FRAME CONTACT HOIST
Vehicle may be raised on single or twin-post swiveling arm, or ramp-type drive hoists as long as wide hoist adapters are used. If using single post hoist, ensure that lifting arms, pads or ramps are positioned at the proper lifting points and that adequate underbody clearance is maintained.
If vehicle is to be raised on a twin-post hoist use caution not to damage suspension, rear axle cover and/or steering linkage components when positioning hoist adapters.
FLOOR JACK
To raise front of vehicle, use designated front jacking point. To raise rear of vehicle, use designated rear jacking point.
Front Jacking Point (Bronco & F150-350 4WD). Scheme 9
Scheme 9: Front Jacking Point (Bronco & F150-350 4WD)
Front Jacking Point (E150). Scheme 10
Scheme 10: Front Jacking Point (E150)
Front Jacking Point (E & F250-350 2WD). Scheme 11
Scheme 11: Front Jacking Point (E & F250-350 2WD)
Rear Jacking Point (Bronco, E & F150-350 2WD & 4WD). Scheme 12
Scheme 12: Rear Jacking Point (Bronco, E & F150-350 2WD & 4WD)
Front Jacking Point (Ranger 2WD). Scheme 13
Scheme 13: Front Jacking Point (Ranger 2WD)
Front Jacking Point (Bronco II & Ranger 4WD). Scheme 14
Scheme 14: Front Jacking Point (Bronco II & Ranger 4WD)
Rear Jacking Point (Bronco & Ranger). Scheme 15
Scheme 15: Rear Jacking Point (Bronco & Ranger)
