REMOVAL & INSTALLATION
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in appropriate AIR BAG RESTRAINT SYSTEM article in ACCESSORIES/SAFETY EQUIPMENT section below. |
- «AIR BAG RESTRAINT SYSTEM»(ref-27817) (for 3000GT)
- AIR BAG RESTRAINT SYSTEM (for Stealth)
Removal
- Disconnect battery ground cable. Drain coolant. Remove cup holder and plug from rear floor console. Remove rear console. Remove radio panel, radio and switch panel from front floor console. Remove front console side covers and trim plates. Remove shift lever knob (M/T models) and front floor console.
- Remove hood release handle, light dimmer and rear wiper/washer switch from knee bolster plate. Remove knee bolster plate and steering column cover. Remove glove box striker. Remove glove box and upper cover. Using screwdriver, disengage center air outlet panel clips. Remove panel using trim stick. Remove heater control panel screws, instrument cluster bezel and instrument cluster.
- Disconnect speedometer cable (mechanical-type speedometer) from transaxle. Remove adapter locks from instrument panel. Pull speedometer cable slightly toward passenger compartment, and remove adapter. Remove speakers or plugs. Disconnect electrical wiring harness connectors. Remove steering column bolts and instrument panel.
- Disconnect heater hoses. Remove center reinforcement and glove box undercover. Remove air distribution ducts. Remove heater unit. Remove heater core cover plate. Remove heater core from heater unit. (Схема №1)
Installation
To install, reverse removal procedure. Ensure heater hose clamps are fully secured to prevent leaks.
- Disconnect battery ground cable. Drain coolant. Remove cup holder and plug from rear floor console. Remove rear console. Remove radio panel, radio and switch panel from front floor console. Remove front console side covers and trim plates. Remove shift lever knob (M/T models) and front floor console. Remove glove box door stops. Remove glove box upper cover.
- Disconnect air selector cable. Remove hood release handle, light dimmer and rear wiper/washer switch from knee bolster plate. Remove knee bolster plate and foot shower duct. (Схема №1) Disconnect mode selector cable and temperature control cable. Using screwdriver, disengage center air outlet panel clips. Remove panel using trim stick. Remove heater control panel. To install, reverse removal procedure. Adjust heater control cables. See «ADJUSTMENTS»(ref-39039-S06747735342001011200000).
Remove glove box door stops. Remove glove box and upper cover. Remove glove box undercover, lower frame and side frame. Disconnect air selector cable. Remove blower assembly, blower motor and blower case. To install, reverse removal procedure. Adjust mode selector cable. See ADJUSTMENTS .
