COMPONENT LOCATION
| Application | (1) Symbol/Location |
|---|
| Automatic Seat Belt Control Unit | (Scheme 42) "G" |
| Automatic Seat Belt Motor (2 Door) | (Scheme 38) "C" |
| Automatic Seat Belt Motor (4 Door) | (Scheme 39) "C" |
| Automatic Seat Belt Motor Relay (2 Door) | (Scheme 38) "D" |
| Automatic Seat Belt Motor Relay (4 Door) | (Scheme 39) "D" |
| Buckle Switch | (Scheme 41) "F" |
| Buzzer | (Scheme 45) "K" |
| Door Latch Switch | (Scheme 37) "B" |
| Fasten Switch | (Scheme 36) "A" |
| Fusible Link No. 6 (Green, 40A) | In Engine Compartment Relay Box |
| Key Reminder Switch | (Scheme 43) "I" |
| Outer Switch | (Scheme 42) "H" |
| Passenger Compartment Junction Block (Fuse Block) | (Scheme 46) |
| Seat Belt Warning Light | (Scheme 44) "J" |
| Release Switch | (Scheme 40) "E" |
| Body Ground 6 | Behind Instrument Cluster, On Cross Body Brace |
| Body Ground 9 | In Passenger Compartment, In Front Of Shift Lever Housing |
| Body Ground 11 | At Base Of Left Side B Pillar, Near Seat Belt Motor |
| Body Ground 13 (Hatchback) | On Bottom Part Of Liftgate |
| Body Ground 15 (Sedan) | In Trunk, On Left Side Of Rear Panel |
| (1) To view symbols (Scheme 35) |
AUTOMATIC SEAT BELT COMPONENT LOCATIONS
Automatic Seat Belt Component Locations (A-I). Scheme 35
Scheme 35: Automatic Seat Belt Component Locations (A-I)
Guide Rail & Fasten Switch (Symbol A). Scheme 36
Scheme 36: Guide Rail & Fasten Switch (Symbol A)
Door Latch Switch (Symbol B). Scheme 37
Scheme 37: Door Latch Switch (Symbol B)
Auto. Seat Belt Motor Relay & Motor (Symbol C, D - Hatchback). Scheme 38
Scheme 38: Auto. Seat Belt Motor Relay & Motor (Symbol C, D - Hatchback)
Auto. Seat Belt Motor Relay & Motor (Symbol C, D - Sedan). Scheme 39
Scheme 39: Auto. Seat Belt Motor Relay & Motor (Symbol C, D - Sedan)
Release Switch (Symbol E). Scheme 40
Scheme 40: Release Switch (Symbol E)
Buckle Switch (Symbol F). Scheme 41
Scheme 41: Buckle Switch (Symbol F)
Automatic Seat Belt Control Unit & Outer Switch (Symbol G, H). Scheme 42
Scheme 42: Automatic Seat Belt Control Unit & Outer Switch (Symbol G, H)
Key Reminder Switch (Symbol I). Scheme 43
Scheme 43: Key Reminder Switch (Symbol I)
Seat Belt Warning Light (Symbol J). Scheme 44
Scheme 44: Seat Belt Warning Light (Symbol J)
Buzzer (Symbol K). Scheme 45
Scheme 45: Buzzer (Symbol K)
Locating Passenger Compartment Junction Block (Fuse Block). Scheme 46
Scheme 46: Locating Passenger Compartment Junction Block (Fuse Block)
Scheme 47
