BELT ADJUSTMENT
| CAUTION | Incorrect drive belt installation will cause excessive drive belt wear and may cause the drive belt to come off the drive pulleys. |
Inspect belt for fraying. If fraying has occurred, ensure belt and tensioner are aligned properly. (Scheme 1) If tensioner has reached its limit of travel, belt is excessively stretched and replacement of belt is required. If excessive noise is noticed from tensioner or idler, check for possible bearing failure. With the engine running, visually observe the grooves in the pulleys (not the pulley flanges or the pulley forward faces) for excessive wobble. Install new components as necessary. Check all accessories, mounting brackets, and the drive belt tensioner for any interference that would prevent the components from mounting correctly. Correct any interference condition and recheck the drive belt tracking. Tighten all accessories, mounting brackets, and the drive belt tensioner retaining hardware to specification. Recheck the drive belt tracking.
Automatic tensioners are calibrated to provide correct amount of tension to belt for an accessory drive system. Unless a spring within tensioner assembly breaks, or some other mechanical part of tensioner fails, there is no need to check tensioner for correct tension.
Scheme 1
Scheme 2
Scheme 3
COOLANT
| WARNING | Never remove the radiator cap under any conditions while the engine is operating. Failure to follow these instructions could result in personal injury and/or damage to the cooling system or engine. To avoid having scalding hot coolant or steam blow out of the radiator, use extreme care when removing the radiator cap from a hot radiator. Wait until the engine has cooled, then wrap a thick cloth around the radiator cap and turn it slowly to the first stop. Step back while the pressure is released from the cooling system. When you are certain all the pressure has been released, press down on the radiator cap (with a cloth), turn and remove. |
Note. The addition of Motorcraft Cooling System Stop Leak Pellets (VC-6), darkens Motorcraft Premium Gold Engine Coolant from Yellow to Golden Tan.
When adding engine coolant, use a 50/50 mixture of engine coolant and distilled water. To maintain the integrity of the coolant and the cooling system
- Add Motorcraft Premium Engine Coolant VC-4-A (in Oregon VC-5, in Canada CXC-10) or equivalent meeting Ford specification ESE-M97B44-A (Green color), Motorcraft Specialty Orange Engine Coolant such as VC-2, meeting Ford specification WSS-M97B44-D or Motorcraft Premium Gold Engine Coolant VC-7-A or equivalent meeting Ford specification WSS-M97B51-A1 (Yellow color). Use the same coolant that was drained from the cooling system. Do not mix coolant types.
- Do not add/mix Orange-colored Motorcraft Speciality Orange Engine Coolant VC-2 or equivalent meeting Ford specification WSS-M97B44-D. Mixing coolants may degrade the coolant's corrosion protection.
- Do not add alcohol, methanol, or brine, or any engine coolants mixed with alcohol or methanol antifreeze. These can cause engine damage from overheating or freezing.
- Do not mix with recycled coolant unless it meets the requirements of Ford specification ESE-M97B44-A or WSS-M97B51-A1. Not all coolant recycling processes meet these Ford specifications. Use of such coolants can harm the engine and cooling system components.
| Application | Specification | ||
|---|---|---|---|
| Coolant Capacity (1) | |||
| 4.6L 2V | 18.9 Qts. (17.9L) | ||
| 4.6L 4V | 18.6 Qts. (17.6L) | ||
| Cooling System Test Pressure | 16 psi (110 kPa) | ||
| Pressure Relief Cap Opening Pressure | 16 psi (110 kPa) | ||
| Thermostat Opens | |||
| 4.6L (2V) | |||
| Starts To Open | 192-199°F (87-93°C) | ||
| Fully Open | 219°F (104°C) | ||
| 4.6L (4V) | |||
| Starts To Open | 183-190°F (84-88°C) | ||
| Fully Open | 210°F (99°C) | ||
| (1) Includes degas bottle fluid level between the COOLANT FILL LEVEL lines. | |||
| (1) | Includes degas bottle fluid level between the COOLANT FILL LEVEL lines. |
COOLING SYSTEM SPECIFICATIONS
