No Torque Converter Clutch
Check valve body and torque converter.
Torque Converter Clutch Always Engaged
Check valve body, oil pump assembly, torque converter and transaxle case.
TURBINE TORQUE CHECK
Install End Play Checking Tool (T81P-7902-D) with sleeve into turbine splines in converter. Using torque wrench, measure turbine turning torque. Replace converter if torque exceeds 71 INCH lbs. (8 N.m).
Scheme 10
TORQUE SPECIFICATIONS
| Application | Ft Lbs. (N.m) | |
|---|---|---|
| Axle Nut | ||
| Contour & Mystique | 246 (340) | |
| Probe | 174-235 (235-319) | |
| Drain Plug | 19-21 (25-29) | |
| Ball Joint Clamp Bolt | ||
| Contour & Mystique | 54-67 (74-92) | |
| Probe | 25-42 (34-57) | |
| Bearing Bracket Bolt | ||
| Contour & Mystique | 15-23 (21-32) | |
| Probe | 31-46 (42-62) | |
| Main Control Cover Bolt | 10-13 (14-18) | |
| Manual Control Lever Bolt | 18-22 (25-30) | |
| Stabilizer Link Nut | ||
| Contour & Mystique | 14-23 (20-32) | |
| Probe | 27-40 (36-54) | |
| Steering Knuckle Clamp Bolt | 25-42 (34-57) | |
| Tie Rod End Nut | 20 (28) | |
| Transaxle Case Bolt | 15-18 (20-24) | |
| Transmission Speed Sensor Bolt | 11 (15) | |
| Wheel Lug Nut | ||
| Contour & Mystique | 85-105 (115-142) | |
| Probe | 65-87 (88-118) | |
| INCH Lbs. (N.m) | ||
| Accumulator-To-Transfer Plate Bolt | 89 (10) | |
| Control Valve-To-Transfer Plate Bolt | 80-97 (11-13) | |
| Manual Valve Lever Ball Stud Nut | 96-117 (11-13) | |
| Oil Level Control Valve Bolt | 96-117 (11-13) | |
| Oil Pump Bolt | 115 (13) | |
| Pressure Tap Plate Bolt | 71 (8) | |
| Transmission Speed Sensor | 106-124 (12-14) | |
| Valve Body-To-Transaxle Case Bolt | 80-97 (9-11) | |
| Vehicle Speed Sensor Bolt | 44-53 (5-6) | |
TORQUE SPECIFICATIONS
TRANSAXLE SPECIFICATIONS
| Application | In. (mm) |
|---|---|
| Direct Clutch Pack Clearance | .020-.044 (.52-1.12) |
| Forward/Coast Clutch Pack Clearance | .020-.043 (.50-1.09) |
| Reverse Clutch Pack Clearance | .012-.035 (.33-.89) |
| Low/Reverse Clutch Pack Clearance | .021-.046 (.54-1.17) |
| Low/Intermediate Planetary Thrust Clearance | .006-.028 (.15-.72) |
| Oil Pump Drive Gear Clearance | .0015-.0030 (.040-.080) |
| Oil Pump Driven Gear Clearance | .0015-.0030 (.040-.080) |
| Reverse/OD Planetary Thrust Clearance | .006-.028 (.15-.72) |
| INCH lbs. (N.m) | |
| Oil Pump Rotating Torque | 2 (.3) |
TRANSAXLE SPECIFICATIONS
