PRE-MEASUREMENT CHECKS
Check tire pressure. Specifications are found on door pillar or in glove box. Place front seats in rearmost position. Cargo compartment must be empty. Fuel tank should be full. Normalize riding height by bouncing vehicle up and down. Measure riding height at locations shown.
Riding Height Measuring Points (Bronco & "F" Series 4WD). Scheme 4
Scheme 4: Riding Height Measuring Points (Bronco & "F" Series 4WD)
Riding Height Measuring Points (Bronco II & Ranger). Scheme 5
Scheme 5: Riding Height Measuring Points (Bronco II & Ranger)
Riding Height Measuring Points ("E" Series). Scheme 6
Scheme 6: Riding Height Measuring Points ("E" Series)
Riding Height Measuring Points ("F" Series 2WD). Scheme 7
Scheme 7: Riding Height Measuring Points ("F" Series 2WD)
Rear Riding Height Measuring Points. Scheme 8
Scheme 8: Rear Riding Height Measuring Points
SPECIFICATIONS
| Application | Front "A" | Rear "B" |
|---|
| Aerostar | N/A | N/A |
| Bronco & F150 | (1) 3 1/4-4 3/4" | (2) 29-30" |
| Bronco II & Ranger | 3 1/8-4 3/8" | (3) 21" |
| E150 | 4-6" | 26 1/2-27 1/2" |
| E250/350 | 3 3/4-5 1/2" | (4) 29" |
| F250/350 |
| 2WD | (5) 2 1/2-4" | (6) 31-34" |
| 4WD | 5-6 3/4" | (6) 32-34" |
| (1) Height is 3 11/32-5" on left side of vehicle. (2) F150 models only; height for 4WD models is 32-33". (3) Ranger only. (4) E350 height is 32". (5) Height is 2 11/16-4 1/4" on left side of vehicle. (6) F250 chassis frame height is 24-27 1/2". F350 chassis frame height is 23 1/2-26". |
| (1) | Height is 3 11/32-5" on left side of vehicle. |
| (2) | F150 models only; height for 4WD models is 32-33". |
| (5) | Height is 2 11/16-4 1/4" on left side of vehicle. |
| (6) | F250 chassis frame height is 24-27 1/2". F350 chassis frame height is 23 1/2-26". |
RIDING HEIGHT SPECIFICATIONS
