REMOVAL & INSTALLATION
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in appropriate AIR BAG RESTRAINT SYSTEM article in ACCESSORIES/SAFETY EQUIPMENT section below. |
- «AIR BAG RESTRAINT SYSTEM»(ref-27817) (for 3000GT)
- AIR BAG RESTRAINT SYSTEM (for Stealth)
| CAUTION | When battery is disconnected, radio will go into anti-theft protection mode. Obtain radio anti-theft protection code from owner prior to servicing vehicle. |
Note. For removal of basic A/C-heater system components, see HEATER SYSTEM and/or REMOVAL & INSTALLATION information in A/C-HEATER SYSTEM - MANUAL article in the AIR CONDITIONING & HEAT section.
- Disconnect battery ground cable. Remove cup holder and plug from rear floor console. Remove rear console. Remove radio panel, radio and switch panel from front floor console. Remove front console side covers and trim plates. Remove shift lever knob (M/T models) and front floor console.
- Using flat-tip screwdriver, remove clips from center air outlet panel. Remove center air outlet assembly using plastic trim stick. Remove A/C-heater control panel. Remove A/C control unit from panel. To install, reverse removal procedure.
Remove glove box door stops and outer case. Remove power transistor. Remove glove box under cover and belt lock controller. To install, reverse removal procedure.
Remove glove box door stops and outer case. Remove fresh/recirculated air selector damper motor. To install, reverse removal procedure.
- Disconnect battery ground cable. Drain coolant. Remove cup holder and plug from rear floor console. Remove rear console. Remove radio panel, radio and switch panel from front floor console. Remove front console side covers and trim plates. Remove shift lever knob (M/T models) and front floor console.
- Using flat-tip screwdriver, remove clips from center air outlet panel. Remove center air outlet assembly using plastic trim stick. Remove A/C-heater control panel and A/C control unit. Remove blend-air damper motor. To install, reverse removal procedure.
Remove left knee protector. Remove left console cover, left shower duct and lap cooler duct. Remove mode selector damper motor assembly. To install, reverse removal procedure.
Remove glove box door stops and outer case. Disconnect photo sensor connector. Using a trim stick, pry out photo sensor from top of left defroster outlet. To install, reverse removal procedure.
Drain coolant. Remove glove box door stops and outer case. Reach behind glove box opening and remove coolant temperature sensor. To install, reverse removal procedure. Refill coolant and check for leaks.
Remove glove box door stops and outer case. Remove air-inlet temperature sensor mounted near evaporator case. To install, reverse removal procedure.
Use trim stick to pry out in-car temperature sensor from headliner. Disconnect electrical connector, and remove sensor. To install, reverse removal procedure.
