TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Hatchback |
| Automatic Seat Belt Guide Rail Mounting Bolt (Lower) | 12-17 (16-23) |
| Motor Mounting Bolts | 25-40 (35-55) |
| Sedan |
| Automatic Seat Belt Guide Rail Mounting Bolt (Lower) | 12-17 (16-23) |
| Motor Mounting Bolts | 25-40 (35-55) |
| Rear Seat Belt Anchor Plate Bolt | 25-40 (35-55) |
| All Models |
| Bezel To Reactor Bolt (For Lap Belt) (1) | 25-40 (35-55) |
| Buckle Mounting Bolt | 25-40 (35-55) |
| Front Seat Mounting Bolts (C & D) (2) | 25-40 (35-55) |
| Front Seat Mounting Nuts (A & B) (2) | 17-26 (24-36) |
| INCH Lbs. (N.m) |
| Hatchback |
| Automatic Seat Belt Guide Rail Mounting Bolt (Upper) | 35-53 (4-6) |
| Sedan |
| Automatic Seat Belt Guide Rail Mounting Bolt (Upper) | 35-53 (4-6) |
| All Models |
| Seat Belt Guide Ring Bolt | 80-124 (9-14) |
| (1) Bolt is secured with the motor mounting bolt on sedans. (2) For mounting bolt identification see scheme 34 |
| (1) | Bolt is secured with the motor mounting bolt on sedans. |
| (2) | For mounting bolt identification see scheme 34 |
Automatic Seat Belt Wiring Diagram (1990 - 1 Of 2). Scheme 1
Scheme 1: Automatic Seat Belt Wiring Diagram (1990 - 1 Of 2)
Automatic Seat Belt Wiring Diagram (1990 - 2 Of 2). Scheme 2
Scheme 2: Automatic Seat Belt Wiring Diagram (1990 - 2 Of 2)
Scheme 3
Scheme 4
