Maintenance Information Dodge Shadow I

MODEL IDENTIFICATION

Note. For scheduled maintenance intervals and the related fluid capacities, fluid specifications and labor times for major service intervals, see SCHEDULED SERVICES article in this section. Warranty information and specifications for fluid capacities, lubrication specifications, wheel and tire size, and battery type are covered in this article.

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 2

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation. Normal Service and Severe Service are based on the following primary operating conditions

Severe Service

1. Sustained High Speed Driving In Hot Weather
2. Stop-And-Go Driving In Dusty Conditions
3. Extensive Idling
4. Frequent Short Trips
5. Trailer Towing Or Commercial Use
6. Driving Off-Road Or In Salty Or Sandy Areas

Normal Service

1. Driven More Than 10 Miles Daily
2. No Severe Service Operating Conditions

CAMSHAFT TIMING BELT

Replace camshaft timing belt at 90,000 mile intervals. Inspect timing belt on 3.0L engine at 60,000 miles and replace if necessary.

The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".

Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.

Belts or components should be inspected and replaced if any of the following conditions exist

1. Cracks Or Tears In Belt Surface
2. Missing, Damaged, Cracked Or Rounded Teeth
3. Oil Contamination
4. Damaged Or Faulty Tensioners
5. Incorrect Tension Adjustment

Scheme 3

Scheme 4

SERVICE LABOR TIMES

Note. For 1990 and newer vehicles, labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

TIRE INFLATION

Tire pressure specification decal is attached to the rear face of the driver's door. Inflation pressures listed on decal are always cold inflation pressure. The cold inflation pressure must never exceed the maximum values molded into the tire side wall.

Note. Cold inflation pressure is defined as the tire pressure after the vehicle has set for at least 3 hours without being driven or vehicle has been driven less than a mile after being parked for a 3-hour period.

WHEEL TIGHTENING

Tighten all wheel lug nuts to 95 ft. lbs. (129 N.m). Always tighten wheel lug nuts in a crisscross pattern. All wheel lug nuts have right-hand threads.

BATTERY WARNING

1. COMPUTER RELEARN PROCEDURES - 1987-90 Vehicles
2. COMPUTER RELEARN PROCEDURES - 1991-93 Vehicles
3. COMPUTER RELEARN PROCEDURES - 1994 Vehicles

Vehicles are delivered with maintenance-free battery. Water need never be added to a maintenance-free battery. The battery contains a visual test. A Green indicator is seen when an adequate charge level exists, a Black indicator means that charging is required and a Yellow indicator appears when replacement is necessary.

AIR BAG SYSTEM

The fuse access panel located in the left, lower instrument panel must be in place for proper knee impact protection in the event of a collision.

SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG SYSTEM)

AIR CONDITIONING SERVICING

1. A/C SYSTEM GENERAL SERVICING - 1987
2. A/C SYSTEM GENERAL SERVICING - 1989
3. A/C SYSTEM GENERAL SERVICING - 1990-91
4. A/C SYSTEM GENERAL SERVICING - 1992
5. A/C SYSTEM GENERAL SERVICING - 1993
6. A/C SYSTEM GENERAL SERVICING - 1994

ANTI-LOCK BRAKE SYSTEM

The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by improperly installed or high output radio transmitting equipment. Since this interference could cause the possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals.

On models equipped with anti-lock brake systems, ALWAYS observe the following cautions

1. DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
2. ANTI-LOCK BRAKE SYSTEM - BENDIX-6 - 1993
3. ANTI-LOCK BRAKE SYSTEM - 1994
4. DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
5. Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.

1. COMPUTER RELEARN PROCEDURES - 1987-90 Vehicles
2. COMPUTER RELEARN PROCEDURES - 1991-93 Vehicles
3. COMPUTER RELEARN PROCEDURES - 1994 Vehicles

If battery shows any signs of freezing, leaking, loose posts or low electrolyte level, DO NOT TEST. An explosive condition could result.

REPLACING BLOWN FUSES

Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.

BRAKE HOSE INSPECTION

If front wheel, rear axle, or anti-lock unit brake hose outer cover is cracked, chafed, or bulged, replace hose immediately. Brake failure could result.

BRAKE PAD WEAR INDICATOR

Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.

CATALYTIC CONVERTER

Continued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle.

Any modification to the exhaust system on turbo models, which reduces exhaust backpressure, will lead to lean fuel mixtures and excessive spark advance. This could cause serious engine damage.

COOLANT (PROPYLENE-GLYCOL FORMULATIONS)

ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

ENGINE OIL

FUEL SYSTEM SERVICE

HALOGEN BULBS

RADIATOR CAP

RADIATOR FAN

REAR WHEEL BEARING LUBRICATION

Combining two types of lubricant can cause bearing failure. Wash used or new bearings with solvent and blot dry with lint-free cloth before packing with new lubricant.

TURBOCHARGED MODELS

WARRANTY INFORMATION

BASIC NEW CAR LIMITED WARRANTY

Everything is covered for 12 months or 12,000 miles, whichever occurs first. This basic warranty covers the cost of all parts and labor needed to repair or adjust any item (except tires) on the vehicle that has been proven defective in material, workmanship or factory preparation under normal use.

OWNER'S CHOICE COVERAGE

Beginning in 1992, Chrysler offers a choice of new car coverage. At the time of purchase, owner must choose either the 12-month/12,000-mile warranty with 7-year/70,000-mile powertrain coverage OR the 36-month/36,000-mile basic new car warranty covering any item that's defective in material, workmanship or factory preparation for 36 months or 36,000 miles, whichever occurs first. Under the 36-month/36,000 mile warranty, the following items are only warranted for the first 12 months or 12,000 miles, whichever occurs first

1. Light Bulbs
2. Seat Covers and Carpets
3. Brakes (Rotors, Pads, Linings And Drums
4. Fuses
5. Wiper Blades
6. Adjustments
7. Battery
8. Drive Belts

AIR BAG LIMITED WARRANTY

Air bag components listed below are covered for 36 months or 36,000 miles, whichever occurs first, with no deductible

1. Air Bag Module
2. Clockspring Switch Assembly
3. Front Impact Sensors
4. Air Bag System Diagnostic Module

1987-89 POWERTRAIN WARRANTY

This warranty takes effect upon the expiration of the 12-month/12,000-mile Basic New Car Limited Warranty and covers the following components for 5 years or 50,000 miles, whichever occurs first. This warranty is subject to a 100.00 deductible for each repair visit.

1990-94 POWERTRAIN WARRANTY

Covers parts and components listed below, for 7 years or 70,000 miles, whichever occurs first, starting from vehicle's warranty start date.

1. Gasoline Engine Cylinder block and all internal parts, cylinder head assemblies, core plugs, valve covers, oil pan, timing gear drive belts and/or chains and cover, oil pump, intake and exhaust manifolds, water pump and housing, turbocharger housings and internal parts, turbocharger wastegate actuator, seals and gaskets.
2. Transmission/Transfer Case Case and all internal parts, oil pan, torque converter with starter ring gear, flex plate, bell housing, flywheel, seals and gaskets.
3. FWD Components Transaxle electronic controller, transaxle case and all internal parts, oil pan and differential cover, torque converter and drive plate with starter ring gear, bellhousing, flywheel, drive shaft assemblies, universal joints, housing and boots, seals and gaskets.

CORROSION WARRANTY

This warranty is effective starting on the date vehicle is delivered or put in use, whichever occurs first. It covers all rust-through damage to any sheet metal panels due to corrosion. A 36-month, unlimited mileage warranty covers all body sheet metal panels. For "outer-body" sheet metal panels, the limits are 7 years or 100,000 miles, whichever occurs first.

EMISSION SYSTEM "DEFECT" & "PERFORMANCE" WARRANTY (FEDERAL)

Under the "Defect" Warranty, Chrysler warrants that the vehicle is free from defects in material and workmanship which would cause it to fail to meet Federal standards for emission control system set at the time the vehicle was built.

The "Performance" Warranty covers all costs of repairing or adjusting any components or parts as needed in order for the vehicle to pass a Federally-approved state or local emissions test.

The following is a list of some of the primary components that affect the emissions of the vehicle and are covered by both warranties. Other emission control parts related to these components are covered by the "Performance" warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. Warranties begin on warranty start date and last for 5 years or 50,000 miles, whichever occurs first.

1. Carburetor Feedback Control System
2. Electronic Fuel Injection System
3. Air Cleaner Vapor Containment Door System
4. Electronic Spark Control
5. Electronic Control Module
6. Vapor Storage Canister And Controls
7. Deceleration Throttle Control
8. Exhaust Gas Recirculation Valve And Control System
9. Air Pump, Belt And Pulley
10. Air Injection Controls
11. Intake Manifold
12. Diesel LDA (Boost Control)
13. Diesel KSB Valve
14. PCV Valve
15. Catalytic Converter
16. Vacuum Hoses, Clamps, Fittings And Tubing
17. Vacuum, Temperature, Altitude, Speed And Time-Sensitive Valves

CALIFORNIA EMISSION CONTROL SYSTEM WARRANTY

This warranty applies to all vehicles certified for sale or sold for initial registration in the State of California. Chrysler warrants that the vehicle is free from defects in material and workmanship which would cause it to fail to conform with applicable regulations set by the California Air Resources Board at the time of sale.

This warranty shall apply until the first scheduled maintenance point specified by Chrysler. If no maintenance is scheduled, warranty is applied for 3 years or 50,000 miles, whichever occurs first. This warranty also covers some emissions parts (which were installed as original parts) for 7 years or 70,000 miles, whichever occurs first. See customer's copy of warranty information for specific items covered. Warranty begins on the date vehicle is sold to original purchaser or first placed in service or original use, whichever occurs first.

RELAY IDENTIFICATION (1987-88 MODELS)

The fuse access panel is behind the steering column cover. To remove the panel, pull it out from the bottom and slide the tabs out from the top. The relay and flasher module is behind the fuse panel. A relay or flasher can be removed by pulling it straight down from the module.

Scheme 5

Scheme 6

1. 1 - Relay - Horn
2. 2 - Flasher - Turn Signal
3. 3 - Relay - Ignition Key Light Time Delay
4. 4 - Flasher - Hazard Warning Light

FUSE & CIRCUIT BREAKER IDENTIFICATION (1987-88 MODELS)

1. 1 - 4 Amp (Pink) - Instrument Cluster Lights, AC/Heater, Radio, Heated Rear Window, Turbo Gauge, Cigarette Lighter, Ash Receiver, Console Gear Selector
2. 2 - 20 Amp (Yellow) - Fuel Pump
3. 3 - (Empty)
4. 4 - 5 Amp - BRAKE Warning, Power Loss, Fuel, Heater, Seat Belt, Shift Indicator Lights, Temperature, Voltage Gauges, Seat Belt Buzzer, Tachometer, Speed Control
5. 5 - 20 Amp (Yellow) - Hazard Flasher
6. 6 - 10 Amp (Red) - Back-Up Lights, Radiator Fan, Heated Rear Window Relay
7. 7 - 30 Amp (Green) - A/C Blower Motor
8. 7 - 20 Amp (Yellow) - Heater Blower Motor
9. 8 - Empty (1987)
10. 8 - 30 Amp (Circuit Breaker) - Power Windows
11. 9 - 20 Amp (Yellow) - Glove Box Light, Horn, Horn Relay, Chimes, Radio Memory, Cigarette Lighter
12. 10 - 20 Amp (Yellow) - License, Side Marker, Park and Taillights, Radio Light, Fog Lights
13. 11 - 30 Amp (Circuit Breaker) - Power Door Locks
14. 12 - 20 Amp (Yellow) 1987 - Stoplights, Key, Power Mirrors, Time Delay Relay, Map & Cargo
15. 12 - 20 Amp (Yellow) 1988 - Stoplights
16. 13 - (Empty) 1987
17. 13 - 10 Amp (Red) - Dome, Cargo, Key-In & Glove Box Lights, Time Delay, Power Mirrors & Underhood Lights
18. 14 - 20 Amp (Yellow) - Windshield Wipers & Washers
19. 15 - 10 Amp (Red) - Turn Signals
20. 16 - 10 Amp (Red) - Radio

FUSE PANEL IDENTIFICATION (1989-94 MODELS)

The fuse access panel is behind the steering column cover. To remove the panel, pull it out from the bottom and slide the tabs out from the top. The relay and flasher module is behind the fuse panel. A relay or flasher can be removed by pulling it straight down from the module.

RELAY IDENTIFICATION (1989-94 MODELS)

1. 1 - Relay - Horn
2. 2 - Not Used
3. 3 - Relay - Ignition Light Time Delay
4. 4 - Flasher - Hazard Warning Light

FUSE & CIRCUIT BREAKER IDENTIFICATION (1989-94 MODELS)

1. 1 - 4 Amp (Pink) - Instrument Cluster Lights, AC/Heater, Radio, Heated Rear Window, Turbo Gauge, Cigarette Lighter, Ash Receiver, Console Gear Selector
2. 2 - 20 Amp (Yellow) 1989-1992 - Fuel Pump
3. 2 - 15 Amp (Lt. Blue) 1993-94 - Power Door Locks
4. 3 - Blank (1989)
5. 3 - 2 Amp (Gray) 1990-94 - Speed Control
6. 4 - 5 Amp (Tan) 1989-1993 - BRAKE Warning, Power Loss, Heater, Seat Belt, Shift Indicator Lights, Fuel, Temperature & Voltage Gauges, Tachometer, Seat Belt Buzzer, Speed Control, Foglights
7. 4 - 5 Amp (Tan) 1994 - Instrument Cluster, Chime, Airbag, Automatic Seat Belt
8. 5 - 20 Amp (Yellow) - Hazard Flasher
9. 6 - 10 Amp (Red) - Back-Up Lights, Radiator Fan, Air Bag, Rear Window Defroster, Overhead Console
10. 7 - 30 Amp (Green) - A/C Heater Blower Motor
11. 8 - 30 Amp (Circuit Breaker) - Power Windows
12. 9 - 20 Amp (Yellow) - Horn, Horn Relay, Cigarette Lighter, Air Bag, Amplified Speakers
13. 10 - 20 Amp (Yellow) - License & Side Marker Lights, Parking & Taillights, Radio Light, Foglights, Overhead Console
14. 11 - 30 Amp (Circuit Breaker) 1989-90 - Power Door Locks, Power Seats, Motorized Seat Belt Module
15. 11 - Empty (1991-92)
16. 11 - 30 Amp (Circuit Breaker) 1993-94 - Power Seats
17. 12 - 20 Amp (Yellow) 1989-1993 - Stoplights
18. 12 - 20 Amp (Yellow) 1994 - Stoplights, Chimes, ABS
19. 13 - 10 Amp (Red) - Radio Memory, Power Mirrors, Time Delay, Underhood Lights, Dome, Cargo, Map, Key-In & Glove Box Lights
20. 14 - 20 Amp (Yellow) - Windshield Wipers & Washers
21. 15 - 10 Amp (Red) - Turn Signals
22. 16 - 10 Amp (Red) - Radio
