 10.
4. Check for battery voltage Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310B, terminal No. 7 (Dark Blue/Light Green wire, circuit No. 964). (Scheme 61) Voltage should be 9-16 volts. Measure voltage between ground and harness side of RCM connector C310B, terminal No. 8 (Black wire, circuit No. 57). There should be no measurable voltage. If voltage is as specified, go to next step. If voltage is not as specified, repair appropriate wire as necessary. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 10.
5. Check for ground Turn ignition switch to OFF position. Measure resistance between ground and harness side of RCM connector C310B, terminal No. 7 (Dark Blue/Light Green wire). Resistance should be more than one megohm. Measure resistance between ground and harness side of RCM connector C310B, terminal No. 8 (Black wire). Resistance should be less than 5 ohms. If resistance is as specified, go to step 8. If resistance is not as specified, repair appropriate wire as necessary. Go to step 10.
6. Visually inspect circuits Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect both connectors. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Access and disconnect front crash sensor harness connector. See «FRONT CRASH SENSOR»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Visually inspect Pink/Orange wire (circuit No. 617) and Violet/Light Green wire (circuit No. 618) in front crash sensor harness connector and RCM connector C310A for damage, corrosion or dirt. Inspect component side of front crash sensor and RCM connectors damage, corrosion or dirt. If problems are found, repair as necessary. Go to step 10. If no problems are found, go to next step.
7. Check front crash sensor part number Check part number on front crash sensor against part number listen in master parts catalog. If part number on front crash sensor matches part number listed in master parts catalog, go to next step. If part number on front crash sensor does not match part number listed in master parts catalog, replace front air bag system. Go to step 10.
8. Check RCM part number Check part number on RCM against part number listen in master parts catalog. If part number on RCM matches part number listed in master parts catalog, replace RCM with same part number. Go to step 10. If part number on RCM does not match part number listed in master parts catalog, replace RCM with correct part number. Go to step 10.
9. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC C1414 was retrieved during on-demand self-test, go to step 1. If DTC C1414 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
10. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST U: SEAT TRACK POSITION SENSOR CIRCUIT OPEN (DTC C1946)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) monitors seat track position switch circuits for faults. If RCM detects an open circuit, it will store Diagnostic Trouble Code (DTC) C1946 in memory and flash Code 49 on AIR BAG warning light.

A seat track position sensor open circuit fault could be caused by damaged wiring, terminals or connectors, faulty seat track position sensor or faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC C1946 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC C1946 was not retrieved, fault is intermittent. Go to step 8.
2. Check circuit for open between left front seat & RCM Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect left front seat floor connector C311. Measure resistance between harness side RCM connector C310A, terminal No. 8 and vehicle harness side of left front seat floor connector C311, terminal No. 5 (Light Green wire, circuit No. 1520). (Scheme 61)& (Scheme 69). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Light Green wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 9.
3. Check circuit for open between left front seat & RCM Measure resistance between harness side of RCM connector C310A, terminal No. 9 and vehicle harness side of left front seat floor connector C311, terminal No. 4 (Tan/Black wire, circuit No. 1558). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Tan/Black wire. Go to step 9.
4. Check circuit for open between left front seat & RCM Turn ignition switch to OFF position. Disconnect seat track position sensor connector. Measure resistance in Light Green wire between seat harness side of left front seat floor connector C311, terminal No. 5 and harness side of seat track position sensor connector. (Scheme 70) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Light Green wire. Go to step 9.
5. Check circuit for open between left front seat & RCM Measure resistance in Tan/Black wire between seat harness side of left front seat floor connector C311, terminal No. 4 and harness side of seat track position sensor connector. (Scheme 70) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Tan/Black wire. Go to step 9.
6. Check seat track position sensor Reconnect RCM connector C310A. Install known-good seat track position sensor. See «SEAT TRACK POSITION SENSOR»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Position left front seat in vehicle. Reconnect seat floor harness connector C311. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC C1946 was retrieved during on-demand self-test, go to next step. If DTC C1946 was not retrieved, fault is corrected. Go to step 9. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
7. Confirm RCM Fault Turn ignition switch to OFF position. Reinstall original seat track position sensor. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC C1946 was retrieved during on-demand self-test, replace RCM. Go to step 9. If DTC C1946 was not retrieved during on-demand self-test, fault is corrected. Go to step 9.
8. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC C1946 was retrieved during on-demand self-test, go to step 2. If DTC C1946 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
9. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST V: SEAT TRACK POSITION SENSOR CIRCUIT SHORT TO GROUND (DTC C1947)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) monitors seat track position switch circuits for faults. If RCM detects a short to ground, it will store Diagnostic Trouble Code (DTC) C1947 in memory and flash Code 49 on AIR BAG warning light.

A seat track position sensor short to ground circuit fault could be caused by damaged wiring, terminals or connectors or a faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC C1947 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC C1947 was not retrieved, fault is intermittent. Go to step 6.
2. Check circuit for short to ground between left front seat & RCM Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect left front seat floor connector C311. Measure resistance between ground and vehicle harness side of left front seat floor connector C311, terminal No. 5 (Light Green wire, circuit No. 1520). (Scheme 69) Measure resistance between ground and vehicle harness side of left front seat floor connector C311, terminal No. 4 (Tan/Black wire, circuit No. 1558). If resistance is more than one megohm in both circuits, go to next step. If resistance is less than one megohm in either circuit, repair short to ground in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 7.
3. Check circuit for short to ground in left front seat Reconnect left front seat floor connector C311. Disconnect seat track position sensor connector. Measure resistance in Light Green wire between ground and harness side of seat track position sensor connector. Measure resistance in Tan/Black wire between ground and harness side of seat track position sensor connector. If resistance is more than one megohm in both circuits, replace RCM. Go to step 7. If resistance is less than one megohm in either circuit, repair short to ground in appropriate wire. Go to step 7.
4. Check seat track position sensor Reconnect RCM connector C310A. Install known-good seat track position sensor. See «SEAT TRACK POSITION SENSOR»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Position left front seat in vehicle. Reconnect seat floor harness connector C311. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC C1947 was retrieved during on-demand self-test, go to next step. If DTC C1947 was not retrieved, fault is corrected. Go to step 7. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
5. Confirm RCM Fault Turn ignition switch to OFF position. Reinstall original seat track position sensor. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC C1947 was retrieved during on-demand self-test, replace RCM. Go to step 7. If DTC C1947 was not retrieved during on-demand self-test, fault is corrected. Go to step 7.
6. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC C1947 was retrieved during on-demand self-test, go to step 2. If DTC C1947 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
7. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST W: SEAT TRACK POSITION SENSOR CIRCUIT RESISTANCE OUT OF RANGE (DTC C1948)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) monitors seat track position switch circuits for faults. If RCM detects a resistance out of range condition, it will store Diagnostic Trouble Code (DTC) C1949 in memory and flash Code 49 on AIR BAG warning light.

A seat track position sensor resistance out of range fault could be caused by damaged wiring, terminals or connectors, a faulty seat track position sensor or a faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC C1949 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC C1949 was not retrieved, fault is intermittent. Go to step 8.
2. Check circuit for open between left front seat & RCM Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect left front seat floor connector C311. Measure resistance between harness side of RCM connector C310A, terminal No. 8 and vehicle harness side of left front seat floor connector C311, terminal No. 5 (Light Green wire, circuit No. 1520). (Scheme 61)& (Scheme 69). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Light Green wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 9.
3. Check circuit for open between left front seat & RCM Measure resistance between harness side of RCM connector C310A, terminal No. 9 and vehicle harness side of left front seat floor connector C311, terminal No. 4 (Tan/Black wire, circuit No. 1558). If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Tan/Black wire. Go to step 9.
4. Check circuit for open between left front seat & seat track position sensor Disconnect seat track position sensor connector. Measure resistance in Light Green wire between seat harness side of left front seat floor connector C311, terminal No. 5 and harness side of seat track position sensor connector. (Scheme 70) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohms, repair open in Light Green wire. Go to step 9.
5. Check circuit for open between left front seat & seat track position sensor Measure resistance in Tan/Black wire between seat harness side of left front seat floor connector terminal No. 4 and harness side of seat track position sensor connector. (Scheme 70) If resistance is less than 0.5 ohm, go to next step. If resistance is more than 0.5 ohm, repair open in Tan/Black wire. Go to step 9.
6. Check seat track position sensor Reconnect RCM connector C310A. Install known-good seat track position sensor. See «SEAT TRACK POSITION SENSOR»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Position left front seat in vehicle. Reconnect left front seat floor connector C311. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC C1948 was retrieved during on-demand self-test, go to next step. If DTC C1948 was not retrieved, fault is corrected. Go to step 9. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
7. Confirm RCM Fault Turn ignition switch to OFF position. Reinstall original seat track position sensor. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC C1948 was retrieved during on-demand self-test, replace RCM. Go to step 9. If DTC C1948 was not retrieved during on-demand self-test, fault is corrected. Go to step 9.
8. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC C1948 was retrieved during on-demand self-test, go to step 2. If DTC C1948 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
9. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST X: SEAT TRACK POSITION SENSOR CIRCUIT SHORT TO BATTERY (DTC C1982)

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Restraints Control Module (RCM) monitors seat track position switch circuits for faults. If RCM detects a short to battery, it will store Diagnostic Trouble Code (DTC) C1982 in memory and flash Code 49 on AIR BAG warning light.

A seat track position sensor short to battery circuit fault could be caused by damaged wiring, terminals or connectors or a faulty RCM.

1. Check for hard or intermittent DTC Turn ignition switch to OFF position. Connect scan tool to Data Link Connector (DLC). See «USING SCAN TOOL»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__using-scan-tool) under DIAGNOSTICS. Turn ignition switch to RUN position. Retrieve and record any continuous DTCs. See «RETRIEVING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__retrieving-fault-codes) under DIAGNOSTICS. Perform on-demand self-test. See «ON-DEMAND SELF-TEST»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__on-demand-self-test) under DIAGNOSTICS. If DTC C1982 was retrieved during on-demand self-test, fault is hard. Go to next step. If DTC C1982 was not retrieved, fault is intermittent. Go to step 5.
2. Check circuit for short to battery between left front seat & RCM Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310A. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Disconnect left front seat floor connector C311. Turn ignition switch to RUN position. Measure voltage between ground and vehicle harness side of left front seat floor connector C311, terminal No. 5 (Light Green wire, circuit No. 1520). (Scheme 69) Measure voltage between ground and vehicle harness side of left front seat floor connector C311, terminal No. 4 (Tan/Black wire, circuit No. 1558). If voltage is less than 0.2 volt in both circuits, go to next step. If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Go to step 6.
3. Check circuit for short to battery in left front seat Turn ignition switch to OFF position. Reconnect left front seat floor connector C311. Disconnect seat track position sensor connector. Turn ignition switch to RUN position. Measure voltage in Light Green wire between ground and harness side of seat track position sensor connector. Measure voltage in Tan/Black wire between ground and harness side of seat track position sensor connector. If voltage is less than 0.2 volt in both circuits, go to next step. If voltage is more than 0.2 volt in either circuit, repair short to battery in appropriate wire. Go to step 6. NOTE: Ensure all air bag system simulators, sensor electrical connectors and RCM electrical connectors are connected prior to carrying out on-demand self-test or erroneous faults may be set.
4. Confirm RCM fault Turn ignition switch to OFF position. Reconnect RCM connector C310A. Turn ignition switch to RUN position. Perform on-demand self-test. If DTC C1982 was retrieved during on-demand self-test, replace RCM. Go to step 6. If DTC C1982 was not retrieved during on-demand self-test, fault is corrected. Go to step 6.
5. Check for intermittent fault Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Perform on-demand self-test. If DTC C1982 was retrieved during on-demand self-test, go to step 2. If DTC C1982 was not retrieved during on-demand self-test, check for cause of intermittent fault. Attempt to recreate fault by flexing wire harness and cycling ignition switch frequently. Repair any intermittent problems found. Go to next step.
6. Check for additional DTCs Refer to continuous DTCs recorded in step 1. If any continuous DTCs were retrieved, go to diagnostic trouble code identification table for direction to appropriate test. See «DIAGNOSTIC TROUBLE CODE IDENTIFICATION»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) table. DO NOT clear any DTCs until all DTCs have been resolved. If no DTCs were retrieved, reconnect air bag system. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Clear all DTCs. See «CLEARING FAULT CODES»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__clearing-fault-codes) under DIAGNOSTICS.

TEST Y: NO COMMUNICATION WITH RCM

Note. Before proceeding, see AIR BAG SAFETY PRECAUTIONS .

Scan tool communicates with Restraints Control Module (RCM) through Data Link Connector (DLC) terminal No. 7 (Light Blue/White wire).

A no communication with RCM fault could be caused by damaged wiring, terminals or connectors, faulty DLC or faulty RCM.

1. Check RCM connector & pin for damage Turn ignition switch to OFF position. Disable air bag system. See «DISABLING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Access RCM and disconnect connector C310B. See «RESTRAINTS CONTROL MODULE (RCM)»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under REMOVAL & INSTALLATION. Inspect both harness side and component side of RCM connector C310B, terminal No. 4 for damage, corrosion or dirt. (Scheme 61)& (Scheme 64). If no problem is found with connector or component, go to next step. If problems are found, repair RCM and/or connector as necessary. Retest communication to RCM. Activate air bag system. See «ACTIVATING SYSTEM»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
2. Check DLC connector & pin for damage Inspect DLC connector and terminal No.7 (Light Blue/White wire, circuit No. 70) for damage, corrosion or dirt. (Scheme 71) If no problem is found with connector or terminal, go to next step. If problem is found, repair connector or terminal as necessary. Retest communication to RCM. Activate air bag system.
3. Check ignition circuit for open Turn ignition switch to RUN position. Measure voltage between ground and harness side of RCM connector C310B, terminal No. 1 (Dark Blue/Light Green wire, circuit No. 964). If voltage is 9-16 volts, go to next step. If voltage is not 9-16 volts, repair open in Dark Blue/Light Green wire. See «WIRING DIAGRAMS»(/ford/crown-victoria/ii-1997-2011/remont/airbag/#supplemental-inflatable-restraint-system). Retest communication to RCM. Activate air bag system.
4. Check ground circuit for open Turn ignition switch to OFF position. Measure resistance between ground and harness side of RCM connector C310B, terminal No. 10 (Black wire, circuit No. 57). If resistance is less than 5 ohms, go to next step. If resistance is more than 5 ohms, repair open in Black wire. Retest communication to RCM. Activate air bag system.
5. Check circuit for open Measure resistance between harness side of RCM connector C310B, terminal No. 4 and harness side of DLC connector terminal No. 7 (Light Blue/White wire). If resistance is less than 5 ohms, replace RCM. Retest communication to RCM. Activate air bag system. If resistance is more than 5 ohms, repair open in Light Blue/White wire. Retest communication to RCM. Activate air bag system.

Scheme 71

Air Bag System Wiring Diagram (Crown Victoria, Grand Marquis, Marauder-1 Of 2). Scheme 72

Air Bag System Wiring Diagram (Crown Victoria, Grand Marquis, Marauder-2 Of 2). Scheme 73

See also:
• AIR BAG/SRS COMPONENT INSPECTION & REPLACEMENT TABLES
• AIR BAG SAFETY PRECAUTIONS
• COMPONENT LOCATIONS
• DIAGNOSTICS
• DIAGNOSTIC SYMPTOMS
• DISABLING & ACTIVATING AIR BAG SYSTEM
• DISPOSAL PROCEDURES
• SYSTEM OPERATION CHECK
• SCRAPPED VEHICLE
• COMPUTER RELEARN
• DUAL-STAGE PASSENGER-SIDE AIR BAG MODULE
• AIR BAG SIMULATOR
• DEPLOYED AIR BAG OR PRETENSIONER
• UNDEPLOYED AIR BAG OR PRETENSIONER-FAULTY UNIT
• DISABLING SYSTEM
• SIDE AIR BAG MODULE
• CLOCKSPRING CENTERING
• STEERING WHEEL
• TORQUE SPECIFICATIONS
• ZERO OCCUPANT CLASSIFICATION SENSOR (OCS)
• REPAIR PROCEDURE
• RETRIEVING FAULT CODES
• ON-DEMAND SELF-TEST
• USING SCAN TOOL
• TEST Y: NO COMMUNICATION WITH RCM
• TEST A: AIR BAG WARNING LIGHT ON CONTINUOUSLY-RCM DISCONNECTED OR INOPERATIVE
• TEST B: AIR BAG WARNING LIGHT CIRCUIT OPEN OR SHORT TO GROUND (DTC B1869)
• TEST C: AIR BAG WARNING LIGHT CIRCUIT SHORT TO BATTERY (DTC B1870)
• TEST D: AIR BAG TONE WARNING INDICATOR CIRCUIT SHORT TO BATTERY (DTC B1891)
• TEST E: AIR BAG TONE WARNING INDICATOR CIRCUIT SHORT TO GROUND OR OPEN (DTC B1892)
• TEST F: GROUND RESISTANCE TOO HIGH OR RCM NOT MOUNTED TO VEHICLE PROPERLY (DTC B1921)
• TEST G: OCCUPANT CLASSIFICATION SENSOR (OCS) CIRCUIT FAULT (DTC B2290)
• TEST H: RESTRAINT SYSTEM-SEAT BELT PRETENSIONER STATUS (DTC B2292)
• TEST I: RESTRAINT SYSTEM-AIR BAG STATUS (DTC B2293)
• TEST J: RESTRAINT SYSTEM-SIDE AIR BAG STATUS (DTC B2295)
• TEST K: RESTRAINT SYSTEM-CRASH SENSOR STATUS (DTC B2296)
• TEST L: LEFT SEAT BELT BUCKLE CIRCUIT OPEN (DTC B2432)
• TEST M: LEFT SEAT BELT BUCKLE CIRCUIT SHORT TO BATTERY (DTC B2433)
• TEST N: LEFT SEAT BELT BUCKLE CIRCUIT SHORT TO GROUND (DTC B2434)
• TEST O: LEFT SEAT BELT BUCKLE CIRCUIT RESISTANCE OUT OF RANGE (DTC B2435)
• TEST P: RIGHT SEAT BELT BUCKLE CIRCUIT OPEN (DTC B2436)
• TEST Q: RIGHT SEAT BELT BUCKLE CIRCUIT SHORT TO BATTERY (DTC B2437)
• TEST R: RIGHT SEAT BELT BUCKLE CIRCUIT SHORT TO GROUND (DTC B2438)
• TEST S: RIGHT SEAT BELT BUCKLE CIRCUIT RESISTANCE OUT OF RANGE (DTC B2439)
• TEST T: INCORRECT VEHICLE IDENTIFICATION (DTC C1414)
• TEST U: SEAT TRACK POSITION SENSOR CIRCUIT OPEN (DTC C1946)
• TEST V: SEAT TRACK POSITION SENSOR CIRCUIT SHORT TO GROUND (DTC C1947)
• TEST W: SEAT TRACK POSITION SENSOR CIRCUIT RESISTANCE OUT OF RANGE (DTC C1948)
• TEST X: SEAT TRACK POSITION SENSOR CIRCUIT SHORT TO BATTERY (DTC C1982)
• REMOVAL & INSTALLATION
• CLEARING FAULT CODES
• BIT-MAPPED DIAGNOSTIC TROUBLE CODES
• OCCUPANT CLASSIFICATION SENSOR (OCS)
• CLOCKSPRING
