Charging System - Generators & Regulators (Except Coupe): Specifications Dodge Stratus I

Charging System 2 illustrations

GENERATOR SPECIFICATIONS

Application		Rated Amps	Minimum Amps
Breeze (2.0L)		90	63
Cirrus & Stratus
2.0L & 2.4L		90	63
2.5L		90	63
Neon (2.0L)		85	60
Sebring Convertible (2.4L & 2.5L)		125	88
(1) At 2500 RPM.

(1)	At 2500 RPM.

GENERATOR SPECIFICATIONS (1)

TORQUE SPECIFICATIONS

Application	Ft. Lbs. (N.m)
Battery Hold-Down Bolt	10 (13.5)
Generator Mounting Bolts & Nuts	40 (54.0)
Generator Pivot Bolt	40 (54.0)
INCH Lbs. (N.m)
Generator BAT Terminal Nut	75 (8.5)

TORQUE SPECIFICATIONS

Charging System Schematic (Breeze, Cirrus & Stratus). Scheme 1

Scheme 1: Charging System Schematic (Breeze, Cirrus & Stratus)

Scheme 1: Charging System Schematic (Breeze, Cirrus & Stratus)

Charging System Schematic (Neon). Scheme 2

Scheme 2: Charging System Schematic (Neon)

Scheme 2: Charging System Schematic (Neon)
